KSF-R1001SER100-1-SE Aperio Reader

Part Number 500-24045, Rev. A ©2013, Securitron, Inc. 1 R100 Reader Installation Instructions Package Contents Recommended Tools Approved Credential: i.e., iCLASS or Prox ID card Level Pencil, wax pencil Optional Dress Cover: R100-DCA Optional Clamping device Product Specifications Wireless Frequency: 2.4 GHz, IEEE 802.15.4, using AES 128bit encryption Lock Battery Type: CR2, providing 35,000 Cycles FCC Part 15, Class B Compliant, Industry Canada, CE Compliant Reader Operating Temperature: -40F (-40C) to 122 F (+50C) Credentials Supported: 125kHz Proximity or 13.56MHz iCLASS credentials are supported depending on reader model. For technical support please call 1-800-810-9473 System Overview The R100 wireless reader installs in locations where wiring may be difficult or undesired for aesthetic reasons. The R100 wireless reader connects to an access control system through an Aperio communication hub. The communication hub connects to the access control system with wiegand or RS-485 wiring. When a credential card is presented to the reader the request for access is sent wirelessly to the communication hub. The communication hub then communicates to the access control system where the decision is made to grant or deny access. When access is granted the access control system unlocks the locking device seperately. Glue Reader Screws CR2 Battery Hex Wrench Securitron Magnalock Corp. Phoenix, AZ 800.624.5625 www.securitron.com Part Number 500-24045, Rev. A ©2013, Securitron, Inc. 2 1. Preparing the R100 Use a level to mark the position. Hold the reader body on the outside of the window and position it where you would like it to be mounted. 2. Insert Battery Install the battery, ensure correct orientation. The reader will self test and beep once. 3. Mounting the Unit The R100 can be mounted using glue or wood screws based on your needs. 3a. Apply Glue It is recommended that a thin thread of glue is applied to three sides of the back-plate as shown. This allows oxygen to enter and aid in the curing process. Do not use tissue or a brush to spread the adhesive. Quickly affix to the pre-marked area and hold or clamp until the adhesive has bonded (at least five seconds) The seal becomes functional within a short time and permanent after 24- 72 hours. Note the rate of cure depends on the ambient relative humidity. The best results are achieved when the relative humidity in the working environment is 40-60% at 22 ̊C. Lower humidity leads to a slower cure. High humidity accelerates it, but may impair the final strength of the bond. Glue line Position mark Battery Pull the cover up while pressing on the LED Use a pencil to mark this point on the window Part Number 500-24045, Rev. A ©2013, Securitron, Inc. 3 3b. Mounting with wood screws This is an alternate method for mounting the R100 to your door. Separate the components by gripping the electronic module at the noted side areas. Rock up, pull down, and lift out. Pre-drill through the mounting plate at the four corners and insert wood screws. Reattach electronic module by sliding the top under the mounting plate’s raised edges and pressing down firmly until it clicks. 4. Test Reader Reattach cover and insert screw with the included hex wrench. Use a credential known to the access control system to confirm it will read as desired. A green LED indicates access is granted. Refer to the LED reference card for any other codes. 5. Optional: Attach Dress Cover A separately purchased dress cover (R100-DCA) can be installed on the inside of a glass mounting surface. Peel the backing from the adhesive on the cover and affix to the window. Cover Screw Dress Cover R100 (rear view) Mounting Plate Side grip areas Wood screws Part Number 500-24045, Rev. A ©2013, Securitron, Inc. 4 WARNING FCC Statement This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. Operation with non-approved equipment is likely to result in interference to radio and TV reception. The user is cautioned that changes and modifications made to the equipment without the approval of manufacturer could void the user’s authority to operate this equipment. IC Statement This device complies with Industry Canada license-exempt RSS standards(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation. Conformité aux normes FCC Cet équipement a été testé et trouvé conforme aux limites pour un dispositif numérique de classe B, conformément à la Partie 15 des règlements de la FCC. Ces limites sont conçues pour fournir une protection raisonnable contre les interférences nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut émettre des fréquences radio et, s'il n'est pas installé et utilisé conformément ment aux instructions du fabricant, peut causer des interferences nuisibles aux communications radio. Rien ne garantit cependant que …

Text truncated - open the document above for the full version.

Assa Abloy EMS&OEM 10027 S. 51st Street, Ste 102 Phoenix, AZ 85044 Tel +1 623-582-4626 February 11, 2014 To whom it may concern, ASSA ABLOY is the largest global supplier of intelligent locks and security solutions. Its products account for more than one in ten of all lock and security installations worldwide. Assa Abloy was formed in 1994 when ASSA AB was detached from Swedish security firm Securitas AB. Shortly thereafter, the Finnish high-security lock manufacturer Abloy Oy (a subsidiary of the Finnish company Wärtsilä) was acquired. The company was introduced to the Stockholm stock exchange later the same year. Assa Abloy has since made over 150 acquisitions. Securitron Magnalock Corporation is one of the leading manufacturers of magnetic locks and electromechanical exit devices in the US.Securitron was purchased and consolidated by Assa Abloy in 1998. In 1999, Hanchett Entry Systems was acquired by Assa Abloy throught the purchase of effeff, their owners at the time. Hanchett Entry Systems is committed to being the leading provider of innovative electromechanical locking solutions and support, creating safety, security and peace of mind for our customers, while providing an environment that enables employees to contribute and fulfill their potential. Sincerely, Andrew Wilding EM Product Development Engineer ASSA ABLOY AEHG 225 Episcopal Rd Berlin, CT 06037 P: 860.828.7291

Securitron Magnalock Corp. 10027 S. 51st Street, Ste 102 Phoenix, AZ 85044 Tel +1 623-582-4626 R100-1-SE Photos Exterior Photos Placed next to a quarter for scale

2.00 1.00 4X R.09 0 8X .13 1.01 1.86 0 .06 .33 .55 .635 .787 .86 A 6 7 .24 .21 DETAIL A SCALE 4 : 1 SIZE RELATIONSHIP SHALL BE MAINTAINED REVISIONS ZONEREV.CR#DESCRIPTIONREV BYAPPROVEDDATE X01CR 410-1311/21/2013 4 3 2 1 4 3 2 1 F E D C B A F E D C B A NOTES: UNLESS OTHERWISE SPECIFIED. COMPONENTS AND OR PARTS TO COMPLY WITH1. EU DIRECTIVE 2002/95/EC (RoHS). MATERIAL: COATED PAPER WITH PERMANENT LATEX2. ADHESIVE. USE LABEL P/N: 3000021.006 OR HES APPROVED EQUIVALENT. WHITE LABEL WITH BLACK LETTERING.3. FINISH: PRINTED IN DENSE BLACK INK. TEXT SHALL4. BE SHARP AND LEGIBLE. FONT: ARIAL5. FONT HEIGHT: 4 POINT MINIMUM ALIGNMENT: LEFT JUSTIFIED SECURITRON LOGO DEFINED BY DRAWING 49-00052.6. APERIO LOGO DEFINED BY DRAWING 4000505.002.7. PARTS SHALL BE CLEAN AND FREE OF FOREIGN8. MATERIAL. PARTS SHALL BE PACKAGED TO PREVENT DAMAGE9. RESULTING FROM SHIPPING, STORAGE, AND HANDLING. TITLE UNRELEASED XDJ MFG ENGR LABEL: FCC, APERIO, R100, HF DWG. NO. ssullivan LAST SAVED BY: 11/21/2013 PRINT DATE: SHEET 1 OF 1 SCALE: 2:1 X01B 5080021.007 RC JP SPS X X 09/25/13 3RD ANGLE PROJECTION HANCHETT ENTRY SYSTEMS, INC. 10027 S. 51st Street, Suite 102 - Phoenix AZ 85044 P (623)582-4626 - F (623)582-4641 THIS DOCUMENT IS THE CONFIDENTIAL PROPERTY OF HES, INC. AND IS LOANED SUBJECT TO RETURN UPON DEMAND. TITLE TO THIS DOCUMENT IS NEVER TO BE SOLD OR TRANSFERRED FOR ANY REASON. THIS DOCUMENT IS TO BE USED ONLY PURSUANT TO WRITTEN LICENSE OR WRITTEN INSTRUCTIONS OF HES, INC. ALL RIGHTS TO DESIGN AND INVENTIONS ARE RESERVED BY HES, INC. POSSESSION OF THE DOCUMENT IS ACCEPTED SUBJECT TO THE FOREGOING. © HES, INC. 2013 STATUS: R&D QA DRAWN BY DATENAME UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES TOLERANCES ARE: FRACTIONAL 1/32 ANGLES 1 .XX .01 .XXX .005 DO NOT SCALE DRAWING INTERPRET PER ASME Y14.5M-2009 REV. SIZE FAMILY NAME:

Interior Photos Antenna board Antenna board mounted on main board Side view All boards with PCB tub and light guide Assembled unit Top view Top view next to cover Side view (distance between antenna and cover = 1.5mm)

FCC: Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V4.0 2012-07-20 © Copyright by CETECOM FCC/IC Partial Scope Test Report FOR Manufacturer: Securitron Magnalock Corp. Model Number: R100-1-SE Product Description: Aperio Wall Mounted Reader FCC ID: KSF-R1001SE IC Certification Number: 11564A-R1001SE FCC CFR 47 Part 15.225 IC RSS-210 Issue 8, Annex 2.6 TEST REPORT #: EMC_HANC1_002_13502_R100_RFID-C DATE: March 11, 2014 Test Report #: EMC_HANC1_002_13502_R100_RFID-C FCC ID: KSF-R1001SE Date of Report: March 11, 2014 IC Cert. No.: 11564A-R1001SE Page 2 of 17 TABLE OF CONTENTS 1 Assessment _____________________________________________________________________ 4 2 Administrative Data _____________________________________________________________ 5 2.1 Identification of the Testing Laboratory Issuing the Test Report __________________________ 5 2.2 Identification of the Client __________________________________________________________ 5 2.3 Identification of the Manufacturer ___________________________________________________ 5 3 Equipment under Test (EUT) ______________________________________________________ 6 3.1 Details of the Equipment under Test __________________________________________________ 6 3.2 Identification of the Equipment Under Test (EUT) ______________________________________ 7 3.3 Identification of Accessory equipment ________________________________________________ 7 3.4 Other EUT Notes __________________________________________________________________ 7 4 Summary of Measurement Results _________________________________________________ 7 5 Measurement Information ________________________________________________________ 8 5.1 Dates of Testing ___________________________________________________________________ 8 5.2 Measurement Uncertainty __________________________________________________________ 8 5.3 Nominal EUT Conditions During Test ________________________________________________ 8 5.4 Nominal Environmental Conditions During Test _______________________________________ 8 5.5 RF Antenna Port Conducted Measurement Procedure __________________________________ 8 5.6 Associated Test Reports ____________________________________________________________ 8 5.7 Other Testing Notes _______________________________________________________________ 8 6 Measurement Results ____________________________________________________________ 9 6.1 20 dB Emission Bandwidth _________________________________________________________ 9 6.1.1 References _____________________________________________________________________________ 9 6.1.2 Spectrum Analyzer Settings ________________________________________________________________ 9 6.1.3 Test Results _____________________________________________________________________________ 9 6.1.4 Measurement Verdict _____________________________________________________________________ 9 6.1.5 Test Plots _____________________________________________________________________________ 10 6.2 99% Occupied Bandwidth _________________________________________________________ 11 6.2.1 References ____________________________________________________________________________ 11 6.2.2 Spectrum Analyzer Settings _______________________________________________________________ 11 6.2.3 Test Results ____________________________________________________________________________ 11 6.2.4 Measurement Verdict ____________________________________________________________________ 11 6.2.5 Test Plots _____________________________________________________________________________ 12 6.3 Frequency Stability _______________________________________________________________ 13 6.3.1 References ____________________________________________________________________________ 13 6.3.2 Testing Notes __________________________________________________________________________ 13 6.3.3 Test Results ____________________________________________________________________________ 14 6.3.4 Measurement Verdict ____________________________________________________________________ 14 7 Test Equipment and ancillaries used for tests ________________________________________ 15 Test Report #: EMC_HANC1_002_13502_R100_RFID-C FCC ID: KSF-R1001SE Date of Report: March 11, 2014 IC Cert. No.: 11564A-R1001SE Page 3 of 17 8 Test Setup Diagrams ____________________________________________________________ 16 9 Revision History _______________________________________________________________ 17 Test Report #: EMC_HANC1_002_13502_R100_RFID-C FCC ID: KSF-R1001SE Date of Report: March 11, 2014 IC Cert. No.: 11564A-R1001SE Page 4 of 17 1 Assessment The following device, as detailed in section 3 of this test report, was evaluated against the applicable criteria specified in FCC CFR 47 Parts 15.207, 15.209, 15.215, 15.225, and Industry Canada Radio Standard Specification RSS 210 Issue 8, Annex 2.6. No deviations were ascertained during the course of the tests performed. This partial scope test report only contains the details of the conducted RF antenna port measurements of the above listed rules. Radiated measurements are documented in a separate test report as identified in section 4. Manufacturer Description Model # Securitron Magnalock Corp. Aperio Wall Mounted Reader R100-1-SE Responsible for Testing Laboratory: March 11, 2014 Compliance Franz Engert (Manager of Compliance) Date Section Name Signature Responsible for the Report: March 11, 2014 Compliance Josie Sabado (Test Lab Manager) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section 3. CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the t…

Text truncated - open the document above for the full version.

FCC: Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V4.0 2012-07-20 © Copyright by CETECOM FCC/IC Partial Scope Test Report FOR: Manufacturer: Securitron Magnalock Corp. Model Number: R100-1-SE Product Description: Aperio Wall Mounted Reader FCC ID: KSF-R1001SE IC Certification Number: 11564A-R1001SE FCC CFR 47 Part 15.225 IC RSS-210 Issue 8, Annex 2, Section 6 TEST REPORT #: EMC_HANC1_002_13502_R100_RFID-R DATE: March 11, 2014 Test Report #: EMC_HANC1_002_13502_R100_RFID-R FCC ID: KSF-R1001SE Date of Report: March 11, 2014 IC Cert. No.: 11564A-R1001SE Page 2 of 19 TABLE OF CONTENTS 1 Assessment _____________________________________________________________________ 3 2 Administrative Data _____________________________________________________________ 4 2.1 Identification of the Testing Laboratory Issuing the Test Report __________________________ 4 2.2 Identification of the Client __________________________________________________________ 4 2.3 Identification of the Manufacturer ___________________________________________________ 4 3 Equipment under Test (EUT) ______________________________________________________ 5 3.1 Details of the Equipment under Test __________________________________________________ 5 3.2 Identification of the Equipment Under Test (EUT) ______________________________________ 6 3.3 Identification of Accessory equipment ________________________________________________ 6 4 Summary of Measurement Results _________________________________________________ 7 5 Measurement Information ________________________________________________________ 8 5.1 Dates of Testing ___________________________________________________________________ 8 5.2 Measurement Uncertainty __________________________________________________________ 8 5.3 Nominal EUT Conditions During Test ________________________________________________ 8 5.4 Nominal Environmental Conditions During Test _______________________________________ 8 5.5 Radiated Measurement Procedure ___________________________________________________ 9 5.5.1 Sample Calculations for Radiated Measurements ______________________________________________ 11 6 Measurement Results ___________________________________________________________ 12 6.1 In Band Transmitter Spurious Emissions _____________________________________________ 12 6.1.1 References ____________________________________________________________________________ 12 6.1.2 Spectrum Analyzer settings _______________________________________________________________ 12 6.1.3 Testing Notes __________________________________________________________________________ 12 6.1.4 Measurement Verdict ____________________________________________________________________ 12 6.1.5 Test Plots _____________________________________________________________________________ 13 6.2 Out of Band Transmitter Spurious Radiated Emissions _________________________________ 14 6.2.1 References ____________________________________________________________________________ 14 6.2.2 Spectrum Analyzer Settings _______________________________________________________________ 14 6.2.3 Testing Notes __________________________________________________________________________ 14 6.2.4 Measurement Verdict ____________________________________________________________________ 14 6.2.5 Test Plots _____________________________________________________________________________ 15 7 Test Equipment and ancillaries used for tests ________________________________________ 17 8 Test Setup Diagrams ____________________________________________________________ 18 9 Revision History _______________________________________________________________ 19 Test Report #: EMC_HANC1_002_13502_R100_RFID-R FCC ID: KSF-R1001SE Date of Report: March 11, 2014 IC Cert. No.: 11564A-R1001SE Page 3 of 19 1 Assessment The following device, as detailed in section 3 of this test report, was evaluated against the applicable criteria specified in FCC CFR 47 Parts 15.209, 15.215, 15.225, and Industry Canada Radio Standard Specification RSS 210 Issue 8, Annex 2.6. No deviations were ascertained during the course of the tests performed. This partial scope test report only contains the details of radiated measurements of the above listed rules. The conducted RF antenna port measurements are documented in a separate test report as identified in section 4. Manufacturer Description Model # Securitron Magnalock Corp. Aperio Wall Mounted Reader R100-1-SE Responsible for Testing Laboratory: March 11, 2014 Compliance Franz Engert (Manager of Compliance) Date Section Name Signature Responsible for the Report: March 11, 2014 Compliance Josie Sabado (Test Lab Manager) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section 3. CETECOM Inc. USA does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples of the type of the equipment represented by the test item. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of CETECOM Inc. USA. Test Report #: EMC_HANC1_002_13502_R100_RFID-R FCC ID: KSF-R1001SE Date of Report: March 11, 2014 IC Cert. No.: 11564A-R1001SE Page 4 of 19 2 Administrative Data 2.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Address: 411 Dixon Landing Road Milpitas, CA 95035 U.S.A. Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Acting Test Lab Manager: Franz Engert Test Engineer: Josie Sabado 2.2 Identification of the Client Applicant’s Name: Assa Abloy Street Address: 10027 S. 51st St. Ste. 102 City/Zip Code Phoenix, AZ 85044 Count…

Text truncated - open the document above for the full version.

Project #: EMC_HANC1_002_13502_R100 FCC ID: KSF-R1001SE IC Cert. No.: 11564A-R1001SE Page 1 of 4 Test Setup Photographs Model Number: R100-1-SE Product Description: Aperio Wall Mounted Reader Manufacturer: Securitron Magnalock Corp. FCC ID: KSF-R1001SE IC Certification Number: 11564A-R1001SE Test Site Information: CETECOM Inc. Milpitas, CA USA Project #: EMC_HANC1_002_13502_R100 FCC ID: KSF-R1001SE IC Cert. No.: 11564A-R1001SE Page 2 of 4 RF Antenna Port Conducted Test Setup: Project #: EMC_HANC1_002_13502_R100 FCC ID: KSF-R1001SE IC Cert. No.: 11564A-R1001SE Page 3 of 4 Radiated Emissions Test Setup: <30 MHz Measurement setup: 30MHz -1 GHz Measurement setup: Project #: EMC_HANC1_002_13502_R100 FCC ID: KSF-R1001SE IC Cert. No.: 11564A-R1001SE Page 4 of 4 >1 GHz Measurement setup: >18 GHz Measurement setup:
