L4QCDMA32VOIPUSCellular/PCS CDMA Gateway

CELLX Reference Manual Software version 16.2 TELES AG | HEADQUARTERS Ernst-Reuter-Platz 8 10587 Berlin GERMANY Phone +49 30 399 28-066 Fax+49 30 399 28-051 E-mail sales @ teles.com httpwww.teles.com © Copyright 2010 TELES AG Informationstechnologien. All rights reserved. TELES ® , IntraSTAR ® , Intra* ® , iGATE ® , and iSWITCH ® are registered trademarks of TELES AG Informationstechnologien. All other trademarks used are the property of their respective owners. The supplied hardware/software systems are protected by copyright and can be used solely by their lawful owners. All text and figures in this publication have been compiled with great attention to detail. Nonetheless, inaccuracies and typographical errors cannot be entirely avoided. TELES AG Informationstechnologien provides this document 'as is' without warranty of any kind, expressed or implied. TELES AG Informationstechnologien reserves the right to make changes in product design or specifications without notice. Reference Manual CELLX CELLX 16.2 Revised:18 November 2011Software version: 16.2 Page 1CELLX 16.2 1 About this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1.1Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 1.2Conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 1.3Safety symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 2 Safety and security precautions . . . . . . . . . . . . . . . . . . . . . . . . 9 2.1Safety measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 2.2FCC / Industry Canada Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 2.3EMC protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 2.4System security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 2.5Servicing the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 2.5.1Replacing components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 2.5.2Protecting the operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 2.6CDR files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 2.7Network security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 3 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 3.1What’s new in version 16.2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 3.2New Access Gateway product names starting version 16.1 . . . . . . . . . . . . . . . . . . .16 3.3How CELLX works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 3.4Supported implementation scenarios . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 4.1Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 4.2Package contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 4.3Hardware description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 4.4Installation requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 4.4.1Ethernet wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 4.4.2PRI wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 4.4.2.1TELES to TBR12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 4.4.3Antenna connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 4.4.4SIM card assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 4.5Preparing for installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 4.6Hardware connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 4.7Startup with Quickstart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 4.7.1Installing Quickstart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 4.7.2Configuration with Quickstart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 4.8Startup via GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 4.9LED functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 4.9.1Ethernet port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 4.9.2Base Board PRI port LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 4.9.3Mobile Board SIM card LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 4.10Remote access and access security. . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP External Photos EUT Type: CDMA Gateway Page 1 of 4 © 2011 PCTEST Engineering Laboratory Inc. EXTERNAL PHOTOGRAPHS TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP External Photos EUT Type: CDMA Gateway Page 2 of 4 © 2011 PCTEST Engineering Laboratory Inc. TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP External Photos EUT Type: CDMA Gateway Page 3 of 4 © 2011 PCTEST Engineering Laboratory Inc. TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP External Photos EUT Type: CDMA Gateway Page 4 of 4 © 2011 PCTEST Engineering Laboratory Inc. TitleCELLX CDMA 32 VoIPLabel position created by: AnPa 80mm 100mm Manufacturer Information FCC ID Serial Number Model Information FCC Warning Statement DateOct 4, 2011

TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Internal Photos EUT Type: CDMA Gateway Page 1 of 5 © 2011 PCTEST Engineering Laboratory Inc. INTERNAL PHOTOGRAPHS TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Internal Photos EUT Type: CDMA Gateway Page 2 of 5 © 2011 PCTEST Engineering Laboratory Inc. TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Internal Photos EUT Type: CDMA Gateway Page 3 of 5 © 2011 PCTEST Engineering Laboratory Inc. TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Internal Photos EUT Type: CDMA Gateway Page 4 of 5 © 2011 PCTEST Engineering Laboratory Inc. TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Internal Photos EUT Type: CDMA Gateway Page 5 of 5 © 2011 PCTEST Engineering Laboratory Inc.

Reviewed by: FCC ID: L4QCDMA32VOIPUS FCC Pt. 22/24 CDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1102110262.L4Q February 11, 2011 CDMA Gateway Page 1 of 38 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3CFI 10/26/2010 Applicant Name: Date of Testing: TELES AG, Informationstechnologien February 11, 2011 Ernst-Reuter-Platz 8 Test Site/Location: 10587 Berlin PCTEST Lab., Columbia, MD, USA GERMANY Test Report Serial No.: 0Y1102110262.L4Q FCC ID: L4QCDMA32VOIPUS APPLICANT: TELES AG, INFORMATIONSTECHNOLOGIEN Application Type: Certification FCC Classification: PCS Licensed Transmitter (PCB) FCC Rule Part(s): §2; §22(H), §24(E) IC Specification(s): RSS-129 Issue 2; RSS-133 Issue 5 EUT Type: CDMA Gateway Model(s): CellX CDMA-8 VoIP Tx Frequency Range: 824.70 - 848.31MHz (Cell. CDMA) / 1851.25 - 1908.75MHz (PCS CDMA) Max. Conducted Power: 0.0129 W Cell. CDMA (11.1 dBm) / 0.0134 W PCS CDMA (11.28 dBm) Emission Designator(s): 1M28F9W (CDMA) / 1M29F9W (PCS) Test Device Serial No.: identical prototype [S/N: TAG39011028325925] This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in §2.947. Test results reported herein relate only to the item(s) tested. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Conditions: Power output listed is conducted for Part 22 and 24. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com MEASUREMENT REPORT FCC Part 22 & 24 / IC RSS-129/RSS-133 Reviewed by: FCC ID: L4QCDMA32VOIPUS FCC Pt. 22/24 CDMA MEASUREMENT REPORT (CERTIFICATION) Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1102110262.L4Q February 11, 2011 CDMA Gateway Page 2 of 38 © 2011 PCTEST Engineering Laboratory, Inc. REV 1.3CFI 10/26/2010 TABLE OF CONTENTS FCC PART 22 & 24 MEASUREMENT REPORT...........................................................................3 1.0 INTRODUCTION....................................................................................................................4 1.1 SCOPE..................................................................................................................................................................4 1.2 TESTING FACILITY............................................................................................................................................4 2.0 PRODUCT INFORMATION.....................................................................................................5 2.1 EQUIPMENT DESCRIPTION...........................................................................................................................5 2.2 EMI SUPPRESSION DEVICE(S)/MODIFICATIONS....................................................................................5 2.3 LABELING REQUIREMENTS...........................................................................................................................5 3.0 DESCRIPTION OF TESTS......................................................................................................6 3.1 MEASUREMENT PROCEDURE......................................................................................................................6 3.2 OCCUPIED BANDWIDTH.................................................................................................................................6 3.3 CELLULAR - BASE FREQUENCY BLOCKS.................................................................................................6 3.4 CELLULAR - MOBILE FREQUENCY BLOCKS.............................................................................................7 3.5 PCS - BASE FREQUENCY BLOCKS..............................................................................................................7 3.6 PCS - MOBILE FREQUENCY BLOCKS.........................................................................................................7 3.7 SPURIOUS AND HARMONIC EMISSIONS AT ANTENNA TERMINAL...................................................7 3.8 RADIATED POWER AND RADIATED SPURIOUS EMISSIONS...............................................................8 3.9 PEAK-AVERAGE RATIO...................................................................................................................................8 3.10 FREQUENCY STABILITY / TEMPERATURE VARIATION.........................................................................8 4.0 TEST EQUIPMENT CALIBRATION DATA...............................................................................9 5.0 SAMPLE CALCULATIONS....................................................................................................10 6.0 TEST RESULTS...................................................................................................................11 6.1 SUMMARY.........................................................................................................................................................11 6.2 CONDUCTED OUTPUT POWER..................................................................................................................12 6.3 EFFECTIVE RADIATED POWER OUTPUT DATA.....................................................................................13 6.4 EQUIVALENT ISOTROPIC RADIATED POWER OUTPUT DATA..........................................................14 6.5 CELLULAR CDMA RADI…

Text truncated - open the document above for the full version.

Reviewed by: FCC ID: L4QCDMA32VOIPUS MAXIMUM PERMISSIBLE EXPOSURE (MPE) DATA REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1102110264.L4Q October 18, 2011 CDMA Gateway Page 1 of 7 © 2011 PCTEST Engineering Laboratory, Inc. REV 3.1MPE 02/09/09 Applicant Name: Date of Testing: TELES AG, Informationstechnologien October 18, 2011 Ernst-Reuter-Platz 8 Test Site/Location: 10587 Berlin PCTEST Lab, Columbia, MD, USA GERMANY Test Report Serial No.: 0Y1102110264.L4Q FCC ID: L4QCDMA32VOIPUS APPLICANT: TELES AG, Informationstechnologien EUT Type: CDMA Gateway FCC Rule Part(s): FCC Part 1 (§1.1310) and Part 2 (§2.1091) FCC Classification: PCS Licensed Transmitter (PCB) Test Procedure: OET Bulletin 65 The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in the measurement report and has been tested in accordance with the measurement procedures specified in FCC OET Bulletin 65 (See Test Report). These measurements were performed with no deviation from the standards. Test results reported herein relate only to the item(s) tested. I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti -Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST ENGINEERING LABORATORY, INC. 6660-B Dobbin Road, Columbia, MD 21045 USA Tel. 410.290.6652 / Fax 410.290.6554 http://www.pctestlab.com RF EXPOSURE EVALUATION (MAXIMUM PERMISSIBLE EXPOSURE) Reviewed by: FCC ID: L4QCDMA32VOIPUS MAXIMUM PERMISSIBLE EXPOSURE (MPE) DATA REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1102110264.L4Q October 18, 2011 CDMA Gateway Page 2 of 7 © 2011 PCTEST Engineering Laboratory, Inc. REV 3.1MPE 02/09/09 TABLE OF CONTENTS 1.0 RF EXPOSURE EVALUATION – MAXIMUM PERMISSIBLE EXPOSURE (MPE).......................3 1.1 INTRODUCTION...................................................................................................................................................3 1.2 EUT DESCRIPTION.............................................................................................................................................3 1.3 MPE REQUIREMENTS OVERVIEW.................................................................................................................4 1.4 PROCEDURE........................................................................................................................................................5 1.5 SUMMARY OF RESULTS...................................................................................................................................6 2.0 CONCLUSION.......................................................................................................................7 Reviewed by: FCC ID: L4QCDMA32VOIPUS MAXIMUM PERMISSIBLE EXPOSURE (MPE) DATA REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1102110264.L4Q October 18, 2011 CDMA Gateway Page 3 of 7 © 2011 PCTEST Engineering Laboratory, Inc. REV 3.1MPE 02/09/09 1.0 RF EXPOSURE EVALUATION – MAXIMUM PERMISSIBLE EXPOSURE (MPE) 1.1 Introduction This document is prepared on behalf of TELES AG, Informationstechnologien to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC Rules and Regulations and RSS-102 of Industry Canada. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310 and RSS-102: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits For Occupational / Control Exposures (f = frequency) 30-300 61.4 0.163 1.0 6 300-1500 ... ... f/300 6 1500-100,000 ... ... 5.0 6 (B) Limits For General Population / Uncontrolled Exposure (f = frequency) 30-300 27.5 0.073 0.2 30 300-1500 ... ... f/1500 30 1500-100,000 ... ... 1.0 30 Table 1-1. Limits for Maximum Permissible Exposure (MPE) 1.2 EUT Description The TELES AG Model: CellX CDMA-8 VoIP is a CDMA Gateway containing the Telit CDMA Wireless Module (Model: CC864-DUAL). For this MPE evaluation the device is set to transmit from the antenna terminal and the RF exposure of the transmitter is evaluated. EUT: Model: CellX CDMA-8 VoIP Grantee: TELES AG, Informationstechnologien FCC ID: L4QCDMA32VOIPUS Antenna Gains: External Antenna: 5.16 dBi @ 850 MHz and 1900 MHz Output Powers: Cellular CDMA11.10 dBm PCS CDMA11.28 dBm Reviewed by: FCC ID: L4QCDMA32VOIPUS MAXIMUM PERMISSIBLE EXPOSURE (MPE) DATA REPORT Quality Manager Test Report S/N: Test Dates: EUT Type: 0Y1102110264.L4Q October 18, 2011 CDMA Gateway Page 4 of 7 © 2011 PCTEST Engineering Laboratory, Inc. REV 3.1MPE 02/09/09 1.3 MPE Requirements Overview Three different categories of transmitters are defined by the FCC in OET Bulletin 65. These categories are fixed installation, mobile, and portable and are defined as follows: o Fixed Installations: fixed location means that the device, including its antenna, is physically secured at a permanent location and is not able to be easily moved to another location. Additionally, distance to humans from the antenna is maintained to at least 2 meters. o Mobile Devices: a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to be generally used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating st…

Text truncated - open the document above for the full version.

TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Test Set-Up Photos EUT Type: CDMA Gateway Page 1 of 2 © 2011 PCTEST Engineering Laboratory Inc. TEST SETUP PHOTOGRAPHS TELES AG FCC ID: L4QCDMA32VOIPUS Model: CellX CDMA-8 VoIP Test Set-Up Photos EUT Type: CDMA Gateway Page 2 of 2 © 2011 PCTEST Engineering Laboratory Inc.
