KA2WA556A1D-Link DWA-556 Xtreme N PCIe Desktop Adapter

D-Link DWA-556 User Manual Table of Contents Product Overview ........................................................3 Package Contents .....................................................3 System Requirements ...............................................3 Introduction ...............................................................4 Features ....................................................................5 Hardware Overview ...................................................6 LEDs ......................................................................6 Installation ....................................................................7 Getting Started ..........................................................7 Remove Existing Installations ................................7 Disable Other Wireless Adapters ...........................8 Wireless Installation Considerations .......................10 Adapter Installation .................................................11 Configuration .............................................................15 D-Link Wireless Connection Manager .....................15 Wireless Networks ...............................................16 My Wireless Networks ..........................................17 Support.................................................................20 About ....................................................................21 Windows ® XP Configuration Utility ..........................22 Disabling The Windows ® XP Utility .......................23 Wireless Security .......................................................25 What is WEP? .........................................................25 What is WPA? ..........................................................26 Configure WEP........................................................27 Using the D-Link Wireless Connection Manager ..27 Using the Windows ® XP Utility..............................29 Configure WPA/WPA2 Passphrase .........................31 Using the D-Link Wireless Connection Manager ..31 Using the Windows ® XP Utility..............................33 Configure WPA/WPA2 .............................................35 Using the D-Link Wireless Connection Manager ..35 Troubleshooting .........................................................36 Wireless Basics .........................................................41 Networking Basics ....................................................46 Check your IP address ............................................46 Statically Assign an IP address ...............................47 Technical Specifications ...........................................48 Contacting Technical Support ..................................49 Warranty .....................................................................50 Registration ................................................................56 Table of Contents D-Link DWA-556 User Manual Section 1 - Product Overview • D-Link DWA-556 Xtreme N™ PCI Express Desktop Adapter • Manual and Warranty on CD • D-Link Wireless Connection Manager on CD System Requirements • A desktop computer with an available 64-bit PCI Express slot • Windows ® 2000 (Service Pack 4) or XP (Service Pack 2) • 300MHz processor and at least 64MB of RAM • A draft 802.11n or 802.11g access point (for Infrastructure mode), or another draft 802.11n or 802.11g wireless adapter (for Ad-Hoc networking mode). Product Overview Package Contents D-Link DWA-556 User Manual Section 1 - Product Overview Introduction The D-Link Xtreme N™ Desktop Adapter (DWA-556) is a Draft 802.11n client device that delivers unrivaled wireless performance for your desktop computer. With the DWA-556, you can add or upgrade your Desktop PC’s wireless connectivity without having to purchase a new computer. Once connected, access your network’s high-speed Internet connection while sharing photos, files, music, video, printers, and storage. Get a better Internet experience with a faster wireless connection so you can enjoy digital phone calls, gaming, downloading, and video streaming. Powered by Xtreme N™ technology, the DWA-556 provides a faster wireless connection and superior reception than 802.11g*. The DWA-556 is designed for use in bigger homes and for those that demand higher networking. Maximize wireless performance by connecting this desktop adapter to a Xtreme N ™ Router and stay connected from virtually anywhere in the home. This adapter supports WEP, WPA, and WPA2 encryption to prevent outside intrusion and protect your personal information from being exposed. The D-Link Xtreme N™ DWA-556 is a powerful 64-bit desktop adapter that installs quickly and easily into desktop computers. Like all D-Link wireless adapters, the DWA-556 can be used in ad-hoc mode to connect directly with other cards for peer-to-peer file sharing or in infrastructure mode to connect with a wireless access point or router for access to the Internet in your office or home network. The DWA-556 features robust security to help protect the wireless network from intruders, complying with the latest wireless networking security protocols, including WEP encryption and Wi-Fi Protected Access (WPA) support for WPA2-PSK. The DWA-556 also includes a configuration utility to discover available wireless networks and create and save detailed connectivity profiles for those networks most often accessed. • Maximum wireless signal rate derived from IEEE Standard 80.11g and draft 80.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. 5D-Link DWA-556 User Manual Section 1 - Product Overview • Faster Wireless Networking* - Enable wireless connectivity on your Desktop PC computer with the DWA-556. With the performance of D-Link’s Xtreme N ™ line of wirel…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

FCC ID .: KA2WA556A1 Label Location

MADE IN CHINA FCC ID: KA2WA556A1 IC: 4216A - WA556 DWA-556 PCIe DESKTOP ADAPTER PCIe DESKTOP ADAPTER TM TM 98mm 54mm This device complies with Part 15 of the FCC Rules. Operation is subject to the (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. Z576 following two conditions:

Page 5 Page 6 Page 7

FCC ID: KA2WA556A1 Report No.: RF951116L07 OPERATIONAL DESCRIPTION This device is a D-Link DWA-556 Xtreme N TM PCIe Desktop Adapter, which operates in the 2.4GHz frequency spectrum with throughput of up to 300Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is dipole antenna with R-SMA antenna connector. For more detailed instruction, please take a look at the user’s manual.

FCC ID: KA2WA556A1 Report No: SA951116L07 1 RF EXPOSURE REPORT REPORT NO.: SA951116L07 MODEL NO.: DWA-556 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: KA2WA556A1 Report No: SA951116L07 2 RF EXPOSURE MEASUREMENT (MOBILE DEVICE) 1. INTRODUCTION In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF EXPOSURE LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) (A)LIMITS FOR OCCUPATIONAL / CONTROL EXPOSURES 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: KA2WA556A1 Report No: SA951116L07 3 3. FRIIS FORMULA Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT OPERATING CONDITION The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. CLASSIFICATION This device is fixed inside the host equipment. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: KA2WA556A1 Report No: SA951116L07 4 6. TEST RESULTS 6.1 ANTENNA GAIN The maximum Gain measured in Fully Anechoic Chamber is 2dBi or 1.585(numeric). 6.2 OUTPUT POWER INTO ANTENNA & RF EXPOSURE VALUE AT DISTANCE 20cm: 802.11b DSSS MODULATION: PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 56.234 56.754 57.148 17.50 17.54 17.57 6 2437 55.847 57.016 57.677 17.47 17.56 17.61 11 2462 56.364 57.412 57.943 17.51 17.59 17.63 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM 2 )) LIMIT OF POWER DENSITY (mW/CM 2 ) 1 2412 170.136 22.31 0.0536 1.0 6 2437 170.540 22.32 0.0538 1.0 11 2462 171.718 22.35 0.0541 1.0 FCC ID: KA2WA556A1 Report No: SA951116L07 5 802.11g OFDM MODULATION: PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 34.914 35.975 36.559 15.43 15.56 15.63 6 2437 44.771 45.814 47.098 16.51 16.61 16.73 11 2462 34.674 35.727 36.308 15.40 15.53 15.60 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM 2 )) LIMIT OF POWER DENSITY (mW/CM 2 ) 1 2412 107.448 20.31 0.0339 1.0 6 2437 137.683 21.39 0.0434 1.0 11 2462 106.709 20.28 0.0336 1.0 FCC ID: KA2WA556A1 Report No: SA951116L07 6 DRAFT 802.11n (20MHz) OFDM modulation PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 28.119 28.774 28.973 14.49 14.59 14.62 6 2437 39.902 40.458 40.832 16.01 16.07 16.11 11 2462 28.708 29.376 29.854 14.58 14.68 14.75 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM 2 )) LIMIT OF POWER DENSITY (mW/CM 2 ) 1 2412 85.866 19.34 0.0271 1.0 6 2437 121.192 20.83 0.0382 1.0 11 2462 87.938 19.44 0.0277 1.0 FCC ID: KA2WA556A1 Report No: SA951116L07 7 DRAFT 802.11n (40MHz) OFDM modulation PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2422 13.900 14.223 14.588 11.43 11.53 11.64 4 2437 21.979 22.856 23.496 13.42 13.59 13.71 7 2452 14.028 14.256 14.488 11.47 11.54 11.61 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM 2 )) LIMIT OF POWER DENSITY (mW/CM 2 ) 1 2422 42.711 16.31 0.0135 1.0 4 2437 68.331 18.35 0.0215 1.0 7 2452 42.772 16.31 0.0135 1.0

Report No.: RF951116L07 1 Report Format Version 2.0.5 FCC TEST REPORT REPORT NO.: RF951116L07 MODEL NO.: DWA-556 RECEIVED: Nov. 17, 2006 TESTED: Nov. 18 ~ Nov. 20, 2006 ISSUED: Nov. 23, 2006 APPLICANT: D-Link Corporation ADDRESS: 17595 Mt. Herrmann, Fountain Valley, CA 92708, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No.47, 14 th Ling, Chia Pau Tsuen, Linko Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 140 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF951116L07 2 Report Format Version 2.0.5 TABLE OF CONTENTS 1. CERTIFICATION...............................................................................................4 2. SUMMARY OF TEST RESULTS.......................................................................5 2.1 MEASUREMENT UNCERTAINTY....................................................................5 3. GENERAL INFORMATION...............................................................................6 3.1 GENERAL DESCRIPTION OF EUT..................................................................6 3.2 DESCRIPTION OF TEST MODES....................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST...............................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.....................9 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.................................12 3.4 DESCRIPTION OF SUPPORT UNITS............................................................12 4. TEST TYPES AND RESULTS.........................................................................13 4.1 CONDUCTED EMISSION MEASUREMENT..................................................13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT................................13 4.1.2 TEST INSTRUMENTS....................................................................................13 4.1.3 TEST PROCEDURES.....................................................................................14 4.1.4 DEVIATION FROM TEST STANDARD...........................................................14 4.1.5 TEST SETUP..................................................................................................15 4.1.6 EUT OPERATING CONDITIONS....................................................................15 4.1.7 TEST RESULTS.............................................................................................16 4.2 RADIATED EMISSION MEASUREMENT.......................................................34 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.....................................34 4.2.2 TEST INSTRUMENTS....................................................................................35 4.2.3 TEST PROCEDURES.....................................................................................36 4.2.4 DEVIATION FROM TEST STANDARD...........................................................36 4.2.5 TEST SETUP..................................................................................................37 4.2.6 EUT OPERATING CONDITIONS....................................................................37 4.2.7 TEST RESULTS.............................................................................................38 4.3 6dB BANDWIDTH MEASUREMENT..............................................................66 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT............................................66 4.3.2 TEST INSTRUMENTS....................................................................................66 4.3.3 TEST PROCEDURE.......................................................................................66 4.3.4 DEVIATION FROM TEST STANDARD...........................................................66 4.3.5 TEST SETUP..................................................................................................67 4.3.6 EUT OPERATING CONDITIONS....................................................................67 4.3.7 TEST RESULTS.............................................................................................68 4.4 MAXIMUM PEAK OUTPUT POWER..............................................................88 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT................88 4.4.2 INSTRUMENTS..............................................................................................88 4.4.3 TEST PROCEDURES.....................................................................................88 4.4.4 DEVIATION FROM TEST STANDARD...........................................................88 4.4.5 TEST SETUP..................................................................................................89 4.4.6 EUT OPERATING CONDITIONS....................................................................89 4.4.7 TEST RESULTS.............................................................................................90 4.5 POWER SPECTRAL DENSITY MEASUREMENT..........................................94 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT........................94 4.5.2 TEST INSTRUMENTS....................................................................................94 4.5.3 TEST PROCEDURE.......................................................................................94 4.5.4 DEVIATION FROM TEST STANDARD...........................................................94 4.5.5 TEST SETUP..................................................................................................95 Report No.: RF951116L07 3 Report Format Version 2.0.5 4.5.6 EUT OPERATING CONDITION…

Text truncated - open the document above for the full version.

Report No.: RF951116L07 81 Report Format Version 2.0.5 CH 11 FOR CHAIN 2: CH 1 Report No.: RF951116L07 82 Report Format Version 2.0.5 CH 6 CH 11 Report No.: RF951116L07 83 Report Format Version 2.0.5 DRAFT 802.11n (40MHz) OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 15Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen 6dB BANDWIDTH (MHz) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 MINIMUM LIMIT (MHz) PASS / FAIL 1 2422 36.40 36.48 36.48 0.5 PASS 4 2437 36.40 36.40 36.48 0.5 PASS 7 2452 36.40 36.48 36.48 0.5 PASS FOR CHAIN 0: CH 1 Report No.: RF951116L07 84 Report Format Version 2.0.5 CH 4 CH 7 Report No.: RF951116L07 85 Report Format Version 2.0.5 FOR CHAIN 1: CH 1 CH 4 Report No.: RF951116L07 86 Report Format Version 2.0.5 CH 7 FOR CHAIN 2: CH 1 Report No.: RF951116L07 87 Report Format Version 2.0.5 CH 4 CH 7 Report No.: RF951116L07 88 Report Format Version 2.0.5 4.4 MAXIMUM PEAK OUTPUT POWER 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT The Maximum Peak Output Power Measurement is 30dBm. 4.4.2 INSTRUMENTS DESCRIPTION & MANUFACTURER MODEL NO. SERIAL NO. CALIBRATED UNTIL R&S SPECTRUM ANALYZER FSP40 100040 Jun. 07, 2007 AGILENT SIGNAL GENERATOR E8257C MY43320668 Dec. 07, 2006 DIGITAL RT OSCILLOSCOPE TDS1012 C037299 Nov. 28, 2006 NARDA DETECTOR 4503A FSCM99899 NA NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.4.3 TEST PROCEDURES 1. A detector was used on the output port of the EUT. An oscilloscope was used to read the response of the detector. 2. Replaced the EUT by the signal generator. The center frequency of the S.G was adjusted to the center frequency of the measured channel. 3. Adjusted the power to have the same reading on oscilloscope. Record the power level. 4.4.4 DEVIATION FROM TEST STANDARD No deviation Report No.: RF951116L07 89 Report Format Version 2.0.5 4.4.5 TEST SETUP 4.4.6 EUT OPERATING CONDITIONS Same as Item 4.3.6. EUT or S.G OSCILLOSCOPE DETECTOR Report No.: RF951116L07 90 Report Format Version 2.0.5 4.4.7 TEST RESULTS 802.11b DSSS MODULATION: TRIPLE TX: MODULATION TYPE DBPSK TRANSFER RATE 1Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 56.234 56.754 57.148 17.50 17.54 17.57 6 2437 55.847 57.016 57.677 17.47 17.56 17.61 11 2462 56.364 57.412 57.943 17.51 17.59 17.63 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2412 170.136 22.31 30 PASS 6 2437 170.540 22.32 30 PASS 11 2462 171.718 22.35 30 PASS Report No.: RF951116L07 91 Report Format Version 2.0.5 802.11g OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 6Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 34.914 35.975 36.559 15.43 15.56 15.63 6 2437 44.771 45.814 47.098 16.51 16.61 16.73 11 2462 34.674 35.727 36.308 15.40 15.53 15.60 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2412 107.448 20.31 30 PASS 6 2437 137.683 21.39 30 PASS 11 2462 106.709 20.28 30 PASS Report No.: RF951116L07 92 Report Format Version 2.0.5 DRAFT 802.11n (20MHz) OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 7.2Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 28.119 28.774 28.973 14.49 14.59 14.62 6 2437 39.902 40.458 40.832 16.01 16.07 16.11 11 2462 28.708 29.376 29.854 14.58 14.68 14.75 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2412 85.866 19.34 30 PASS 6 2437 121.192 20.83 30 PASS 11 2462 87.938 19.44 30 PASS Report No.: RF951116L07 93 Report Format Version 2.0.5 DRAFT 802.11n (40MHz) OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 15Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2422 13.900 14.223 14.588 11.43 11.53 11.64 4 2437 21.979 22.856 23.496 13.42 13.59 13.71 7 2452 14.028 14.256 14.488 11.47 11.54 11.61 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2422 42.711 16.31 30 PASS 4 2437 68.331 18.35 30 PASS 7 2452 42.772 16.31 30 PASS Report No.: RF951116L07 94 Report Format Version 2.0.5 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS DESCRIPTION & MANUFACTURER MODEL NO. SERIAL NO. CALIBRATED UNTIL R&S SPECTRUM ANALYZER FSP40 100040 Jun. 07, 2007 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3kHz RBW and 30kHz VBW, set sweep time = span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3kHz for a full response of the mixer in the spectrum analyzer. 4.5.4 DEVIATION FROM TEST STANDARD No deviation Report No.: RF951116L07 95 Report Format Version 2.0.5 4.5.5 TEST SETUP 4.5.6 EUT OPERATING CONDITION Same as Item 4.3.6. SPECTRUM ANA…

Text truncated - open the document above for the full version.

Report No.: RF951116L07 101 Report Format Version 2.0.5 CH 11 Report No.: RF951116L07 102 Report Format Version 2.0.5 802.11g OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 6Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen RF POWER LEVEL IN 3kHz BW (mW) RF POWER LEVEL IN 3kHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 0.033 0.034 0.035 -14.76 -14.63 -14.60 6 2437 0.042 0.042 0.043 -13.79 -13.76 -13.68 11 2462 0.034 0.034 0.035 -14.74 -14.67 -14.55 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2412 0.103 -9.89 8 PASS 6 2437 0.127 -8.97 8 PASS 11 2462 0.103 -9.88 8 PASS Report No.: RF951116L07 103 Report Format Version 2.0.5 FOR CHAIN 0: CH 1 CH 6 Report No.: RF951116L07 104 Report Format Version 2.0.5 CH 11 FOR CHAIN 1: CH 1 Report No.: RF951116L07 105 Report Format Version 2.0.5 CH 6 CH 11 Report No.: RF951116L07 106 Report Format Version 2.0.5 FOR CHAIN 2: CH 1 CH 6 Report No.: RF951116L07 107 Report Format Version 2.0.5 CH 11 Report No.: RF951116L07 108 Report Format Version 2.0.5 DRAFT 802.11n (20MHz) OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 7.2Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen RF POWER LEVEL IN 3kHz BW (mW) RF POWER LEVEL IN 3kHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2412 0.026 0.026 0.027 -15.88 -15.84 -15.73 6 2437 0.037 0.038 0.039 -14.33 -14.24 -14.12 11 2462 0.026 0.027 0.027 -15.84 -15.75 -15.63 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2412 0.079 -11.04 8 PASS 6 2437 0.113 -9.46 8 PASS 11 2462 0.080 -10.97 8 PASS Report No.: RF951116L07 109 Report Format Version 2.0.5 FOR CHAIN 0: CH 1 CH 6 Report No.: RF951116L07 110 Report Format Version 2.0.5 CH 11 FOR CHAIN 1: CH 1 Report No.: RF951116L07 111 Report Format Version 2.0.5 CH 6 CH 11 Report No.: RF951116L07 112 Report Format Version 2.0.5 FOR CHAIN 2: CH 1 CH 6 Report No.: RF951116L07 113 Report Format Version 2.0.5 CH 11 Report No.: RF951116L07 114 Report Format Version 2.0.5 DRAFT 802.11n (40MHz) OFDM MODULATION: TRIPLE TX: MODULATION TYPE BPSK TRANSFER RATE 15Mbps INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 25deg.C, 63%RH, 991hPa TESTED BY Long Chen RF POWER LEVEL IN 3kHz BW (mW) RF POWER LEVEL IN 3kHz BW (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 2 CHAIN 0 CHAIN 1 CHAIN 2 1 2422 0.008 0.008 0.008 -20.98 -20.88 -20.74 4 2437 0.013 0.014 0.014 -18.74 -18.66 -18.61 7 2452 0.008 0.008 0.009 -20.73 -20.98 -20.68 CHANNEL CHANNEL FREQUENCY (MHz) TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) PEAK POWER LIMIT (dBm) PASS / FAIL 1 2422 0.025 -16.09 8 PASS 4 2437 0.041 -13.90 8 PASS 7 2452 0.025 -16.02 8 PASS Report No.: RF951116L07 115 Report Format Version 2.0.5 FOR CHAIN 0: CH 1 CH 4 Report No.: RF951116L07 116 Report Format Version 2.0.5 CH 7 FOR CHAIN 1: CH 1 Report No.: RF951116L07 117 Report Format Version 2.0.5 CH 4 CH 7 Report No.: RF951116L07 118 Report Format Version 2.0.5 FOR CHAIN 2: CH 1 CH 4 Report No.: RF951116L07 119 Report Format Version 2.0.5 CH 7 Report No.: RF951116L07 120 Report Format Version 2.0.5 4.6 BAND EDGES MEASUREMENT 4.6.1 LIMITS OF BAND EDGES MEASUREMENT Below –20dB of the highest emission level of operating band (in 100kHz Resolution Bandwidth). 4.6.2 TEST INSTRUMENTS DESCRIPTION & MANUFACTURER MODEL NO. SERIAL NO. CALIBRATED UNTIL Spectrum Analyzer ROHDE & SCHWARZ FSEK30 100049 Aug. 21, 2007 BILOG Antenna SCHWARZBECK VULB9168 9168-153 Jan. 15, 2007 HORN Antenna SCHWARZBECK BBHA 9120 D 9120D-407 Jan. 22, 2007 HORN Antenna SCHWARZBECK BBHA 9170 BBHA9170242 Jan. 19, 2007 RF signal cable HUBER+SUHNNER SUCOFLEX 104 218188/218189 Dec. 13, 2006 RF signal cable Worken 8D-FB Cable-HYCH9-01 Mar. 08, 2007 Software ADT. ADT_Radiated_ V7.6.01 NA NA Antenna Tower EMCO 2070/2080 512.835.4684 NA Antenna Tower Controller EMCO 2090 NA NA Turn Table EMCO 2087-2.03 NA NA Turn Table Controller EMCO 2090 NA NA NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA.

Report No.: RF951116L07 121 Report Format Version 2.0.5 4.6.3 TEST PROCEDURE a. The EUT was placed on the top of a rotating table 0.8 meters above the ground at a 3 meter semi-anechoic chamber. The table was rotated 360 degrees to determine the position of the highest radiation. b. The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top of a variable-height antenna tower. c. The antenna is a broadband antenna, and its height is varied from one meter to four meters above the ground to determine the maximum value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the measurement. d. For each suspected emission, the EUT was arranged to its worst case and then the antenna was tuned to heights from 1 meter to 4 meters and the rotatable table was turned from 0 degrees to 360 degrees to find the maximum reading. e. Set both RBW and VBW of spectrum analyzer to 100kHz with suitable frequency span including 100MHz bandwidth from band edge. The band edges was measured and recorded. The spectrum plots (Peak RBW = VBW = 100kHz; Average RBW = 1MHz, VBW = 10Hz)…

Text truncated - open the document above for the full version.
