JJ4-AS00900Wireless Keyboard

Movea, Inc
Wireless Keyboard - FCC ID JJ4-AS00900 - Movea, Inc
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Apr 07, 2005
Application Purpose
Original Equipment
Date of Application
Apr 07, 2005
Equipment Note
Wireless Keyboard
Frequency Range
2403.00000000 - 2479.00000000
Company
Movea, Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

COMPACT KEYBOARD CLAVIER COMPACT User Guide Guide de l’utilisateur GC1105CKM_NA_IB_REVA_K6.qxd 2/11/05 12:51 PM Page 1 TABLE OF CONTENTS Compact Keyboard .......................................................... 1 Key Features .............................................................. 1 Setting Up and Synchronizing .................................... 2 Powering On and Off ............................................... 4 Special Keyboard Media Keys .................................... 5 RF Receiver .................................................................... 6 Connect Button ............................................................. 6 Status LED ................................................................... 6 Troubleshooting .............................................................. 7 PRODUCT SPECIFICATIONS * Internet and Multimedia hot keys not supported by Macintosh or Windows 98 (Second Edition). Standardkeyboard keys are functional.Note : 49 MHz mouse, keyboard and remotes are not compatible with the 2.4 GHz RF Receiver. Spec Compact Keyboard RF Receiver System RequirementsSize 12.5" L x 6" W x 1"H (32 cm x 15 cm x 2.5 cm) 70'' L x 1.18'' W x .35'' H(178 cm x 3 cm x .9 cm) Weight 21 ounces (653 g) includes batteries .53 ounces (15 g) Radio 2.4 GHz (U.S.) with automatic channel selection 2.4 GHz (U.S.) Batteries 4 AAA N/A Connector N/A Operating Temp +10 to +40 C (+50 to +104 F) Storage Temp -30 to +70 C (-86 to +158 F) USB • Full functionality on IBM compatible PCs running Windows 2000, ME, XP or higher• Limited functionality on MAC OS 8.0 and higher and Windows 98 (Second Edition)* • Available USB port GC1105CKM_NA_IB_REVA_K6.qxd 2/11/05 12:51 PM Page 2 1 GYRATION COMPACT KEYBOARDGyration’s Wireless Compact Keyboard is small, ultra-light and perfect forconference rooms, classrooms, traveling or even the living room with yourmedia PC. Having no line-of-sight limitations, its powerful range allows you tocontrol your PC from virtually anywhere in the room and when you includethe whisper quiet keys, you have the ultimate in portability and efficiency.Setting Up and Synchronizing the Keyboard and the Gyration RF ReceiverWhen installing the Compact Keyboard for the first time or when addingadditional Gyration devices to the system, it is necessary to synchronize thedevices with the receiver. Key Features Status LED Connect Button GC1105CKM_NA_IB_REVA_K6.qxd 2/11/05 12:51 PM Page 4 3 Note: Repeat steps 3 and 4 for any additional Gyration ® GO 2.4 GHz mice, keyboards, and/or remotes that will be added to the system. 5. Connect Mode will automatically time out after one minute. After the Connect/Connect sequence is performed, the receiver and device(s) willremain synchronized after powering down. It is only necessary to perform the Connect/Connect sequence when setting a device up for the first time or whenadding additional devices to the system. To set up and synchronize the Compact Keyboard and the RF Receiver: 1. Connect the RF receiver into an available USB port and power on yourcomputer. Your operating system should detect the new hardware deviceand initiate the installation procedure. Continue to follow the standard USBdevice installation screens until installation is complete. 2. Insert four AAA batteries (included) into the keyboard. 3. Press and hold the Connect button on the receiver for two seconds, and then release it. The Connect light will blink rapidly, indicating the receiver is in “Connect Mode.” 4. Press and release the Connect button located at the top of the keyboard. The Connect light on the receiver will stop blinking and remain lit. 2 Status LED Connect Button Connect Button RF Receiver Top of Compact Keyboard The above illustrates the Connect/Connect sequence discussed in this guide. GC1105CKM_NA_IB_REVA_K6.qxd 2/11/05 12:51 PM Page 6 5 4 POWERING THE KEYBOARD ON AND OFFIt is only necessary to power down your keyboard if traveling without itsprotective cover (included with select models only). If the hard shell cover isused, powering down is not required and the keyboard will remain in SleepMode with no radio transmission. However, it is recommended you power downto avoid inadvertent key presses that may occur without snapping on the cover.To power on: • Press the Connect button at the top of the keyboard. It will confirm it is powering on by flashing its Status light for one second. To power off: • Press the Connect button at the top of the keyboard for seven seconds. It will immediately power off and be unresponsive to button clicks. It willconfirm it is powering off by flashing its Status light three times. Special Keyboard Media Keys Key OS Support Win 2000 ME, XP Windows CD Player, Default Media Player CD or Media player scans for previously played trackToggles player between Play and Pause modes Win 2000 ME, XP Windows CD Player, Default Media Player CD or Media player scans for next track on CD or music file Win 2000 ME, XP Windows CD Player, Default Media Player Puts player into Stop mode Win 2000 ME, XP Windows CD Player, Default Media Player Decreases Windows volume setting Win 2000 ME, XP Windows Sound Control Increases Windows volume setting Win 2000 ME, XP Windows Sound Control Mutes Windows sound volume Win 2000 ME, XP Windows Sound Control Loads the last page you viewed in the browser window Win 2000 ME, XP Microsoft Internet Explorer Program Support Function Win 2000 ME, XP Microsoft Internet Explorer Reloads a page you viewed before clicking the Back button Win 2000 ME, XP Microsoft Internet Explorer Stops the loading process in the browser window Win 2000 ME, XP Microsoft Internet Explorer Reloads the currently displayed page in the browser window Win 2000 ME, XP Microsoft Internet Explorer Launches Browser (if closed) and loads your Home page in the browser window Win 2000 ME, XP Microsoft Internet Explorer Opens the Search frame in the browser window or, if closed, launches Windows search Win 2000 ME, XP Microsoft Internet…

Text truncated - open the document above for the full version.

Users Manual

Regulatory Information Notice to Users: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Plug the equipment into an outlet on a circuit different from that which the receiver is plugged. • Consult the dealer or an experienced radio/TC technician for help. This product works using a radio frequency, so use on an airplane may be restricted due to interference. FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. CE Statement: This equipment has been tested and found to comply with the limits of the European Council Directive on the approximation of the law of the member states relating to electromagnetic compatibility (89/336/EEC) according to EN 55022 Class B. Industry Canada Equipment Notice: The Industry Canada certification identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements as prescribed in the appropriate Terminal Equipment Technical Document(s). The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company. The equipment must also be installed using an accept - able method of connection. The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensure, for their own protection, that the electrical ground connectors of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This presentation may be particularly important in rural areas. Caution: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority or electrician, as appropriate. Warranty Information Limited Two Year Warranty Our company (in the U.S.,THOMSON INC. / In Canada, Thomson multimedia Ltd.) warrants that for two years from the date of purchase, it will replace this product if found to be defective in materials or workmanship. For a prompt, no charge replacement of equivalent product, return the defective product postage prepaid to the appropriate address. If purchased in the US: If purchased in Canada: Product Exchange Center Thomson multimedia Ltd. 11721 Alameda Avenue 6200 Edwards Boulevard Socorro TX 79927 Mississauga, Ontario Canada L5T 2V7 This replacement is the company's sole obligation under this warranty. THOMSON INC. / Thomson multimedia Ltd. will not be responsible for any incidental or consequential damages or for any loss arising in connection with the use or inability to use this product. Some states/provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty excludes defects or damage due to misuse, abuse, or neglect. This warranty gives you specific legal rights, and you may also have other rights, which vary from state to state/province to province. Information sur la réglementation Avis aux utilisateurs : Cet appareil a été testé et approuvé en conformité avec les limites qui définissent un appareil de Classe B, suivant la Partie 15 des règlements de la FCC. Ces limites sont conçues pour assurer une protection raisonnable contre l'interférence nuisible dans une installation résidentielle. Cet appareil produit, utilise et peut transmettre par rayonnement de l'énergie radiofréquence et, s'il n'est pas installé et utilisé conformément aux instructions, peut produire de l'interférence nuisible aux communications radio. Toutefois, il n'est aucunement garanti qu'aucune interférence ne sera produite dans une installation particulière. Si cet appareil cause une interférence nuisible à la réception de la radio ou de la télévision, ce qui peut être déterminé en éteignant et en rallumant l'appareil, l'utilisateur peut tenter de corriger la situation en prenant les mesures suivantes : • Réorienter ou déplacer les antennes de réception. • Augmenter la distance entre l'appareil et le récepteur. • Brancher l'appareil dans une prise d'un circuit différent de celui du récepteur. • Consulter le revendeur ou un technicien compétent en radio/télévision pour obtenir de l'aide. Cet appareil fonc tionne par radiof…

Text truncated - open the document above for the full version.

Cover Letter(s)

1 Helen Zhao From:Claire Hoque Sent:Friday, April 08, 2005 9:44 AM To:Helen Zhao Cc:Julia Luke; Thu Chan; Danielle Zhan Subject:answer: TCB questions: Gyration, Inc. , FCC ID: JJ4-AS00900, Assessment NO.: AN05T4678 (keyboard) 05U3274-1 REV B FCC REPORT(KEY... Internal Photos(revised).pdf Compliance info User Manual(re... Hi Helen, Pls see our answer as follows. Question #1: Neither "Regulatory Information" nor "User manual" includes user information as specified in FCC15.21 and RF exposure statement as specified in FCC 15.247(i). The possible RF Exposure statement for this device could be: "The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. " Please revise the exhibit(s) accordingly. <answer>pls see revised compliance sheet as attached. Question #2: This device is considered as a portable device, due to the low power output, it is exempted from SAR evaluation. The test report, however, includes MPE calculation, which is not applicable to portable devices. Please remove MPE calculation from the test report. [Danielle]Original Section 7.1.4 Maximum Permissible Exposure removed from the report. Question #3: Please provide additional internal photos to clearly show top view and bottom view of all the PCBs. <answer>pls see revised internal photos. Thanks, Claire

ID Label/Location Info

PROPOSED FCC ID LABEL AND LOCATION GYRATION INC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID : JJ4-AS00900 FCC ID LABEL

Test Report

FCC CFR47 PART 15 SUBPART C CERTIFICATION TEST REPORT FOR WIRELESS KEYBOARD MODEL NUMBER: AS00900-007 FCC ID: JJ4-AS00900 REPORT NUMBER: 05U3274-1 REV B ISSUE DATE: APRIL 6, 2005 Prepared for GYRATION 12950 SARATOGA AVE. SARATOGA, CA 95070, USA Prepared by COMPLIANCE ENGINEERING SERVICES, INC. d.b.a. COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 05U3274-1 REV B DATE: APRIL 6, 2005 EUT: WIRELESS KEYBOARD FCC ID: JJ4-AS00900 Page 2 of 54 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By B Delete the original Section 7.1.4 Maximum Permissible Exposure Danielle Z. REPORT NO: 05U3274-1 REV B DATE: APRIL 6, 2005 EUT: WIRELESS KEYBOARD FCC ID: JJ4-AS00900 Page 3 of 54 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. TEST METHODOLOGY .................................................................................................................. 5 3. FACILITIES AND ACCREDITATION .......................................................................................... 5 4. CALIBRATION AND UNCERTAINTY.......................................................................................... 5 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................................. 5 4.2. MEASUREMENT UNCERTAINTY ............................................................................................... 5 5. EQUIPMENT UNDER TEST............................................................................................................6 5.1. DESCRIPTION OF EUT ..............................................................................................................6 5.2. MAXIMUM OUTPUT POWER .................................................................................................... 6 5.3. DESCRIPTION OF AVAILABLE ANTENNAS ............................................................................. 7 5.4. SOFTWARE AND FIRMWARE .................................................................................................... 7 5.5. WORST-CASE CONFIGURATION AND MODE......................................................................... 7 5.6. DESCRIPTION OF TEST SETUP ................................................................................................ 8 6. TEST AND MEASUREMENT EQUIPMENT .............................................................................. 10 7. LIMITS AND RESULTS ................................................................................................................. 11 7.1. CHANNEL TESTS FOR THE 2400 TO 2483.5 MHz BAND ...................................................... 11 7.1.1. 6 dB BANDWIDTH ........................................................................................................... 11 7.1.2. 99% BANDWIDTH............................................................................................................ 15 7.1.3. PEAK OUTPUT POWER .................................................................................................. 19 7.1.4. AVERAGE POWER........................................................................................................... 24 7.1.5. PEAK POWER SPECTRAL DENSITY ............................................................................ 25 7.1.6. CONDUCTED SPURIOUS EMISSIONS.......................................................................... 29 7.2. RADIATED EMISSIONS.............................................................................................................36 7.2.1. TRANSMITTER RADIATED SPURIOUS EMISSIONS ................................................. 36 7.2.2. TRANSMITTER ABOVE 1 GHz FOR 2400 TO 2483.5 MHz BAND ............................. 39 7.2.3. WORST-CASE RADIATED EMISSIONS BELOW 1 GHz ............................................. 48 8. SETUP PHOTOS .............................................................................................................................. 52 REPORT NO: 05U3274-1 REV B DATE: APRIL 6, 2005 EUT: WIRELESS KEYBOARD FCC ID: JJ4-AS00900 Page 4 of 54 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: GYRATION 12950 SARATOGA AVE. SARATOGA, CA 95070, USA EUT DESCRIPTION: WIRELESS KEYBOARD MODEL: AS00900-007 SERIAL NUMBER: 001 DATE TESTED: FEBRUARY 25 – MARCH 01, 2005 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 15 SUBPART C NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approv…

Text truncated - open the document above for the full version.

Test Setup Photos

REPORT NO: 05U3274-1 DATE: MARCH 25, 2005 EUT: WIRELESS KEYBOARD FCC ID: JJ4-AS00900 Page 55 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 8. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ANTENNA PORT CONDUCTED PHOTO REPORT NO: 05U3274-1 DATE: MARCH 25, 2005 EUT: WIRELESS KEYBOARD FCC ID: JJ4-AS00900 Page 56 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. RADIATED RF MEASUREMENT SETUP RADIATED FRONT PHOTO REPORT NO: 05U3274-1 DATE: MARCH 25, 2005 EUT: WIRELESS KEYBOARD FCC ID: JJ4-AS00900 Page 57 of 57 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. END OF REPORT RADIATED BACK PHOTO

Contact Information

Applicant

Tim Kelliher(Movea engineering Director)
[email protected](408)416-4650Fax: (408)416-4695

Test Firm

Compliance Certification Services IncSteve Cheng
[email protected]408-463-0885Fax: 408-463-0888

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz620.00 µW
Confidentiality
Long Term
Grant Notes
Power Output listed is conducted. The antennas used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
