KBS050238Wireless Fence Transmitter, WF-020

Page 1 of 21 Report No: FC00-027 CERTIFICATION TEST REPORT FOR THE WIRELESS FENCE TRANSMITTER, WF-020 FCC PART 15 SUBPART C COMPLIANCE DATE OF ISSUE: MARCH 30, 2000 PREPARED FOR: Innotek Pet Products, Inc. One Innoway Garrett, IN 46738 P.O. No: 51142 W.O. No: 73919 PREPARED BY: Joyce Walker CKC Laboratories, Inc. 5473A Clouds Rest Mariposa, CA 95338 Date of test: March 23 & 24, 2000 Report No: FC00-027 DOCUMENTATION CONTROL: _____________________________ Tracy Phillips Documentation Control Supervisor CKC Laboratories, Inc. APPROVED BY: _____________________________ Dennis Ward Director of Laboratories CKC Laboratories, Inc. This report contains a total of 21 pages and may be reproduced in full only. Partial reproduction may only be done with the written consent of CKC Laboratories, Inc. Page 2 of 21 Report No: FC00-027 TABLE OF CONTENTS Administrative Information ............................................................................................. 3 Summary Of Results........................................................................................................ 4 Equipment Under Test (EUT) Description...................................................................... 4 Measurement Uncertainty................................................................................................ 4 Peripheral Devices ........................................................................................................... 4 Report Of Measurements................................................................................................. 5 Table 1: Fundamental Radiated Emission Levels .............................................. 5 Table 2: Six Highest Radiated Emission Levels - 9kHz-1000MHz ................... 6 Table A : List Of Test Equipment ................................................................................... 7 EUT Setup .......................................................................................................................8 Test Instrumentation And Analyzer Settings................................................................... 8 Table B : Analyzer Bandwidth Settings Per Frequency Range........................... 8 Spectrum Analyzer Detector Functions............................................................... 9 Peak ......................................................................................................... 9 Quasi-Peak............................................................................................... 9 Average.................................................................................................... 9 Test Methods ................................................................................................................... 10 Radiated Emissions Testing................................................................................. 10 Occupied Bandwidth ........................................................................................... 11 Sample Calculations ........................................................................................................ 12 Appendix A : Information About The Equipment Under Test........................................ 13 I/O Ports............................................................................................................... 14 Crystal Oscillators ............................................................................................... 14 Printed Circuit Boards ......................................................................................... 14 Required EUT Changes To Comply.................................................................... 14 Photograph Showing Radiated Emissions ........................................................... 15 Photograph Showing Radiated Emissions ........................................................... 16 Appendix B : Measurement Data Sheets ......................................................................... 17 Occupied Bandwidth Plot Part 15.215 ................................................................ 18 Page 3 of 21 Report No: FC00-027 CKC Laboratories, Inc. has Certificates of Accreditation from the following agencies: DATech (Germany); A2LA (USA); FCC (USA); VCCI (Japan); BSMI (Taiwan); HOKLAS (Hong Kong). CKC Laboratories, Inc. has Letters of Acceptance through an MRA for the following agencies: ACA/NATA (Australia); SABS (South Africa); SWEDAC (Sweden); TUV Rheinland-Germany; TUV Rheinland- Korea; TUV Rheinland-Russia; Radio Communication Agency (RA); NEMKO (Norway). ADMINISTRATIVE INFORMATION DATE OF TEST: March 23 & 24, 2000 PURPOSE OF TEST: To demonstrate the compliance of the Wireless Fence Transmitter, WF-020, with the requirements for FCC Part 15 Subpart C devices. MANUFACTURER: Innotek Pet Products, Inc. One Innoway Garrett, IN 46738 REPRESENTATIVE: Pete Johnson TEST LOCATION: CKC Laboratories, Inc. 22105 Wilson River Hwy Tillamook, OR 97141 TEST PERSONNEL: Mike Wilkinson TEST METHOD: ANSI C63.4 1992 & FCC Parts 15.209, 15.215 & 15.227 FREQUENCY RANGE TESTED: 9 kHz - 1000 MHz EQUIPMENT UNDER TEST: Wireless Fence Transmitter Manuf:Innotek Pet Products, Inc. Model:WF-020 Serial:N/A FCC ID:KBS050238 (pending) Page 4 of 21 Report No: FC00-027 SUMMARY OF RESULTS The Innotek Pet Products, Inc. Wireless Fence Transmitter, WF-020, was tested in accordance with ANSI C63.4 1992 for compliance with FCC Part 15 Subpart C. As received, the above equipment was found to be fully compliant with the limits of FCC Part 15 Subpart C. The results in this report apply only to the items tested, as identified herein. EQUIPMENT UNDER TEST (EUT) DESCRIPTION Short range transmitter used to create a confinement field. MEASUREMENT UNCERTAINTY Associated with data in this report is a±4dB measurement uncertainty. PERIPHERAL DEVICES The EUT was tested not tested with peripheral devices. Page 5 of 21 Report No: FC00-027 REPORT OF MEASUREMENTS The following tables report the highes…
