KEAXDLM

Trimble Navigation Ltd

UHF Transceiver Module

Click to zoom

Application Details

Equipment Class: TNB - Licensed Non-Broadcast Station Transmitter
Date of Grant: Mar 08, 2012
Application Purpose: Original Equipment
Date of Application: Mar 08, 2012
Equipment Note: UHF Transceiver Module
Frequency Range: 430.00000000 - 473.00000000
Company: Trimble Navigation Ltd
Country: United States

Documents & Files

Select a file to view

Users Manual

Cover Letter(s)

External Photos

ID Label/Location Info

Internal Photos

RF Exposure Info

Test Report

Test Setup Photos

Technical Specifications

#	Rule Parts	Frequency Range	Power Output	Emission	Tolerance
3	9	430 MHz - 473 MHz	2 W	8K34F1D	1.5 ppm

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Module Approval. Output Power listed is rated conducted. The antenna installation and operating configurations of this transmitter, including any applicable duty factor, antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of �2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 45 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
