JYCPG-3310TripleBand GSM850/DCS1800/PCS1900 (with WAP&GPRS)

USER’S MANUAL PG-3310 Thank you for choosing Pantech PG-3310 and welcome to wireless mobile communication networking with the PG-3310, our tri-band GSM mobile phone. . Pantech is delighted to introduce this brand new portable phone which will always keep you conne cted to the network. This user manual explains in detail its unique features and how to use them. NOTE : Some of the contents in this User Manual could vary from your phone. It may vary depending on the S/W version and the network provider you subscribed to. 2 Specification Display Dual clamshell 262,144 TFT LCD internal and 65,536 STN Color LCD external. z 26.112 mm x 28.16 mm display for 1.5” internal LCD z 18.71 mm x 18.71 mm display for 1.04” external Color STN z Supports up to 262,144 colours within 128 x 128 pixels internal and 96 x 96 pixels external z 5 lines for text in basic mode with 16-pixel font z Two Soft keys and four-way scroll and selection ([ OK ]) keys Melody Yamaha 64 poly sound(Support MP3 Ringtones) Camera Integrated VGA(300k) CMOS Camera. z Resolution up to 640 x 480 (307,200 pixels) z Self timer function (5 sec or 10 sec) z Phone display used as a viewfinder z Photo album in Gallery z Photo Gallery for image storing and editing z 3 image quality options: Fine, Normal, Low z Auto white balance (AWB), Auto exposure(AE), Various effects Dimension & Weight z Weight: 68 g z Dimensions: 82.7 mm x 41.5 mm x 18.4 mm Power Management (Performance) Battery Type Capacity Standby Time Talk Time Standard (Li-ion) 710 mAh 240 Hours (Paging 5) 3.2 Hour (Level 8) Operating Frequency z EGSM: 900Mhz, DCS : 1800Mhz, PCS : 1900Mhz networks in Europe, Africa, Asia-Pacific, North America, and South America where these networks are supported z Automatic band switching 3 views Receiver Infrared p or t Power On/Off Menu exit key Headset Jack Left Soft ke y DiaI key Call Accept Voicemail A l p hanumeric ke y Cancel/Back Text Clear/Edit exit key 4-way Menu Navigation Special Menu Short key Volume up/down Menu Scroll WAP Access key Select/Menu Confirm ke y Phone Lock/Unlock Indicator LED Camera ke y Internal LCD Microphone Vibration Mode Right Soft key Camera 4 Quick & Easy Key Function (Left/Right) Performs the functions shown at the bottom line of the display. Scrolls through the menu options in Menu mode. In standby mode, Left key ( ): Favorite list screen Right key ( ): Messages menu screen Up key ( ): Sound Settings menu for sound change. Down key ( ): Contacts menu screen to find contact names. For details, see “Using the Shortcut Key in Standby Mode”. Opens the WAP (Wireless Application Protocol) menu list if pressed shortly in standby mode Launches the WAP browser directly, if pressed and held in standby mode. Selects a menu functions which stores user input information, such as names, SIM memory. Also used for confirmation. Deletes characters from the display, or returns to previous menu. Opens Calendar view if pressed shortly in standby. Sends or receives a call. Shows the recent call list in standby mode. Re-dials the last call number if pressed and held in standby mode. Completes the current call. Turns on/off the phone if pressed and held. Cancels user input and returns to standby mode while in Menu mode. Quickly connects to the voice mail server if pressed and held in standby mode. ~ Enters numbers, letters or special characters. Goes to the dial screen if pressed in standby mode. Enters or exits from Vibration mode if pressed and held in standby mode. Shows the symbol input screen if pressed in text input mode. Works in Word search mode if pressed in the Predictive text input mode. Enters an international dialling prefix. Enters the space character in text input mode. Locks or unlocks the phone if pressed and held in standby mode. Changes various text input modes if pressed and held at the text-editing screen. Adjusts the earpiece volume while making a call, and moves the cursor upwards or downwards in the menu. Controls the key tone volume in standby mode if the phone flip is opened, Turns camera capture mode on. Works as a camera shutter in capture mode. Turns Video Mode on if pressed and held. 5 Safety Precautions Using a phone while driving is prohibited. Please check local laws and regulations with regard to the prohibition of phone usage while driving, and comply with them. - Use of your mobile phone while you are driving may disturb your concentration and consequently cause accidents. Please turn it off as soon as possible. - Should you use your phone in an emergency, please make use of the hands free device built in your car, or pull your car over to a safe place for your utmost safety. - The electronic wave energy emitting from your phone may affect the electronic devices built in your car. Please be aware of this characteristic. Mobile Phone Use Restriction Area Make sure to turn your phone off in a phone usage restricted area. Using a Phone in an Explosive or Dangerous Area is not Permitted Please turn your phone off in areas with explosive or dangerous materials (such as fuel, fuel stations, or pl aces with chemical goods) and abide by any instructions or signals. Never tr y to detach your mobile phone battery from the phone in such areas. Boarding an Aircraft - Please turn your phone off when you are on the aircraft. The electronic wave from your phone may affect the electronic navigation device in the aircraft. Using Medical Equipment - Please turn your phone off while you are in a hospital. - Please abide by the regulations or rules of the hospital. - Please turn off your phone when using medical equipment for private purposes if possible. You should consult with the manufacturer or an expert regarding phone usage near medical equipment. Installing a Vehicle Hands Free Device - Please keep the vehicle hands free device away from the steering, and air bag expansion range, or otherwise injury may result. Effect of Mobile Phone and Electronic Devices Some electronic devices may be affect ed by the electro…

Text truncated - open the document above for the full version.

Pantech Co., Ltd. Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5939 Fax: +82-2-3660-5828 ______________________________________________________________________ LETTER OF AUTHORIZATION DATE :Feb.27, 2006 To whom it may concern: We the undersigned, hereby authorize ETS Germany to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by ETS Germany on our behalf shall have the same affect as acts of our own. This authorization is valid until further written notice from Pantech Co.,LTd. Sincerely, (Company counsel or company officer signature) Name : Yong-Woo Kim Title : Vice President (Name and Title)

Pantech Co., Ltd. Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5939 Fax: +82-2-3660-5828 ______________________________________________________________________ Date : :Feb.27, 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Request for Confidentiality Pantech Co., Ltd. FCC ID: JYCPG-3310 Gentlemen, In accordance with 0.459 of CFR 47, Pantech Co., Ltd. hereby requests confidentiality of all Schematics, Block Diagram, Parts List, Operational Description attachments for the subject application. These documents contain detailed system and equipment description and related information about the product which Pantech Co., Ltd. considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Pantech Co., Ltd. considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Name : Yong-Woo Kim Title : Vice President Company : Pantech Co., Ltd.

Pantech Co., Ltd. Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5939 Fax: +82-2-3660-5828 ______________________________________________________________________ Declaration concerning Antenna Specification It’s hereby declared that the product: ............ PG-3310.................... fulfills the requirement in FCC test relating to the antenna type. The ............PG-3310.............confirm to FCC recommendation with Internal antenna type: (model if applicable) PG-3310 built into the housing and has a unique connector GSM850 DCS1800 PCS1900 824 – 894MHz 1710 - 1880MHz 1850 – 1990MHz TX RX TX RX TX RX Frequency Range (GHz) Band (MHz) 824 - 849 869-894 1710- 1785 1805- 1880 1850- 1910 1930- 1990 E2-PLANE Gain(dBi) (Peak Gain , More Than) folder Type 0.6 0.1 2.2 2.3 0.9 -0.4 The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company: Pantech Co.,Ltd. Address: Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong,Yeoungdeungpo-gu, City: Seoul ZIP / Postal code: 150-711 Country: Korea Place: KOREA Date: FEB., 27,2006 Signature:

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 1 of 14 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 2 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 3 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 4 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 5 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 6 of 14

Pantech Co., Ltd. Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5939 Fax: +82-2-3660-5828 ______________________________________________________________________ [Label Location] Description: Triple Band GSM 850 /DCS 1800 /PCS 1900 (with WAP & GPRS) FCC ID: JYCPG-3310

Pantech Co., Ltd. Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5939 Fax: +82-2-3660-5828 ______________________________________________________________________ [FCC ID Label sample] Description: Triple Band GSM 850/DCS 1800 /PCS 1900 (with WAP & GPRS) FCC ID: JYCPG-3310

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 7 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 8 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 9 of 14 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ETS Dr. Genz GmbH, Germany Registration number: G5D206010020-P-2224 Page 10 of 14

Pantech Co., Ltd. Shinsong Center Bldg. 9th Fl., 25-12,Yeouido-dong, Yeoungdeungpo-gu, Seoul, Korea Tel.: +82-2-3660-5939 Fax: +82-2-3660-5828 __________________________________________________________________________________ Date:Feb.27, 2006 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Declaration – Tuning Procedure Pantech Co., Ltd. FCC ID: JYCPG-3310 FCC Part 2, 24 Certification Gentlemen, There are no user accessible adjustments or tuning for this PG-3310. All necessary adjustments and tuning are performed during manufacture of the product. Sincerely, Yong-Woo Kim Vice President Pantech Co., Ltd.

HYUNDAI CALIBRATION & CERTIFICATION TECH. CO., LTD. PRODUCT COMPLIANCE DIVISION SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr CERTIFICATE OF COMPLIANCE SAR EVALUATION EUT Type: Tri-Band GSM Phone (GSM850/DCS1800/GSM1900) - Prototype Tx Frequency: 824.20 — 848.80 MHz (GSM850) 1 850.20 — 1 909.80 MHz (GSM1900) Rx Frequency: 869.20 — 893.80 MHz (GSM850) 1 930.20 — 1 989.80 MHz (GSM 1900) Trade Name/Model(s): Pantech / PG-3310 FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) Application Type: Certification FCC Rule Part(s): §2.1093; FCC/ OET Bulletin Supplement C [July 2001] Maximum SAR: 0.898 W/kg GSM850 Head SAR / 0.159W/kg GSM850 Body SAR 1.39 W/kg GSM1900 Head SAR / 0.333W/kg GSM1900 Body SAR This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/ IEEE Std. C95.1- 1992 and had been tested in accordance with the measurement procedures specified in ANSI/ IEEE Std. C95.3- 1992. (See Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Hyundai C-Tech Co., Ltd. Certifies that no party to this application has been denied FCC benefits pursuant to section 5301 of the Anti- Drug Abuse Act of 1998, 21 U.S. C. 853(a) Report prepared by : Ki-Soo Kim Manager of Product Compliance Team This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the HCT Co., Ltd. FCC ID : APPLICANT : JYCPG-3310 Pantech co., Ltd Date of Issue : February 23, 2006 Test Report No.: HCT-SAR06-0213 Test Site: HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. FRN: 0005866421 Pantech co., Ltd Shinsong Center Bldg, 25-12, Yeouido-dong, Youngdeungpo-gu, Seoul, 150-711, Korea FRN: 0008874489 Report No.: HCT-SAR06-0213 FCC ID : JYCPG-3310 DATE : February 23, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ２ of 23 Table of Contents 1.1 SCOPE ---------------------------------------------------------------------------------------------------------- 2.1 INTRODUCTION / SAR DEFINITION --------------------------------------------------------------------- 3.1 SAR MEASUREMENT SET-UP --------------------------------------------------------------------------- 4.1 E-FIELD PROBE SYSTEM --------------------------------------------------------------------------------- 5.1 EUT ARRANGEMENT ------------------------------------------------------------------------------------- 6.1 E-FIELD PROBE CALIBRATION PROCESS -------------------------------------------------------- 7.1 PHANTOM, HOLDER, & EQUIVALENT TISSUE --------------------------------------------------- 8.1 SYSTEM SPECIFICATIONS ------------------------------------------------------------------------------ 9.1 MEASUREMENT PROCESS ------------------------------------------------------------------------------ 10.1 ANSI/ IEEE C95.1 - 1992 RF EXPOSURE LIMITS -------------------------------------------------------- 11.1 MEASUREMENT UNCERTAINTIES ------------------------------------------------------------------- 12.1 TEST DATA SUMMARY ---------------------------------------------------------------------------------- 13.1 SAR TEST EQUIPMENT LIST --------------------------------------------------------------------------- 14.1 CONCLUSION ------------------------------------------------------------------------------------------------ 15.1 REFERENCES -------------------------------------------------------------------------------------------- APPENDIX A – SAR TEST PLOTS APPENDIX B – SAR TEST SETUP PHOTOGRAPHS APPENDIX C – DIPOLE VALIDATION APPENDIX D – PROBE CALIBRATION DATA APPENDIX E – DIPOLE CALIBRATION DATA 3 4 5 6 7-8 9-10 11 12-13 14 15 16 17-20 21 22 23 Report No.: HCT-SAR06-0213 FCC ID : JYCPG-3310 DATE : February 23, 2006 HYUNDAI CALIBRATION & CERTIFICATION TECHNOLOGIES CO., LTD. SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI,KYOUNKI-DO, 467-701,KOREA TEL : +82 31 639 8518 FAX : +82 31 639 8525 www.hct.co.kr ３ of 23 SAR MEASUREMENT REPORT 1.1 SCOPE Environmental evaluation measurements of specific absorption rate 1 (SAR) distributions in emulated human head and body tissues exposed to radio frequency (RF) radiation from wireless portable devices for compliance with the rules and regulations of the U.S. Federal Communications Commission (FCC). 2 1. 2 Applicant • EUT Type: Tri-Band GSM Phone (GSM850/DCS1800/GSM1900) - Prototype • Trade Name: Pantech • Model(s): PG-3310 • FCC ID: JYCPG-3310 • Serial Number(s): JYCPG-331020060200001 • Tx Frequency: 824.20 – 848.80 MHz (GSM850) 1850.20 – 1909.80 MHz (GSM1900) • Rx Frequency: 869.20 – 893.80 MHz (GSM850) 1930.20 – 1989.80 MHz (GSM1900) • Application Type: Certification • FCC Classification: Licensed Portable Transmitter Held to Ear (PCE) • FCC Rule Part(s): §2.1093; FCC/ OET Bulletin Supplement C [July 2001] • Modulation(s): GSM • Αntenna Type: Intenna • Date(s) of Tests: February 22, 2006 • Place of Tests: Hyundai C-Tech. EMC Lab. Icheon, Kyounki-Do, KOREA • Report Serial No.: HCT-SAR06-0213 Figure 1. SAR System 1 Specific Absorption Rate (SAR) is a measure of the rate of energy absorption due to exposure to an RF transmitting source (wireless portable device). 2 IEEE/ANSI Std. C95.1-1992 limits are used to determine compliance with FCC ET Docket 93-62. Company Name: Pantech co., Ltd Address: Shinsong Center Bldg, 25-12, Yeouido-dong, Youngdeungpo-gu, Seoul, 150-711, Korea Attention: Min Sang Yeo Tel. / Fax : 82-2-3774-7553 / 82-2-3774-8299 E-…
