JEH2381GATE2381 Gate RFID

NCR Corporation, RSD - Atlanta

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Oct 26, 2010
Application Purpose: Original Equipment
Date of Application: Oct 25, 2010
Equipment Note: 2381 Gate RFID
Frequency Range: 13.56000000 - 13.56000000
Company: NCR Corporation, RSD - Atlanta
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Exhibit FCC ID: JEH2381GATE IC: 470B-2381GATE FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 10-0325.W06.11.A Manufacturer: NCR Corporation Model: 2381GATE Manual NCR SelfServ Entertainment 2381 Gate RFID User Guide FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this device not expressly approved by NCR could void the user’s authority to operate the equipment. IC Compliance This Class B digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Cet appareillage numérique de la classe B répond à toutes les exigences de l'interférence canadienne causant des règlements d'équipement. L'opération est sujette aux deux conditions suivantes: (1) ce dispositif peut ne pas causer l'interférence nocive, et (2) ce dispositif doit accepter n'importe quelle interférence reçue, y compris l'interférence qui peut causer l'opération peu désirée. This device has been designed to operate with the antennas listed below, and having a maximum gain of 0 dBi. Antennas not included in this list or having a gain greater than 0 dBi are strictly prohibited for use with this device. The required antenna impedance is 50 ohms. Authorized antenna: NCR Gate antenna, assembly part number 497-0470304 - 2 - Who Should Use This Document This user guide is intended for use by anyone seeking to operate the 2381 Gate RFID reader independently from the 2381 DVD kiosk as a stand-alone RFID reader. Parts Identification The 2381 Gate RFID module, cable, and antenna are pictured below. This reader is intended to be used only with the cable and antenna supplied by NCR. A 3.3V/5V dual output power supply is required to power the reader. Figure 1 - 3 - System Setup You will need: • PC or laptop running Windows XP • USB type A male to type B male cable • 3.3V/5V dual output power supply • Power supply cable • Microsoft .NET 3.5 • HID terminal software • 2381 FCC Test Firmware IMPORTANT: You must obtain and update the 2381 Gate RFID board with FCC Test Firmware before using the reader in a stand-alone configuration. Refer to the 2381 Installation Guide for firmware update instructions. First, connect the antenna to the reader using the supplied 10 feet long RP-SMA plug to RP-SMA plug 50 ohm cable. Figure 2 Connect the power cable and power supply to the board. Pin 1 (red) must be connected to +5V, connect pin 2 (black) to ground, and connect pin 4 (white) to +3.3V. Figure 3 - 4 - Next, locate the RFID module’s USB connector on the bottom side of the PCBA, and connect the 2381 Gate RFID PCBA to a Windows PC or laptop with a USB cable. Figure 4 - 5 - Operation Open a HID terminal session by selecting the NCR DVD Vending Kiosk HID Terminal icon from the desktop. Accept the default options and click on the Connect button. Then select rfid from the main menu. Figure 5 Select option 5, Gate RFID Test, to initiate an ISO15693 inventory command, and then present an RFID tag to the RFID antenna. The reader will repeatedly send inventory commands until it is interrupted. The terminal will display the UID of any RFID tag that responds to the command. Press a key to terminate the continuous modulation from the repeating inventory command transmissions. Figure 6 Select option 7, Gate RFID On, to generate a continuous wave (CW) tone. The reader will continue to generate a CW tone until it is terminated with the Gate RFID Test option or until power is removed from the device. - 6 -

Cover Letter(s)

Adam Rudd EMC Engineer NCR Corporation 2651 Satellite Blvd Duluth, GA 30096 2010-03-03 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Dear Sir or Madam: I hereby appoint Sam Wismer at Advanced Compliance Solutions, Inc. to act as our agent in the preparation of an application for equipment authorization of FCC ID: JEH2381GATE to the FCC Rules and Regulations. I certify that all exhibits contained within this filing properly describe the device or system for which authorization is sought. I further certify that appropriate arrangements have been made to assure that production units of this equipment bearing the name and FCC IDENTIFIER listed in this application will continue to comply with the Commission's requirements. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment also includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Sincerely, Name: Adam Rudd Title: EMC Engineer

Cover Letter(s)

Advanced Compliance Solutions – 5015 B.U. Bowman Drive, Buford, GA 30518 October 15, 2010 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: NCR Corporation respectfully requests confidentiality of certain materials provided with the submission of the 2381GATE under FCC ID: JEH2381GATE in accordance with FCC Regulations 0.459. The confidentiality request applies to the following exhibits: 10-0325 – Schematics.pdf 10-0325 – System Block Diagram.pdf 10-0325 – Theory of Operation.pdf The 2381GATE has been developed at considerable effort and expense by NCR Corporation. These items are considered as Trade Secrets and therefore public access to the proprietary material could possibly result in duplication of equipment that could severely damage the company’s business advantage. I appreciate your assistance in this matter. Sincerely, Sam Wismer Vice President, Technology Agent Phone: (770) 831-8048 Fax: (770) 831-8598

Cover Letter(s)

5015 B. U. Bowman Dr. Buford, GA 30518 October 15, 2010 ACS TCB 5015 B.U. Bowman Drive Buford, GA 30518 Re: FCC ID: JEH2381GATE To Whom It May Concern: The following application is submitted on behalf of our client, NCR Corporation, for evaluation of their model 2381GATE for certification under FCC Part 15.225. The 2381GATE is a stand-alone module consisting of a single printed circuit board which is designed to be integrated into host devices. The 2381GATE was tested in full to the requirements of the aforementioned rules and was found to be in compliance. Sincerely, Sam Wismer Vice President, Technology Advanced Compliance Solutions, Inc.

Cover Letter(s)

Adam Rudd EMC Engineer NCR Corporation 2651 Satellite Blvd Duluth, GA 30096 Page 1 of 2 REQUEST FOR MODULAR APPROVAL FCC ID: JEH2381GATE 2010-04-26 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: NCR Corporation requests modular approval for our 13.56 MHz RFID transmitter in accordance with 47CFR15.212. The 2381GATE satisfies your definition of a self-contained radiofrequency device that is typically incorporated into another host and complies with all of your requirements as addressed below: 15.212(a)(1)(i) The module features its own integrated shielding in the form of a metal PCB shield over the RF components. 15.212(a)(1)(ii) The module’s RF circuit does not allow for external data input. The transmitter circuit is driven by an onboard microcontroller which provides data buffering and protection from excessive data rates and over- modulation. 15.212(a)(1)(iii) The module features its own integrated DC power regulators to provide the stable voltages necessary for operation even when the input voltage is varied. 15.212(a)(1)(iv) The module complies with the requirements of 15.203 and 15.204. It features a reverse polarity SMA (RP-SMA) connector for its antenna interface which complies with the ‘unique antenna coupler’ requirement. All antennas configurations to be used with the module are included in the application for certification. Page 2 of 2 15.212(a)(1)(v) The module was tested stand-alone and relied only on its own integrated shielding, as shown in the application for certification, and the power cable was > 10cm in length and used no ferrites. 15.212(a)(1)(vi) The module contains a permanently affixed label indicating its FCC ID. The module is not intended for sale to third parties; any device that contains this module will be manufactured under the control of NCR Corporation and will have the appropriate labeling as part of its regulatory compliance label. The application for certification contains examples of these. 15.212(a)(1)(vii) The module complies with all specific rules which apply to complete transmitters of its type. 15.212(a)(1)(viii) There are no applicable RF exposure rules for this module per 15.225 and 2.1091. Sincerely, Name: Adam Rudd Date: 2010-04-26

External Photos

ID Label/Location Info

Internal Photos

Test Report

5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 Certification Test Report FCC ID: JEH2381GATE IC: 470B-2381GATE FCC Rule Part: 15.225 IC Radio Standards Specification: RSS-210 ACS Report Number: 10-0325.W06.11.A Manufacturer: NCR Corporation Model: 2381GATE Test Begin Date: September 20, 2010 Test End Date: September 27, 2010 Report Issue Date: October 15, 2010 FOR THE SCOPE OF ACCREDITATION UNDER LAB Code 200612-0 This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the Federal Government. Prepared by: Kirby Munroe Director, Wireless Certifications ACS, Inc. This test report shall not be reproduced except in full. This report may be reproduced in part with prior written consent of ACS, Inc. The results contained in this report are representative of the sample(s) submitted for evaluation. This report contains 17 pages 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598 TABLE OF CONTENTS 1 GENERAL ............................................................................................................................................ 3 1.1 PURPOSE .......................................................................................................................................... 3 1.2 PRODUCT DESCRIPTION ................................................................................................................... 3 1.3 TEST METHODOLOGY AND CONSIDERATIONS ................................................................................. 3 2 TEST FACILITIES .............................................................................................................................. 4 2.1 LOCATION ....................................................................................................................................... 4 2.2 LABORATORY ACCREDITATIONS/RECOGNITIONS/CERTIFICATIONS ................................................ 4 2.3 RADIATED EMISSIONS TEST SITE DESCRIPTION .............................................................................. 5 2.3.1 Semi-Anechoic Chamber Test Site .......................................................................................... 5 2.3.2 Open Area Tests Site (OATS) ................................................................................................. 6 2.4 CONDUCTED EMISSIONS TEST SITE DESCRIPTION ........................................................................... 7 3 APPLICABLE STANDARD REFERENCES .................................................................................... 7 4 LIST OF TEST EQUIPMENT ............................................................................................................ 8 5 SUPPORT EQUIPMENT .................................................................................................................... 9 6 EQUIPMENT UNDER TEST SETUP BLOCK DIAGRAM ........................................................... 9 7 SUMMARY OF TESTS ..................................................................................................................... 10 7.1 ANTENNA REQUIREMENT – FCC: CFR 47 PART 15.203 ................................................................ 10 7.2 POWER LINE CONDUCTED EMISSIONS – FCC: CFR 47 PART 15.207/ IC RSS-GEN 7.2.2 ............. 10 7.2.1 Measurement Procedure ....................................................................................................... 10 7.2.2 Measurement Results ............................................................................................................ 10 7.3 RADIATED EMISSIONS – INTENTIONAL RADIATION ....................................................................... 12 7.3.1 In-Band Emissions Limitations – FCC Part 15.225(a),(b),(c) / IC RSS-210 A2.6 ............... 12 7.3.1.1 Test Methodology ............................................................................................................................ 12 7.3.1.2 Test Results ...................................................................................................................................... 12 7.3.2 Out-of-Band Emissions – FCC Part 15.225(d), 15.209, 15.109 / IC RSS-210 2.6 ............... 13 7.3.2.1 Test Methodology ............................................................................................................................ 13 7.3.2.2 Distance Correction for Measurements Below 30 MHz – Part 15.31 ............................................... 13 7.3.2.3 Test Results ...................................................................................................................................... 13 7.3.2.4 Sample Calculation: ......................................................................................................................... 14 7.4 OCCUPIED BANDWIDTH – FCC PART 15.215(C) / IC RSS-GEN 4.6.1 ............................................ 15 7.4.1 Test Methodology ................................................................................................................. 15 7.4.2 Test Results ........................................................................................................................... 15 7.5 FREQUENCY STABILITY – FCC CFR 47 PART 15.225(E) / IC RSS-210 A2.6 ................................. 16 7.5.1 Test Methodology ................................................................................................................. 16 7.5.2 Test Results ........................................................................................................................... 16 8 CONCLUSION ................................................................................................................................... 17 Model: 2381GATE FCC ID: JEH2381GATE IC: 470B-2381GATE ACS Report: 10-0325.W06.11.A Advanced Compliance Solutions Page 3 1 GENERAL 1.1 Purpose The purpose of this report is t…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Raymond Verar(Engineer - EMC Certification)

[email protected]7702125972Fax: 4044791172

Test Firm

Advanced Compliance Solutions, Inc.Randy Abernathy

[email protected]770-831-8048Fax: 770-831-8598

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Tolerance
1	15C	13.56 MHz - 13.56 MHz	-	100.0000000000 ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Modular Approval. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device.
