JYCP6020GSM/WCDMA Phone with Bluetooth

User Guide for P6020 Thank you for choosing the Pantech P6020. The Pantech P6020 has many features designed to enhance your mobile experience. With its unique, stylish design and QWERTY keypad, you will enjoy the entire P6020 experience. This User Guide contains important and useful information that will maximize your familiarity with all that the Pantech P6020 has to offer. P6020 2 Some of the contents in this manual may differ from your phone depending on the software of the phone. Actual color may vary. Y our phone is designed to make it easy for you to access a wide variety of content. For your protection, we want you to be aware that some applications that you enable may involve the location of your phone being shared. For applications available through AT&T, we offer privacy controls that let you decide how an application may use the location of your phone and other phones on your account. However, the AT&T privacy tools do not apply to applications available outside of AT&T. Please review the terms and conditions and the associated privacy policy for each location-based service to learn how location information will be used and protected. In addition, your AT&T phone may be used to access the internet and to download, and/or purchase goods, applications, and services from AT&T or elsewhere from third parties. AT&T provides tools for you to control access to the Internet and certain Internet content. These controls may not be available for certain devices which bypass AT&T controls. Service provided by AT&T Mobility. Portions © 2011 AT&T Intellectual Property. All rights reserved. AT&T, the AT&T logo and all other AT&T marks contained herein are trademarks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks contained herein are the property of their respective owners. Copyright © 2011. Pantech. All Rights Reserved. 3 Important Safety Information Specifications Design Touch QWERTY Slider Displays x260k colors TFT with 2.8” display x240*320 (QVGA) pixels in resolution Melodies MP3, AAC, AAC+, eAAC+ and WMA. Camera Integrated 2M CMOS Camera xResolution up to 1600 x 1200 (1,920,000 pixels) xMpeg4 Video recording/playing up to 15f/s(QVGA size) xSelf-timer function (Off, 3, 5 or 10 seconds) xPicture album and video album Dimensions & Weight xWeight: 117g/4.14oz. (with standard battery) xDimensions: 109 x 56.6 x 14.8mm 4.29" x 2.22" X 0.58" Power Management (Performance) Battery TypeCapacityStandby TimeTalk Time Standard Lithium-Ion (Li-ion) 1000 mAh Up to 250 hours Up to 3 hours Operating Frequency x GSM/GPRS/EDGE 850/900/1800/1900 MHz, UMTS/HSDPA 850/1900 MHz networks in North America, South America, Europe, Africa, and Asia-Pacific where these networks are supported. xAutomatic band switching. 4 Important Safety Information Phone overview Touch mode view Earpiece Home/END Key Canceling current operation and move to idle screen. End the current call Proximity sensor Microphone Camera Side Up/Down Key Adjust the earpiece volume. Launch the Multitasking. Charging / Data jack Power/Lock Key Turn the phone on/off. Headset Jack Speaker Internal antenna area 5 Important Safety Information KeysFunctions Turn on/off the phone if pressed and held. Lock the touch screen. Canceling current operation and move to idle screen. End the current call Adjust the earpiece volume while making a call. Adjust ringtone volume, and control vibrate or standby mode. Mute the ringtone of an incoming call. Launch the Multitasking. Note If you use metal accessories (stickers) on the phone or hold the device by the internal antenna area while exchanging data or talking on the phone, sound quality may be affected. CorrectIncorrect 6 Important Safety Information QWERTY keypad CAPS key Enter capital letters Vibrate key Function key Enter numbers or symbols Space key Insert a space Note To use the QWERTY keypad hold the phone horizontally and slide the screen up. Delete key Delete a character/symbol Enter key Move to the next row Symbol key Enter a special symbol 7 Important Safety Information Your phone has a QWERTY keypad which provides a superior typing experience on a small handheld device for easy and comfortable texting. You can use all of the phone functions with the QWERTY keypad. KeysFunctions ! Press to change Abc ABC abc modes on the text editing screen , , (first letter caps/all caps/lowercase). To enter symbols and numbers continually, press until is displayed.  Press to enter a space in text input mode. % Move to the next row in text input mode. $ Delete a character to the left of the text cursor in the text editing screen.  Press to enter a special character that is not on the keypad. Quickly connect to the voice mail server if pressed and held while in standby mode. ~ Enter numbers, letters or special characters. Go to the dial screen if pressed in standby mode. + Activate or deactivate vibrate mode if pressed and held in standby mode. , Enter an international dialing prefix if pressed in standby mode. 8 Important Safety Information Address Book Contacts Groups Favorites Local Search My Settings Fixed Dial Numbers My Phone Number Service Numbers RKDDADFGAFGA ADFDFHDGJKLK;’KJHGFDSFSDS FG FHJGHKJFHSSERYTUTYJFGHKKDFY RSYGHJDGHJFGHJDGJDGHDFGJHG SDFHGJFGJHDGF RSY SY GJFG GGJ Messages Create Message Templates Settings Memory M y AT&T App Center 6 SIM dependent 1 Network dependent Menu Overview 9 Important Safety Information App Manager Delete items View properties Check for upgrades Help Privacy policy AT&T GPS AT&T Navigator AT&T FamilyMap Maps WHERE Web Home Bookmarks Feed Enter Address History Manage YPmobile 10 Important Safety Information Mobile Email Yahoo! AOL AIM Hotmail AT&T Mail Gmail Others Facebook AT&T Social NetMySpace 11 Important Safety Information Twitter My Stuff App manager Game & Apps Audio Music Pictures Video Application Data Other Files Memory Tools Alarm Clock Calendar Notepad Sketch Pad Voice Memo World Time Calculator Tip Calculator Converter Stop Watch T…

Text truncated - open the document above for the full version.

Pantech Co., Ltd. Date: Mar. 16, 2009 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. SunHee Kim of HCT Co., Ltd and hereafter referred to as HCT, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. SunHee Kim of HCT Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing HCT as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Byung-Wan Kim / Senior Vice President Pantech Co., Ltd.

Pantech Co., Ltd. Pantech Building, I-2, DMC, Sangam-dong, Mapo-gu, Seoul, Korea Date: November 16, 2011 ATTESTATION STATEMENT FCC ID: JYCP6020 This device contains an embedded Bluetooth device that Pantech Co., Ltd. confirms compliance with the following Part 15 regulations. 15.247(a)(1) the hopping sequence must be pseudorandom all Channels are used equally on average the receiver input bandwidth is approximately equal to the transmit bandwidth the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. Sincerely, ------------------------------------------- Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Byung-Wan Kim - Pantech Co., Ltd.

Pantech Co., Ltd. Pantech Building, I-2, DMC, Sangam-dong, Mapo-gu, Seoul, Korea Date: November 16, 2011 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 RE: Request of Confidentiality for FCC ID: JYCP6020 To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, Pantech Co., Ltd. hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give Pantech Co., Ltd. temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description CONFIDENTIAL 1Block Diagram 2Operational Descriptions 3 Parts Lists and Tune-Up Procedure 4 Schematics SHORT-TERM CONFIDENTIAL 5External Photos 6Internal Photos 7Test-Setup Photos 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, Sun-Hee Kim-Engineer HCT Co., Ltd. cc. Pantech Co., Ltd.

FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 9 EXTERNAL PHOTOGRAPHS FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 9 ■ EXTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 9 ■ EXTERNAL PHOTO

FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page １ of 9 INTERNAL PHOTOGRAPHS FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ２ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ３ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ４ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ５ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ６ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ７ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ８ of 9 ■ INTERNAL PHOTO FCC ID: JYCP6020 HCT CO., LTD 105-1, JANGAM-RI, MAJANG-MYEON, ICHEON-SI, KYUNGGI-DO, 467-811 KOREA TEL : + 82 31 645 6300 FAX : + 82 31 645 6401 www.hct.co.kr Page ９ of 9 ■ INTERNAL PHOTO

FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1109FR08-1 Date of Issue: December 14, 2011 EUT Type: GSM/WCDMA Phone with Bluetooth FCC ID : JYCP6020 Page 2 of 50 Version TEST REPORT NO. DATE DESCRIPTION HCTR1109FR08 September 09, 2011 First Approval Report HCTR1109FR08-1 December 14, 2011 Insert a information about hopping on and off FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1109FR08-1 Date of Issue: December 14, 2011 EUT Type: GSM/WCDMA Phone with Bluetooth FCC ID : JYCP6020 Page 3 of 50 Table of Contents 1. GENERAL INFORMATION ....................................................................................................................... 4 2. EUT DESCRIPTION .................................................................................................................................. 4 3. TEST METHODOLOGY ............................................................................................................................ 5 3.1 EUT CONFIGURATION ............................................................................................................. 5 3.2 EUT EXERCISE ......................................................................................................................... 5 3.3 GENERAL TEST PROCEDURES ............................................................................................. 5 3.4 DESCRIPTION OF TEST MODES ............................................................................................ 5 4. INSTRUMENT CALIBRATION .................................................................................................................. 6 5. FACILITIES AND ACCREDITATIONS ...................................................................................................... 6 5.1 FACILITIES ................................................................................................................................ 6 5.2 EQUIPMENT .............................................................................................................................. 6 6. ANTENNA REQUIREMENTS.................................................................................................................... 6 7. SUMMARY OF TEST RESULTS ............................................................................................................... 7 8. FCC PART 15.247 REQUIREMENTS ....................................................................................................... 8 8.1 PEAK POWER ........................................................................................................................... 8 8.2 BAND EDGES MEASUREMENT ............................................................................................ 12 8.3 FREQUENCY SEPARATION / OCCUPIED BANDWIDTH (99% BW) ................................... 17 8.4 NUMBER OF HOPPING FREQUENCY .................................................................................. 22 8.5 TIME OF OCCUPANCY (DWELL TIME) ................................................................................. 25 8.6 SPURIOUS EMISSIONS .......................................................................................................... 29 8.6.1 CONDUCTED SPURIOUS MEASUREMENT .................................................................. 29 8.6.2 RADIATED SPURIOUS EMISSIONS .............................................................................. 36 8.6.3 RADIATED RESTRICTED BAND EDGE MEASUREMENTS ......................................... 44 8.7 POWERLINE CONDUCTED EMISSIONS ............................................................................... 45 9. LIST OF TEST EQUIPMENT ................................................................................................................... 50 FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1109FR08-1 Date of Issue: December 14, 2011 EUT Type: GSM/WCDMA Phone with Bluetooth FCC ID : JYCP6020 Page 4 of 50 1. GENERAL INFORMATION Applicant Name: Pantech Co., Ltd. Address: Pantech Bldg, I-2, DMC, Sangam-dong, Mapo-gu, Seoul, 121-792, Korea FCC ID: JYCP6020 EUT: GSM/WCDMA Phone with Bluetooth Model name(s): P6020 Date(s) of Tests: August 23, 2011 ~ September 07, 2011 Contact Person: Name: Jong Chul Yoon Phone #: +82-2-2030-1311 Place of Tests: HCT Co., Ltd. 105-1, Jangam-ri , Majang-Myeon, Icheon-si, Kyunggi-Do, 467-811, KOREA. (IC Recognition No. : 5944A-3) 2. EUT DESCRIPTION EUT Type GSM/WCDMA Phone with Bluetooth FCC Model Name P6020 Power Supply DC 3.7 V Battery Type Li-ion Battery(Standard) Frequency Range 2402 MHz - 2480 MHz (Bluetooth) Transmit Power 4.31 dBm(2.70 mW) Modulation Type GFSK(Normal), PSK(EDR) Modulation Technique FHSS Number of Channels 79Channels Antenna Specification Antenna type: Internal Antenna Peak Gain : -1.51 dBi ※ 15.247 Requirements for Bluetooth transmitter ▪ This Bluetooth module has been tested by a Bluetooth Qualification Lab, and we confirm the following: 1) This system is hopping pseudorandomly. 2) Each frequency is used equally on the average by each transmitter. 3) The receiver input bandwidths that match the hopping channel bandwidths of their corresponding transmitters 4) The receiver shifts frequencies in synchronization with the transmitted signals. ▪ 15.247(g): The system, consisting of both the transmitter and the receiver, must be designed to comply with all of the regulations in this Section 15.247 should the transmitter be presented with a continuous data (or information) stream. ▪ 15.247(h): The coordination of frequency hopping systems in any other manner for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters is not permitted. FCC PT.15.247 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1109FR08-1 Date of Issue: December 14, 2011 EUT Type: GSM/WCDMA Phone with Bluetooth F…
