JYCP5000GSM/WCDMA Phone with Bluetooth

Thank you for choosing the Pantech P5000. The Pantech P5000 has many features designed to enhance your mobile experience. From its unique, stylish design and QWERTY keypad, we know you will enjoy the entire P5000 experience. This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech P5000 has to offer. User Guide 2 Specifications Design QWERTY bar Displays • 262k colors TFT LCD with 2.4” display • 320*240 resolution • 5 lines for text in basic mode with 16-point font • Two soft keys and four-way scroll and pressingO Melodies .mp3, .midi, .mid, .iMelody, .wav, .mmf, .wma, .3gpa Camera Integrated 2M CMOS Camera • Resolution up to 1600 x 1200(1,920,000 pixels) • Mpeg4 Video recording/playing up to 15f/s (QVGA size) • Self-timer function (5 seconds or 10 seconds) • Photo album and video album Dimensions & Weight • Weight: TBD (with standard battery) • Dimensions: 115.9 mm x 61 mm x 9.95 mm 3 Power Management (Performance) Battery TypeCapacityStandby TimeTalk Time Standard Lithium-Ion (Li-ion) 1000 mAh Minimum 10 days (250 hrs) Minimum 3 hrs Operating Frequency • GSM 850Mhz, GSM 900Mhz, GSM 1800Mhz, GSM 1900Mhz, UMTS 850Mhz and UMTS 1900Mhz networks in North America, South America, Europe, Africa, and Asia-Pacific where these networks are supported. • Automatic band switching. Receiver Display Left/Right Soft key Perform the functions shown at the bottom line of the display. Clear key Return to previous screen or delete characters in text mode. Power on&off / Menu exit key / End key Turn phone on/off, end calls, exit menus. Delete key Press to delete a number or letter. Enter key Press to move to the next row. Space key Press to enter a space. Navigation Up: Write New SMS Down: Contact Left: Mobile Email Right: IM Center: OK / Web Speaker Phone Key Send Key CAPS/Shift key To type a single uppercase letter, press this key then a letter. Function key To enter a number or a symbol, press the function key, and press the corresponding key. Phone overview 4 Left Side key Volume up and down Charger slot / Ear mic Camera Camera key Internal antenna area Speaker 5 note: Holding the device by the internal antenna area might affect the quality of all calls. 6 Using shortcuts Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Menu mode, Main Menus can be accessed by pressing the number keys (1 to 0, *, #) corresponding to their location on the screen. Example: Accessing the Language menu. 1. Press Menu. 2. Press the#for Settings. 3. Press the4for Phone. 4. Press the1for Language. 5. Press Select for Screen Text. 6. Press the U or D scroll key to display the list of available languages. 1 Messaging 2 Mobile Email 3 IM 4 Web 5 Address Book 6 AppCenter 7 App Manager 8 AT&T GPS 9 YPmobile 9 My Stuff * AT&T Music # Settings 7 Menu overview Messaging Conversations Create Message Mobile Email IM Outbox Drafts Voice Mail Settings Templates Used Space Mobile EmailIM Web Address Book Contacts Groups Favorites Yellow Pages Settings Fixed Dial Numbers My Phone Number Service Numbers AppCenter 8 App Manager AT&T GPS AT&T Navigator Where AllSport GPS Maps AT&T Family Map YPmobile My Stuff Applications Audio Games Online Locker Picture Video Tools Other Files Used Space AT&T Music Music Player Shop Music AT&T Radio Settings Profiles Display Call Phone Network Connections Connectivity Security S AT&T Software Update Reset TTY Phone Information S SIM dependent N Network dependent 9 Quick & Easy KeysFunctions <> Performs the functions shown at the bottom line of the display by using these soft keys. Scroll through the menu options in Menu mode. In standby mode, Left: Access Mobile Email menu Right: Access IM menu Up: Access Create Message menu Down: Access Contacts menu Works in Word search mode if pressed in the Predictive text input mode. O Select a menu function or store user-input information, such as names. Also use this key for confirmation. Launches the Web directly if pressed in standby mode. N Turns on the speaker mode. C Deletes characters from the display, or return to previous menu. S Sends or receives a call. Shows the recent call list in standby mode. E Completes the current call. Turns on/off the phone if pressed and held. Cancels user input and return to main screen while in Menu mode. 1 Quickly connects to the voice mail server if pressed and held in standby mode. 0~9 Enters numbers, letters or special characters. Goes to the dial screen if pressed in standby mode. B Enters or exits from vibrate mode if pressed and held in standby mode. 10 KeysFunctions q Enters an international dialing prefix if pressed and held in standby mode. m Changes various text input modes if pressed at the text-editing screen. l Locks the keypad. Displays special characters that are not placed on the keypad. Adjusts the earpiece volume while making a call. Controls the Ringtone volume, vibrate mode and silent all mode in standby. Mutes the ringtone of an incoming call. Q Turns camera capture mode on. Works as a camera shutter in capture mode. 11 Specifications ......................................................2 Phone overview ...................................................4 Using shortcuts ...................................................6 Menu overview .....................................................7 Quick & Easy ..........................................................9 1. Getting Started SIM card and battery .......................................16 Turning the phone on/off .............................18 Keypad unlock ....................................................18 Essential display indications ........................19 Memory card .....................................................20 Assigning the menu .......................................22 Updating software ..........................................22 Using the QWERTY keypad .........................23 Using the Multi…

Text truncated - open the document above for the full version.

Pantech Co., Ltd. Date: Mar. 16, 2009 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. SunHee Kim of HCT Co., Ltd and hereafter referred to as HCT, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. SunHee Kim of HCT Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing HCT as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Byung-Wan Kim / Senior Vice President Pantech Co., Ltd.

Pantech Co., Ltd. Pantech Building, I-2, DMC, Sangam-dong, Mapo-gu, Seoul, Korea Date: August 2, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: JYCP5000 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Pantech Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Pantech Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Pantech Co., Ltd.

FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO

FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 10 INTERNAL PHOTOGRAPHS FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 10 ■ INTERNAL PHOTO FCC ID: JYCP5000 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １０ of 10 ■ INTERNAL PHOTO

APPROVAL SHEET Customer ： PANTECH Item ： Link2 Description ： Inverted F Antenna Customer p/no ： Date ： 2011. 03.30 CUSTOMER’S APPROVED Rev No ; Cuit. Mech. Safety EMI Chkd Appd A p p r o v e d Pantech EN’GR CHKD APPD Approval Date Approval No. DESC DONGNAM Co., Ltd. KRD01-00A10-01A 2 DongNam’s Approved Project Manager : Keun Sung Jang Document No. KAT-1103-IN018P Rev. No. IR Model Name KIN-QU4-PC1056 Date 2011. 03.30 Application System GSM850/GSM900/GSM1800/GSM1900 W850/W1900 Customer PANTECH Notice DONGNAM Co., Ltd. [R&D Center] Address : 102-103, Bucheon-technopark, 364, Samjung-Dong, Ojung-Gu, Bucheon-city, Kyounggi-Do, Korea Tel : +82-32-621-1666 / Fax : +82-32-621-1670 Investigation Verification Approval Approval No. Approval Date DONGNAM Co., Ltd. KRD01-00A10-01A 3 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR < CONTENTS > 1. Revision History 2. Electrical & Mechanical Specifications 3. Measurement Setup 3.1 Test Equipments 3.2 Test Equipments Setting 3.3 Calibration 4. Test Procedures 4.1 VSWR 4.2 Gain & Pattern 5. Measurement Data 5.1 VSWR 5.2 Gain & Pattern DONGNAM Co., Ltd. KRD01-00A10-01A 4 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 1. Revision History Rev No. Rev Date Des. Page History Drafter Remarks IR 2011. 03.30 DONGNAM Co., Ltd. KRD01-00A10-01A 5 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 2. Electrical And Mechanical Specifications Electrical Specifications Frequency Range 824 MHz ~ 894 MHz / 880 MHz ~ 960 MHz 1710 MHz ~ 1880 MHz / 1850 MHz ~ 1990 MHz V.S.W.R EGSM900 ≤ 14.0 GSM850 ≤ 5.5 DCS1800 ≤ 10.5 PCS1900 ≤ 3.5 Gain(Avg.) EGSM900 ≥ -13.0 dBi GSM850 ≥ -8.5 dBi DCS1800 ≥ -12.5 dBi PCS1900 ≥ -7.5 dBi Nominal Impedance 50 ohm Radiation Pattern Omni – Directional Polarization Linear Power Handling 3 watts (max) Matching Value Mechanical Specifications Dimensions 47.70X12.10X5.20mm Weight 1.10g Radiator STS304 / 0.15t Operating Temp -20 ~ 90 °C Operating Humidity 0 ~ 95 % DONGNAM Co., Ltd. KRD01-00A10-01A 6 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 3 Measurement Setup 3.1 Test Equipments Network Analyzer HP8753E Calibration Kit HP85033E Adaptor SMA Type Female ↔ SMA male 3.2 Test Equipments Setting Split display On Sweep setup Number of points : 401 Test port power 0 dBm Measure Channel 1 : S11 3.3 Calibration Calibration Cal. Kit : 3.5mmD/E Calibration menu → S11 1-Port Open → Short → Load Done DONGNAM Co., Ltd. KRD01-00A10-01A 7 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 4. Test Procedures 4.1 VSWR. Step 1. Connect ANT port with cable included adaptor to port1 of Network analyzer. Step 2. Point out markers on network analyzer display at Step 3. Measurement Inspect VSWR DONGNAM Co., Ltd. KRD01-00A10-01A 8 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 4.2 Radiation pattern and Gain Step 1. Calibrate chamber system for gain measurement using horn antenna. At the same time set up software program for chamber system control. Step 2. Change over from a horn antenna to measuring antenna on target positioner. Step 3. Start a software program for chamber system control & measuring NETWORK ANALYZER MOTION CONTROLLER COMPUTER DONGNAM Co., Ltd. KRD01-00A10-01A 9 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 5. Measurement Data Items Spec Test Result (#1) Frequency 824 MHz ~ 894 MHz / 880 MHz ~ 960 MHz 1710 MHz ~ 1880 MHz / 1850 MHz ~ 1990 MHz O.K V.S.W.R EGSM900 ≤ 14.0 O.K GSM850 ≤ 5.5 O.K DCS1800 ≤ 10.5 O.K PCS1900 ≤ 3.5 O.K Gain(Avg.) EGSM900 ≥ -13.0 dBi O.K GSM850 ≥ -8.5 dBi O.K DCS1800 ≥ -12.5 dBi O.K PCS1900 ≥ -7.5 dBi O.K Polarization Linear Linear Model Name KIN-QU4-PC1056 Written by Keun Sung Jang Authorized by YOUNGCHUN AHN Instrument Network Analyzer: 8753ES (HP) Subject Inverted F Antenna Frequency 824 MHz ~ 894 MHz / 880 MHz ~ 960 MHz 1710 MHz ~ 1880 MHz / 1850 MHz ~ 1990 MHz DONGNAM Co., Ltd. KRD01-00A10-01A 10 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 5.1 SWR DONGNAM Co., Ltd. KRD01-00A10-01A 11 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR 5.2 Gain & Pattern GSM850 VerHorTotalVerHorTotal -19.2 dBi-7.2 dBi-6.9 dBi-10.2 dBi-3.6 dBi-3.0 dBi -18.1 dBi-5.9 dBi-5.6 dBi-9.4 dBi-2.3 dBi-1.7 dBi -16.6 dBi-4.4 dBi-4.2 dBi-9.1 dBi-1.0 dBi-1.0 dBi -16.3 dBi-4.3 dBi-4.0 dBi-5.3 dBi-1.0 dBi-1.0 dBi -17.0 dBi-4.5 dBi-4.3 dBi-7.1 dBi-1.5 dBi-1.5 dBi -17.9 dBi-5.4 dBi-5.2 dBi-5.2 dBi-2.6 dBi-1.3 dBi 3.90 dB 3.23 dB 3.03 dB 2.82 dB 3.86 dB Theta90/Pie345 Theta90/Pie345 Theta75/Pie0 27.4 % 38.2 % 20.3 % Max Gain Theta90/Pie0 Theta90/Pie345 39.9 % 37.1 % 30.2 %894.000000 MHz 838.000000 MHz 852.000000 MHz 866.000000 MHz 824.000000 MHz 880.000000 MHz Theta90/Pie03.96 dB Frequency EfficiencyDirectivityMax Position Average Gain DONGNAM Co., Ltd. KRD01-00A10-01A 12 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR EGSM900 VerHorTotalVerHorTotal -17.0 dBi-4.5 dBi-4.3 dBi-7.1 dBi-1.5 dBi-1.5 dBi -17.9 dBi-5.4 dBi-5.2 dBi-5.2 dBi-2.6 dBi-1.3 dBi -19.8 dBi-7.2 dBi-7.0 dBi-7.8 dBi-4.2 dBi-3.4 dBi -21.8 dBi-8.6 dBi-8.4 dBi-10.1 dBi-5.2 dBi-5.0 dBi -23.2 dBi-9.6 dBi-9.4 dBi-12.2 dBi-5.8 dBi-5.7 dBi -25.3 dBi-11.6 dBi-11.4 dBi-15.1 dBi-7.9 dBi-7.8 dBi 3.72 dB 3.66 dB 2.82 dB 3.86 dB 3.57 dB 3.40 dB Theta90/Pie330 Theta90/Pie345 Theta75/Pie0 Theta75/Pie0 Theta90/Pie120 Theta90/Pie120 Max Gain 37.1 % 30.2 % 20.0 % 14.4 % 11.6 % 7.2 % 894.000000 MHz 912.000000 MHz 928.000000 MHz 944.000000 MHz 960.000000 MHz 880.000000 MHz Frequency EfficiencyDirectivityMax Position Average Gain DONGNAM Co., Ltd. KRD01-00A10-01A 13 Document No. KAT-1103-IN018P Model Name KIN-QU4-PC1056 Rev. No. IR DCS1800 VerHorTotalVerHorTotal -14.7 dBi-13.6 dBi-11.1 dBi-3.6 dBi-3.6 dBi-2.6 dBi -12.7 dBi-11.5 dBi-9.1 dBi-1.4 dBi-1.4 dBi-1.4 dBi -11.5 dBi-9.9 dBi-7.6 dBi-0.3 dBi-0.4 dBi-0.1 dBi -10.2 dBi-8.5 dBi-6.3 dBi0.5 dBi0.5 dBi1.1 dBi -10.3 dBi-8.3 dBi-6.2 dBi-0.7 dBi-0.7 dBi0.0 dBi -8.8 dBi-7.5 dBi-5.1 dBi0.8 d…

Text truncated - open the document above for the full version.

BT 안테나 Main 안테나 GPS 안테나 100 mm

SAR TEST REPORT HCT CO., LTD EUT Type: GSM/WCDMA Phone with Bluetooth GPRS Class10 and GPRS mode class B(GPRS and GSM, but not simultaneously) FCC ID: JYCP5000 Model: P5000 Date of Issue: Mar. 30, 2011 Test report No.: HCTA1103FS08 Test Laboratory: HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL: +82 31 639 8565 FAX: +82 31 639 8525 Applicant : Pantech Co., Ltd. Pantech Building, I-2, DMC, Sangam-dong, Mapo-gu,Seoul, Korea(ZIP :121-792) Tel: 82-2-2030-1319 Fax: 82-2-2030-2500 Testing has been carried out in accordance with: RSS-102 Issue 4; Health Canada Safety Code 6 47CFR §2.1093 FCC OET Bulletin 65(Edition 97-01), Supplement C (Edition 01-01) ANSI/ IEEE C95.1 – 2005 IEEE 1528-2003 Test result: The tested device complies with the requirements in respect of all parameters subject to the test. The test results and statements relate only to the items tested. The test report shall not be reproduced except in full, without written approval of the laboratory. Signature Report prepared by Approved by : Young-Soo Jang : Jae-Sang So Test Engineer of SAR Part Manager of SAR Part Report No.: HCTA1103FS08 FCC ID: JYCP5000 Date of Issue: Mar. 30, 2011 HCT CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8565 FAX : +82 31 639 8525 www.hct.co.kr 2 of 109 Table of Contents 1. INTRODUCTION .........................................................................................................................３ 2. DESCRIPTION OF DEVICE........................................................................................................４ 3. DESCRIPTION OF TEST EQUIPMENT......................................................................................５ 3.1 SAR MEASUREMENT SETUP ....................................................................................................５ 3.3 PROBE CALIBRATION PROCESS ..............................................................................................７ 3.4 SAM Phantom .............................................................................................................................９ 3.5 Device Holder for Transmitters .....................................................................................................９ 3.6 Brain & Muscle Simulating Mixture Characterization ..................................................................１０ 3.7 SAR TEST EQUIPMENT ..........................................................................................................１１ 4. SAR MEASUREMENT PROCEDURE.....................................................................................１２ 5. DESCRIPTION OF TEST POSITION......................................................................................１３ 5.1 HEAD POSITION .....................................................................................................................１３ 5.2 Body Holster/Belt Clip Configurations ........................................................................................１４ 6. MEASUREMENT UNCERTAINTY...........................................................................................１５ 7. ANSI/ IEEE C95.1 - 2005 RF EXPOSURE LIMITS.................................................................１６ 8. SYSTEM VERIFICATION........................................................................................................１７ 8.1 Tissue Verification ....................................................................................................................１７ 8.2 System Validation .....................................................................................................................１７ 9. RF CONDUCTED POWER......................................................................................................１８ 9.1 Procedures Used to Establish RF Signal for SAR ......................................................................１８ 9.2 SAR Measurement Conditions for UMTS ...................................................................................１８ 10. SAR Evaluation Considerations for Handsets with Multiple Transmitters and Antennas.......２０ 11. SAR TEST DATA SUMMARY.................................................................................................２１ 11.1 Measurement Results (GSM850 Head SAR) ...........................................................................２１ 11.2 Measurement Results (GSM1900 Head SAR) ..........................................................................２２ 11.3 Measurement Results (WCDMA850 Head SAR) ......................................................................２３ 11.4 Measurement Results (WCDMA1900 Head SAR) ....................................................................２４ 11.5 Measurement Results (GSM850 Body SAR) ............................................................................２５ 11.6 Measurement Results (GSM1900 Body SAR) ..........................................................................２６ 11.7 Measurement Results (WCDMA850 Body SAR) ......................................................................２７ 11.8 Measurement Results (WCDMA1900 Body SAR) ....................................................................２８ 12. CONCLUSION.......................................................................................................................２９ 13. REFERENCES......................................................................................................................３０ Attachment 1. – SAR Test Plots ...................................................................................................３１ Attachment 2. – Dipole Validation Plots.......................................................................................... 6 8 Attachment 3. – Probe Calibration Data.......................................................................................７７ Attachment 4. – Dipole Calibration Data .........................................…

Text truncated - open the document above for the full version.

Report No.: HCTA1105FM02 FCC ID: JYCP5000Date of Issue: May 30, 2011 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 64851 FAX: +82 31 645 6401 www.hct.co.kr 1 of 25 APPENDIX A. HAC TEST PLOTS Report No.: HCTA1105FM02 FCC ID: JYCP5000Date of Issue: May 30, 2011 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 64851 FAX: +82 31 645 6401 www.hct.co.kr 2 of 25 Test Laboratory: HCT CO., LTD. Ambient Temperature / Channel 21.3 °C /128 Test Date May 27, 2011 DUT: P5000; Type: Bar; Serial: #1 Communication System: GSM 850; Frequency: 824.2 MHz;Duty Cycle: 1:8.3 Medium parameters used: σ = 0 mho/m, ε r = 1; ρ = 1000 kg/m 3 Phantom section: E Dipole Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ER3DV6R - SN2242; ConvF(1, 1, 1); Calibrated: 2010-09-20 - Sensor-Surface: (Fix Surface) - Electronics: DAE4 Sn869; Calibrated: 2010-09-21 - Phantom: HAC Test Arch; Type: SD HAC P01 BA E Scan - ER3D - 2007: 15 mm from Probe Center to the Device/Hearing Aid Compatibility Test (101x101x1): Measurement grid: dx=5mm, dy=5mm Maximum value of peak Total field = 103.8 V/m Probe Modulation Factor = 2.68 Device Reference Point: 0.000, 0.000, 354.7 mm Reference Value = 50.8 V/m; Power Drift = -0.032 dB Hearing Aid Near-Field Category: M4 (AWF -5 dB) Peak E-field in V/m Grid 1 102.3 M4 Grid 2 103.7 M4 Grid 3 96.9 M4 Grid 4 101.6 M4 Grid 5 103.8 M4 Grid 6 97.3 M4 Grid 7 94.6 M4 Grid 8 96.9 M4 Grid 9 91.4 M4 Cursor: Total = 103.8 V/m E Category: M4 Location: 1.5, -6.5, 370.9 mm 0 dB = 103.8V/m Report No.: HCTA1105FM02 FCC ID: JYCP5000Date of Issue: May 30, 2011 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 64851 FAX: +82 31 645 6401 www.hct.co.kr 3 of 25 Test Laboratory: HCT CO., LTD. Ambient Temperature / Channel 21.3 °C /190 Test Date May 27, 2011 DUT: P5000; Type: Bar; Serial: #1 Communication System: GSM 850; Frequency: 836.6 MHz;Duty Cycle: 1:8.3 Medium parameters used: σ = 0 mho/m, ε r = 1; ρ = 1000 kg/m 3 Phantom section: E Dipole Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ER3DV6R - SN2242; ConvF(1, 1, 1); Calibrated: 2010-09-20 - Sensor-Surface: (Fix Surface) - Electronics: DAE4 Sn869; Calibrated: 2010-09-21 - Phantom: HAC Test Arch; Type: SD HAC P01 BA E Scan - ER3D - 2007: 15 mm from Probe Center to the Device/Hearing Aid Compatibility Test (101x101x1): Measurement grid: dx=5mm, dy=5mm Maximum value of peak Total field = 99.0 V/m Probe Modulation Factor = 2.68 Device Reference Point: 0.000, 0.000, 354.7 mm Reference Value = 47.9 V/m; Power Drift = -0.017 dB Hearing Aid Near-Field Category: M4 (AWF -5 dB) Peak E-field in V/m Grid 1 98.0 M4 Grid 2 99.0 M4 Grid 3 93.4 M4 Grid 4 96.0 M4 Grid 5 98.9 M4 Grid 6 93.6 M4 Grid 7 87.2 M4 Grid 8 90.7 M4 Grid 9 86.9 M4 Cursor: Total = 99.0 V/m E Category: M4 Location: 1.5, -11, 370.9 mm 0 dB = 99.0V/m Report No.: HCTA1105FM02 FCC ID: JYCP5000Date of Issue: May 30, 2011 HCT CO., LTD. 105-1, Jangam-ri, Majang-myeon, Icheon-si,Gyeonggi-do,Korea 467-811 TEL: +82 31 645 64851 FAX: +82 31 645 6401 www.hct.co.kr 4 of 25 Test Laboratory: HCT CO., LTD. Ambient Temperature / Channel 21.3 °C /251 Test Date May 27, 2011 DUT: P5000; Type: Bar; Serial: #1 Communication System: GSM 850; Frequency: 848.8 MHz;Duty Cycle: 1:8.3 Medium parameters used: σ = 0 mho/m, ε r = 1; ρ = 1000 kg/m 3 Phantom section: E Dipole Section ; Measurement SW: DASY4, V4.7 Build 71; Postprocessing SW: SEMCAD, V1.8 Build 184 DASY4 Configuration: - Probe: ER3DV6R - SN2242; ConvF(1, 1, 1); Calibrated: 2010-09 -20 - Sensor-Surface: (Fix Surface) - Electronics: DAE4 Sn869; Calibrated: 2010-09-21 - Phantom: HAC Test Arch; Type: SD HAC P01 BA E Scan - ER3D - 2007: 15 mm from Probe Center to the Device/Hearing Aid Compatibility Test (101x101x1): Measurement grid: dx=5mm, dy=5mm Maximum value of peak Total field = 94.2 V/m Probe Modulation Factor = 2.68 Device Reference Point: 0.000, 0.000, 354.7 mm Reference Value = 45.5 V/m; Power Drift = 0.006 dB Hearing Aid Near-Field Category: M4 (AWF -5 dB) Pea…

Text truncated - open the document above for the full version.
