JYCA100Triple Band GSM 850/ DCS 1800/ PCS 1900 (WAP&GPRS)

A100 USER MANUAL ii Thank you for choosing Pantech A100 and welcome to wireless mobile communication networking with the A100, our tri-band GSM mobile phone. Pantech is delighted to introduce th is outstanding mobile phone which will keep you constantly connected to the network. This User Manual explains in detail your phone’s features and functions and how to use them. NOTE : Some information in this User Manual may differ from your phone, depending on your software version and network provider. iii Phone specification Design Bar type phone with single display. Displays z Supports up to 65K colors in 128 x 128 pixels z 4 lines for text in basic mode with 14-pixel font z Two programmable (“Soft”) selection keys; five-way scroll/selection key Melodies AMR, G-MIDI, SP-MIDI, C-MIDI, SMF, i-Melody Camera Integrated VGA(0.3M) CMOS camera z Resolution up to 640x480 z Mjpeg Video recording/replay up to 7.5 f/s (LCD size) z Mjpeg Video maximum size LCD z Self timer function (5 sec or 10 sec) z Phone display used as a viewfinder z Photo album in Gallery z Photo Gallery for image storage and editing z 3 image quality options: Fine, Normal, Low Dimensions & Weight z Weight : 81g z Dimensions: 98.0 mm x 38 mm x 12.9 mm Power Management (Performance) Battery Type Capacity Standby Time Talk Time Slim (Li-ion) 570 mAh 150 Hours 202min Standard (Li-ion) 790 mAh 200 Hours 278min Operating frequencies z EGSM: 850 MHz( 멕시코 ) 900 MHz( 러시아 ), DCS: 1800 MHz, PCS: 1900 MHz networks in Europe, Africa, Asia-Pacific, North America, and South America where these networks are supported z Automatic band switching iv Safety precautions Using a mobile phone while driving may be prohibited. Please check local laws and regulations with regard to the prohibition of mobile phone use while driving, and comply with them. Use of your phone while you are driv ing may disturb your concentration and so cause an accident. Always switch your phone off as soon as possible. Should you use your phone in an emergency, either use a hands free device built into your car, or pull over in a safe place first. Switch off in restricted areas Always switch your phone off in areas where mobile phone use is restricted. Switch off in explosive or dangerous areas Always switch your phone off in ar eas with explosive or dangerous materials (such as fuels, fuel statio ns or areas containing chemical goods) and obey any instructions or signals. Do not remove your mobile phone’s battery in such areas. Switch off in aircraft Always switch your phone off when you are in an aircraft. The electromagnetic waves emitted by your phone may affect the electronic navigation equipment in the aircraft. Switch off in hospitals and near medical equipment Always switch your phone off in hospitals, and obey the regulations or rules of the hospital. Switch your phone off when using medical equipment for private purposes, if possible. Always consult with the medical equipment’s manufacturer or an expert regarding phone use near the medical equipment. Installing a hands free device in your vehicle Install vehicle hands free devices aw ay from the steering and airbag expansion area, otherwise injury may result. Mobile phones and other electronic devices Mobile phones emit electromagnetic waves that may affect nearby electronic devices. When it is switc hed on, do not place your phone close to delicate electronic equipment. v View Ear p iece Power on/off End Call key Menu exit ke y Left Soft ke y Send ke y Voicemail Alphanumeric keypad Cancel/Back Text editing clear/edit key Left scroll ke y WAP access key Selection/Confirmation ke y Keypad Lock/Unlock Main LCD V ibration Mode Right Soft key Infrared port Headset Jack Charger Ri g ht scroll Ke y vi Quick & easy Key Function [ ] [ ] (Left/Right) Performs the functions shown in the bottom line of the display. [ ] Scrolls through the menu options in Menu mode. In Standby mode, [ ]: displays the Favorite list screen. [ ]: displays the Messages menu screen. [ ]: Scroll Up: displays the Sound Settings menu to change sound. Scroll Down: displays the Contacts menu to find contact names. For details, see Using shortcut keys in Standby mode. [ ] Deletes characters from the display, or returns to the previous menu. If pressed briefly in Standby mode, opens Calendar view. [ ] Makes or receives a call. If pressed in Standby mode, displays the Recent calls list. If pressed and held in Standby mode, redials the last Key Function number called. [ ] Ends the current call. If pressed and held in Menu mode, cancels user input and returns to Standby mode. If pressed and held, outside Menu mode, switches your phone on/off. [ ] If pressed and held in Standby mode, connects to the voicemail server automatically. [ ]~ [ ] Enters numbers, letters or special characters. If pressed in Standby mode, displays the dialling screen. [ ] If pressed and held in Standby mode, enters or exits from Vibration mode. If pressed and held in Text input mode, displays the Symbol input screen. If pressed in Predictive text input mode, switches to Word search mode. [ ] Enters an international dialling prefix. In Text input mode, enters the space character. [ ] If pressed and held in Standby mode, locks or unlocks your phone. vii Key Function If pressed and held in Text editing mode, toggles between text input modes. viii Contents Phone specif ication .................................................................................. iii Safety preca utions .................................................................................... iv View ............................................................................................................. v 1. Getting st arted........................................................................................ 6 1. Package c ontents .............................................................................. 6 2. SIM card .........................................................................................…

Text truncated - open the document above for the full version.

Pantech Co., Ltd. Sinsong Center Bldg. 6th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5862 Fax: +82-2-3660-5990 ______________________________________________________________________ LETTER OF AUTHORIZATION DATE : Nov.27, 2006 To whom it may concern: We the undersigned, hereby authorize ETS Germany to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ETS Germany on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Pantech Co.,LTd. Sincerely, (Company counsel or company officer signature) Name : Byung-Wan Kim Title : Vice President (Name and Title)

Pantech Co., Ltd. Sinsong Center Bldg. 6th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5862 Fax: +82-2-3660-5990 ______________________________________________________________________ Date : Nov.27, 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Pantech Co., Ltd. FCC ID: JYCA100 Gentlemen, In accordance with 0.459 of CFR 47, Pantech Co., Ltd. hereby requests confidentiality of all Schematics, Parts List, Operational Description attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Pantech Co., Ltd. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Pantech Co., Ltd. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Name : Byung-Wan Kim Title : Vice President Company : Pantech Co., Ltd.

REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 1 of 10 Appendix A. Pictures REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 2 of 10 REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 3 of 10

Pantech Co., Ltd. Sinsong Center Bldg. 6th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5862 Fax: +82-2-3660-5990 ______________________________________________________________________ [FCC ID Label sample] Description: Triple Band GSM 850/DCS 1800 /PCS 1900 (with WAP & GPRS) FCC ID: JYCA100

Pantech Co., Ltd. Sinsong Center Bldg. 6th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5862 Fax: +82-2-3660-5990 ______________________________________________________________________ [Label Location] Description: Triple Band GSM 850 /DCS 1800 /PCS 1900 (with WAP & GPRS) FCC ID: JYCA100

REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 4 of 10 REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 5 of 10 REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 6 of 10 REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 7 of 10 REGISTRATION NUMBER: G5M206110086-P-2224 ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 8 of 10

ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C Appendix C. Pictures ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C ETS Product Service AG, Germany Registration number: G5M206110086-S-8 Appendix C

FCC Part 24 E Emission Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 24 Subpart E - Broadband PCS Comment 1 Channel: 512 Comment 2-26 dB Emission Bandwidth 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 1.8502 GHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1 ndB] ndB 26.00 dB BW 314.62925852 kHz 1 [T1] 22.79 dBm 1.85023307 GHz ndB 26.00 dB BW 314.62925852 kHz T1 [T1] -1.73 dBm 1.85004269 GHz T2 [T1] -3.67 dBm 1.85035731 GHz Date: 8.DEC.2006 18:36:01 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 24 E Emission Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 24 Subpart E - Broadband PCS Comment 1 Channel: 661 Comment 2-26 dB Emission Bandwidth 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 1.88 GHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1 ndB] ndB 26.00 dB BW 312.62525050 kHz 1 [T1] 23.66 dBm 1.87998096 GHz ndB 26.00 dB BW 312.62525050 kHz T1 [T1] -2.79 dBm 1.87984469 GHz T2 [T1] -2.57 dBm 1.88015731 GHz Date: 8.DEC.2006 18:35:09 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 24 E Emission Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 24 Subpart E - Broadband PCS Comment 1 Channel: 810 Comment 2-26 dB Emission Bandwidth 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 1.9098 GHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1 ndB] ndB 26.00 dB BW 314.62925852 kHz 1 [T1] 22.88 dBm 1.90983507 GHz ndB 26.00 dB BW 314.62925852 kHz T1 [T1] -2.85 dBm 1.90964269 GHz T2 [T1] -3.53 dBm 1.90995731 GHz Date: 8.DEC.2006 18:34:27 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 22 H Emission Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 22 Subpart H - Cellular Radiotelephone Service Comment 1 Channel: 128 Comment 2-26 dB Emission Bandwidth 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 824.2 MHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1 ndB] ndB 26.00 dB BW 314.62925852 kHz 1 [T1] 25.40 dBm 824.18496994 MHz ndB 26.00 dB BW 314.62925852 kHz T1 [T1] -0.62 dBm 824.04468938 MHz T2 [T1] 0.73 dBm 824.35931864 MHz Date: 8.DEC.2006 18:27:08 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 22 H Emission Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 22 Subpart H - Cellular Radiotelephone Service Comment 1 Channel: 188 Comment 2-26 dB Emission Bandwidth 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 836.2 MHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1 ndB] ndB 26.00 dB BW 316.63326653 kHz 1 [T1] 24.02 dBm 836.18296593 MHz ndB 26.00 dB BW 316.63326653 kHz T1 [T1] -1.59 dBm 836.04468938 MHz T2 [T1] -2.47 dBm 836.36132265 MHz Date: 8.DEC.2006 18:26:21 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 22 H Emission Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 22 Subpart H - Cellular Radiotelephone Service Comment 1 Channel: 251 Comment 2-26 dB Emission Bandwidth 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 848.8 MHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1 ndB] ndB 26.00 dB BW 312.62525050 kHz 1 [T1] 25.67 dBm 848.81302605 MHz ndB 26.00 dB BW 312.62525050 kHz T1 [T1] -0.14 dBm 848.64468938 MHz T2 [T1] -1.16 dBm 848.95731463 MHz Date: 8.DEC.2006 18:25:35 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 24 E Occupied Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH CO., LTD. Temperature / Voltage23̓C / Unom.: 4.20 V DC Test Site / OperatorETS / Mr. Schlaps Test SpecificationFCC Part 24 Subpart E - Broadband PCS Comment 1 Channel: 512 1MAX Ref Lvl 36 dBm Ref Lvl 36 dBm RBW 3 kHz VBW 3 kHz SWT 280 ms RF Att 50 dB 7 dB Offset A SGL 1MA Unit dBm 100 kHz/Center 1.8502 GHzSpan 1 MHz -60 -50 -40 -30 -20 -10 0 10 20 30 -64 36 1 T1 T2 Marker 1 [T1] 22.67 dBm 1.85018497 GHz 1 [T1] 22.67 dBm 1.85018497 GHz OPB 246.49298597 kHz T1 [T1] 8.95 dBm 1.85007675 GHz T2 [T1] 7.51 dBm 1.85032325 GHz Date: 8.DEC.2006 18:32:13 Measurement diagram ETS Product Service AG Storkower Str. 38C, D-15526 REICHENWALDE B. BERLINPage 1 of 1 FCC Part 24 E Occupied Bandwidth EUTTriple Band GSM 850/DCS1800/PCS1900 (with WAP & GPRS) ModelA100 Approval HolderPANTECH…
