JYCP2050GSM/WCDMA Phone with Bluetooth

User Guide Thank you for choosing the Pantech P2050. The Pantech P2050 has many features designed to enhance your mobile experience. From its EZ to read menus, to its sleek, stylish design, we know you will enjoy the entire P2050 experience. This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech P2050 has to offer. P2050 32 Specifications Design Clamshell phone with internal and external display Displays • 260K Colors TFT LCD with 3” internal display • 65K Colors CSTN LCD with 1.44” external display • 7 lines for text in basic mode with 16 point font • Two soft keys and four-way scroll and pressing Melodies MIDI, i-Melody, MP3, AMR, WAV, AAC, AAC+, WMA Camera Integrated 3M CMOS Camera • Resolution up to 1280 x 1024 (1.3M pixels) • 3GP Video recording/playing up to 15f/s (QVGA size) • Self-timer function (5 seconds or 10 seconds) • Photo album and video album Dimensions & Weight Weight: 102 g (with standard battery) Dimensions: 106.5 mm x 53 mm x 17.4 mm Power Management (Performance) Battery Type Capacity Standby Time Talk Time Standard Lithium- Ion (Li-ion) Up to 920mAh Up to 250 hours Up to 3 hours Operating Frequency • GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz, and PCS 1900Mhz networks in North America, South America, Europe, Africa, and Asia-Pacific where these networks are supported • Automatic band switching Contents 54 Specifications ..............................2 Phone overview ...........................8 Using Shortcuts .........................10 Menu overview ............................11 Quick & Easy ...............................14 SIM card and battery ................17 Turning the phone on/off .......20 Essential display indications .20 Setting the phone mode..........23 Entering text ...............................24 EZ quick call keys ......................26 PC Suite ........................................27 Memory card ..............................28 Memo ............................................32 Breeze Mode 1. Calls and address book Making, receiving and ending a call .........................................................34 Options during a call .....................36 Checking all calls ............................39 Speed dialing ...................................42 Using address book ......................43 Using your headset .......................45 Service and fixed dialing number ...............................................46 2. Messaging Receiving messages.....................48 Creating and sending text messages ..........................................49 Creating multimedia messages ..49 Managing messaging memory ...55 Email ....................................................56 3. Multimedia Camera ...............................................58 Photo album .....................................64 Video album .....................................66 4. Useful Features Magnifier ............................................70 Calendar.............................................70 Alarm clock ........................................71 Pill Reminder.....................................72 User Guide ........................................74 Calculator ..........................................74 Tip calculator ...................................75 Stop watch ........................................75 Say a Command .............................76 Readout Mode .................................77 5. Connectivity Bluetooth ...........................................80 Using Mobile Web ..........................82 6. Settings Phone status ....................................84 Sounds & alerts ...............................84 Display settings...............................85 Voice command setting .............85 Advanced Mode 1. Calls and address book Making, receiving and ending a call .........................................................88 Call settings ......................................93 Checking all calls ............................93 Speed dialing ...................................96 Using address book ......................97 Using your headset .......................99 Service and fixed dialing number .............................................100 Caller identification ......................101 Contents 76 2. Messaging Receiving messages...................104 Creating and sending text messages ........................................106 Creating multimedia messages ........................................107 Message templates .......................112 Message settings ..........................113 Managing messaging memory .............................................115 Email ....................................................117 Using instant messenger............117 3. Multimedia Camera .............................................120 Photo album ...................................126 Video album ...................................128 Audio album ...................................130 Music player .....................................132 Music player settings ...................137 Media player ...................................138 Other files ........................................140 Managing memory ......................140 Playing games ................................141 AppCenter .......................................141 4. Useful Features Calendar...........................................144 Alarm clock .....................................145 Pill Reminder...................................146 User Guide ......................................147 Calculator ........................................148 Tip calculator .................................148 Stop watch ......................................149 Notepad and voice memo .......149 World time ........................................151 Converter .........................................151 Timer ..................................................152 Say a Command ............................152 Rea…

Text truncated - open the document above for the full version.

Pantech Co., Ltd. Pantech Building, I- 2, DMC, Sangam-dong, Mapo-gu, Seoul, Korea Date: August 05, 2013 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 Attn: Office of Engineering and Technology Re: HAC Attestation - FCC ID: JYCP2050 To whom it may concern: We hereby declare that the MIF values detailed below are based on worst case operating modes for all air interfaces for which the HAC rating is provided based on the current methodology for determining MIF values. Reference Test report Number(s): HCTA1307FM01 SPEAG test files UID Communication System Name MIF (dB) 10021-CAA GSM-FDD (TDMA, GMSK) 3.63 10011-CAA UMTS-FDD (WCDMA) -27.23 Sincerely, ____________________ Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Byung-Wan Kim - Pantech Co., Ltd.

Pantech Co., Ltd. Date: July. 03, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. SunHee Kim of HCT Co., Ltd and hereafter referred to as HCT, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. SunHee Kim of HCT Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing HCT as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e)upon suspension or cancellation of certification, discontinue use of all advertising m atter that contains any reference thereto and return any certification docume nts as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified st andards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a m isleading ma nner; h)ensure t hat any reference to our product certification in communication medi a such as docum ents, brochures or advertising, complies with the requirements of th e Certification Division ; i)kee p a record of all complaints made known to the us relating to the pro duct’s com pliance with requirements of the relevant standard and to make these record s avai lable to the Certification Division wh en requested; j)take appropriate action with respect to such complaints and any deficienci es fou nd in products or services that affect compliance with the requirements for certific ation; k)do cument the acti ons taken. Th is authorization is valid until further written notice from the applicant. Sincerely Yours, Byung-Wan Kim / Senior Vice President Pantech Co., Ltd.

Pantech Co., Ltd. Pantech Building, I- 2, DMC, Sangam-dong, Mapo-gu, Seoul, Korea Date: July. 03, 2013 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: JYCP2050 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Pantech Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Pantech Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description CONFIDENTIAL 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure 4 Schematics SHORT-TERM CONFIDENTIAL 5 External Photos 6 Internal Photos 7 Test-Setup Photos 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Pantech Co., Ltd.

FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 13 EXTERNAL PHOTOGRAPHS FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １１ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １２ of 13 ■ EXTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １３ of 13 ■ EXTERNAL PHOTO

FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 11 INTERNAL PHOTOGRAPHS FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 11 ■ Main Antenna INTERNAL PHOTO Main Antenna FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 11 ■ BT Antenna_INTERNAL PHOTO BT Antenna FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 11 ■ INTERNAL PHOTO FCC ID: JYCP2050 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １１ of 11 ■ INTERNAL PHOTO

Report No.: HCTA1307FS01 FCC ID: JYCP2050 Date of Issue: Jul. 23, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 2 of 96 Version Rev DATE DESCRIPTION Jul. 04, 2013 First Approval Report 1 Jul. 23, 2013 Page 31 is revised Report No.: HCTA1307FS01 FCC ID: JYCP2050 Date of Issue: Jul. 23, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 3 of 96 Table of Contents 1. INTRODUCTION .......................................................................................................................................... ４ 2. TEST METHODOLOGY ............................................................................................................................... ５ 3. DESCRIPTION OF DEVICE ......................................................................................................................... ６ 4. DESCRIPTION OF TEST EQUIPMENT ...................................................................................................... ７ 5. SAR MEASUREMENT PROCEDURE ..................................................................................................... １４ 6. DESCRIPTION OF TEST POSITION ....................................................................................................... １６ 7. MEASUREMENT UNCERTAINTY ........................................................................................................... １８ 8. ANSI/ IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................................................. １９ 9. SAR SYSTEM VALIDATION .................................................................................................................... ２０ 10. SYSTEM VERIFICATION ....................................................................................................................... ２１ 11. RF CONDUCTED POWER MEASUREMENT ....................................................................................... ２３ 11.4 SAR Test Exclusions Applied ............................................................................................................ ３０ 12. SAR Test configuration & Antenna Information ................................................................................ ３１ 13. SAR TEST DATA SUMMARY ................................................................................................................ ３２ 13.1 Measurement Results (GSM850 Head SAR) ................................................................................ ３２ 13.2 Measurement Results (GSM1900 Head SAR) .............................................................................. ３３ 13.3 Measurement Results (WCDMA850 Head SAR) .......................................................................... ３４ 13.4 Measurement Results (WCDMA1900 Head SAR) ........................................................................ ３５ 13.5 Measurement Results (GSM850 Body-worn SAR) ....................................................................... ３６ 13.6 Measurement Results (GSM1900 Body-worn SAR) ..................................................................... ３７ 13.7 Measurement Results (WCDMA850 Body-worn SAR) ................................................................. ３８ 13.8 Measurement Results (WCDMA1900 Body-worn SAR) ............................................................... ３９ 14. SAR Measurement Variability and Uncertainty ................................................................................. ４０ 15. SAR Summation Scenario ................................................................................................................... ４１ 16. CONCLUSION ........................................................................................................................................ ４３ 17. REFERENCES ....................................................................................................................................... ４４ Attachment 1. – SAR Test Plots ................................................................................................................ ４５ Attachment 2. – Dipole Verification Plots................................................................................................. ６２ Attachment 3. – Probe Calibration Data ................................................................................................... ６７ Attachment 4. – Dipole Calibration Data .................................................................................................. ８０ Report No.: HCTA1307FS01 FCC ID: JYCP2050 Date of Issue: Jul. 23, 2013 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 6300 FAX: +82 31 645 6401 www.hct.co.kr 4 of 96 1. INTRODUCTION The FCC has adopted the guidelines for evaluating the environmental effects of radio frequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices. The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017. The measurement procedure described in IEEE/ANSI C95.3-1992 Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields - RF and Microwave is used for guidance in measuring SAR due to the RF radiation exposure from the Equipment Under Test (EUT). These criteria for SAR evaluation are similar to those recommended by the National Council on Radiation Protection and Measureme…
