KSX-XVP525

Xirlink Inc

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Jul 30, 1998
Application Purpose: Original Equipment
Date of Application: Jun 21, 1998
Company: Xirlink Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

C-it Digital Video PC Camera Model XVP-525 For Windows User's Guide Release 2.0 June, 1998 Xirlink, Inc. Copyright Information C-it Digital Video PC Camera for Windows. Copyright ©1997-1998 Xirlink, Inc. All rights reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. C-it, C-it Video Conference Center, C-it Video Camera, OpArt Video Mail, and C-it Video Album are trademarks of Xirlink, Inc. The C-it logo is a registered trademark of Xirlink, Inc. Information is subject to change without notice and does not represent a commitment on the part of Xirlink, Inc. The software described is furnished under a licensing agreement. The software may be used or copied only in accordance with the terms of such an agreement. It is against the law to copy the software on any medium except as specifically allowed in the licensing agreement. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, or translated to another language, for any purpose other than the licensee's personal use and as specifically allowed in the licensing agreement, without the express written permission of Xirlink, Inc. Restricted Rights Legend Use, duplication, or disclosure is subject to restrictions as set forth in contract subdivision (c)(1)(ii) of the Rights in Technical Data and Computer Software Clause 52.227-FAR14. Material scanned by this product may be protected by governmental laws and other regulations, such as copyright laws. The customer is solely responsible for complying with all such laws and regulations. Xirlink’s Limited Product Warranty If you find physical defects in the materials or the workmanship used in making the product described in this document, Xirlink will repair, or at its option, replace, the product at no charge to you, provided you return it (postage prepaid, with proof of your purchase from the original reseller) during the 12-month period after the date of your original purchase of the product. THIS IS C-it'S ONLY WARRANTY AND YOUR EXCLUSIVE REMEDY CONCERNING THE PRODUCT, ALL OTHER REPRESENTATIONS, WARRANTIES OR CONDITIONS, EXPRESS OR IMPLIED, WRITTEN OR ORAL, INCLUDING ANY WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON- INFRINGEMENT, ARE EXPRESSLY EXCLUDED. AS A RESULT, EXCEPT AS SET OUT ABOVE, THE PRODUCT IS SOLD ÒAS ISÓ AND YOU ARE ASSUMING THE ENTIRE RISK AS TO THE PRODUCTS SUITABILITY TO YOUR NEEDS, ITS QUALITY AND ITS PERFORMANCE, IN NO EVENT WILL XIRLINK BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY DEFECT IN THE PRODUCT OR FROM ITS USE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. All exclusions and limitations in this warranty are made only to the extent permitted by applicable law and shall be of no effect to the extent in conflict with the express requirements of applicable law. FCC Radio Frequency Interference Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction guide, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: *Reorient or relocate the receiving antenna. *Increase the separation between the equipment and the receiver. *Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio or TV technician for help. Introduction................................................................................................................................5 Welcome to the C-it Digital Video PC Camera for video media...............................................5 What's In the Box......................................................................................................................5 What You Need.........................................................................................................................5 A Quick Look at C-it Digital Video Camera.............................................................................7 Hints for Taking Good Pictures.................................................................................................7 A Quick Look at C-it applications.............................................................................................8 OpArt Video Mail..................................................................................................................8 C-it Video Camera.................................................................................................................8 C-it Video Conference Center................................................................................................8 C-it Video Album...................................................................................................................9 Installation................................................................................................................................10 Before You Begin....................................................................................................................10 Registering Your C-it..............................................................................................................10…

Text truncated - open the document above for the full version.

Cover Letter(s)

June 19, 1998 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 SUBJECT:XIRLINK Inc. FCC ID: KSX-XVP525 Gentlemen: Transmitted herewith, on behalf of XIRLINK Inc., is an application for certification of the following Data/Fax/Voice Modem Card: FCC ID:KSX-XVP525 MODEL(s):XVP525 TRADE NAME:XIRLINK EUT TYPE:Digital USB Video Camara Attached is the applicant’s attestation statement, measurement report (Radiation emission data, Line Conducted emission data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc:Patrick Lin President XIRLINK Inc.

External Photos

ID Label/Location Info

© 1998 PCTEST Lab FCC ID SAMPLE LABEL LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Required FCC statement will be placed in the users manual per § 15.19(c) of the FCC Rules. Fig 12. Sample label SEE NEXT PAGE © 1998 PCTEST Lab FCC ID SAMPLE LABEL LOCATION LABELLING REQUIREMENTS PER §§ 2.925 & §§ 15.19 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. Required FCC statement will be placed in the users manual per § 15.19(c) of the FCC Rules. Fig 12. Sample label SEE NEXT PAGE

Internal Photos

Test Report S/N: B.980609406.KSXFCC Class B Test Date(s): June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525) NVLAP Lab Code: 100431-0 XIRLINK Digital USB Video Camera Test Report S/N: B.980609406.KSXFCC Class B Test Date(s): June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525) NVLAP Lab Code: 100431-0 XIRLINK Digital USB Video Camera Test Report S/N: B.980609406.KSXFCC Class B Test Date(s): June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525) NVLAP Lab Code: 100431-0 XIRLINK Digital USB Video Camera Test Report S/N: B.980609406.KSXFCC Class B Test Date(s): June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525) NVLAP Lab Code: 100431-0 XIRLINK Digital USB Video Camera Test Report S/N: B.980609406.KSXFCC Class B Test Date(s): June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525) NVLAP Lab Code: 100431-0 XIRLINK Digital USB Video Camera

Test Report

PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE Xirlink, Inc.Dates of Tests: June 15-16, 1998 2210 O’Toole AvenueTest Report S/N: B.980609406.KSX San Jose, CA 95131Test Site: PCTEST Lab, MD U.S.A. Attn: Patrick Lin, PresidentJob No.: CHANEY#8008A FCC IDENTIFIER APPLICANT Rule Part(s): FCC Part 15 Subpart B Equipment Class:Class B Digital Device / Peripheral (JBP) EUT Type:Digital USB Video Camera Model:XVP525 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C63.4-1992 (Note Code: #37) I attest to the accuracy of data and all measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Lab Code 100431-0 KSX-XVP525 XIRLINK, INC. © 1998 PCTEST Engineering Lab., Inc. Certification © 1998 PCTEST Engineering Laboratory, Inc. Class B TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 1 INTRODUCTION (SITE DESCRIPTION) 2 PRODUCTION INFORMATION 3 DESCRIPTION OF TESTS (CONDUCTED) 4 DESCRIPTION OF TESTS (RADIATED) 5 LIST OF SUPPORT EQUIPMENT 6 TEST DATA (CONDUCTED) 7 PLOTS OF EMISSIONS 8 TEST DATA (RADIATED) 9 SAMPLE CALCULATIONS 10 ACCURACY OF MEASUREMENT 11 LIST OF TEST EQUIPMENT 12 TEST SOFTWARE USED 13 RECOMMENDATION / CONCLUSION 14 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: BLOCK DIAGRAM(S) ATTACHMENT G: SCHEMATIC DIAGRAM(S) ATTACHMENT H: TEST SETUP PHOTOGRAPHS ATTACHMENT I: EXTERNAL PHOTOGRAPHS ATTACHMENT J: INTERNAL PHOTOGRAPHS ATTACHMENT K: USER’S MANUAL MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name:XIRLINK, INC. Address:2210 O’Toole Avenue San Jose, CA 95131 Attention:Patrick Lin - President •FCC ID:KSX-XVP525 •Class: B Digital Device / Peripheral (JBP) •EUT Type:Digital USB Video Camera •Model:XVP525 •Cable(s):Shielded USB •Rule Part(s): FCC Part 15 Subpart B •Test Procedure:ANSI C-63.4 (1992) •Dates of Tests: June 15-16, 1998 •Place of Tests: PCTEST Lab, Columbia, MD U.S.A. •Test Report S/N:B.980609406.KSX •Job No.:CHANEY#8008A Lab Code 100431-0 Test Report S/N: B.980609406.KSXFCC Class B Test Dates: June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525)1 XIRLINK Digital USB Video Camera Introduction The measurement procedure described in American National Standard for Methods of Meas- urement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40 GHz (ANSI C63.4-1992) was used in determining radiated and con- ducted emissions emanating from XIRLINK Digital USB Video Camera FCC ID: KSX-XVP525. These measurement tests were conducted at PCTEST Engineering Laboratory facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660- B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Colum- bia area with an elevation of 390 feet above mean sea level. The site coordinates are 39°°11’15" N latitude and 76°°49’38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed descrip- tion of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. Fig. 1. The map above shows the Columbia vicinity area. The map also shows PCTest Lab, FCC Lab and BWI airport. (Scale 1"=2miles) Test Report S/N: B.980609406.KSXFCC Class B Test Dates: June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525)2 XIRLINK Digital USB Video Camera Product Information Equipment Description: The Equipment Under Test (EUT) is the XIRLINK Digital USB Video Camera FCC ID: KSX- XVP525. Crystal/Oscillator(s): 16.9344MHz Chipset(s): SANYO (LC99052, LC99062W50) XCHIP (XP-80801) Connector(s): USB (Universal Serial Bus) Cable(s):Shielded USB Power Supply:from host computer EMI suppression device(s) installed in production: *see schematics (Attachment G) EMI suppression device(s) added and/or modified during testing: *none Test Report S/N: B.980609406.KSXFCC Class B Test Dates: June 15-16, 1998Certification © 1998 PCTEST LabFCC ID: KSX-XVP525 (Model: XVP525)3 XIRLINK Digital USB Video Camera Description of Tests Conducted Emissions The line-conducted facility is located inside a 16’x20’x10’ shielded enclo- sure. It is manufactured by Ray Proof Series 81 (Fig. 2). The shielding effec- tiveness of the shielded room is in accordance with MIL-Std-285 or NSA 65- 6. A 1m.x1.5m. wooden table 80 cm. high is placed 40cm. away from the ver- tical wall and 1.5m away from the side wall of the shielded room (Fig. 3). Solar Electronics and EMCO Model 3725/2 (10kHz-30MHz) 50 ΩΩ/50 uH Line-Impedance Stabilization Networks (LISNs) are bonded to the shielded room (FIg. 4). The EUT is powered from the Solar LISN and the support equipment is powered from the EMCO LISN. Power to the LISNs are fil- tered by a high-current high-insertion loss Ray Proof power line filters (100dB 14kHz-10GHz). The purpose of the filter is to attenuat…

Text truncated - open the document above for the full version.

Test Setup Photos
