KE3-3003444Training e-collar with health monitor

Quick Start Guide FieldSentinel 825/1825 2 Read all the safety information below before using the product. FieldSentinel is not a medical device and should not be used as a substitute for professional medical judgment. It is not designed or intended for use in the diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or prevention of any condition or disease. Please consult your veterinarian prior to making any decisions related to your dog’s health. Always consider your dog’s health! DO NOT exercise your dog to the point of exhaustion. • This product is intended to be used only for recreational purposes and not for medical purposes, and is not intended to diagnose, monitor, treat, cure, or prevent any disease or condition. • The heart rate, heart rate variability, and other readings are for reference only, and no responsibility is accepted for the consequences of any erroneous readings. • NOTICE: Avoid contact with spray cleaners & Deet as they could damage the product’s plastics. To avoid serious risk or injury to your dog, it is important you complete the following steps in order before you begin using this system. Thank you for choosing the SportDOG® Brand FieldSentinel. With proper use, this system will help you train your dog efficiently and safely. The Quick Start Guide will get you and your dog started with this remote training system. For the best experience, review this guide thoroughly. For more detailed information, we recommend reading the complete manual online. You can easily access it with the QR code provided. It will include information on Collar stim ranges; pairing your Collar to the Handheld, etc. 3 In addition to being a fully functional training e-collar, this system also monitors your dog’s health. This will allow you to know how your dog is doing, even if he is not within eyesight, and quickly address any potentially dangerous health situations. HEALTH SENSORS will alert you when there has been a serious change. 4 Handheld between uses to maximize battery life. 1. Connect the magnetic charger to the back of the Handheld by aligning the two and letting it snap into place. The Handheld takes 2 hours to fully charge. 2hrs 2. Snap the charging clip on the Collar by aligning the brass contacts on the clip to the connection points on the Collar and matching up the SportDOG ® logos. The Collar takes 4 hours to charge. 4hrs 3. Connect each of the USB ends on the charging cables to the wall adapter and plug into a standard wall outlet. The Collar and Handheld Indicator Lights will be solid green while charging and flash green when fully charged. HANDHELD: To power the Handheld ON or OFF, press and hold the power button (found on top) until it beeps. COLLAR: To power the Collar ON, press and release the power button (between the probes). The Collar will beep, and the Indicator Light will flash red or green depending on battery status. The health sensor lights will glow steady green. To power OFF, press and hold the button until the Collar beeps and light is red. FPO 5 STEP 2: GET TO KNOW THE HANDHELD & COLLAR INDICATOR LIGHT Indicates battery status (slow blink) or lights accordingly when button pressed. TOGGLE SWITCH Allows for quickly switching between Dog 1 and Dog 2. SIDE BUTTON * 1-7 on Dial: Tone V/T on Dial: Vibe UPPER BUTTON * 1-7 on Dial: Continuous Stim V/T on Dial: Vibe LOWER BUTTON * 1-7 on Dial: Momentary (nick) Stim V/T on Dial: Vibe ALERT LED Begins flashing when your dog’s composite health score reaches its threshold (for more info see page x). Red - DOG 1; will flash Blue when powering on. POWER BUTTON Powers the Handheld ON or OFF by pressing and holding until it tones. INTENSITY DIAL Adjusts the intensity level of static stimulation or sets the collar function to Vibe or Tone. MUD PLUG On the back of the Handheld. Important to keep this sealed. PROBES/ CONTACT POINTS Administer the stimulation to your dog. These are not interchangeable. HEALTH SENSORS Monitor your dog’s health by detecting vitals during use. INDICATOR LIGHT Indicates when the Collar has been turned on or off, serves as a low-battery indicator, and also indicates when a continuous or momentary (nick) static stimulation button is pressed. POWER BUTTON Powers the Collar ON or OFF by pressing and holding until it tones. *Your Handheld is programmed to Mode 1 (toggle online manual. 6 and use. as necessary. down on the dog’s neck. 1. Your dog should be standing comfortably while fitting the collar. 2. Position the collar as high as possible on your dog’s neck and slightly to either side, not directly centered. Buckle the collar so that it fits snuggly. 3. You should only be able to fit one finger between the strap and your dog’s neck. This will help ensure the health sensor and the contact points are both touching your dog’s skin. If your dog has a long or thick coat, trim the hair around the contact points to ensure contact with the skin. 7 collar from your dog while traveling or while in his kennel. stimulation. Once the collar is fit on your dog and powered on, it needs up to 5 MINUTES to calibrate to your dog and start tracking vitals allowing your hunt/training session to start with a valid heart rate. Do not remove the collar or turn it off during this time. Every time you put the collar on your dog, it is important to make sure you wait 5 minutes for the collar to calibrate before use. Also, keep the health monitor sensors are clean by using soap, warm water, and a microfiber cloth. During this 5 minutes, there should be minimal motion of your dog. The system will do X when ready to be used and collecting health information. For effective training, it is important to find the best level of static stimulation for your dog. RECOGNITION LEVEL: The lowest level of static stimulation at which your dog acknowledges feeling the stimulation through a reaction. This reaction can be flicking his ears, looking around in curiosity, or standing up from a sitting or lying p…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 13, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: KE3-3003444, KE3-30034451 Radio Systems Corporation certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Deborah J. LeMaster Regulatory Compliance Specialist Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 13, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: KE3-3003444, KE3-30034451 Radio Systems Corporation certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Deborah J. LeMaster Regulatory Compliance Specialist

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 13, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: KE3-3003444, KE3-30034451 Radio Systems Corporation certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0014529481 Name: Radio Systems Corporation Address: 10427 PetSafe Way, Knoxville, TN 37932 Contact Person: Deborah J. LeMaster Tel.: 865-909-7296 Email: [email protected] Sincerely, Deborah J. LeMaster Regulatory Compliance Specialist

3505 Francis Circle, Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com SDoC Attestation Letter Date: July 13, 2023 Subject: SDoC Attestation Letter: FCC ID: KE3-3003444 The following equipment meets FCC Part 15 SDoC Requirements for digital device: Responsible Party: Deborah LeMaster Radio Systems Corporation 10427 PetSafe Way Knoxville, TN 37932 Equipment: Field Sentinel Remote Trainer Model Name: STD00-17813 Sincerely, By: __________________________ ___George Yang__- Agent (Signature/Title) (Print name)

AGENCY AGREEMENT Federal Communications Commission Date: 7/13/2023 P.O. Box 429 Columbia, MD21045 Gentlemen: By signature below, we hereby appoint US Tech employees Sandi McEnery, Alan Ghasiani and George Yang to act as our agents with regard to all FCC equipment authorizations. This appointment will remain in effect until otherwise notified. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Name: Deborah J. LeMaster Signature: Title: Regulatory Compliance Specialist Date: 7/13/2023

Request for Confidentiality Date: ___July 13, 2023_____ Subject: Confidentiality Request for: ___FCC ID: KE3-3003444 IC: 2721A-3003444 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual Radio Systems Corporation has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: __________________________ George Yang__- Agent (Signature/Title) (Print name)

US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 1 of 6 EXTERNAL PHOTOGRAPHS Figure 1. Top of EUT (STD00-17813) Note: Cable indicated above are for programming purposes only US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 2 of 6 Figure 2. Back of EUT (STD00-17813) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 3 of 6 Figure 3. Left Side of EUT (STD00-17813) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 4 of 6 Figure 4. Right Side of EUT (STD00-17813) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 5 of 6 Figure 5. Front of EUT (STD00-17813) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 6 of 6 Figure 6. Bottom of EUT (STD00-17813)

Radio Systems Sample Label and Label Location Field Sentinel Collar Page 1 of 1 1111222222 cmwwyy MOD: STD00-17813 CONTAINS FCC ID: KE3-3003444 FCC ID: QOQ-GM240S IC: 2721A-3003444 IC: 5123A-GM240S Top View 300-3444 5VDC 1A Side View Notes: 1. Laser etch artwork as shown 2. Do not print part outlines or dimensions (For ref erence only) 3. Tolerance +/- .3mm 4. Scale: 1 to 1 5. 1111222222: ref er to 490-897 latest version, Figure 1, RSC serialization single label format standard section. 6. cmwwyy: ref er to 490-897 latest version, Figure 9, RSC standard date code format section.

US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 1 of 4 INTERNAL PHOTOGRAPHS Figure 1. Back Cover Removed (STD00-17813) Note: Cable indicated above are for programming purposes only US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 2 of 4 Figure 2. Main PCB Front and Antenna (STD00-17813) Antenna Radio 2.4 GHz Radio and Antenna US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 3 of 4 Figure 3. Main PCB Back (STD00-17813) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 4 of 4 Figure 4. Battery (STD00-17813)

US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 1 of 7 MPE/SAR exclusion/RF Exposure Evaluation Maximum Permissible Exposure to RF (MPE) CFR 15.247 (i), CFR 1.1310 (e) The maximum exposure level to the public from the RF power of the EUT shall not exceed a power density, S as per the respective limits in Table 1 below, at a distance, d, of 5 cm (portable condition) from the EUT. TABLE 1—LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 f = frequency in MHz * = Plane-wave equivalent power density Therefore, for: MPE for 902 MHz – 928 MHz: Limit: f/1500 mW/cm 2 = 915/1500 = 0.61 mW/cm 2 Peak Power (dBm) = +27.08 dBm Peak Power (Watts) = 0.5105 W Gain of Transmit Antenna = +2.0 dB i = 1.585 numeric d = Distance = 5 cm = 0.05 m S = (PG/ 4π ππ πd 2 ) = EIRP/4A = 0.5105 (1.585)/4*π*0.05*0.05) = 0.8092/0.0314 = 25.771 W/m 2 = (25.771 W/m 2 ) (1m 2 /W) (0.1 mW/cm 2 ) = 2.5771 mW/cm 2 US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 2 of 7 MPE for 2400 – 2483.5 MHz: Limit = 1.0 mW/cm 2 Peak Power (dBm) = +10.33 dBm (FCC ID: QOQ-GM240S) Peak Power (Watts) = 0.0108 W Gain of Transmit Antenna = +2.8 dBi = 1.905 numeric d = Distance = 5 cm = 0.05 m S = (PG/ 4πd2) = EIRP/4A = 0.0108 (1.905)/4*π*0.05*0.05 = 0.0206/0.0314 = 0.6561 W/ m2 = (0.6561 W/m 2 ) (1m 2 /W) (0.1 mW/cm 2 ) = 0.06561 mW/cm 2 Simultaneous MPE (900 MHz band +2.4 GHz band) Calculation: Total MPE (%) = [(900 MHz MPE result*100%] + [(2.4 GHz MPE result*100%] << 100% = [(2.5771%] + [(0.06561%] = 2.6427% << 100% Calculation above shows device complies with the simultaneous MPE requirement. US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 3 of 7 SAR Exclusion: General SAR test exclusion per KDB 447498 D01 V06 section 4.3 Test exclusion conditions are based on source-based time averaged maximum conducted output power of the RF channel, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel mW) / (min. test separation distance, mm)] * [( √f GHz )] Where the result must be ≤ 3.0 for 1-g SAR and ≤ 7.0 for 10-g SAR EUT source based time averaged (SBTA) = (output power + antenna gain * duty cycle) SBTA= 27.08 dBm + 2.0 dBm * (809.09 mW) * (0.06%) = 48.59 mW 48.59 mW/15 mm * ( √0.915 GHz) = 3.09 ≤ 7.0 for 10-g SAR Extremity EUT duty cycle measurement: DC= T total = 2.3 sec + 0.995 sec = 3.295 sec, T on = 199 mSec therefore 199 mSec/3.295 sec = 0.06% US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 4 of 7 RSS-102, 2.5.1 Exemption Limits for Routine Evaluation SAR Evaluation: SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 20 cm except when the device operates at or below the applicable output power levels presented in Table 1 below. Output power level shall be the higher of the maximum conducted or equivalent isotopically radiated power (e.i.r.p) source-based time averaged (SBTA) output power. In this case the maximum SBTA value = 48.59 mW is used. The limit at a separation distance of 15 mm @ 925 MHz = (37.8 mW * 2.5) = 94.5 mW for limb exposure. The EUT meets the Exemption Limits. The 2402-2480 MHz radio is not used at a distance less than 12 mm where it was pre-approved under FCC ID: QOQ-GM240S and IC: 5123A-GM240S; therefore, it is considered to be exempt from routine evaluations. A 2.5 multiplication factor is also added to the limit for limb exposure. All calculations performed by: Test Engineer: ___Gabriel Medina___ Date: July 13, 2023 Signature:____________________ US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 5 of 7 RSS-102, 2.5.2 compliance: At or above 300 MHz and below 6 GHz and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 x 10 -2 ƒ0.6834 W (adjusted for tune-up tolerance), where ƒ is in MHz; for 905 - 925 MHz: Limit= 1.31 x 10 -2 x 9150.6834 = 1.38 Watts Max EIRP = +7.35 dBm + 1.0 dBi = 8.35 dBm = 6.8mW << 1380 mW 2402 MHz – 2480 MHz: Limit= 1.31 x 10 -2 x 24400.6834 = 2.7 Watts Max EIRP = 10.33 dBm + 2.8 dBi = 13.13 dBm = 20.55mW << 2700 mW Simultaneous Evaluation Percentage: [Max EIRP (2.4 GHz)/ Limit in Watts * 100] + [Max EIRP (900 MHz)/Limit in Watts * 100] <<< 100% [(0.02055/2.71) * 100] + [(0.0068/1.38) *100] = 1.251 % << 100 % All calculations performed by: Date: July 13, 2023 Test Engineer: Gabriel Medina Signature:_ ___________________ US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 6 of 7 Antenna Separation Photographs Figure 1. Side View Antenna identified with Blue arrow shows that there is at least 15…

Text truncated - open the document above for the full version.

Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 Features: • 860-930MHz • Impedance 50 Ohm • Plastic support helical antenna • Length 29.5mm, • Gain 2dBi • SMD Mounting on PCB • RoHS Compliant Applications: • 868MHz and 915MHz ISM Band Systems • IoT systems • Metering, Automation • Security, surveillance • Remote controls, toys All dimensions are in mm / inches Issue: 1943 In the effort to improve our products, we reserve the right to make changes judged to be necessary. For more information: 1 Pulse Worldwide Headquarters Pulse/Larsen Antennas Europe Headquarters Pulse (Suzhou) Wireless Products Co, Inc. 15255 Innovation Drive #100 18110 SE 34 th St Bldg 2 Suite 250 Pulse GmbH & Do, KG 99 Huo Ju Road(#29 Bldg,4 th Phase San Diego, CA 92128 Vancouver, WA 98683 Zeppelinstrasse 15 Suzhou New District USA USA Herrenberg, Germany Jiangsu Province, Suzhou 215009 PR China Tel:1-858-674-8100 Tel: 1-360-944-7551 Tel: 49 7032 7806 0 Tel: 86 512 6807 9998 - Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 ELECTRICAL SPECIFICATIONS Antenna Type Helical monopole Frequency 860-930MHz Nominal Impedance 50 Ω VSWR Max 2.5 Radiation Pattern Omni Gain 2 dBi Efficiency 65% Polarization Linear Power Withstanding 2W MECHANICAL SPECIFICATIONS Overall Length 29.5mm Weight 2.52g Antenna Color / Material White Fix system SMD+Glue Recommended Glue Resinlab EP1320LV Black Solder Paste Thickness Min 0.15mm MSL 3 ENVIRONMENTAL SPECIFICATIONS Operating Temperature -40°C~+85°C Storage Temperature -40°C~+85°C RoHS Compliant Yes OTHER SPECIFICATIONS Issue: 1943 2 In the effort to improve our products, we reserve the right to make changes judged to be necessary. Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 MECHANICAL DRAWING Suction Pick Area Dimension Unit: mm[inch] Issue: 1943 3 In the effort to improve our products, we reserve the right to make changes judged to be necessary. Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 FIX SYSTEM RECOMMENDATION Fix system 1. SMD process 2. Solder paste thickness: minimum 0.15mm 3. Glue is required, Recommended Glue: Resinlab EP1320LV Black, usage and position see below recommended area. Solder paste Glue Recommended Glue Type Issue: 1943 4 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 FIX SYSTEM RECOMMENDATION Fix system 1. Glue position on PCB for recommendation Glue position on PCB for recommendation Issue: 1943 5 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 FIX SYSTEM RECOMMENDATION Solder effect Back view of glue area Issue: 1943 6 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 TEST SETUP PWB Layout for W3136 SMD Helical Antenna Solder pad Feed contact Ground via hole Tuning Component Match Component Feed line 50ohm Issue: 1943 7 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 TEST SETUP PWB ground clearance area (Top):40x9.5mm PWB ground clearance area (Bottom):40x9.5mm Top Ground Clearance Area(40x9.5mm) All metallization should be removed from all PWB Layers Bottom Issue: 1943 8 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 TEST SETUP PWB Pad dimension in top copper Issue: 1943 9 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 TEST SETUP PWB Layout, Pulse PWB size:121x40mm, Thickness 1.0mm, other size boards can be used depending on customer size. Top Bottom Issue: 1943 10 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 TEST SETUP PWB Layout, Pulse PWB size:121x40mm, Thickness 1.0mm, other size boards can be used depending on customer size. Antenna feed point Capacitance for S11 matching , 3.6pF, series Inductance for S11 matching , 8.2nH, shunt Note : Exact matching and tuning components value depend on application , board size ,cover etc. Issue: 1943 11 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 CHARTS Measured on the 121x40mm test board with tuning and matching circuit Issue: 1943 12 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 TESTCHARSETSUP Measured on the 121x40mm test board with tuning and matching circuit. Test in PSU China Chamber. z x Y Issue: 1943 13 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 CHARTS Issue: 1943 14 In the effort to improve our products, we reserve the right to make changes judged to be necessary. . Description: 860-930MHz Embedded Helical Antenna Series: SMD Helical Antenna PART NUMBER: W3136 CHARTS Issue: 1943 15 In the effort to improve our products, we reserve the…

Text truncated - open the document above for the full version.

Page 1 of 48 Application For Part 2, Subpart J, Paragraph 2.907 Equipment Authorization of Certification for an Intentional Radiator per Part 15, Subpart C, paragraphs 15.207, 15.209 and 15.247 And IC Radio Standards Specification: RSS-247 Innovation, Science, and Economic Development Canada Certification Per IC RSS-Gen General Requirements for Radio Apparatus And RSS-247Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSS) and License-Exempt Local Area Network (LE-LAN) Devices For the Radio Systems Corporation Model: STD00-17813 FCC ID: KE3-3003444 IC:2721A-3003444 UST Project: 23-0110 Issue Date: July 13, 2023 Total Pages in This Report: 48 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com Page 2 of 48 I certify that I am authorized to sign for the Test Agency and that all of the statements in this report and in the Exhibits attached hereto are true and correct to the best of my knowledge and belief: US TECH (Agent Responsible For Test): By: Alan Ghasiani Name: Title: Compliance Engineer – President Date July 13, 2023 This report shall not be reproduced except in full. This report may be copied in part only with the prior written approval of US Tech. The results contained in this report are subject to the adequacy and representative character of the sample provided. This report must not be used to claim product certification, approval, or endorsement by NVLAP, NIST or any agency of the Federal Government. 3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 Fax: 770-740-1508 www.ustech-lab.com US Tech Test Report: FCC Part 15 Certification/ RSS 247 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 3 of 48 MEASUREMENT TECHNICAL REPORT COMPANYS NAME: Radio Systems Corporation MODEL: STD00-17813 FCC ID: KE3-3003444 IC: 2721A-3003444 DATE: July 13, 2023 This report concerns (check one): Original grant X Class II change Equipment type: FHSS Transmitter Module Technical: Radio Technology: FHSS Frequency of Operation (MHz): 905-925 Output Power (dBm): +27.08 Type of modulation: GFSK # of Hopping Frequencies 50 Antenna Gain Refer to Table 5 Software used to program EUT: Silicon Labs Simplicity Commander EUT firmware number: 820-578_SDFS_Collar_v02.hex Maximum Power Setting (dBm) 30 Power Setting: 13 Report prepared by: US Tech 3505 Francis Circle Alpharetta, GA 30004 Phone Number: (770) 740-0717 Fax Number: (770) 740-1508 US Tech Test Report: FCC Part 15 Certification/ RSS 247 FCC ID: KE3-3003444 IC: 2721A-3003444 Test Report Number: 23-0110 Issue Date: July 13, 2023 Customer: Radio Systems Corporation Model: STD00-17813 Page 4 of 48 Table of Contents Paragraph Title Page 1 General Information .............................................................................................. 7 1.1 Purpose of this Report ...................................................................................... 7 1.2 Characterization of Test Sample ...................................................................... 7 1.3 Product Description .......................................................................................... 7 1.4 Configuration of Tested System ....................................................................... 7 1.5 Test Facility ...................................................................................................... 8 1.6 Related Submittals ........................................................................................... 8 1.6.1 The EUT is subject to the following FCC authorizations: ........................... 8 2 Tests and Measurements ................................................................................... 10 2.1 Test Equipment .............................................................................................. 10 2.2 Modifications to EUT Hardware ...................................................................... 11 2.3 Number of Measurements for…
