FCC ID: KX7LZE Report No.: F910912A021Issued: Oct. 23, 2002 FCC TEST REPORT REPORT NO.: F910912A02 MODEL NO.: LZE-568 RECEIVED: Sept. 12, 2002 TESTED: Oct. 7 ~ 8, 2002 APPLICANT:THREE SOMA TECHNOLOGY CO., LTD. ADDRESS:2F, No. 27, Shoei Biann 2 nd Rd., Taoyuan, Taiwan, R. O. C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 20 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: KX7LZE Report No.: F910912A022Issued: Oct. 23, 2002 Table of Contents 1CERTIFICATION............................................................................................. 3 2SUMMARY OF TEST RESULTS .................................................................... 4 3GENERAL INFORMATION ............................................................................. 5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................5 3.3DESCRIPTION OF SUPPORT UNITS ............................................................6 4EMISSION TEST ............................................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT...................................................7 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ................................7 4.1.2 TEST INSTRUMENTS.....................................................................................7 4.1.3 TEST PROCEDURE........................................................................................8 4.1.4 DEVIATION FROM TEST STANDARD............................................................8 4.1.5 TEST SETUP...................................................................................................8 4.1.6 EUT OPERATING CONDITIONS ....................................................................9 4.1.7 TEST RESULTS ............................................................................................10 4.2RADIATED EMISSION MEASUREMENT......................................................12 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT ...................................12 4.2.2 TEST INSTRUMENTS...................................................................................13 4.2.3 TEST PROCEDURE......................................................................................14 4.2.4 DEVIATION FROM TEST STANDARD..........................................................14 4.2.5 TEST SETUP.................................................................................................15 4.2.6 EUT OPERATING CONDITIONS ..................................................................15 4.2.7 TEST RESULTS ............................................................................................16 5PHOTOGRAPHS OF THE TEST CONFIGURATION ................................... 18 6APPENDIX - INFORMATION ON THE TESTING LABORATORIES ............ 20 FCC ID: KX7LZE Report No.: F910912A023Issued: Oct. 23, 2002 1 CERTIFICATION PRODUCT:15β LCD MONITOR BRAND NAME:Three SOMA, no brand MODEL NO.:LZE-568 TEST ITEM:ENGINEERING SAMPLE APPLICANT:THREE SOMA TECHNOLOGY CO., LTD. STANDARDS:FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility from Oct. 7 ~ 8, 2002. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: KX7LZE Report No.: F910912A024Issued: Oct. 23, 2002 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: StandardTest TypeResultRemarks Conducted TestPASS Meets Class B Limit Minimum passing margin is β10.55 dB at 0.199 MHz FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B Radiated TestPASS Meets Class B Limit Minimum passing margin is β2.40 dB at 131.25 MHz FCC ID: KX7LZE Report No.: F910912A025Issued: Oct. 23, 2002 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT15β LCD MONITOR MODEL NO.LZE-568 POWER SUPPLY Switching power adapter Brand: CHI Model: CH-1204 I/P: 100-240Vac, 1A Max., 50-60Hz O/P: 12Vdc, 4A, 48W Max. Non-shielded DC 3-pin (1.8m) with a ferrite core Non-shielded AC (1.8m) DATA CABLEVGA shielded (1.5m) with two ferrite cores NOTE: The EUT is a 15β LCD MONITOR with resolution up to 1024x768. The EUT is using a 15β Chi Mei LCD panel, model: M150X3-T05. For a more detailed features description, please refer to the manufacturerβs specifications or the User's Manual. 3.2 DESCRIPTION OF TEST MODES The EUT was pre-tested under the following resolution & horizontal synchronization speed modes: β¦ 1024x768 (75Hz/60KHz) β¦ 800x600 (75Hz/47KHz) β¦ 640x480 (60Hz/31.5KHz) The worst emission level was found when the EUT was tested under 1024x768 (75Hz/60KHz) resolution. Therefore only the test data of this mode was recorded in this report. FCC ID: KX7LZE Report No.: F910912A026Issued: Oct. 23, 2002 3.3 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. NO.PRODUCTBRANDMODEL NO.SERIAL NO.FCC ID 1 PERSONAL COMPUTER HPBrio BA410SG12106012FCC DoC Approved 2PRINTEREPSONLQ-300+DCGY01β¦
