PRODUCT SPECIFICATIONS GlobalCell IID DUAL MODE AMPS/TDMA BASE STATION EIA/TIA-136 GENERAL BASE STATION SPECIFICATIONS Supply voltage:26.5 VDC Maximum ripple on supply line:< 200 millivolts from 20 Hz to 10 MHz Maximum noise on supply line:< 40 millivolts from 20 Hz to 10 MHz Current draw (26.5 VDC):24 Channels (PA off) – 26 Amps 24 Channels (PA on) – 160 Amps RF connectors:Receive:Type N Transmit <16 Channel:Type N Transmit > 16 Channel:Type DIN T1 connection:RJ-48 E1 connection:BNC Circuit breakers:1 for every 3 power amplifiers 1 for communications drawer Split power buss:Software controlled relay TRANSMIT SPECIFICATIONS Frequency coverage:869 MHz to 894 MHz Frequency stability:+/- 0.1PPM Minimum channel spacing:600 KHz for 20 Watt per channel output Output power:1 to 20 Watts variable under software control + 1 to –3dBm for variation of temperature and voltage FM modulationVoice - 12 KHz peak (adjustable) SAT – 2 KHz (adjustable) Data – 8 KHz (adjustable) Simultaneous voice and SAT 14 KHz (adjustable) Digital: π/4 shifted differentially encoded quadrature phase shift keying signals (VSELP and ACELP voice encoding) Unmodulated carrier hum+noise:32 dB below a 1 KHz tone modulated at 8 KHz peak deviation Frequency response:+/- 1 dB – 300 to 3000 Hz (6 dB/octave pre-emphasis) Compressor characteristics:2:1 in/out ratio, +/- 5 dB from 0 dB to limiting, +/- 1.0 dB From 0 dB to –30 dB (reference 1 KHz @ 2.9 KHz deviation) Spurious emission and harmonics:-90 dBm maximum conducted in the receive band Spurious emission and harmonics:-13 dBm maximum with 20 Watts nominal output power conducted outside of receive band Intermodulation products:- 60 dBc Audio muting:> 45 dB Carrier on/off time:< 1 millisecond RECEIVER SPECIFICATIONS Frequency coverage:824 MHz to 849 MHz Type of demodulation:Analog: FM + 12 KHz voice, + 2 KHz SAT, + 8KHz ST and 10 Kbit/sec signaling, + 14 KHz combined voice and SAT Digital: π/4 shifted differentially encoded quadrature phase shift keying signals VSELP and ACELP Frequency stability:+/- 0.1PPM RF sensitivity:Analog: < -116 dBm minimum (-121 dBm typical) for 12 dB SINAD with C – Message Filter Digital: < 3% for DTC at RF of –103dBm speed between 8 and 100 Km/h and for static at –110 dBm RACH = < 9% for speed of 100 Km/h and RF of –103 dBm, speed of 8 Km/h and RF of –100 dBm, and static at RF of – 111 dBm Bit Error Rate: < 0.0054 for 15 dB CNR per IS-138 minimum Selectivity (EIA):> 50 dB for adjacent channel : BER < 3% > 70 dB for alternate channel : BER < 3% Co-Channel BER:per IS-138 Spurious and image rejection:> 70 dB AM rejection:>-35 dBm Audio output level:Adjustable form + 10 dBm to – 25 dBm for 8 KHz peak deviated 1 KHz tone Loudness contrast:< 2 dB Audio distortion:< 5% Frequency response:+/- 1 dB – 300 to 3000 Hz (6 dB/octave de-emphasis) Expander characteristics:2:1 in/out ratio, +/- 5 dB from 0 dB to limiting, +/- 1.0 dB From 0 dB to –30 dB (reference 1 KHz @ 2.9 KHz deviation) Audio muting:> 40 dB Hum and noise:> 32 dB below audio
