L4OR330TS

EXHIBIT C User Manual

EXHIBIT E Block Diagram

EXHIBIT F Photographs of EUT

EXHIBIT A Sample Label LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID: L4OR330TS Model No.: WS-R330T/S LABEL Size : 3316 mm LABEL Position:

EXHIBIT D Circuit Diagram

EXHIBIT B Test Report Test Report------------------------------------------------------------------------------------------------------------ Report No.: C0915655, Ethernet Card for PCI, FCC Part 15.109 (g), Class B Test date: 08/11/99, Training Research Co., Ltd., TEL: 886-2-26935155,Fax: 886-2-26934440 2/13 Contents Chapter 1 Introduction Description of EUT........................................................................................................................3 Configuration of Test Setup............................................................................................................4 List of Support Equipment..............................................................................................................5 Chapter 2 Conducted Emission Test Test Condition and Setup...............................................................................................................7 Conducted Test Placement.............................................................................................................8 Chapter 3 Radiated Emission Test Test Condition and Setup...............................................................................................................9 Radiated Test Placement...............................................................................................................10 Appendix A: Conducted test result.....................................................................................................................11 Appendix B: Radiated test result........................................................................................................................12 Test Report------------------------------------------------------------------------------------------------------------ Report No.: C0915655, Ethernet Card for PCI, FCC Part 15.109 (g), Class B Test date: 08/11/99, Training Research Co., Ltd., TEL: 886-2-26935155,Fax: 886-2-26934440 3/13 Chapter 1Introduction Description of EUT: The Lan Card is a data transmitting / receiving facility. It is designed to install in the PC or compatible computer and makes your data equipment available to transmit / receive data via the EUT. During testing the EUT was operated at Tx or Rx mode for each emission measured. This was done in order to insure that maximum emission levels were attained. Connections of EUT: (1) Put the EUT into a personal computer’ PCI bus and screw it. (2) The RJ45 jack of EUT was connected with another Lan card installed in another PC located remotely. Test method: Pretest was found that the emission of operating mode is worse than standby mode. So, The final test is made at the operating mode. During radiation testing, the EUT was operated at “transmitting” mode. The test placement as the photographs showed is the worst case emission placed. (If the emission is close to the ambient, the resolution BW and view resolution will be reduced and the data will be recorded by detection of maximum hold peak mode.) The testing configuration of test setup is showing in the next page. Test Report------------------------------------------------------------------------------------------------------------ Report No.: C0915655, Ethernet Card for PCI, FCC Part 15.109 (g), Class B Test date: 08/11/99, Training Research Co., Ltd., TEL: 886-2-26935155,Fax: 886-2-26934440 4/13 Configuration of test setup Connections: PC: *Serial A port --- a external modem with 76 cm shielded RS-232 cable *Serial B port --- a shielded RS232 cable with 76cm long, no ferrite bead *Printer port --- a Printer with 1.2m length data cable *Keyboard port --- a Keyboard with 1m length data cable *Mouse port --- a Mouse with 0.7m long of data cable *Monitor port --- a monitor with 1m length data cable *USB ports --- two USB joysticks with 1.5m long, shielded, no ferrite bead data cable (Each port on PC is connected with suitable device) EUT: *RJ45 Jack --- via a 20m long, non-shielded, no ferrite bead, RJ45 cable to another Lan card installed in another PC located remotely. PC EUT Printer Monitor Modem RS-232 cable Keyboard To Far-End PC Power Mouse USB Joysticks Test Report------------------------------------------------------------------------------------------------------------ Report No.: C0915655, Ethernet Card for PCI, FCC Part 15.109 (g), Class B Test date: 08/11/99, Training Research Co., Ltd., TEL: 886-2-26935155,Fax: 886-2-26934440 5/13 List of support equipment Conducted (Radiated) test: PC : HP Model :VE6/350 SERIES 8 Serial No. :SG91002329 FCC ID:DoC Approval Power type:AC 100~127 / 200~240 VAC, Switching Power cord :non-Shielded, 1.7m long, Plastic, no ferrite core Monitor :HP Model No.:D2821 Serial No.:TW 73512262 (TW 73147163) FCC ID:A3KMO64 Power type:AC 110~120 / 220~240 VAC, Switching Power cord:Non-Shielded, 3m long, no ferrite core Data cable :Shielded, 1.8m long, with ferrite core Keyboard:Digital Model No.:KB-5923 Serial No.:9S74904837 (9S74904665) FCC ID:E8HKB-5923 Power type:By PC Data cable :Shielded, 1.8m long, with ferrite core Printer:HP Model No.:C2642A Serial No.:SG69A196GV FCC ID:B94C2642X Power type:220 VAC, 50Hz Power cord:Non-shielded, 2m long, no ferrite core Data cable :Shielded, 1.84m long, no ferrite core (1.7m) Test Report------------------------------------------------------------------------------------------------------------ Report No.: C0915655, Ethernet Card for PCI, FCC Part 15.109 (g), Class B Test date: 08/11/99, Training Research Co., Ltd., TEL: 886-2-26935155,Fax: 886-2-26934440 6/13 Modem:ACEEX Model No.:XDM-9624 FCC ID:IFAXDM-9624 Power type:220VAC, 50Hz / 9VAC, 1A Power cord:Non-shielded, 1.9m long, no ferrite cord Data cable :RS232, Shielded, 1.2m long, no ferrite core RJ11C x 2, 7’ long non-shielded, no ferrite core Mouse:Hewlett Packard Mouse Model No.:C3751B Serial No.:LCA52707170 FCC ID:DZL210582 Power type:Powered by PC Power Cable:Non – Shielded. 5.5' long, Plastic hoods, No ferrite bead Joystick:Padix Model:QF-606U, QF…
