JEBQT-20Wireless Microphone Transmitter

From: willyauo [[email protected]] Sent: Monday, August 05, 2002 7:17 AM To: Mike Kuo Subject: Re: WA GOL INDUSTRIAL CO., LTD., FCC ID:JEBQT-20, AN02T2112 Hi Mike, Regarding your questions, please see the following reply and explanation. FCC ID JEBQT-20 Question# 1 Reply: We have modified the limit to 50mW. Please see the attachment test report. Question# 2 Reply: The tune-up procedure 10mW is wrong. Our assistant engineer typed wrong. We have corrected this. Please see the attachment tune-up procedure. Question# 3 Reply: Please see the attachment for update frequency response data in the test report. Question# 4 Reply: Please see the attachment for emission mask plots. Question# 5 Reply: The emission designator is 161KF3E. The calculation is (2M+2DK) K=1 and (2 x 32.768 + 2x 48) = 161.5kHz , so the emission designator is 161KF3E F means the Frequency modulation , 3 means a single channel containing quantized or digital information and E means Telephony(including sound broadcasting) The fourth and fifth symbols don't use. If you have any question, please advise us. We will submit the document as your request. Thank you very much. Best regards, Will Yauo / ETC ----- Original Message ----- From: Mike Kuo <[email protected]> To: Will Yauo (E-mail) <[email protected]>; Will Yauo-Personal (E-mail) <[email protected]> Sent: Tuesday, July 30, 2002 7:58 AM Subject: FW: WA GOL INDUSTRIAL CO., LTD., FCC ID:JEBQT-20, AN02T2112 > > > -----Original Message----- > From: CERTADM > Sent: Monday, July 29, 2002 4:44 PM > To: '[email protected]' > Subject: WA GOL INDUSTRIAL CO., LTD., FCC ID:JEBQT-20, AN02T2112 > > > Notice_content > ------------- > Question #1: Per Section 74.861(e)(1)(I) of FCC rules, the max. allowable > antenna conducted power for 174-216MHz band is 50mW. However, page 4 and > page 6 of test report indicated otherwise, please explain. > > Question #2: The tune-up procedure indicates the max. allowable output power > is 10mW but the user manual indicates the max. output is 30mW. The tune up > procedure does not agree with the measured or spec. Please explain. > > Question #3: Page 7 ( Modulation Characteristic ) section. Section 4.2 C2 > of test report described the modulating frequency of 15000Hz was made but > there is no data to demonstrate 15000Hz modulating frequency. For units > with extended audio frequency response like wireless microphones, the audio > frequency response should be measured up to 15kHz. The reason being that > any Broadcast related audio device is allowed to operate with an audio > frequency response up to 15kHz. Please provide 15000Hz data to demonstrate > compliance. > > Question #4: Emission mask per section 74.861((e)(6)(I)(ii)(iii). There is > no emission mask plots provided to demonstrate compliance. Please provide > it. > > Question #5: Please justify Emission designator ( 180KF3E ) by using Carson > rules ( 2M+2DK). > > Best Regards > > Mike Kuo / TCB Certifier > The items indicated above must be submitted before processing can continue > on the above referenced application. Failure to provide the requested > information within 60 days of the original e-mail date may result in > application dismissal and forfeiture of the filing fee. Also, please note > that partial responses increase processing time and should not be submitted. > Any questions about the content of this correspondence should be directed to > the e-mail address listed below the name of the sender. >

ETC Report No.:ET91R-06-083-03 FCC ID.:JEBQT-20 CONSTRUCTED PHOTOS of EUT Front View of EUT Rear View of EUT

ETC Report No.:ET91R-06-083-03 FCC ID.:JEBQT-20 CONSTRUCTED PHOTOS of EUT Internal View of EUT Component View of Main PCB ETC Report No.:ET91R-06-083-03 FCC ID.:JEBQT-20 CONSTRUCTED PHOTOS of EUT Solder View of Main PCB

The EUT is a frequency modulation Transmitter / Wireless Microphone with following features : Operation Frequency Range: 174MHz to 216MHz. Type of emission is 180KF3E for headset. 1. To adjust GT/MT Switch, and Gain Control, Simply push down both snap locks on the sides of battery cover and flip it backwards to expose the adjustment panel. 2. Before power on, ascertain if same channel was set up for both receiver and microphone. If not adjust to same channel accordingly. 3. The LED indicator flashes briefly when power on indicating normal battery status. If not flash occurs it has either no battery, the battery is drained or installed incorrectly. Change accordingly. 4. Plug the microphone connector into the input jack and tighten the connector screw by clockwise direction.

FCC Part 74 Subpart H EMI TEST REPORT of E.U.T. : Transmitter / Wireless Microphone FCC ID. : JEBQT-20 MODEL : QT-20 Working Frequency : 174-216MHz for APPLICANT : WA GOL INDUSTRIAL CO., LTD. ADDRESS : No. 85 Chang Hsing First Street, Tai-tzu Village, Jen-Te Hsian, Tainan Hsien, Taiwan, R.O.C. Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34, LIN 5, DING FU TSUN, LINKOU HSIANG TAIPEI HSIEN, TAIWAN, R.O.C. Tel:(02)226023052, 26023054 Fax:(02)26010910 Report Number : ET91R-06-083-03 ETC Report No.:ET91R-06-083-03 FCC ID.: JEBQT-20 TEST REPORT CIRTIFICATION Applicant : WA GOL INDUSTRIAL CO., LTD. No. 85 Chang Hsing First Street, Tai-tzu Village, Jen-Te Hsian, Tainan Hsien, Taiwan, R.O.C. Manufacturer : WA GOL INDUSTRIAL CO., LTD. No. 85 Chang Hsing First Street, Tai-tzu Village, Jen-Te Hsian, Tainan Hsien, Taiwan, R.O.C. Description of EUT : a) Type of EUT : Transmitter / Wireless Microphone b) Trade Name : MASCOT c) Model No. : QT-20 d) FCC ID : JEBQT-20 e) Working Frequency : 174-216MHz f) Power Supply : DC 3V Batteries Regulation Applied : FCC Rules and Regulations Part 74 Subpart H (2001) I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Issued Date : Jul. 15, 2002 Test Engineer : ( Jeff Chuang ) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.:ET91R-06-083-03 FCC ID.: JEBQT-20 Table of Contents Page 1. GENERAL INFORMATION .................................................................................................................................. 1 1.1 PRODUCT DESCRIPTIO N............................................................................................................................................ 1 1.2 CHARACTERISTICS OF DEVICE:.................................................................................................................................. 1 1.3 TEST METHODOLOGY................................................................................................................................................ 1 1.4 TEST FACILITY.......................................................................................................................................................... 1 2. REQUIREMENTS OF PROVISIONS ................................................................................................................... 2 2.1 DEFINITION............................................................................................................................................................... 2 2.2 FREQ UEN CIES AVAILABLE......................................................................................................................................... 2 2.3 REQUIREMENTS FOR RADIO EQUIPMENT ON CERTIFICATIO N..................................................................................... 2 2.4 LABELIN G REQ UIREMEN T.......................................................................................................................................... 3 3. OUTPUT POWER MEASUREMENT ................................................................................................................... 4 3.1 PROVISION APPLICABLE............................................................................................................................................ 4 3.2 MEASUREMEN T PROCEDURE...................................................................................................................................... 4 3.3 TEST DATA................................................................................................................................................................ 6 3.3 RESULT CALCULATIO N.............................................................................................................................................. 6 3.4 TEST EQUIPMENT...................................................................................................................................................... 6 4. MODULATION CHARACTERISTICS................................................................................................................. 7 4.1 PROVISIONS APPLICABLE.......................................................................................................................................... 7 4.2 MEASUREMEN T METHO D........................................................................................................................................... 7 4.3 MEASUREMEN T IN STRUMEN T.................................................................................................................................... 8 4.4 MEASUREMEN T RESULT............................................................................................................................................ 8 5. OCCUPIED BANDWIDTH OF EMISSION........................................................................................................ 10 5.1 PROVISIONS APPLICABLE........................................................................................................................................ 10 5.2 MEASUREMEN T METHO D......................................................................................................................................... 10 5.3 OCCUPIED BANDWIDTH TEST EQUIPMENT............................................................................................................... 10 5.4 BANDWIDTH MEASURED......................................................................................................................................... 11 5.4.1 Input Level Derived....................................................................................................................................... 1…

Text truncated - open the document above for the full version.

ETC Report No.:ET91R-06-083-03 FCC ID.:JEBQT-20 Radiated Measurement Photos
