LAK171PLCD Monitor With TV Tuner

This equipment has been designed for the normal use. It is certified to comply with Electron Wave Suitable Registration. The user this equipment in everywhere including residential areas. 171P USER GUIDE Notice This equipment is one of first class quality. The LCD panel is composed of about 4 Million pixels and may have some faulty pixels. LCD panels with a maximum of 10 faulty pixels are classified as products of good quality. This standard is accepted by other manufacturers of LCD panels. An LCD panel without any faulty pixels is too expensive for the average customer. Our ”A” class panels have the least 5 faulty pixels. We guarantee that our panels will provide the user with high quality performance. Therefore, no product exchanges or refunds will be made in regards to this matter. Please observe all following rules for installation, usage, and services so as to not defeat the safeguards incorporated into this monitor. Safety precautions are divided into Warning and Attention. Warning : Please ensure that no water leaks or gets onto or into the LCD monitor. Accidental exposure to water may cause fire or electrical damage. If case occurs, please turn off and unplug the monitor. If there is smoke or abnormal noises, please contact the store or customer service center. Attention ; Breaking the basic rules can cause injury can cause injury to yourself or damage to the equipment. Save the manual near to future users after you read it. Do not open the monitor. Contact your dealer if the monitor is not operating properly. Do not place the monitor in direct sunlight or close to any heat source. -Product malfunction or fire hazard may occur. Do not drop metal objects like coins or hairpins into the monitor. -Electrical shock or fire hazard may result. Provide a secure connection to the power supply and do not use damaged power cords or plugs. - Electrical shock or fire hazard may result. Do not place the monitor in exposed places or near water. Do not clean the monitor with water or touch it with wet hands. -Electrical shock or fire hazard may result. During lightening storms, unplug the monitor from the wall outlet and do not touch it. -Electrical shock or fire hazard may result Not using the monitor for hours, unplug the monitor from the wall outlet. - Dust may cause heat, fire, shock or short circuit If you use an outdoor antenna, be ensure that no water leaks through connectors and get onto the monitor. - Any liquid spill on the TV may cause fire or electric shock In case of any smoke or abnormal noise, immediately stop use of product and pull the power cord from the wall outlet. Then call your local dealer or service representative for assistance. -Any subsequent use may result in fire or electric shock. Install the monitor at the specified position from the wall to be well ventilated. - A rise in temperature of monitor may cause fire. Install the monitor in stable place. - An unstable monitor may crash or fall. Personal injury, damage, or malfunction may result. Do not block ventilation openings with any curtain or tablecloths. - The increase of inside temperature may cause fire DO not drop the unit or make any scratch on the panel when you move the product. -Any scratch on the panel or drop of the product may cause functional failure. When moving the monitor, turn it off and disconnect all cables and the plug. - Product damage, electric shock, or fire hazard may result. When disconnecting from the wall outlet, grab the plug. - Grabbing the cord may result in heat generation or fire hazard. Keep your eyes 20 inch away from the screen and 0~15° down in relation to the screen. - Viewing at too close a position and wrong posture can weaken your eyes. Do not press hard with your finger or scratch with sharp object on the surface of the LCD. -Any damage on the surface of the LCD may cause functional failure. When you clean the monitor and the surface of LCD, be sure to pull the plug from wall outlet. Use soft cloth instead of using damp duster. Do not use any chemicals such as industrial polisher, abrasive solution, wax, benzene, alcohol, or clearing detergents. - Chemical cleaners may fade, dissolve, or crack the monitor surface. If you install outdoor antenna, be sure to install it at the distance from power wire. - If the antenna contacts with the power wire, it may cause electric shock. Be sure to keep the distance of the outdoors antenna so that it would not touch electric wire in case it falls by heavy wind. - If the antenna touches electric wire, it may cause injury and electric shock. 1. Adjust Buttons : Moves the selector up or down on the OSD. Increases or decreases the channel number. 2. Volume Buttons : Adjusts OSD Settings on the OSD. Increases or decreases the level of speaker volume. 3. Auto Button : Automatically adjusts the monitor settings on PC mode. 4. Select Button : Selects the input source. (PC / TV / AV1 / AV2). 5. Menu Button : Opens or Closes the OSD. 6. Power Button : Turns ON/OFF the Monitor. 1. Power In Terminal Connect the DC Adaptor to the power terminal on the back of the monitor. 2. D-SUB Terminal Connect the monitor D-SUB connector and the PC using the D-SUB signal cable. 3. S-Video Input Terminal Connect S-Video cable to this input. 4. Composite Video Input Terminal Connect video cable to this input. 5. Audio Input (Left) Terminal Connect left audio cable to this input. 6. Audio Input (Right) Terminal Connect right audio to this input. 7. PC Audio Input Terminal Connect the audio output of the PC. 8. PC Audio Output Terminal Connect the stereo speaker system to Audio output. 9. Antenna Input Terminal Use to connect antennas (AIR/CATV) and VCR. 10. VESA HOLE for fixing on the wall. Supports VESA mounting standard for use with various VESA mounting devices. Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Attention : Power off your Monitor before making any connections. 1. Power Connection : Co…

Text truncated - open the document above for the full version.

Speaker 2W Speaker 2W 1. Block Diagram 1) 17 Inch Panel LV D S RGB TTL RGB DDC Vo l u m e Control SCALAR NT68520EF EEPROM AT24C16 (2K Bytes) MCU NT68F63 (60K Bytes) LCD PANEL (17 Inch) AUDIO BOARD DC/DC Converter (5.0V Output) Linear Regulator (3.3V Output) INVERTER BUFFER 74HC14 P C HIS/VSI Analog RGB Hsync Vsync LV D S NT7181F POWER CONTORL IIC INVERTER MODULE High Voltage Power Brightness Control OSD BOARD 12V 5V 3.3V NFS-15 A/D BOARD SPK L 2W SPK R 2W
