JYCP2030Quad-band GSM/WCDMA Phone with BT

User Guide Thank you for choosing the Pantech P2030, our latest mobile phone. The Pantech P2030 has many features designed to enhance your mobile experience. From its EZ to read menus, to its sleek, stylish design, we know you will enjoy the entire P2030 experience. This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech P2030 has to offer. P2030 2 Specifications Design Clamshell phone with internal and external display Displays • 260K Colors TFT LCD with 2.2” internal display • 65K Colors TFT LCD with 1.38” external display • 7 lines for text in basic mode with 16 point font • Two soft keys and four-way scroll and selection @ keys Melodies MIDI, i-Melody, MP3, AMR, WAV, AAC, AAC+, WMA Camera Integrated 1.3M CMOS Camera • Resolution up to 1280 x 1024 (1.3M pixels) • Mpeg4 Video recording/playing up to 15f/s (QCIF size) • Self-timer function (5 seconds or 10 seconds) • Photo album and video album Dimensions & Weight Weight: 101 g (with standard battery) Dimensions: 99 mm x 50 mm x 18.65 mm 3 Power Management (Performance) Battery Type Capacity Standby Time Talk Time Standard Lithium-Ion (Li-ion) Up to 920mAh Up to 250 hours Up to 3 hours Operating Frequency • GSM 850Mhz, GSM 900Mhz, DCS 1800Mhz, and PCS 1900Mhz networks in North America, South America, Europe, Africa, and Asia-Pacific where these networks are supported. • Automatic band switching. 4 Specifications ................................................2 Phone overview ............................................8 Using Shortcuts ...........................................10 Menu overview ...........................................11 Quick & Easy ................................................14 SIM card and battery ...................................17 Turning the phone on/off ............................20 Essential display indications ........................20 Setting the phone mode .............................22 Entering text ...............................................23 EZ quick call keys .........................................26 PC Suite .......................................................26 Memory card ...............................................27 Breeze Mode 1. Calls and address book Making, receiving and ending a call .............32 Using video share ..........................................34 Options during a call .....................................36 Checking all calls ...........................................39 Speed dialing ................................................40 Using address book .......................................41 Using your headset .......................................44 Service and fixed dialing number .................44 2. Messaging Receiving messages ......................................48 Creating and sending text messages ............49 Creating multimedia messages ....................49 Managing messaging memory ....................54 Email ..............................................................55 Contents 5 3. Multimedia Camera ..........................................................58 Photo album .................................................63 Video album ..................................................64 4. Useful Features Calendar ........................................................68 Alarm clock ....................................................69 Pill Reminder .................................................69 User Guide ....................................................71 Calculator .......................................................71 Tip calculator .................................................71 Stop watch ....................................................72 Voice recognition ...........................................72 5. Connectivity Bluetooth ......................................................76 Using Mobile Web .........................................78 6. Settings Phone status ..................................................80 Sounds & alerts .............................................80 Display settings .............................................80 Memo ............................................................82 Advanced Mode 1. Calls and address book Making, receiving and ending a call .............84 Using video share ..........................................86 Options during a call .....................................88 Call settings ...................................................91 Settings for video share ................................91 Checking all calls ...........................................92 Speed dialing ................................................94 6 Using address book .......................................95 Using your headset .......................................97 Service and fixed dialing number .................98 Caller identification .......................................99 2. Messaging Receiving messages ....................................102 Creating and sending text messages ..........103 Creating multimedia messages ..................104 Message templates .....................................109 Message settings.........................................109 Managing messaging memory ..................111 Email ............................................................113 Using instant messenger ............................113 3. Multimedia Camera ........................................................116 Photo album ...............................................121 Video album ................................................123 Audio album ................................................125 Music player ................................................126 Music player settings ..................................131 Media player ................................................132 Other files ....................................................134 Managing memory ..................................…

Text truncated - open the document above for the full version.

Breeze Mode - Messaging 01 51 04 05 06 01 02 03 04 05 06 07 02 03 51 3. Press Insert > Video > Video. 4. Scroll to the saved video clip and press Select. 5. To preview the message, press Options > Preview > Current or Whole Message. To go back to text editor page, press Stop. 6. To edit the text message, press U/D to select the text box and edit your message. 7. Press Send to and select a contact to send the message and press Select. 8. Press Send. Adding a new video to the message 1. Press U or press Menu > Messaging > Create Message. 2. Enter a message. 3. Select Insert > Record New Video. 4. Focus on the object and press @ or Options > Record. 5. To stop and save the recording, press Stop. 6. To preview the message, press Options > Preview > Current or Whole Message. To go back to text editor page, press Stop. 7. To edit the text message, press U/D to select the text box and edit your 5252 message. 8. Press Send to and select a contact to send the message and press Select. 9. Press Send. For details on recording a video, see page 61. Adding a recorded voice memo to the message 1. Press U or press Menu > Messaging > Create Message. 2. Enter a message. 3. Select Insert > Sound > Audio > My Voice. 4. Scroll to the saved audio clip and press Select. 5. To preview the message, press Options > Preview > Current or Whole Message. 6. Press Pause to stop listening the voice memo or press Stop to go back to text editor page. 7. To edit the text message, press U/D to select the text box and edit your message. 8. Press Send to and select a contact to send the message and press Select. 9. Press Send. Breeze Mode - Messaging 01 53 04 05 06 01 02 03 04 05 06 07 02 03 53 Adding a new voice memo to the message 1. Press U or press Menu > Messaging > Create Message. 2. Enter a message. 3. Select Insert > Record New Sound. 4. Press Record to record the sound. 5. To stop and save the recording, press Stop. 6. To preview the message, press Options > Preview > Current or Whole Message. 7. Press Pause to stop listening the voice memo or press Stop to go back to text editor page. 8. To edit the text message, press U/D to select the text box and edit your message. 9. Press Send to and select a contact to send the message and press Select. 10. Press Send. For details on Recording a voice memo, see page 143. Adding other files to the message 1. Press U or press Menu > Messaging > Create Message. 2. Enter a message. 3. Select Insert > Other Files > Other Files. 4. Select a file and press Select. 5454 5. To preview the message, press Options > Preview > Current or Whole Message. To go back to text editor page, press Stop. 6. To edit the text message, press U/D to select the text box and edit your message. 7. Press Send to and select a contact to send the message and press Select. 8. Press Send. Managing messaging memory Up to 200 messages can be stored in the phone memory, additional messages will be saved to the SIM card. When the message box is full, the messages full icon will appear. All messages share memory. IconDescriptions Text message is full (SIM and phone messages). Deleting a message in the inbox 1. Select a message > Options > Delete > Yes. Deleting multiple messages in the inbox 1. Press Select or Deselect to select or deselect the message. 2. Press Delete > Yes. Breeze Mode - Messaging 01 55 04 05 06 01 02 03 04 05 06 07 02 03 55 Email You can receive emails from your service provider. Receiving an email 1. Press Menu > Messaging > Mobile Email. 2. Select an email > @ . 5656 Memo 3 Camera Photo album Video album Multimedia 5858 Camera You can take pictures and record movies using the built-in camera. The photos and video clips can be saved and sent via multimedia messages and Bluetooth. Zoom Picture remaining Brightness Self Timer Effect White Balance Size Brightness Self Timer Effect White Balance Size Video modeCamera mode note: When you set the photo size to 1280 x 1024, the zoom function is not available. Breeze Mode - Multimedia 01 59 02 05 06 01 02 03 04 05 06 07 03 04 59 Setting camera settings 1. PressQin standby mode or press Menu > Camera > Take a Picture. 2. Press Options to change settings prior to taking a picture. Camera options IconNameDescriptions White Balance Auto ( ), Day Light ( ), Tungsten ( ), Fluorescent ( ) Effect Normal ( ), Sepia ( ), Negative ( ), B&W ( ) Self Timer Off ( ), 5 secs ( ), 10 secs ( ) IconNameDescriptions Size 1280x1024 ( ), 1024x768 ( ), 640x480 ( ), 320x240 ( ), 240x320 ( ) Advanced Picture Quality, Save Location, Shutter Sound, Timer Sound Video camera options IconNameDescriptions White Balance Auto ( ), Day Light ( ), Tungsten ( ), Fluorescent ( ) 6060 IconNameDescriptions Effect Normal ( ), Sepia ( ), Negative ( ), B&W ( ) Self Timer Off ( ), 5 secs ( ), 10 secs ( ) Size 176x144(MMS) ( ), 176x144 ( ), 320x240 ( ), Video Share ( ) Advanced Video Quality, Sound Recording, Save Location, Timer Sound Zoom in and out 1. Press U/D. It ranges from 1 x to 4 x. Increasing or decreasing the brightness 1. Press L/R. It ranges from -2 to +2. Taking a picture 1. PressQin standby mode or press Menu > Camera > Take a Picture. 2. Focus on the object > @ or press Options > Capture. Changing to video camera mode 1. PressQin standby mode or press Menu > Camera > Take a Picture. 2. Press Options while camera mode is activated. 3. Press Video Camera Mode. Breeze Mode - Multimedia 01 61 02 05 06 01 02 03 04 05 06 07 03 04 61 4. Focus on the object > @ or press Options > Record. 5. Press Stop to stop recording. Viewing the taken picture 1. PressQin standby mode or press Menu > Camera > Take a Picture. 2. Press Options > Photo Album. 3. Select a picture > View. After taking pictures ToPress Send a multimedia message Options > Send > as Multimedia Message Send using mobile share Options > Send > via Mobile Share ToPress Send using Bluetooth Options > Send > via Bluetooth Set as wallpaper Options > Set as > Wallpaper Set as Caller ID Options > Set as > Caller ID DeleteOptions > D…

Text truncated - open the document above for the full version.

Pantech Co., Ltd. Date: Mar. 16, 2009 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. SunHee Kim of HCT Co., Ltd and hereafter referred to as HCT, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. SunHee Kim of HCT Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing HCT as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Byung-Wan Kim / Senior Vice President Pantech Co., Ltd.

Pantech Co., Ltd. Pantech Building, I-2, DMC, Sangam-dong, Mapo-gu, Seoul, Korea Date: March 15, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: JYCP2030 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Pantech Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Pantech Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Pantech Co., Ltd.

FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 9 EXTERNAL PHOTOGRAPHS FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ９ of 9 ■ EXTERNAL PHOTO

NOTE Th FCC L b l ill b i ibl t th ti f hNOTE : The FCC Label will be visible at the time of purchase

FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 8 INTERNAL PHOTOGRAPHS FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 8 ■ INTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 8 ■ INTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 8 ■ INTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 8 ■ INTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 8 ■ INTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 8 ■ INTERNAL PHOTO FCC ID: JYCP2030 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 8 ■ INTERNAL PHOTO

BT 안테나 Main 안테나 28 mm

APPROVAL SHEET Customer ： PANTECH Item ： Revere Description ： Inverted F Antenna Customer p/no ： Date ： 2011. 03.03 CUSTOMER’S APPROVED Rev No ; Cuit. Mech. Safety EMI Chkd Appd A p p r o v e d M7 SYSTEM EN’GR CHKD APPD Approval Date Approval No. DESC DONGNAM Co., Ltd. KRD01-00A10-01A 2 DongNam’s Approved Project Manager : Min Kyu KIM Document No. KAT-1103-IN017P Rev. No. IR Model Name KIN-DU2-PC1052 Date 2011. 03.03 Application System GSM850/GSM900/GSM1800/GSM1900 W850/W1900 Customer PANTECH Notice DONGNAM Co., Ltd. [R&D Center] Address : 102-103, Bucheon-technopark, 364, Samjung-Dong, Ojung-Gu, Bucheon-city, Kyounggi-Do, Korea Tel : +82-32-621-1666 / Fax : +82-32-621-1670 Investigation Verification Approval Approval No. Approval Date DONGNAM Co., Ltd. KRD01-00A10-01A 3 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR < CONTENTS > 1. Revision History 2. Electrical & Mechanical Specifications 3. Measurement Setup 3.1 Test Equipments 3.2 Test Equipments Setting 3.3 Calibration 4. Test Procedures 4.1 VSWR 4.2 Gain & Pattern 5. Measurement Data 5.1 VSWR 5.2 Gain & Pattern DONGNAM Co., Ltd. KRD01-00A10-01A 4 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 1. Revision History Rev No. Rev Date Des. Page History Drafter Remarks IR 2011. 03.03 DONGNAM Co., Ltd. KRD01-00A10-01A 5 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 2. Electrical And Mechanical Specifications Electrical Specifications Frequency Range 824 MHz ~ 894 MHz / 880 MHz ~ 960 MHz 1710 MHz ~ 1880 MHz / 1850 MHz ~ 1990 MHz V.S.W.R Folder Close EGSM900 ≤ 10.5 GSM850 ≤ 4.0 DCS1800 ≤ 6.5 PCS1900 ≤ 3.5 Folder open EGSM900 ≤ 9.5 GSM850 ≤ 5.0 DCS1800 ≤ 6.0 PCS1900 ≤ 4.0 Gain(Avg.) Folder Close EGSM900 ≥ -15.5 dBi GSM850 ≥ -13.0 dBi DCS1800 ≥ -13.0 dBi PCS1900 ≥ -6.0 dBi Folder open EGSM900 ≥ -13.5 dBi GSM850 ≥ -9.5 dBi DCS1800 ≥ -10.5 dBi PCS1900 ≥ -5.0 dBi Nominal Impedance 50 ohm Radiation Pattern Omni – Directional Polarization Linear Power Handling 3 watts (max) Matching Value Mechanical Specifications Dimensions 39.46X12.23X6.56mm Weight 1.05g Radiator STS304 / 0.15t Operating Temp -20 ~ 90 °C Operating Humidity 0 ~ 95 % DONGNAM Co., Ltd. KRD01-00A10-01A 6 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 3 Measurement Setup 3.1 Test Equipments Network Analyzer HP8753E Calibration Kit HP85033E Adaptor SMA Type Female ↔ SMA male 3.2 Test Equipments Setting Split display On Sweep setup Number of points : 401 Test port power 0 dBm Measure Channel 1 : S11 3.3 Calibration Calibration Cal. Kit : 3.5mmD/E Calibration menu → S11 1-Port Open → Short → Load Done DONGNAM Co., Ltd. KRD01-00A10-01A 7 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 4. Test Procedures 4.1 VSWR. Step 1. Connect ANT port with cable included adaptor to port1 of Network analyzer. Step 2. Point out markers on network analyzer display at Step 3. Measurement Inspect VSWR Step 1. Network analyzer에 측정 Cable이 달린 시료를 연결한다. Step 2. Network analyzer에 측정하고자 하는 주파수를 display하도록 marker 한다 Step 3.정재파 비(VSWR)를 측정한다 DONGNAM Co., Ltd. KRD01-00A10-01A 8 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 4.2 Radiation pattern and Gain Step 1. Calibrate chamber system for gain measurement using horn antenna. At the same time set up software program for chamber system control. Step 2. Change over from a horn antenna to measuring antenna on target positioner. Step 3. Start a software program for chamber system control & measuring Step 1. Horn 안테나를 이용하여 Chamber system를 Calibration함과 동시에 Chamber system을 Control 하기 위한 software를 setup한다. Step 2. Horn 안테나를 측정할 안테나로 교체한다. Step 3. Gain과 효율을 측정한다. NETWORK ANALYZER MOTION CONTROLLER COMPUTER DONGNAM Co., Ltd. KRD01-00A10-01A 9 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 5. Measurement Data Items Spec Test Result (#1) Frequency 824 MHz ~ 894 MHz / 880 MHz ~ 960 MHz 1710 MHz ~ 1880 MHz / 1850 MHz ~ 1990 MHz O.K V.S.W.R Folder Close EGSM900 ≤ 10.5 O.K GSM850 ≤ 4.0 O.K DCS1800 ≤ 6.5 O.K PCS1900 ≤ 3.5 O.K Folder open EGSM900 ≤ 9.5 O.K GSM850 ≤ 5.0 O.K DCS1800 ≤ 6.0 O.K PCS1900 ≤ 4.0 O.K Gain(Avg.) Folder Close EGSM900 ≥ -15.5 dBi O.K GSM850 ≥ -13.0 dBi O.K DCS1800 ≥ -13.0 dBi O.K PCS1900 ≥ -6.0 dBi O.K Folder open EGSM900 ≥ -13.5 dBi O.K GSM850 ≥ -9.5 dBi O.K DCS1800 ≥ -10.5 dBi O.K PCS1900 ≥ -5.0 dBi O.K Polarization Linear Linear Model Name KIN-DU2-PC1052 Written by Min Kyu KIM Authorized by YOUNGCHUN AHN Instrument Network Analyzer: 8753ES (HP) Subject Inverted F Antenna Frequency 824 MHz ~ 894 MHz / 880 MHz ~ 960 MHz 1710 MHz ~ 1880 MHz / 1850 MHz ~ 1990 MHz DONGNAM Co., Ltd. KRD01-00A10-01A 10 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 5.1 SWR Folder Close Folder Open DONGNAM Co., Ltd. KRD01-00A10-01A 11 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR 5.2 Gain & Pattern Folder Close EGSM900 DONGNAM Co., Ltd. KRD01-00A10-01A 12 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR GSM850 DONGNAM Co., Ltd. KRD01-00A10-01A 13 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR DCS1800 DONGNAM Co., Ltd. KRD01-00A10-01A 14 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR PCS1900 DONGNAM Co., Ltd. KRD01-00A10-01A 15 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR Folder Open EGSM900 DONGNAM Co., Ltd. KRD01-00A10-01A 16 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR GSM850 DONGNAM Co., Ltd. KRD01-00A10-01A 17 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR DCS1800 DONGNAM Co., Ltd. KRD01-00A10-01A 18 Document No. KAT-1103-IN017P Model Name KIN-DU2-PC1052 Rev. No. IR PCS1900

SAR TEST REPORT HCT CO., LTD EUT Type: Quad-band GSM/WCDMA Phone with BT GPRS Class10 and GPRS mode class B(GPRS and GSM, but not simultaneously) FCC ID: JYCP2030 Model: P2030 Date of Issue: Mar. 4, 2011 Test report No.: HCTA1103FS03 Test Laboratory: HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8565 FAX: +82 31 639 8525 Applicant : Pantech Co., Ltd. Pantech Building, I-2, DMC, Sangam-dong, Mapo-gu,Seoul, Korea(ZIP :121-792) Tel: 82-2-2030-1319 Fax: 82-2-2030-2500 Testing has been carried out in accordance with: RSS-102 Issue 4; Health Canada Safety Code 6 47CFR §2.1093 FCC OET Bulletin 65(Edition 97-01), Supplement C (Edition 01-01) ANSI/ IEEE C95.1 – 2005 IEEE 1528-2003 Test result: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Signature Report prepared by Approved by : Young-Soo Jang : Jae-Sang So Test Engineer of SAR Part Manager of SAR Part Report No.: HCTA1103FS03 FCC ID: JYCP2030 Date of Issue: Mar. 4, 2011 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8565 FAX : +82 31 639 8525 www.hct.co.kr 2 of 116 Table of Contents 1. INTRODUCTION .........................................................................................................................３ 2. DESCRIPTION OF DEVICE........................................................................................................４ 3. DESCRIPTION OF TEST EQUIPMENT......................................................................................５ 4. SAR MEASUREMENT PROCEDURE.....................................................................................１２ 5. DESCRIPTION OF TEST POSITION......................................................................................１３ 5.1 HEAD POSITION .....................................................................................................................１３ 5.2 Body Holster/Belt Clip Configurations ........................................................................................１４ 6. MEASUREMENT UNCERTAINTY...........................................................................................１５ 7. ANSI/ IEEE C95.1 - 2005 RF EXPOSURE LIMITS.................................................................１６ 8. SYSTEM VERIFICATION........................................................................................................１７ 8.1 Tissue Verification ....................................................................................................................１７ 8.2 System Validation .....................................................................................................................１７ 9. RF CONDUCTED POWER......................................................................................................１８ 9.1 Procedures Used to Establish RF Signal for SAR ......................................................................１８ 9.2 SAR Measurement Conditions for UMTS ...................................................................................１８ 10. SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas.......２０ 11. SAR TEST DATA SUMMARY.................................................................................................２１ 11.1 Measurement Results (GSM850 Head SAR) ...........................................................................２１ 11.2 Measurement Results (GSM1900 Head SAR) ..........................................................................２２ 11.3 Measurement Results (WCDMA850 Head SAR) ......................................................................２３ 11.4 Measurement Results (WCDMA1900 Head SAR) ....................................................................２４ 11.5 Measurement Results (GSM850 Body SAR) ............................................................................２５ 11.6 Measurement Results (GSM1900 Body SAR) ..........................................................................２６ 11.7 Measurement Results (WCDMA850 Body SAR) ......................................................................２７ 11.8 Measurement Results (WCDMA1900 Body SAR) .................................................................…

Text truncated - open the document above for the full version.
