KE3-3002642REMOTE PET TRAINER

Operating Guide Manuel d’utilisation Gebruiksaanwijzing Manual de funcionamiento Guida all’uso Gebrauchsanweisung ST-100 Remote Trainer Système de dressage Trainer met afstandsbediening Sistema de adiestramiento Sistema di addestramento Ferntrainer Please read this entire guide before beginning Veuillez lire ce manuel en entier avant de commencer Gelieve deze gids volledig door te lezen voordat u begint Por favor, lea detenidamente este manual antes de empezar Si prega di leggere attentamente la guida all’uso prima di utilizzare il collare Bitte lesen Sie die ganze Gebrauchsanleitung vor der Inbetriebnahme aufmerksam durch 2 www.petsafe.net FR EN ES NL IT DE IMPORTANT SAFETY INFORMATION Explanation of Attention Words and Symbols Used in this Guide This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION, used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. CAUTION, used without the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in harm to your pet. • Not for use with aggressive dogs. Do not use this product if your dog is aggressive, or if your dog is prone to aggressive behaviour. Aggressive dogs can cause severe injury and even death to their owner and others. If you are unsure whether this product is appropriate for your dog, please consult your veterinarian or certifi ed trainer. • Risk of explosion if battery is replaced by an incorrect type. Do not short circuit, mix old and new batteries, dispose of in fi re, or expose to water. When batteries are stored or disposed, they must be protected from shorting. Dispose of used batteries properly. www.petsafe.net 3 FR EN ES NL IT DE • The PetSafe ® ST-100 Remote Trainer is not a toy. Keep away from the reach of children. Use it only for its training purpose. • Safety during on-lead training. It is vitally important that you and your dog remain safe while learning during on-lead training. Your dog should wear a flat collar or a harness attached to a strong lead, long enough for him to attempt to chase an object, but short enough for him not to reach a road or other unsafe area. You must also be physically strong enough to restrain your dog when he tries to chase. Risk of skin damage. Please read and follow the instructions in this manual. Proper fi t of the collar is important. A collar worn for too long or made too tight on the pet’s neck may cause skin damage. Ranging from redness to pressure ulcers; this condition is commonly known as bed sores. • Avoid leaving the collar on the dog for more than 12 hours per day. • When possible reposition the collar on the pet’s neck every 1 to 2 hours. • Check the fi t to prevent excessive pressure; follow the instructions in this manual. • Never connect a lead to the electronic collar; it will cause excessive pressure on the contacts. • When using a separate collar for a lead, don’t put pressure on the electronic collar. • Wash the dog’s neck area and the contacts of the collar weekly with a damp cloth. • Examine the contact area daily for signs of a rash or a sore. • If a rash or sore is found, discontinue use of the collar until the skin has healed. • If the condition persists beyond 48 hours, see your veterinarian. For additional information on bed sores and pressure necrosis, please visit our website. 4 www.petsafe.net FR EN ES NL IT DE These steps will help keep your pet safe and comfortable. Millions of pets are comfortable while they wear stainless steel contacts. Some pets are sensitive to contact pressure. You may fi nd after some time that your pet is very tolerant of the collar. If so, you may relax some of these precautions. It is important to continue daily checks of the contact area. If redness or sores are found, discontinue use until the skin has fully healed. • The PetSafe ® ST-100 Remote Trainer must be used only on healthy dogs. We recommend that you take your dog to a veterinarian before using the collar if he is not in good health. • Do not shave the pet’s neck as this may increase the risk of skin irritation. • You should not make the collar any more tight than is required for good contact. A collar that is too tight will increase the risk of pressure necrosis in the contact area. Training Guide Please visit our website at www.petsafe.net to download a detailed Training Guide for this unit or contact our Customer Care Centre for further assistance. For a listing of telephone numbers in your area, visit our website at www.petsafe.net. www.petsafe.net 5 FR EN ES NL IT DE Thank you for choosing the PetSafe ® brand. You and your pet deserve a companionship that includes memorable moments and a shared understanding together. Our products and training tools promote a lifestyle of protection, teaching, and love—essentials that infl uence memories for a lifetime. If you have any questions about our products or training your pet, please visit our website at www.petsafe.net or contact our Customer Care Centre. For a listing of Customer Care Centre telephone numbers, visit our website at www.petsafe.net. To get the most protection out of your warranty, please register your product within 30 days at www.petsafe.net. By registering and keeping your receipt, you will enjoy the product’s full warranty and should you ever need to call the Customer Care Centre, we will be able to help you faster. Most importantly, PetSafe ® will never give or sell your valuable information to anyone. Complete warranty information is available online at www.petsafe.net. Table of Contents Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Other Items You May Need . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Radio Systems RFA-498 User Manual FCC Addendum Approved by Radio Systems FCC - USA This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Modification or changes to this equipment not expressly approved by Radio Systems® Corporation may void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a specific installation. If interference does occur to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult customer care, the dealer, or an experienced radio/TV technician for help.

10427 PetSafe Way Knoxville, TN. 37932 865-777-5404 www.petsafe.net AGENCY AGREEMENT Federal Communications Commission Date: 9/18/2012 P.O. Box 429 Columbia, MD 21045 Gentlemen: By signature below, we hereby appoint US Tech employees Sandi McEnery, Alan Ghasiani and George Yang to act as our agents with regard to all FCC equipment authorizations. This appointment will remain in effect until otherwise notified. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Signature: ________________________ Name: Cindy Allen Title: Product Safety and Regulatory Specialist Date: 9/18/2012

FCC Confidentiality Request January 11, 2013 Timco Engineering PO Box 370 Newberry, FL 32669 RE : FCC ID: KE3-3002642 Dear Applications Examiner: With regards to the exhibits submitted in support of the application for FCC ID: KE3-3002642, please classify the following as confidential under the provision of 47 CFR 0.459: -Schematics - File Name: 12-0487.RadioSystems.RFA-498.CONFIDENTIAL Schematics.pdf - Block Diagram – File Name: 12-0487.RadioSystems.RFA-498.CONFIDENTIAL Block Diagram.pdf -Operational Description – File Name: 12-0487.Radio Systems.RFA-498.CONFIDENTIAL ToO.pdf These exhibits contain technical information that Radio Systems Corp. deems to be sensitive and proprietary. Therefore this information cannot be published. If this information were to be made public it could be used to the disadvantage of the applicant in the marketplace. Sincerely, Sandi McEnery US Tech (Authorized Agent for Radio Systems Corp.) 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com

US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 1 of 4 External Photographs Figure 1- EUT US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 2 of 4 Figure 2- EUT Top US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 3 of 4 Figure 3-EUT side 1 US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 4 of 4 Figure 4- EUT side 2

Project:433 MHz Trainer Description: ARTWORK HOUSING LOWER DTT 433MHz ROHS RSC Part: Revision: Revision Description: RSC File Name: 417-775 Adobe Illustrator CS5.1 Created Date: Material: Drawn By:JB Revision Date: Radio Systems CORPORATION The world leader in pet training products 10/1/12 417-775 NOTES: 1. Scale 1:1 2. Do not print lines (dashed, dimension or arrows). 3. Tolerance +/-.3mm 4. SWR X, X=LATEST SOFTWARE REVISION POSTED IN ORACLE. 5. See document 490-897 for serial number layout Figure 2 format #2. Printing: PMS PROCESS WHITE #01 IC:2721A-3002642 Mod: RFA-498 SWRX FCC ID: KE3-3002642 PAD PRINT : PMS PROCESS WHITE LASER ETCH rrrmmyyMnnnnnn Reference 490-897 INCREASED SPACING PER CM INQUIRY XX/YY/ZZ N 13506 RSCXXXX ECO: IC:2721A-3002642 Mod: RFA-498 FCC ID: KE3-3002642 N 13506

US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 1 of 4 INTERNAL PHOTOGRAPHS Figure 1- Back cover removed US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 2 of 4 Figure 2- PCB removed US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 3 of 4 Figure 3- Top of PCB US Tech Test Report: FCC P15.231/IC RSS-210 Report Number: 12-0487 Issue Date: January 11, 2013 Customer: Radio Systems Corporation Model: RFA-498 FCC ID: KE3-3002642 IC: 2721A-3002642 Page 4 of 4 Figure 4- Bottom of PCB

Page 1 of 28 Application for Certification Per Title 47 USC Part 2, Subpart J, Equipment Authorization Procedures, Paragraph 2.907, Certification and Part 15, Subpart C, Intentional Radiators, Paragraph 15.231, Periodic Operation in the band 40.66 MHz to 40.70 MHz and above 70 MHz For the ST-100 REMOTE TRAINER Model: RFA-498 Transmitter UST Project: 12-0487 Issue Date: January 15, 2013 Number of Pages in this report: 28 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com Page 2 of 28 I certify that I am authorized to sign for the test facility and that all of the statements in this report and in the Exhibits attached hereto are true and correct to the best of my knowledge and belief: US Tech (Agent Responsible For Test): By: Name: Alan Ghasiani__________ Title: President – Consulting Engineer Date: January 15, 2013 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com This report shall not be reproduced except in full. This report may be copied in part only with the prior written approval of US Tech. The results contained in this report are subject to the adequacy and representative character of the sample provided. US Tech Test Report: FCC Part 15.231/ RSS-210 Issue Date: January 15, 2013 Report Number: 12-0487 Customer: Radio Systems Corporation Model RFA-498 Transmitter FCC ID: KE3-3006242 IC: 2721A-3002642 Page 3 of 28 MEASUREMENT/TECHNICAL REPORT COMPANY NAME: Radio Systems Corporation MODEL: RFA-498 Transmitter FCC ID: KE3-3002642 IC: 2721A-3002642 DATE: January 15, 2013 This report concerns (check one): Original grant X Class II change_____ Equipment type: 433 MHz band transmitter module Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? yes_____ No X If yes, defer until:_________________ date N.A. agrees to notify the Commission by N.A. date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: US Tech 3505 Francis Circle Alpharetta, GA 30004 Phone Number: (770) 740-0717 Fax Number: (770) 740-1508 US Tech Test Report: FCC Part 15.231/ RSS-210 Issue Date: January 15, 2013 Report Number: 12-0487 Customer: Radio Systems Corporation Model RFA-498 Transmitter FCC ID: KE3-3006242 IC: 2721A-3002642 Page 4 of 28 Table of Contents Paragraph Title Page 1. General Information .................................................................................................. 6 1.1 Product Description ............................................................................................ 6 1.2 Characterization of Test Sample ...................................................................... 6 1.3 Related Submittal(s)/Grant(s) ............................................................................ 6 1.4 The EUT is subject to the following authorizations: ........................................... 6 2. Tests and Measurements ......................................................................................... 7 2.1 Configuration of Tested System ........................................................................ 7 2.2 Test Facility ........................................................................................................ 7 2.3 Test Equipment .................................................................................................. 7 2.4 Modifications to Equipment ................................................................................ 9 2.5 Test Procedure ............................................................................................... 9 2.5.1 Number of Measurements for Intentional Radiators (15.31(m)) ..................... 9 2.5.2 Frequency Range of Radiated Measurements (Part 15.33(a)/RSS Gen 4.10) 10 Intentional Radiator ................................................................................................ 10 Unintentional Radiator ........................................................................................... 10 2.6 EUT Antenna Description (FCC Sec. 15.203) .................................................. 13 2.7 Intentional Radiator, Power Lines Conducted Emissions (47 CFR 15.207) ..... 14 2.8 Field Strength of Fundamental (47 CFR 15.231(b)) ......................................... 15 2.9 Limits for Operation in the Band above 70 MHz (CFR15.231 (b)) ................... 16 2.10 Peak Radiated Spurious Emissions, 30 MHz to 1000 MHz (47 CFR 15.205, 15.209, 15.225) ......................................................................................................... 17 2.11 Transmitter Duty Cycle (47 CFR 15.35 (c)) ................................................... 17 2.12 Bandwidth of Fundamental (CFR15.231 (c)) ............................................... 21 2.13 Power Line Conducted Emissions for Transmitter and Receiver/Digital Apparatus (47 CFR 15.107). ..................................................................................... 22 2.14 Unintentional Radiator Radiated Emissions (47 CFR 15.33(a); 15.109(a)) .. 24 2.15 Emissions Mask (RSS-210, A1.2.3.2(5)i-iv) .................................................. 26 2.16 Carrier Frequency Stability (RSS-210, A1.2.3.2(4)) ...................................... 28 US Tech Test Report: FCC Part 15.231/ RSS-210 Issue Date: January 15, 2013 Report Number: 12-0487 Customer: Radio Systems Corporation Model RFA-498 Transmitter FCC ID: KE3-3006242 IC: 2721A-3002642 Page 5 of 28 Table of Contents (cont’d.) List of Figures Figure Title Page Figure 1. Test Configuration .......................................................................................... 11 Figure 2. Deactivation per 15.231(a)(1) ........................................................................ 12 Figure 3. Figure 3. Duty Cycle ....................................................................................... 18 Figure 4. Occupied Bandwidth (20 dB BW) .................................................................. 21 …
