SR250-EI00 01/2021PARADOX.COM SR250 Wireless Siren w/Built-In Strobe Light Introduction The SR250 is a weatherproof, stand-alone, fully supervised outdoor wireless siren with built-in strobe light and wireless transceiver. The SR250 uses 2-way wireless communication, which provides continuous supervision between the panel and siren with fast response to alarm signals within four seconds. With its tough weatherproof construction, the SR250 operates reliably from -30 ºC to 50 ºC (-22 ºF to 122 ºF) when using alkaline batteries or power supply. With normal use, the SR250 will function up to 3 years without the need to replace the batteries (battery life can be extended by using an optional AC or DC power supply). This guide describes how to install and configure the SR250 wireless siren. Overview Figure 1: SR250 Overview Installation Only qualified persons should install, operate, maintain, and repair this equipment. 1.Write down the serial number (on the back of the unit) and location of the SR250 for later reference, to insert into the Paradox BabyWare software. 2. Loosen the four screws from the cover from the siren and remove cover. 3.Loosen the four screws from the PCB cover and remove. 4.Screw the SR250 siren onto the wall through the five provided holes (four wall and one Tamper Spacer). 5.Ensure that the Tamper switch is screwed onto the wall through the Tamper Spacer. 6.Batteries: a. If the siren already has batteries installed: • Remove the plastic tab between the top battery terminals and the battery compartment • Leave the cover off until you learn the siren b. If the siren does not have batteries installed: • Insert the batteries - ensure correct polarity • Leave the cover off until you learn the siren Note: We recommend to replace the battery every three years to avoid leakage. 7.After programming the siren (see Programming section): Reinstall the PCB cover. 8.Reinstall the top cover. LED Feedback Figure 2: LED Status Indicators The following table describes LED Status Indicators. NumberOverview Description 1100 dB siren 2 Battery pack (3 “D” size alkaline batteries) For EN installations, 3 “D” batteries must be installed. 3Power supply input (8-16 Vac / 9-20 Vdc) 4Infield connector 5 Dual-action tamper switch (detects when cover is removed and when unit is removed from wall) 6Strobe lights 7 Antenna (Can be extended using an RG6 or RG59 coaxial cable with standard male F connectors. Attach the antenna using a female/female F adapter) 8Status and Signal Strength LEDs 9Learn switch 1 2 3 8 6 7 5 9 4 LED Indicator Description/Status TXSending data RXReceiving data PSSI Signal strength siren receives from control panel Flash 4x - strong signal Flash 3x - good signal Flash 2x - weak signal Flash 1x - very weak signal (relocate) No flash - no signal Status Flash once/sec. - processor is on Flash once/4 sec. - power save mode Red Blue Clear Lenses Amber SR250-EI00 01/2021PARADOX.COM Programming Program the SR250 either though a supported keypad or through BabyWare software (BabyWare). Programming with Keypads Programming with BabyWare 1.Open BabyWare > Connect your Account. 2.In the Main window: Select the Add Item button > Wireless Sirens. 3.Fill-in the SR250 label, location and serial number. 4.Select Save. Upgrading Firmware Upgrade SR250 firmware through the Paradox InField software (V5.5.9 or higher) using the 307USB Direct Connect Interface. The SR250 requires the batteries installed in order to upgrade the firmware. Note: Ensure that the SR250 is awake before upgrading the firmware. To w a k e u p t h e s i r e n: press the Learn switch (see #9 in Figure 1). The siren provides a 60 second delay in order to begin the update. 1.Remove the front cover as well as the PCB cover. 2.Connect the 307USB to the InField connector (see #4 in Figure 1). 3.Upgrade according to the firmware upgrade instructions: Go to www.paradox.com > Software > InField Firmware Upgrade Instructions. Tamper Supervision If a tamper is detected, the SR250 will sound an alarm and the strobe light will flash for 4 minutes. The control panel will follow the global supervision options set in the panel. Specifications FCC and Industry Canada Compliance Statement This device complies with FCC Rules Part 15 and with Industry Canada license exempt RSS standard(s). Operation is subject to two conditions: 1.This device may not cause harmful interference 2.This device must accept any interference that may be received or that may cause undesired operation. Le present appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisee aux deux conditions suivantes : 1. l'appareil ne doit pas produire de brouillage, et 2. l'utilisateur de l'appareil doit accepter tout brouillage radioelectrique subi, meme si le brouillage est susceptible d'en compromettre le fonctionnement. FCC ID: KDYSR250 IC: 2438A-SR250 FCC WARNING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. …
Text truncated - open the document above for the full version.
Page 1 of 1 January 27, 2021 Telefication B.V. Attn: Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Application for certification of an Outdoor Wireless Siren, SR250, FCC ID: KDYSR250 Dear Gentlemen, Please find attached our application for certification of the Outdoor Wireless Siren, brand name SR250, FCC ID: KDYSR250, prepared in accordance with FCC Rules part 15 subpart C section 15.231. The product testing and this application for certification were performed by Hermon Laboratories, which is recognized and accredited by FCC, Test Firm Registration Number is 927748, Designation Number is IL1001. Hermon Labs responsible person is Mr. Michael Nikishin, tel: +972 4626 8440, fax:+972 4628 8277, e-mail: [email protected]. Please send an invoice to Hermon Labs. We hope this application satisfies your requirements Sincerely yours, Alex Chaplik, Certification Manager
RF_160, Issue 04 Declaration of Authorization We Name: Paradox Security Systems Ltd. Address: 780 Industriel Blvd . City: Saint-Eustache, Quebec J7R 5V3. Country: Canada . Declare that: Name Representative of agent: ............. (1) Agent Company name: Hermon Laboratories Ltd.. Address: Harakevet Industrial Zone .. City: Binyamina 30500.. Country Israel . is authorized to apply for Certification of the following product(s): Product description: Outdoor Wireless Siren Type designation: SR250. Trademark: Paradox. Validity/ expiry date: January 26, 2022 on our behalf. Date: January 26, 2021 City: Saint-Eustache .. Name: Alex Chaplik .. (2) Function: Certification manager ............................... Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.
FCC, Request for non-disclosure Date: 19-Oct-10 RF_501, Issue 7 Page 1 of 1 Company Name: Paradox Security Systems Address: 780 Industriel Blvd City: Saint-Eustache, QC, J7R 5V3 Country: Canada To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: KDYSR250 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Patent pending, Competative advantage Planned Release Date STC: 180 days from the grant date (notes 2, 3, 4, 5). If no date is given, 45 days from grant date will be used. Date: January 26, 2021 Name and signature of applicant: Alex Chaplik Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period
Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 1 of 3 EXTERNAL PHOTOGRAPHS This document contains 2 photographs Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 2 of 3 Photograph No.1 Front view Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 3 of 3 Photograph No.2 Rear view
Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 1 of 1 Label The label shown below is affixed on the rear side of the detector. The label material is PVC with a permanent adhesive. Label location Label with FCC ID: KDYSR250 and IC: 2438A-SR250 will be located here. The statement according to FCC part 15 §15.19(a)(3) is placed in User Manual, page ... (Application exhibit User_manual_36712).
Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 1 of 4 INTERNAL PHOTOGRAPHS This document contains 3 photographs Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 2 of 4 Photograph No.1 Internal view Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 3 of 4 Photograph No.2 Print side of the main PCB Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 4 of 4 Photograph No.3 Antenna assembly
Hermon Laboratories Ltd. P.O. Box 23, Binyamina 3055001, Israel Tel. +972 4628 8001 Fax. +972 4628 8277 E-mail: [email protected] Page 1 of 53 Report ID: PARRAD_FCC.36712_SR250 Date of Issue: 28-Jan-21 ELECTRICAL TESTING 0839.01 TEST REPORT ACCORDING TO: FCC CFR 47 Part 15 subpart C, section 15.231 and subpart B, RSS-210 issue 10 Annex A, RSS-Gen issue 5, ICES-003 Issue 6:2016 FOR: Paradox Security Systems Ltd. Outdoor Wireless Siren Model: SR250 FCC ID: KDYSR250 IC: 2438A-SR250 This report is in conformity with ISO/ IEC 17025. The "A2LA Accredited" symbol endorsement applies only to the tests and calibrations that are listed in the scope of Hermon Laboratories accreditation. The test results relate only to the items tested. This test report shall not be reproduced in any form except in full with the written approval of Hermon Laboratories Ltd. Report ID: PARRAD_FCC.36712_SR250 Date of Issue: 28-Jan-21 Page 2 of 53 Table of contents 1 Applicant information ..................................................................................................................................................... 3 2 Equipment under test attributes .................................................................................................................................... 3 3 Manufacturer information .............................................................................................................................................. 3 4 Test details .................................................................................................................................................................... 3 5 Tests summary .............................................................................................................................................................. 4 6 EUT description ............................................................................................................................................................. 5 6.1 General information ....................................................................................................................................................... 5 6.2 Ports and lines .............................................................................................................................................................. 5 6.3 Test configuration .......................................................................................................................................................... 5 6.4 Changes made in EUT .................................................................................................................................................. 5 6.5 Transmitter characteristics ............................................................................................................................................ 6 7 Transmitter tests according to 47CFR part 15 subpart C and RSS-210 requirements .................................................. 7 7.1 Periodic operation requirements ................................................................................................................................... 7 7.2 Field strength of emissions ............................................................................................................................................ 9 7.3 Occupied bandwidth test ............................................................................................................................................. 27 7.4 Conducted emissions .................................................................................................................................................. 30 7.5 Antenna requirements ................................................................................................................................................. 34 8 Unintentional emissions according to 47CFR part 15 subpart B and ICES-003 requirements .................................... 35 8.1 Conducted emissions .................................................................................................................................................. 35 8.2 Radiated emission measurements .............................................................................................................................. 39 9 APPENDIX A Test equipment and ancillaries used for tests ....................................................................................... 44 10 APPENDIX B Test equipment correction factors ......................................................................................................... 45 11 APPENDIX C Measurement uncertainties .................................................................................................................. 50 12 APPENDIX D Test laboratory description ................................................................................................................... 51 13 APPENDIX E Specification references........................................................................................................................ 51 14 APPENDIX F Manufacturer’s declaration about periodic operation ............................................................................ 52 15 APPENDIX G Abbreviations and acronyms ................................................................................................................ 53 Report ID: PARRAD_FCC.36712_SR250 Date of Issue: 28-Jan-21 Page 3 of 53 1 Applicant information Client name: Paradox Security Systems Ltd. Address: 780 Industrial Boulevard St.Eustache, Quebec J7R 5V3 Canada Telephone: 450-491-7444 Fax: 450-497-1095 E-mail: [email protected] Contact name: Mr. Alex Chaplik 2 Equipment under test attributes Product name: Outdoor Wireless Siren Product type: Transceiver Model(s): SR250 Serial number: 400042 Hardware version: 331-5502-991 Software release: V1.00 Receipt date 05-Jan-21 3 Manufacturer information Man…
Text truncated - open the document above for the full version.
Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 1 of 5 SETUP PHOTOGRAPHS This document contains 4 photographs Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 2 of 5 Photograph No.1 Setup for spurious emission field strength measurements in the anechoic chamber below 30 MHz Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 3 of 5 Photograph No.2 Setup for carrier field strength, spurious emission field strength measurements in the anechoic chamber in 30 – 1000 MHz range Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 4 of 5 Photograph No.3 Setup for carrier field strength, spurious emission field strength measurements in the anechoic chamber above 1000 MHz Paradox Security Systems Ltd. FCC ID: KDYSR250 IC: 2438A-SR250 Page 5 of 5 Photograph No.4 Setup for OBW measurements
