KT6B7008FM Wireless Microphone

Date: 1999-11-19TEST REPORTPage 1 of 6 No.: HM101697 _____Law Man Kit____ ____Kitty Choy____ ___Patrick Wong____ Patrick Wong Testing EngineerVerify byfor Managing Director Conditions in issuance of Test Report 1. This Report is issued in confidence to the client and it will be strictly treated as such by the Hong Kong Standards and Testing Centre Ltd. It may not be reproduced either in its entirety or in part and it may not be used for advertising. The client to whom the Report is issued may, however, show or send it, or a certified copy thereof prepared by the Hong Kong Standards and Testing Centre Ltd. to his customer, supplier or other persons directly concerned. The Hong Kong Standards and Testing Centre Ltd. will not, without the consent of the client, enter into any discussion or correspondence with any third party concerning the contents of the Report. 2. The report refers only to the sample tested and does not apply to the bulk, unless the sampling has been carried out by the Hong Kong Standards and Testing Centre Ltd. and is stated as such in the Report. 3. In the event of the improper use of the report, the Hong Kong Standards and Testing Centre Ltd. reserves the rights to withdraw it, and to adopt any other remedies which may be appropriate. 4. Samples submitted for testing are accepted on the understanding that the Report issued cannot form the basis of, or be the instrument for, any legal action against the Hong Kong Standards and Testing Centre Ltd. 5. The Hong Kong Standards and Testing Centre Ltd. will not be liable for or accept responsibility for any loss or damage howsoever i ifthf i ftit i d if it Rtii tih tb t itid t titi ti6Ali t ihi tthR titdi APPLICANT: (Code:BOT005) BOXER TOYS CO. LTD. UNIT 10, 4/F, SUN CHEONG IND. BLDG., 1 CHEUNG SHUN ST., CHEUNG SHA WAN, KOWLOON, HONG. KONG. DATE OF SAMPLES RECEIVED: 1999.10.27 DATE OF TESTING: 1999.11.17 DESCRIPTION OF SAMPLE(S): A sample of product said to be: Product:FM WIRELESS MICROPHONE Manufacturer:AKAMIBARA ELECTS. FTY. Model Number:B7008 Brand Name:BOXER Rating:3Vd.c. ("AA" size battery × 2) Origin:China INVESTIGATIONS REQUESTED: Measurement to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart C - Intentional Radiator. RESULT/ REMARK:Please see attached sheet(s). CONCLUSION: From the measurement data obtained, the tested sample was considered to have COMPLIED after modification with the clause 15.239 of Federal Communications Commission Rules and Regulations Part 15. TEST EQUIPMENT AUDIT: Please see Appendix A. MODIFICATION METHOD: Please see Appendix B. Date: 1999-11-19TEST REPORTPage 2 of 6 No.: HM101697 T E S T S U M M A R Y *** INTENTIONAL RADIATOR *** (1) Measurement of Emission of RF energy on the carrier frequency.................Satisfactory Measurement of the out-of band emissions including harmonics...................Satisfactory (2) Measurement of Emission Within Band Edges...............................................Satisfactory (3) Measurement of Line-Conducted Voltage onto AC Power Line.....................Not applicable T E S T D A T A Please refer to the attached result sheets. Date: 1999-11-19TEST REPORTPage 3 of 6 No.: HM101697 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference ============================== TEST REFERENCE: FCC Rules Part 15 Subpart Section 15.239(88.00-108.00MHz) TEST CONDITION : Normal TEST DATE : 1999.11.17 Emission of RF energy on the carrier frequency -- 89.054 MHz (PEAK VALUE) ======================================================================== EmissionMeter PolarizationAntenna Field StrengthFCC Limit Frequency Reading Factor (at 3m) MHz dB(μV) H-V dB dB(μV/m) μV/m μV/m 89.05 42.7 H + 10.5 53.2 457.1 2500 Emission of RF energy on the carrier frequency -- 89.054 MHz (AVERAGE VALUE) ======================================================================== EmissionMeter PolarizationAntenna Field StrengthFCC Limit Frequency Reading Factor (at 3m) MHz dB(μV) H-V dB dB(μV/m) μV/m μV/m 89.05 32.4 H + 10.5 42.9 139.6 250 ... to be continued Date: 1999-11-19TEST REPORTPage 4 of 6 No.: HM101697 *** INTENTIONAL RADIATOR *** (1) Measurement of Radiated Interference . . Continued .. ============================================ TEST REFERENCE: FCC Rules Part 15 Section 15.239 (88.00-108.00MHz) TEST CONDITION : Normal TEST DATE : 1999.11.17 The out-of-band emissions, including harmonics (25-1000 MHz) (CISPR VALUE) EmissionMeter PolarizationAntenna Field StrengthFCC Limit Frequency Reading Factor (at 3m) MHz dB(μV) H-V dB dB(μV/m) μV/m μV/m 178.110.7H+10.821.511.9150 267.220.1H+16.036.163.8200 356.2<1.0+20.5<21.5<11.9200 445.3<1.0+23.0<24.0<15.8200 534.3<1.0+24.3<25.3<18.4200 623.4<1.0+26.9<27.9<24.8200 712.4<1.0+27.3<28.3<26.0200 801.5<1.0+27.5<28.5<26.6200 890.5<1.0+27.8<28.8<27.5200 979.6<1.0+29.8<30.8<30.9200 ====================SUMMARY=================== Broad-band Antennas were used both polarizations of emissions were measured. polarizations at highest reading indicated as: H -- HorizontalV -- Vertical ============================================= Date: 1999-11-19TEST REPORTPage 5 of 6 No.: HM101697 *** INTENTIONAL RADIATOR *** (2) Measurement of Emissions Within Band Edges. ======================= TEST REFERENCE: FCC Rules Part 15 section 15.239(88.00-108.00 MHz) TEST CONDITION: Normal TEST DATE : 1999.11.17 Please see exhibit of report of bandwidth RESULTS AND NOTES The bandwidth of the emission shall be no wider than 200kHz of the center frequency for devices operating within 88.00MHz to 108.00MHz . The bandwidth is determind at the points 26dB down from the modulated carrier. The bandwidth at 26.0dB down is 32.5kHz which is within the allowable limit of 200KHz at 88.00 to 108.00MHz. L: FCC Lower Band Edge..............................................................................-> 88.000MHz H: FCC Higher Band Edge.............................................................................->108.000MHz C: Unmodulated carrier at frequency.…

Text truncated - open the document above for the full version.

Date:1999-11-19TEST REPORTPage A1 of A1 No.: HM101697 APPENDIX A TEST EQUIPMENT AUDIT Radiated Emission EQP NO.DESCRIPTIONMANUFACTURERMODEL NO.SERIAL NO.LAST CAL EM007SPECTRUM ANALYZERH PHP85660B3144A21192 11/06/99 EM008SPECTRUM ANALYZER DISPLAYH PHP85662A3144A20514 11/06/99 EM009QUASI PEAK ADAPTORH PHP85650A3303A01702 11/06/99 EM010RF PRESELECTORH PHP85685A3221A01410 11/06/99 EM011ATTENNUATOR/SWITCHH PHP11713A2508A10595 11/06/99 EM012PRE-AMPLIFIERH PHP8449B3008A00262 11/06/99 EM013CONTROLLER (COMPUTER), COLOR MONITOR, KEYBOARD & MOUSE FLOPPY DRIVE H P H P H P HP9000 HP A1097C HP9133L 6226A60314 3151J39517 2623A02468 CM EM016ANTENNAARA INC.LPB-2513/A1047 30/12/97 EM072SIGNAL GENERATORHP8640B1948A11892 30/03/98 EM083HKSTC OPEN AREA TEST SITEHKSTCN/AN/A 25/02/99 EM145EMI TEST RECEIVERR & SESCS30830245/021 10/05/99 ABBREVIATIONS: CM = Corrective Maintenance N/A= Not Applicable TBD=To Be Determined
