FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Front View of EUT Bottom View of EUT FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Side View of EUT Top View of EUT FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Side View of EUT Rear View of EUT

F C C 認 證 貼 紙 黑 底 白 字 : 頻 率 6 3 0 ~ 6 6 0 M H z 7 4 0 ~ 7 7 0 M H z M A D E I N T A I W A N F C C I D . : J E B U T - 9 U H F B A N D T R A N S M I T T E R PDF created with FinePrint pdfFactory trial version http://www.fineprint.com

FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Internal View of EUT Component View of PCB FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Component View of PCB Solder View of PCB FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Component View of PCB Solder View of PCB FCC ID.:JEBUT-9 Rev. 2.0 CONSTRUCTED PHOTOS of EUT Component View of PCB Solder View of PCB

The EUT is A frequency modulation Wireless Microphone with following features: 1. Operation Frequency Range:630 - 660MHz; 740 - 770MHz. 2. Type of Modulation:FM, 161KF3E. 3. The emission designator is 161KF3E. The calculation is (2M+2DK), K=1 and (2 x 32.768 + 2 x 48) = 161.5kHz, so the emission designator is 161KF3E. 4. This Wireless Microphone operates within UHF band with PLL synthesized.

UT-9 TRANSMITTER PROCEDURE 1. Audio from the microphone is coupled through IC BA4510 applied to Audio amplifier and buffer stage. Adjust VR R4 to control audio amplify level. 2. (Variable Capacitance Diode) of the VCO modulate the audio signal into RF signal 3. The RF signal of 630MHz to 660MHz is generated from VCO and is locked via PLL IC U4 when selected. Adjust VC C31 to correct the exact frequency.. 4. The locked RF signal is coupled to bufferQ13and amplifiers Q12 & Q11. 5. After RF pre-amplify and final amplify, L7,L8,C41 & L9,L10,C50 to filter the spurious and harmonics and have the correct frequency pass through the maximum pass-point of the filter to transmit out. At this stage, the RF level is about 7dBm. MASCOT ELECTRIC CO, LTD DATE APR 15 2004 UT-9 TRANSMITTER PROCEDURE 1. Audio from the microphone is coupled through IC BA4510 applied to Audio amplifier and buffer stage. Adjust VR R4 to control audio amplify level. 2. (Variable Capacitance Diode) of the VCO modulate the audio signal into RF signal 3. The RF signal of 740MHz to 770MHz is generated from VCO and is locked via PLL IC U4 when selected. Adjust VC C31 to correct the exact frequency.. 4. The locked RF signal is coupled to bufferQ13and amplifiers Q12 & Q11. 5. After RF pre-amplify and final amplify, L7,L8,C41 & L9,L10,C50 to filter the spurious and harmonics and have the correct frequency pass through the maximum pass-point of the filter to transmit out. At this stage, the RF level is about 7dBm. MASCOT ELECTRIC CO, LTD DATE APR 15 2004

Rev. 2.0 FCC Part 74 Subpart H EMI TEST REPORT of E.U.T. : Wireless Bodypack Transmitter Microphone FCC ID. : JEBUT-9 MODEL : UT-9 Working Frequency : 630MHz-770MHz for APPLICANT MASCOT ELECTRIC CO., LTD. ADDRESS No. 85, Chang Hsing First Street, Tai-Tzu Village, Jen-Te Hsian, Tainan Hsien, Taiwan Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 34, LIN 5, DING FU TSUN, LINKOU HSIANG TAIPEI HSIEN, TAIWAN, R.O.C. Tel:(02)226023052 Fax:(02)26010910 http://www.etc.org.tw ; e-mail : [email protected] Report Number : ET93R-04-040-04 ETC Report No.:ET93R-04-040-04 FCC ID.: JEBUT-9 Rev. 2.0 TEST REPORT CIRTIFICATION Applicant : MASCOT ELECTRIC CO., LTD. No. 85, Chang Hsing First Street, Tai-Tzu Village, Jen-Te Hsian, Tainan Hsien, Taiwan. Manufacturer : MASCOT ELECTRIC CO., LTD. No. 85, Chang Hsing First Street, Tai-Tzu Village, Jen-Te Hsian, Tainan Hsien, Taiwan. Description of EUT : a) Type of EUT : Wireless Bodypack Transmitter Microphone b) Trade Name : MASCOT c) Model No. : UT-9 d) FCC ID : JEBUT-9 e) Working Frequency : 630MHz-770MHz f) Power Supply : DC 3V Batteries Regulation Applied : FCC Rules and Regulations Part 74 Subpart H (2003) I HEREBY CERTIFY THAT; The data shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Issued Date : MAY 11, 2004 Test Engineer : ( Kevin Lee ) Approve & Authorized Signer : Will Yauo, Manager EMC Dept. II of ELECTRONICS TESTING CENTER, TAIWAN ETC Report No.:ET93R-04-040-04 FCC ID.: JEBUT-9 Rev. 2.0 Table of Contents Page 1. GENERAL INFORMATION.....................................................................................................................................................1 1.1 PRODUCT DESCRIPTION...........................................................................................................................................................1 1.2 CHARACTERISTICS OF DEVICE:................................................................................................................................................1 1.3 TEST METHODOLOGY...............................................................................................................................................................1 1.4 TEST FACILITY...........................................................................................................................................................................1 2. REQUIREMENTS OF PROVISIONS.....................................................................................................................................2 2.1 DEFINITION.................................................................................................................................................................................2 2.2 FREQUENCIES AVAILABLE.......................................................................................................................................................2 2.3 REQUIREMENTS FOR RADIO EQUIPMENT ON CERTIFICATION.........................................................................................2 2.4 LABELING REQUIREMENT........................................................................................................................................................3 3. OUTPUT POWER MEASUREMENT......................................................................................................................................4 3.1 PROVISION APPLICABLE...........................................................................................................................................................4 3.2 MEASUREMENT PROCEDURE...................................................................................................................................................4 3.3 TEST DATA.................................................................................................................................................................................6 3.4 RESULT CALCULATION............................................................................................................................................................8 3.5 TEST EQUIPMENT......................................................................................................................................................................8 4. MODULATION CHARACTERISTICS..................................................................................................................................9 4.1 PROVISIONS APPLICABLE.........................................................................................................................................................9 4.2 MEASUREMENT METHOD........................................................................................................................................................9 4.3 MEASUREMENT INSTRUMENT..............................................................................................................................................10 4.4 MEASUREMENT RESULT........................................................................................................................................................10 5. OCCUPIED BANDWIDTH OF EMISSION.........................................................................................................................14 5.1 PROVISIONS APPLICABLE.......................................................................................................................................................14 5.2 MEASUREMENT METHOD......................................................................................................................................................14 5.3 OCCUPIED BANDWIDTH TEST EQUIPMENT.............................................................................…
