L2BACEKEY582

Solid Year Co Ltd

Click to zoom

Application Details

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Date of Grant: Dec 22, 1999
Application Purpose: Original Equipment
Date of Application: Oct 31, 1999
Company: Solid Year Co Ltd
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Cover Letter(s)

MESSERS: Max Light Technology Co.,LtdDATE: 10/20/1999 POWER OF ATTORNEY SUBJECT: FCC APPLICATION We, the undersigned, hereby authorize Max Light Technology Co.,Ltd. To act on our behalf in all matters relating to application for equipment authorization of our model: ACK-600HM / ACK-582 / INN-582 including the signing of all documents relating to these matters. Any and all acts carried out by Max Light Technology Co.,Ltd. On our behalf shall have the same effect as acts of our own. Applicant: SOLID YEAR CO.,LTD By: C. P. WANG Signature Printed Title: R&D MANAGER

Cover Letter(s)

External Photos

MAX LIGHT Report Number: MLT9910P15006 FCC ID: L2BACEKEY582 Technology Lab MAX LIGHT Report Number: MLT9910P15006 FCC ID: L2BACEKEY582 Technology Lab MAX LIGHT Report Number: MLT9910P15006 FCC ID: L2BACEKEY582 Technology Lab MAX LIGHT Report Number: MLT9910P15006 FCC ID: L2BACEKEY582 Technology Lab

External Photos

ID Label/Location Info

MAX LIGHT Report Number: MLT9910P15006 FCC ID: L2BACEKEY582 Technology Lab Label Format: Label Position: FCC ID: L2BACEKEY582 This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received ,including. Interference that may cause undesired operation. Model: ACK-582 / INN-582 MADE IN TAIWAN Equipment Label 6CMX3.5CM Rear View

ID Label/Location Info

Test Report

Product : Wireless Keyboard (RX) Manufacture : SOLID YEAR CO., LTD FCC ID : L2BACEKEY582 Model : ACK-582 / INN-582 Report No. : MLT9910P15006 Test Date : October 26.1999 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-363-2447 Fax: 886-2-363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 9 9 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab Table of Contents : I. General 4. II. Conducted Emissions Requirements 8. III. Radiated Emissions Requirements 14. Appendix I (EUT Test Setup) 19. MAX LIGHT MEASUREMENT REPORT Page: 3/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT (Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B. EUT: Wireless Keyboard(RX) Applicant: SOLID YEAR CO., LTD NO.3 PAO CHI LANE, CHUANG YA TSUN, SIU SHUI HSIANG, CHANGHWA HSIEN, TAIWAN R.O.C Manufacturer: SOLID YEAR CO., LTD. NO.3 PAO CHI LANE, CHUANG YA TSUN, SIU SHUI HSIANG, CHANGHWA HSIEN, TAIWAN R.O.C Model No: ACK-582 / INN-582 FCC ID: L2BACEKEY582 Prepared by : Approved by : Country Huang Roger Chen MAX LIGHT MEASUREMENT REPORT Page: 4/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of SOLID YEAR CO., LTD. In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart And B of the Commission’s and Regulations. 1.2 Description of EUT EUT: Wireless Keyboard(RX) Applicant: SOLID YEAR CO., LTD NO.3 PAO CHI LANE, CHUANG YA TSUN, SIU SHUI HSIANG, CHANGHWA HSIEN, TAIWAN R.O.C Manufacturer: SOLID YEAR CO., LTD. NO.3 PAO CHI LANE, CHUANG YA TSUN, SIU SHUI HSIANG, CHANGHWA HSIEN, TAIWAN R.O.C Model No: ACK-582 / INN-582 FCC ID : L2BACEKEY582 Power Type: 5V DC form host computer. Phone Cable: PS/2 connectorx2(Shielded, 30 cm long) The Wireless Keyboard is designed for PC system which built-in Infra-Red technology. EUT is the wireless keyboard’s infra-red receiver. MAX LIGHT MEASUREMENT REPORT Page: 5/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab 1.3 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4-1991, following equipments were used as the support units. Computer: COMPAQ Model No.: 3284 Serial No.: L708BKTB4154 FCC ID: EJH3284 Monitor: COMPAQ Model No.: 303U Serial No.: 704AG19TG099 FCC ID: BJMCM14UH Printer: PANASONIC Model No.: KX-P1080I Serial No.: 7CKAKE98933 FCC ID: ACJ5Z6KX-P10801 Modem: Askey (External Fax / Data Modem) Model No.: WS1414VE Serial No.: IAH-10811 FCC ID: H8N1414VE MAX LIGHT MEASUREMENT REPORT Page: 6/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab 1.4 Configuration of System Under Test During testing the EUT(Wireless Keyboard’s infra-red receiver) was connected to the two Compaq PC’s PS/2 port . So there is no need for additional I/O card. A modem was connected to the series port and a printer was connected to the parallel port. Two telephone line(RJ11C cables) connected to the Phone Jack of modem and the Line Jack of modem. Power Supply PC Monitor Printer Keyboard EUT RJ11C Cables RS-232RS-232 Modem MAX LIGHT MEASUREMENT REPORT Page: 7/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab 1.5 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of unintentional Radiators." 1.6 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests were chosen as that which produced the highest emission levels. However, only those conditions, which the EUT was considered likely to encounter in normal use, were investigated. The system's radiated and conducted emissions were investigated while the computer alternately transferred data to the EUT as well as to the monitor and printer. Using a test program which sent a continuous stream of “H” characters to monitor and transferred data to and from the EUT was proven to worst case emissions.The system's physical layout and cabling was randomly arranged to ensure that maximum emission levels were attained. MAX LIGHT MEASUREMENT REPORT Page: 8/20 Report Number: MLT9910P15006FCC ID: L2BACEKEY582 Technology Lab II. Conducted Emissions Requirements 2.1 General & Setup : The power line conducted emission measurements were performed in a shielded enclosure. The EUT was assembled on a wooden table which is 80 centimeters high, was placed 40 centimeters from the backwall and at least 1 meter from the sidewall. Power wa…
