KE3-30034451Training e-collar with health monitor

Quick Start Guide FieldSentinel 825/1825 2 Read all the safety information below before using the product. FieldSentinel is not a medical device and should not be used as a substitute for professional medical judgment. It is not designed or intended for use in the diagnosis of disease or other conditions, or in the cure, mitigation, treatment, or prevention of any condition or disease. Please consult your veterinarian prior to making any decisions related to your dog’s health. Always consider your dog’s health! DO NOT exercise your dog to the point of exhaustion. • This product is intended to be used only for recreational purposes and not for medical purposes, and is not intended to diagnose, monitor, treat, cure, or prevent any disease or condition. • The heart rate, heart rate variability, and other readings are for reference only, and no responsibility is accepted for the consequences of any erroneous readings. • NOTICE: Avoid contact with spray cleaners & Deet as they could damage the product’s plastics. To avoid serious risk or injury to your dog, it is important you complete the following steps in order before you begin using this system. Thank you for choosing the SportDOG® Brand FieldSentinel. With proper use, this system will help you train your dog efficiently and safely. The Quick Start Guide will get you and your dog started with this remote training system. For the best experience, review this guide thoroughly. For more detailed information, we recommend reading the complete manual online. You can easily access it with the QR code provided. It will include information on Collar stim ranges; pairing your Collar to the Handheld, etc. 3 In addition to being a fully functional training e-collar, this system also monitors your dog’s health. This will allow you to know how your dog is doing, even if he is not within eyesight, and quickly address any potentially dangerous health situations. HEALTH SENSORS will alert you when there has been a serious change. 4 Handheld between uses to maximize battery life. 1. Connect the magnetic charger to the back of the Handheld by aligning the two and letting it snap into place. The Handheld takes 2 hours to fully charge. 2hrs 2. Snap the charging clip on the Collar by aligning the brass contacts on the clip to the connection points on the Collar and matching up the SportDOG ® logos. The Collar takes 4 hours to charge. 4hrs 3. Connect each of the USB ends on the charging cables to the wall adapter and plug into a standard wall outlet. The Collar and Handheld Indicator Lights will be solid green while charging and flash green when fully charged. HANDHELD: To power the Handheld ON or OFF, press and hold the power button (found on top) until it beeps. COLLAR: To power the Collar ON, press and release the power button (between the probes). The Collar will beep, and the Indicator Light will flash red or green depending on battery status. The health sensor lights will glow steady green. To power OFF, press and hold the button until the Collar beeps and light is red. FPO 5 STEP 2: GET TO KNOW THE HANDHELD & COLLAR INDICATOR LIGHT Indicates battery status (slow blink) or lights accordingly when button pressed. TOGGLE SWITCH Allows for quickly switching between Dog 1 and Dog 2. SIDE BUTTON * 1-7 on Dial: Tone V/T on Dial: Vibe UPPER BUTTON * 1-7 on Dial: Continuous Stim V/T on Dial: Vibe LOWER BUTTON * 1-7 on Dial: Momentary (nick) Stim V/T on Dial: Vibe ALERT LED Begins flashing when your dog’s composite health score reaches its threshold (for more info see page x). Red - DOG 1; will flash Blue when powering on. POWER BUTTON Powers the Handheld ON or OFF by pressing and holding until it tones. INTENSITY DIAL Adjusts the intensity level of static stimulation or sets the collar function to Vibe or Tone. MUD PLUG On the back of the Handheld. Important to keep this sealed. PROBES/ CONTACT POINTS Administer the stimulation to your dog. These are not interchangeable. HEALTH SENSORS Monitor your dog’s health by detecting vitals during use. INDICATOR LIGHT Indicates when the Collar has been turned on or off, serves as a low-battery indicator, and also indicates when a continuous or momentary (nick) static stimulation button is pressed. POWER BUTTON Powers the Collar ON or OFF by pressing and holding until it tones. *Your Handheld is programmed to Mode 1 (toggle online manual. 6 and use. as necessary. down on the dog’s neck. 1. Your dog should be standing comfortably while fitting the collar. 2. Position the collar as high as possible on your dog’s neck and slightly to either side, not directly centered. Buckle the collar so that it fits snuggly. 3. You should only be able to fit one finger between the strap and your dog’s neck. This will help ensure the health sensor and the contact points are both touching your dog’s skin. If your dog has a long or thick coat, trim the hair around the contact points to ensure contact with the skin. 7 collar from your dog while traveling or while in his kennel. stimulation. Once the collar is fit on your dog and powered on, it needs up to 5 MINUTES to calibrate to your dog and start tracking vitals allowing your hunt/training session to start with a valid heart rate. Do not remove the collar or turn it off during this time. Every time you put the collar on your dog, it is important to make sure you wait 5 minutes for the collar to calibrate before use. Also, keep the health monitor sensors are clean by using soap, warm water, and a microfiber cloth. During this 5 minutes, there should be minimal motion of your dog. The system will do X when ready to be used and collecting health information. For effective training, it is important to find the best level of static stimulation for your dog. RECOGNITION LEVEL: The lowest level of static stimulation at which your dog acknowledges feeling the stimulation through a reaction. This reaction can be flicking his ears, looking around in curiosity, or standing up from a sitting or lying p…

Text truncated - open the document above for the full version.

3505 Francis Circle Alpharetta, GA 30004 PH: 770-740-0717 www.ustech-lab.com SDoC Attestation Letter Date: July 11, 2023 Subject: SDoC Attestation Letter: FCC ID: KE3-30034451 The following equipment meets FCC Part 15 SDoC Requirements for digital device: Responsible Party: Radio Systems Corporation 10427 Petsafe way Knoxville, TN 37932 Debbie LeMaster Regulatory Compliance Specialist P: +1 865.909.7296 Email: [email protected] Equipment: Field Sentinel Model Name: 300-3445, and 30034451-1 Sincerely, By: __________________________ ___George Yang__- Agent (Signature/Title) (Print name)

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 13, 2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: KE3-30034451 KE3-3003444, Radio Systems Corporation certifies that, as of the date of the filing of the application, we designate ourselves as the U.S. agent for service of process. Designated U.S. Agent Information: FRN: 0014529481 Name: Radio Systems Corporation Address: 10427 PetSafe Way, Knoxville, TN 37932 Contact Person: Deborah J. LeMaster Tel.: 865-909-7296 Email: [email protected] Sincerely, Deborah J. LeMaster Regulatory Compliance Specialist

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 13, 2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: KE3-3003444, KE3-30034451 Radio Systems Corporation certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Deborah J. LeMaster Regulatory Compliance Specialist Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 13, 2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: KE3-3003444, KE3-30034451 Radio Systems Corporation certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Deborah J. LeMaster Regulatory Compliance Specialist

Request for Confidentiality Date: ___July 11, 2023_____ Subject: Confidentiality Request for: ___FCC ID: KE3-30034451 IC: 2721A-30034451 Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual Radio Systems Corporation has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: __________________________ George Yang__- Agent (Signature/Title) (Print name)

AGENCY AGREEMENT Federal Communications Commission Date: 7/13/2023 P.O. Box 429 Columbia, MD21045 Gentlemen: By signature below, we hereby appoint US Tech employees Sandi McEnery, Alan Ghasiani and George Yang to act as our agents with regard to all FCC equipment authorizations. This appointment will remain in effect until otherwise notified. I further certify by signature below that no party (per 47 CFR 1.2002(b)) to the application is subject to a denial of Federal benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This appointment includes the authority to complete FCC Form 731 on our behalf and sign the application as an authorized agent. Name: Deborah J. LeMaster Signature: Title: Regulatory Compliance Specialist Date: 7/13/2023

US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 1 of 13 EXTERNAL PHOTOGRAPHS Figure 1. Top of EUT, one-mile (300-3445) Note: Cable indicated above are for programming purposes only US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 2 of 13 Figure 2. Back of EUT, one-mile (300-3445) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 3 of 13 Figure 3. Left Side of EUT, one-mile (300-3445) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 4 of 13 Figure 4. Right Side of EUT, one-mile (300-3445) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 5 of 13 Figure 5. Front of EUT, one-mile (300-3445) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 6 of 13 Figure 6. Bottom of EUT, one-mile (300-3445) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 7 of 13 Figure 7. Antenna, one-mile (300-3445) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 8 of 13 Figure 8. Top of EUT, Half-Mile (300-3445-1) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 9 of 13 Figure 9. Back of EUT, Half-Mile (300-3445-1) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 10 of 13 Figure 10. Left Side of EUT, Half-Mile (300-3445-1) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 11 of 13 Figure 11. Right Side of EUT, Half-Mile (300-3445-1) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 12 of 13 Figure 12. Front of EUT, Half-Mile (300-3445-1) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: 300-3445, and 300-34451-1 Page 13 of 13 Figure 13. Bottom of EUT, Half-Mile (300-3445-1)

MFG: Radio Systems UST# 23-0105-107 Issue Date: July 28, 2023 Model: STD00-17812 & STD00-17811 FCC ID: KE3-30034451 IC: 2721A-30034451 Page 1 of 2 MOD: STD00-17812 1111222222 cmwwyy FCC ID: KE3-30034451 IC: 2721A-30034451 CONTAINS FCC ID: QOQ-GM240S IC: 5123A-GM240S 5VDC 1A 417-1343 Notes: 1. Laser etch artwork as shown 2. Do not print part outlines or dimensions (For ref erence only) 3. Tolerance +/- .3mm 4. Scale: 1 to 1 5. 1111222222: ref er to 490-897 latest version, Figure 11, RSC serialization single label f ormat standard section. 6. cmwwyy: ref er to 490-897 latest version, Figure 9, RSC standard date code f ormat section. 7. MOD: STD00-17812 , 1 Mile Transmitter MFG: Radio Systems UST# 23-0105-107 Issue Date: July 28, 2023 Model: STD00-17812 & STD00-17811 FCC ID: KE3-30034451 IC: 2721A-30034451 Page 2 of 2 MOD: STD00-17811 1111222222 cmwwyy FCC ID: KE3-30034451 IC: 2721A-30034451 CONTAINS FCC ID: QOQ-GM240S IC: 5123A-GM240S 5VDC 1A 417-1343 Notes: 1. Laser etch artwork as shown 2. Do not print part outlines or dimensions (For ref erence only) 3. Tolerance +/- .3mm 4. Scale: 1 to 1 5. 1111222222: ref er to 490-897 latest version, Figure 11, RSC serialization single label f ormat standard section. 6. cmwwyy: ref er to 490-897 latest version, Figure 9, RSC standard date code f ormat section. 7. MOD: STD00-17811, ½ Mile Transmitter

US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 1 of 11 INTERNAL PHOTOGRAPHS Figure 1. Back Cover Removed, One-Mile (STD00-17812) Note: Cable indicated above are for programming purposes only US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 2 of 11 Figure 2. Main PCB Front, One-Mile (STD00-17812) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 3 of 11 Figure 3. Main PCB Back, One-Mile (STD00-17812) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 4 of 11 Figure 4. Close up of 2.4 GHz Radio, One-Mile (STD00-17812) 2.4 GHz Radio and Antenna US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 5 of 11 Figure 5. Battery, One-Mile (STD00-17812) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 6 of 11 Figure 6. Back Cover Removed, Half-Mile (STD00-17811) Note: Cables indicated above are for programming purposes only US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 7 of 11 Figure 7. Main PCB Front, Half-Mile (STD00-17811) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 8 of 11 Figure 8. Main PCB Back, Half-Mile (STD00-17811) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 9 of 11 Figure 9. Close up of 2.4 GHz Radio, Half-Mile (STD00-17811) 2.4 GHz Radio and Antenna US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 10 of 11 Figure 10. Antenna, Half-Mile (STD00-17811) US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105, and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812, and STD00-17811 Page 11 of 11 Figure 11. Battery, Half-Mile (STD00-17811)

US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105 and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812 and STD00-17811 Page 1 of 12 MPE/SAR exclusion/RF Exposure Evaluation Maximum Permissible Exposure to RF (MPE) CFR 15.247 (i), CFR 1.1310 (e) The maximum exposure level to the public from the RF power of the EUT shall not exceed a power density, S as per the respective limits in Table 1 below, at a distance, d, of 5 mm for 900 MHz and 10 mm for 2.4 GHz (portable condition) from the EUT. TABLE 1—LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 *100 30 1.34-30 824/f 2.19/f *180/f 2 30 30-300 27.5 0.073 0.2 30 300-1,500 f/1500 30 1,500-100,000 1.0 30 Note 1: f = frequency in MHz * = Plane-wave equivalent power density Note 2: multiplication factor of 2.5 applied to the limits to convert to extremity limits. As required by §§ 2.1091(d)(2) and 2.1093(d)(5), RF exposure compliance must be determined at the maximum average power level according to source-based time-averaging requirements to determine compliance for general population exposure conditions. Unless it is specified differently in the published RF exposure KDB procedures, these requirements also apply to test reduction and test exclusion considerations. Time-averaged maximum conducted output power applies to SAR and, as required by § 2.1091(c), time-averaged effective radiated power applies to MPE. Therefore, for: MPE for 902 MHz – 928 MHz Extremity Limit: f/1500 mW/cm 2 = 915/1500 = 0.61 mW/cm 2 x 2.5 = 1.525 mW/cm 2 Extremity limit Peak Power (dBm) = +27.35 dBm * 8.65% (DC from below) = 2.37 dBm Peak Power (Watts) = 0.0017 W Gain of Transmit Antenna = +1.0 dB i = 1.259 numeric d = Distance = 5 mm = 0.005 m S = (PG/ 4π ππ πd 2 ) = EIRP/4A = 0.002(1.259)/4*π*0.005*0.005) = 0.0021/0.0003 = 8.333 W/m 2 = (8.333 W/m 2 ) (1m 2 /W) (0.1 mW/cm 2 ) = 0.8333 mW/cm 2 << 1.525 mW/cm 2 US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105 and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812 and STD00-17811 Page 2 of 12 EUT duty cycle measurement: TX on = 99.5 mSec x 2 = 199.0 mSec TX on+TX off = 2.3 sec DC = 0.199/2.3 = 0.0865 = 8.65% US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105 and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812 and STD00-17811 Page 3 of 12 MPE for 2400 – 2483.5 MHz Extremity Limit:: Limit = 1.0 mW/cm 2 x 2.5 = 2.5 mW/cm 2 Extremity limit Peak Power (dBm) = +10.33 dBm (FCC ID: QOQ-GM240S) Peak Power (Watts) = 0.0107 W Gain of Transmit Antenna = +2.8 dBi = 1.905 numeric d = Distance = 10 mm = 0.01 m S = (PG/ 4πd2) = EIRP/4A = 0.0107(1.905)/(4*π*0.01*0.01) = 0.0204/0.0013 = 15.69 W/m 2 = (15.69 W/m 2 ) (1m 2 /W) (0.1 mW/cm 2 ) = 1.569 mW/cm 2 << 2.5 mW/cm 2 Simultaneous MPE (900 MHz band +2.4 GHz band) Calculation: Total MPE (%) = [(900 MHz MPE result*100%] + [(2.4 GHz MPE result*100%] << 100% = [0.80 %] + [6.49%] = 7.29 % << 100% Calculation above shows device complies with the simultaneous MPE requirement US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105 and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812 and STD00-17811 Page 4 of 12 SAR Exclusion: General SAR test exclusion per KDB 447498 D01 V06 section 4.3 Test exclusion conditions are based on source-based time averaged maximum conducted output power of the RF channel, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions. For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel mW) / (min. test separation distance, mm)] * [(√f GHz )] Where the result must be ≤ 3.0 for 1-g SAR and ≤ 7.0 for 10-g SAR For 900 MHz ISM radio: Max. power of channel = +27.35 dBm * 8.65% (DC) = +2.36 dBm = 1.72 mW Min. test separation distance = 5mm F= 925 MHz Therefore: 1.72 mW/ 5mm * (√0.925 GHz ) = 0.33 ≤ 7.0 for 10-g SAR For 2.4 GHz ISM radio: Max. power of channel = +10.33 dBm = 10.8 mW Min. test separation distance = 5mm F= 2440 MHz Therefore: 10.8 mW/ 5mm * (√2.44 GHz ) = 3.4 ≤ 7.0 for 10-g SAR The Device meets the SAR Threshold exempt for limb and extremity. US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105 and 23-0107 Issue Date: July 11, 2023 Customer: Radio Systems Corporation Model: STD00-17812 and STD00-17811 Page 5 of 12 RSS-102, 2.5.1 Exemption Limits for Routine Evaluation SAR Evaluation: SAR evaluation is required if the separation distance between the user and/or bystander and the antenna and/or radiating element of the device is less than or equal to 20 cm except when the device operates at or below the applicable output power levels presented in Table 1 below. Output power level shall be the higher of the maximum conducted or equivalent isotopically radiated power (e.i.r.p) source-based time averaged (SBTA) output power. For 900 MHz ISM radio: In this case the maximum SBTA value is used: EUT source based time averaged (SBTA) = (output power + antenna gain * duty cycle) SBTA= 27.35 dBm + 1.0 dBm = 28.35 dBm * (8.65% (DC)) = 2.45 dBm = 1.75 mW The limit at a separation distance of 5 mm @ 925 MHz = (16.15 mW * 2.5) = 40.38 mW for limb exposure. The EUT meets the Exemption Limits. US Tech Test Report: FCC Part 15 Certification/ RSS 210 FCC ID: KE3-30034451 IC: 2721A-30034451 Test Report Number: 23-0105…

Text truncated - open the document above for the full version.

th - th Description: 3G Pentaband 824-2170MHz, Series: Stubby Antenna Straight PART NUMBER: W1910-MPS Features: - All information provided in this datasheet is for the W1910, W1910/W1911 - The W1910-MPS is a custom version of W1910-M without the - Characteristics may differ for W1910-MPS - Small form factor monopole - Lead free materials - RoHS Compliant Product Applications: - Penta band EU/US GSM/WCDMA W1910-M - Frequency range: 850 / 900 / 1800 / 1900/ 2100 MHz - M2M Applications All dimensions are in mm Issue: 2312 In the effort to improve our products, we reserve the right to make changes judged to be necessary. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. For more information: Pulse Worldwide Headquarters Pulse/Larsen Antennas Europe Headquarters Pulse (Suzhou) Wireless Products Co, Inc. 1 15255 Innovation Drive #100 18110 SE 34 St Bldg 2 Suite 250 Pulse GmbH & Do, KG 99 Huo Ju Road(#29 Bldg,4 Phase San Diego, CA 92128 Vancouver, WA 98683 Zeppelinstrasse 15 Suzhou New District USA USA Herrenberg, Germany Jiangsu Province, Suzhou 215009 PR China Tel:1-858-674-8100 Tel: 1-360-944-7551 Tel: 49 7032 7806 0 Tel: 86 512 6807 9998 th - th ELECTRICAL SPECIFICATIONS Description: 3G Pentaband 824-2170MHz, Series: Stubby Antenna Straight PART NUMBER: W1910-MPS Frequency 824-960MHz 1710-2170MHz Nominal Impedance 50 Return Loss -4dB 824-960MHz -6dB 1710-2170MHz Peak Gain 1dBi 824-960MHz 2dBi 1710-2170MHz Efficiency 51% Radiation Pattern Omni Polarization: Linear Power withstanding 5W Issue: 2312 In the effort to improve our products, we reserve the right to make changes judged to be necessary. Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. For more information: Pulse Worldwide Headquarters Pulse/Larsen Antennas Europe Headquarters Pulse (Suzhou) Wireless Products Co, Inc. 2 15255 Innovation Drive #100 18110 SE 34 St Bldg 2 Suite 250 Pulse GmbH & Do, KG 99 Huo Ju Road(#29 Bldg,4 Phase San Diego, CA 92128 Vancouver, WA 98683 Zeppelinstrasse 15 Suzhou New District USA USA Herrenberg, Germany Jiangsu Province, Suzhou 215009 PR China Tel:1-858-674-8100 Tel: 1-360-944-7551 Tel: 49 7032 7806 0 Tel: 86 512 6807 9998 Description: 3G Pentaband 824-2170MHz, Series: Stubby Antenna Straight PART NUMBER: W1910-MPS MECHANICAL SPECIFICATIONS Weight W1910/W1911:7.5g W1910-M :7.8g Antenna Color / Material Black Connector type W1910/W1910-M SMA(Male) W1911 RP-SMA(Male) ENVIRONMENTAL SPECIFICATIONS Operating Temperature -30/+75 ° C Storage Temperature -30/+75 ° C Ingress Protection IP65(W1910-M) Wind-loading 100km/h RoHS Compliant Yes Issue: 2312 In the effort to improve our products, we reserve the right to make changes judged to be necessary. 3 Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Description: 3G Pentaband 824-2170MHz, Series: Stubby Antenna Straight PART NUMBER: W1910-MPS MECHANICAL DRAWING W1910/W1911 W1910-M Issue: 2312 In the effort to improve our products, we reserve the right to make changes judged to be necessary. 4 Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written authorization of Pulse is strictly forbidden. Frequency(MHz) 556 616 675 734 794 853 913 972 1031 1091 1150 1209 1269 1328 1388 1447 1506 1566 1625 1684 1744 1803 1863 1922 1981 2041 2100 2159 2219 2278 2338 2397 2456 2516 2575 2634 2694 2753 2813 2872 2931 2991 Description: 3G Pentaband 824-2170MHz, Series: Stubby Antenna Straight PART NUMBER: W1910-MPS CHARTS Return Loss Return Loss 0.0 -5.0 -10.0 -15.0 -20.0 -25.0 Measured Spec Issue: 2312 In the effort to improve our products, we reserve the right to make changes judged to be necessary. 5 Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or use without specific written au…

Text truncated - open the document above for the full version.
