KX7MW7S17" Multi VGA Color Monitor

(Photo 1) FCC ID: KX7MW7S (Photo 2) FCC ID: KX7MW7S 5

(Fig. 1) FCC ID: KX7MW7S FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

(Photo 10) FCC ID: KX7MW7S (Photo 11) FCC ID: KX7MW7S (Photo 12) FCC ID: KX7MW7S (Photo 13) FCC ID: KX7MW7S 6 (Photo 14) FCC ID: KX7MW7S (Photo 15) FCC ID: KX7MW7S

(Photo 3) FCC ID: KX7MW7S (Photo 4) FCC ID: KX7MW7S (Photo 5) FCC ID: KX7MW7S 1 (Photo 6) FCC ID: KX7MW7S 1 2 3 (Photo 7) FCC ID: KX7MW7S 4 (Photo 8) FCC ID: KX7MW7S (Photo 9) FCC ID: KX7MW7S

FCC ID: KX7MW7S Report No.: F900223021Issued: March 29, 2001 FCC TEST REPORT REPORT NO.: F90022302 MODEL NO.: MW7SK, MD-BTC-MW7S RECEIVED: Feb. 23, 2001 TESTED: March 27, 2001 APPLICANT:Three SOMA TECHNOLOGY CO., LT D. ADDRESS: FL.2 NO.27, SHOEI BIANN 2 ND RD., TAOYUAN, TAIWAN, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 18 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. The test results in this report are traceable to the national or international standards. 0528 Lab Code: 200102-0 FCC ID: KX7MW7S Report No.: F900223022Issued: March 29, 2001 Table of Contents 1CERTIFICATION............................................................................................. 3 2SUMMARY OF TEST RESULTS..................................................................... 4 3GENERAL INFORMATION ............................................................................. 5 3.1GENERAL DESCRIPTION OF EUT ............................................................... 5 3.2DESCRIPTION OF TEST MODES ................................................................. 5 3.3DESCRIPTION OF SUPPORT UNITS............................................................ 6 4EMISSION TEST ............................................................................................ 7 4.1CONDUCTED EMISSION MEASUREMENT .................................................. 7 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................... 7 4.1.2 TEST INSTRUMENTS .................................................................................... 7 4.1.3 TEST PROCEDURE ....................................................................................... 8 4.1.4 DEVIATION FROM TEST STANDARD ........................................................... 8 4.1.5 TEST SETUP .................................................................................................. 8 4.1.6 EUT OPERATING CONDITIONS.................................................................... 9 4.1.7 TEST RESULTS............................................................................................ 10 4.2RADIATED EMISSION MEASUREMENT ..................................................... 12 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .................................. 12 4.2.2 TEST INSTRUMENTS .................................................................................. 12 4.2.3 TEST PROCEDURE ..................................................................................... 13 4.2.4 DEVIATION FROM TEST STANDARD ......................................................... 13 4.2.5 TEST SETUP ................................................................................................ 14 4.2.6 EUT OPERATING CONDITIONS.................................................................. 14 4.2.7 TEST RESULTS............................................................................................ 15 5PHOTOGRAPHS OF THE TEST CONFIGURATIO ...................................... 16 6APPENDIX - INFORMATION ON THE TESTING LABORATORIES............. 18 FCC ID: KX7MW7S Report No.: F900223023Issued: March 29, 2001 1 CERTIFICATION PRODUCT:17” MULTI VGA COLOR MONITOR BRAND NAME:Three Soma, BTC MODEL NO:MW7SK, MD-BTC-MW7S APPLICANT:Three SOMA TECHNOLOGY CO., LTD. STANDARDS:FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample (model: MW7SK ) of the designation has been tested in our facility on March 27, 2001. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: KX7MW7S Report No.: F900223024Issued: March 29, 2001 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: StandardTest TypeResultRemarks Conducted TestPASS Meets Class B Limit Minimum passing margin is –3.78 dB at 0.187 MHz FCC Part 15, Subpart B, CISPR 22: 1997, Class B Radiated TestPASS Meets Class B Limit Minimum passing margin is –2.0 dB at 226.76 MHz NOTE: For conducted emission test, the test limit used is according to FCC Part 15.107. In this part, conducted emission test for telecom port is not mentioned and therefore this item is not tested. FCC ID: KX7MW7S Report No.: F900223025Issued: March 29, 2001 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCT17” MULTI VGA COLOR MONITOR MODEL NO.MW7SK, MD-BTC-MW7S POWER SUPPLY Switching Power Cord: Nonshielded, 3 pin, AC (1.8m) DATA CABLENA NOTE: The EUT has two models listed in this report, model: MW7SK and MD-BTC-MW7S which are identical to each other in all aspects except for their brand names only:
MW7SK – for Three SOMA
MD-BTC-MW7S – for BTC For a more detailed features description, please refer to the manufacturer's specifications or the User's Manual. 3.2 DESCRIPTION OF TEST MODES The EUT was pre-tested under the following conditions in electromagnetic interference: CONDITIONRESOLUTION 11280x1024 (64 kHz) 21024x768 (68.9 kHz) 3640x480 ( 31.5 kHz) Since the worst emission levels were found when the EUT was tested under 1280x1024 resolution, Condition 1 is adopted for the final test. FCC ID: KX7MW7S Report No.: F900223026Issued: March 29, 2001 3.3 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. NO.PRODUCTBRA…

Text truncated - open the document above for the full version.

FCC ID: KX7MW7S Report No.: F9002230216Issued: March 29, 2001 5 PHOTOGRAPHS OF THE TEST CONFIGURATIO CONDUCTED EMISSION TEST FCC ID: KX7MW7S Report No.: F9002230217Issued: March 29, 2001 RADIATED EMISSION TEST
