LDK-IR529UWPIR529 915Mhz WPAN IP67 Range Extender

REVIEW DRAFT—CISCO CONFIDENTIAL 42 Regulatory Compliance and Safety Information for the Cisco IR 500 Series WPAN Gateway and Range Extender OL-141020-0B Translated Safety Warnings Statement 1058—Power and Relay Connector 158°F (70°C) 158°F (70°C) 158°F (70°C) 158°F (70°C) 158°F (70°C) 158°F (70°C) 158°F (70°C) Warning When you connect or disconnect the power and/or alarm connector with power applied, an electrical arc can occur. This could cause an explosion in hazardous area installations. Be sure that all power is removed from the switch and any other circuits. Be sure that power cannot be accidentally turned on or verify that the area is nonhazardous before proceeding. Statement 1058 Waarschuwing Wanneer u de voedings- en/of alarmconnector aansluit of loskoppelt terwijl de stroom is ingeschakeld, kan er een vlamboog ontstaan. Dit kan leiden tot explosies in installaties op gevaarlijke locaties. Zorg ervoor dat de stroom is uitgeschakeld voor de switch en alle andere circuits. Zorg ervoor dat de stroom niet ongewild kan worden ingeschakeld of controleer of de locatie ongevaarlijk is alvorens door te gaan. REVIEW DRAFT—CISCO CONFIDENTIAL 43 Regulatory Compliance and Safety Information for the Cisco IR 500 Series WPAN Gateway and Range Extender OL-141020-0B Translated Safety Warnings Varoitus Jos kytket tai irrotat virta- ja/tai hälytysliittimen virta kytkettynä, järjestelmä saattaa aiheuttaa valokaaren. Tämä voi aiheuttaa räjähdyksen räjähdysvaarallisissa asennuskohteissa. Varmista, että virta on katkaistu kytkimestä ja kaikista muista piireistä. Varmista ennen jatkamista, että virtaa ei voida kytkeä vahingossa tai että alue on turvallinen. Attention Si vous connectez ou déconnectez le connecteur d'alimentation et/ou d'alarme, un arc électrique risque de se produire. Cela risque d'entraîner une explosion dans les installations situées dans des environnements dangereux. Assurez-vous que le commutateur et tous les autres circuits ne sont pas sous tension. Avant de commencer, assurez-vous qu'il est impossible de brancher accidentellement l'alimentation électrique et vérifiez que la zone n'est pas dangereuse. Warnung Wenn Sie den Netz- und/oder Alarmstecker an eine Stromquelle anschließen, kann sich ein Lichtbogen bilden. Dies kann bei Installationen in als gefährlich eingestuften Bereichen zu einer Explosion führen. Stellen Sie sicher, dass der Switch und alle sonstigen Schaltkreise nicht mit Strom versorgt werden. Vergewissern Sie sich, dass die Stromversorgung nicht versehentlich hergestellt werden kann bzw. dass es sich um einen nicht als gefährlich eingestuften Bereich handelt, bevor Sie den Vorgang fortsetzen. Avvertenza Quando si collega o scollega l'alimentazione e/o il connettore dell'allarme a spina inserita, potrebbe verificarsi un arco elettrico. Tale condizione potrebbe provocare un'esplosione nelle installazioni in aree a rischio. Assicurarsi che l'alimentazione sia scollegata dallo switch ed eventuali altri circuiti. Assicurarsi che non sia possibile collegare accidentalmente l'alimentazione, oppure verificare che l'area non sia a rischio prima di continuare. Advarsel Når du kobler til eller fra strøm og/eller alarmkontakt med strøm tilknyttet, kan det oppstå en elektrisk lysbue. Dette kan føre til eksplosjon ved installasjon på områder med eksplosjonsfare. Kontroller at all strøm er koblet fra bryteren og eventuelle andre kretser. Sjekk at strømmen ikke kan slås på ved et uhell, og kontroller at området ikke er farlig før du fortsetter. Aviso Quando ligar ou desligar o conector de alimentação e/ou de alarme com a energia ligada, pode ocorrer um arco eléctrico. Isto poderá originar uma explosão em instalações que possuam um local perigoso. Certifique-se de que toda a energia é removida do interruptor e de todos os outros circuitos. Certifique-se que não é possível ligar acidentalmente a alimentação ou verifique se a área não apresenta perigo antes de continuar. ¡Advertencia! Cuando conecte o desconecte el conector de alarma o alimentación con la electricidad, se puede producir un arco eléctrico. Esto podría provocar una explosión en instalaciones de ubicaciones peligrosas. Asegúrese de haber desconectado la electricidad del switch o de cualquier otro circuito. Asegúrese de que la electricidad no pueda activarse accidentalmente o de que la zona no sea peligrosa antes de realizar cualquier acción. Varning! När du ansluter eller kopplar ifrån strömmen och/eller larmanslutningen med strömmen på, kan en elektrisk ljusbåge uppstå. Detta kan leda till en explosion vid installation på farliga platser. Se till att det inte finns någon ström i strömbrytaren eller andra kretsar. Se till att inte strömmen kan sättas på av misstag och kontrollera att området är säkert innan du fortsätter. REVIEW DRAFT—CISCO CONFIDENTIAL 44 Regulatory Compliance and Safety Information for the Cisco IR 500 Series WPAN Gateway and Range Extender OL-141020-0B Translated Safety Warnings REVIEW DRAFT—CISCO CONFIDENTIAL 45 Regulatory Compliance and Safety Information for the Cisco IR 500 Series WPAN Gateway and Range Extender OL-141020-0B Translated Safety Warnings Statement 1059—Switch Installation In Hazardous Location WarningIn switch installations in a hazardous location, the DC power source could be located away from the vicinity of the switch. Before performing any of the following procedures, locate the DC circuit to ensure that the power is removed and cannot be turned on accidentally, or verify that the area is nonhazardous before proceeding. Statement 1059 Waarschuwing Bij schakelinstallaties in een gevaarlijke locatie, mag de gelijkstroombron zich niet in de buurt van de schakelaar bevinden. Voordat u een van de volgende procedures uitvoert, dient u bij het gelijkstroomcircuit te controleren of de stroom is afgesloten en niet per ongeluk kan worden aangezet of dient u te controleren of het gebied niet gevaarlijk is voordat u doorgaat. Varoitus Kun kytkimen asennus tehdään vaaralliselle paikalle, tasav…

Text truncated - open the document above for the full version.

29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL Cisco Systems, Inc. www.cisco.com Cisco has more than 200 offices worldwide. Addresses, phone numbers, and fax numbers are listed on the Cisco website at www.cisco.com/go/offices. Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide October 29, 2014 Revision 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIP PED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY. The following information is for FCC compliance of Class A devices: Th is equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. The following information is for FCC compliance of Class B devices: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment causes interference to radio or television reception, which can be determined by turning the equipment off and on, users are encouraged to try to correct the interference by using one or more of the following measures: •Reorient or relocate the recei ving antenna. •Inc rease the separation between the equipment and receiv er. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for hel p. Modifications to this product not authorized by Cisco could void the FCC approval and negate your authority to operate the product. The Cisco im plementation of TCP header compression is an adap tation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULT S. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITAT ION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOU T LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Cisco and the Cisco logo are trademarks or regist ered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respectiv e owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R) Any Internet Protocol (IP) addresses and phone numbers used in this document are no t intended to be actual addresses and phone numbers. Any examples, command display output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental. © 2014 Cisco Systems, Inc. All rights reserved. iii Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL CONTENTS Preface ix Audience ix Conventions ix Related Documents x Obtaining Documentation and Submitting a Service Request xi CHAPTER 1Overview 1-1 Features 1-1 WPAN Gateway Features 1-1 WPAN Range Extender Features 1-2 Models 1-2 WPAN Gateway Models 1-2 WPAN Range Extender Models 1-3 Assembly Details 1-3 Front Panel—WPAN Gateway 1-3 Status LEDS 1-4 Antenna Connector 1-4 RS232/RS485 DCE Port 1-5 RS232 DTE Port 1-5 USB Port 1-5 10/100 Fast Ethernet Port 1-5 Power and Alarm Connector 1-5 Reset Switch 1-6 Rear Panel—WPAN Gateway 1-6 Bottom Panel—WPAN Range Extender 1-7 Antenna Connector 1-10 Hard Points 1-10 Console Port 1-10 Protective Vent Port 1-11 Ground Connection 1-11 Power Connector 1-11 System LED 1-11 Top Panel—WPAN Range Extender 1-11 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL Contents iv Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide LEDs 1-12 WPAN Gateway LEDs 1-12 WPAN LED 1-13 RSSI LED 1-14 RS232-DCE LED 1-…

Text truncated - open the document above for the full version.

CHAPTER 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL 3-1 Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide 3 Battery Backup Unit A selection of the WPAN advanced range extender models support one battery backup unit (BBU), which provide power to the rang extender if the AC power supply fails or is not available. For more information about the WPAN advanced range extender models that support a BBU, see the “WPAN Range Extender Models Supporting BBUs” section on page 3-1. This chapter describes the BBU features and instal lation procedures, and includes the following sections: •Battery Backup Units, page 3-1 •BBU Configuration during Transportation, page 3-4 •Disabling and Enabling the BBU in the Range Extender, page 3-4 •Installing a BBU in the Range Extender, page 3-5 •BBU Technical Specifications, page 3-5 Battery Backup Units This section contains information about: •WPAN Range Extender Models Supporting BBUs, page 3-1 •Battery Backup Operations, page 3-2 •BBU Status, page 3-2 •Battery Backup Mode, page 3-2 •BBU Firmware Upgrade, page 3-3 WPAN Range Extender Models Supporting BBUs Ta b le 3-1 details the WPAN range extender models that support a BBU. Ta b l e 3-1WPAN Range Extender Models Supporting BBUs WPAN Range Extender ModelDescriptionBBU Support IR529-WP-915S/K9Connected Grid Basic Range Extender—IEEE 802.15.4e/g WP AN 900 MHz No IR529-UBWP- 915S/K9Connected Grid Advanced Range Extender , configurable with single antenna and battery backup support—IEEE 802.15.4e/g WPAN 900 MHz Ye s ( B B U i s optional) IR529-UBWP-915D/K9Connected Grid Advanced Range Extender , configurable with dual antenna and battery backup support—IEEE 802.15.4e/g WPAN 900 MHz Ye s ( B B U i s optional) IR529-UWP-915D/K9Connected Grid Advanced Range Extender , configurable with dual antenna—IEEE 802.15.4e/g WPAN 900 MHz No 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL 3-2 Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide Chapter 3 Battery Backup Unit Battery Backup Units Battery Backup Operations The battery backup unit (BBU) provides the WPAN range extender with an emergency power source if the AC power source is unavailable. The unit is mounted in the range extender housing. Ta b le 3-2describes the BBU model. Ta b l e 3-2BBU Models BBU ModelDescription CGR-BATT-4AHBattery backup unit, capacity = 48 Watt-hours BBU Status The BBU is automatically enabled and begins supplying power when the range extender detects that power is not being received from the AC power supply. The BBU continues to supply power to the range extender until at least one of the following conditions is met: •BBU is completely discharged •AC power to the range extender is enabled •BBU is disabled via the Connected Grid Network Management System (CG-NMS) software application. Battery Backup Mode This section describes impact on the range extender configuration and operating capabilities when the range extender switches from AC power to BBU power. The topics covered include: •Range Extender Configuration, page 3-3 •Range Extender Interface Operation, page 3-3 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL 3-3 Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide Chapter 3 Battery Backup Unit Battery Backup Units Range Extender Configuration The range extender software configuration is not impacted when the range extender switches from AC power to BBU power. Range Extender Interface Operation When the BBU is operating and powering the range extender, the range extender operates and performs normally. The range extender does not power off any interfaces to conserve power when AC power is not available, and the range extender is being powered by the BBU. BBU Firmware Upgrade It is only possible to use the CG-NMS to upgrade the BBU firmware and to show information about the BBU firmware upgrade. To upgrade the BBU firmware and to show information about the BBU firmware upgrade, use the CG-NMS firmwa re upgrade option. The firmware upgrade is executed in background and an output message is generated in the CG-NMS when th e BBU firmware upgrade is complete. During the firmware upgrade, you can use the CG-NMS to view the state of the BBU firmware upgrade. 29/OCT/2014 REVIEW DRAFT — CISCO CONFIDENTIAL 3-4 Cisco IR500 Series WPAN Gateway and Range Extender Installation and Configuration Guide Chapter 3 Battery Backup Unit BBU Configuration during Transportation BBU Configuration during Transportation The BBU configuration during transportation is controlled by a dedicated bit in the BBU NVRAM register called the Transportation bit or (T-bit). The T-Bit is set at the factory and is used to place the BBU in a disabled (lo w power) state. This is necessary in order to preserve the battery charge while the WPAN range extender device (with BBU installed) is in storage, or being transported between the factory and the final installation site. This sections contains: •Setting the BBU NVRAM Register T-bit, page 3-4 •BBU NVRAM Register T-bit Settings and BBU Status, page 3-4 Setting the BBU NVRAM Register T-bit The T-bit in the BBU NVRAM register is set to 1 using the CG-NMS. NoteThe T-bit is set to 1 by Cisco manufacturing at the factory. The T-bit is reset to 0 or cleared only by the CG-NMS during ZTD deployment. BBU NVRAM Register T-bit Settings and BBU Status Ta b l e 3-3BBU NVRAM T-bit Settings and BBU Status T-bit SettingBBU Status T-bit = 1 •AC ON: BBU enabled automatically (to allow battery to charge) •AC OFF: BBU disabled automatically (to prevent battery from discharging) T-bit = 0The BBU can be set to a disabled or enabled status for AC ON or OFF con ditions. NoteIf the BBU is disabled due to being < 5% capacity, it will be enabled automatically when AC power resumes. If the customer disables the BBU, the customer must enable the BBU manually. Disabling and Enabling the BBU in the Range Extender In normal operating mode (T-bit is off), th…

Text truncated - open the document above for the full version.

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 Direct: 408 526 4000 FAX: 408 526 4100 www.cisco.com December 1, 2014 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Request for Temporary Confidentiality To whom it may concern: In accordance with 47CFR Section 0.457 and Section 0.459, FCC Public Notice DA04-1705 and KDB Publication 726920 pertaining to confidential material, we hereby request to hold temporarily confidential for 180 days all information contained within the below identified exhibits/document categories submitted pursuant to radio equipment certification requirements for FCC ID: LDK-IR529UWP. 1) Block Diagram 2) Operational Description 3) Schematics 4) Parts List The above material contains trade secrets and proprietary information as specified by 47CFR 0.457(d) and technical data, which would customarily be guarded from competitors. Pre-marketing public disclosure of this information might be harmful to our company and provide unjustified benefits to our competitors. Sincerely, Charles Troia EMC Project Manager, IoT Group Cisco Systems, Inc 560 McCarthy Blvd Milpitas, CA 95134 desk: 408-525-6080 cell: 408-307-8997

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 Direct: 408 526 4000 FAX: 408 526 4100 www.cisco.com 10/20/2014 To Whom It May Concern: We hereby delegate CKC Certification Services, LLC (CKC CS) power of attorney to act on our behalf in matters pertaining to certification of products. The actions of CKC CS shall be considered the same as our own. Sincerely, Charles Troia EMC Project Manager, IoT Group Cisco Systems, Inc 560 McCarthy Blvd Milpitas, CA 95134 desk: 408-525-6080 cell: 408-307-8997 AA6YV

EDCS-1216337 07/09/2014 Subject : Authorized signatures The following people are authorized by Cisco Systems to sign documents for FCC product approval under FCC Grantee code LDK on behalf of the company. Further this right is extended to any regular Cisco employee as deemed necessary. David A, Case Jim Nicholson Trinh Tien Donn Foster Howard Ji Jose Aguirre Colin Wilson Lisa Bevington Andy Griffin Mark King Dave Wilson Allan Beecroft Bob Lyall Pushpinder Sawanni Julius “ Bud” Chiller Chuck Troia Steve Granzella Rekha Simha Regards Gerard Thorpe Cisco Systems

Regarding Professional Installation: 1) Justify what is special or unique about this system which would require system to be professionally installed. The range extenders, (both base and advanced) will extend the range of a RF900 wireless mesh network, providing longer reach between WPAN endpoints and other WPAN networks. It will provide the necessary Omni or directional antennas and optional backup battery in a ruggedized IP67 outdoor enclosure. It will operate in an ambient temperature range of -40C to +70C. It is intended to operate inside a RF900 mesh network, providing DA control over devices that use Serial (RS232/RS485), USB, or FE (Fast Ethernet) ports for intelligent control. 2) Explain marketing avenues; devices cannot be accessible or marketed to the general public Cisco does not sell these products directly to end users; these devices are sold through distributors or resellers, business to business. The very nature of this product is to provide networking in the utility industry, using 900 MHz radios for mesh networks by the utility industry eliminates the use of this product by the general public. It is intended to operate inside a RF900 mesh network, providing DA control over devices that use Serial (RS232/RS485), USB, or FE (Fast Ethernet) ports for intelligent control. It will complement the CGR1000 series of routers, primarily in the electrical grid by providing a low cost, low power, small size DA solution. It will be ruggedized with an IP41 enclosure (for installations inside outdoor cabinets) and will operate in an ambient temperature range of -40C to +70C. 3) Installation must be controlled; detailed installation instructions are to be provided. Refer to users/installation manual Submitted by Chuck Troia, November 17, 2014 via email communication with CKC CS.

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134 USA December 1st, 2014 Subject: Similarities for Models listed in Test Report FCC ID PID Model Number Description LDK-IR509UWP IR509UWP-915/K9 IR509UWP-915 IR509 915Mhz WPAN router w/ 2 serial,1 FE LAN LDK-IR529UWP IR529UBWP-915D/K9 IR529UBWP-915D IR529 915Mhz WPAN IP67 Range Ext. BBU Adv PS Dual antenna LDK-IR529UWP IR529UBWP-915S/K9 IR529UBWP-915S IR529 915Mhz WPAN IP67 Range Ext. BBU Adv PS Single antenna LDK-IR529UWP IR529UWP-915D/K9 IR529UWP-915D IR529 915Mhz WPAN IP67 Range Ext. Adv PS Dual antenna LDK-IR529UWP IR529UWP-915S/K9 IR529UWP-915S IR529 915Mhz WPAN IP67 Range Ext. Adv PS Single antenna To Whom It May Concern, We declare that IR529UBWP-915D/K9 and IR529UBWP-915S/K9 are similar products using a common power supply, a common mother board and a common radio transceiver board. The differences in these models are features to support battery backup options. In addition, there is a factory installed option to utilize an internal RF splitter that is connected to a common radio transceiver. The splitter, when employed allows connection to two antenna options that are used for directional beam forming only and not for increasing antenna gain by means of beam forming; the antenna patterns are not intended to be placed in a way that allows over lapped patterns. This product is meant to be installed outdoors. In addition, the IR509UWP-915/K9 uses the same power supply, motherboard and the same common radio transceiver. For this product, it is intended that installation is within cabinets or enclosures, typically on a DIN RAIL mounting. In all cases, these products require professional installation. Yours truly, _____________________________________ Chuck Troia EMC Project Manager, IoT Group Cisco Systems, Inc 560 McCarthy Blvd Milpitas, CA 95134 desk: 408-525-6080 cell: 408-307-8997 AA6YV

CLASS C. NOTES: (UNLESS OTHERWISE SPECIFIED) THIS IS A COMPUTER GENERATED DOCUMENT. ALL CHANGES 1. MUST BE MADE IN THE MASTER DATABASE ONLY.SHEET DESCRIPTIONS: 2. SHT 1: COVER AND LABEL ATTACH SHT 2: CHASSIS PREPERATION SHT 3: MOTHERBOARD AND INTERFACE CARD INSTALLATION SHT 4: MOTHERBOARD HEATSINK INSTALLAT ION SHT 5: POWER SUPPLY INSTALLATION SHT 6: BBU INSTALLATION SHT 7: RF CABLE CONFIGURATION SEE APPROPRIATE BOM 68-5314-XX (1 RF PORT) OR 68-53 21-XX 3. (2 RF PORTS) FOR ITEM NUMBERS.SHALL MEET MECHANICAL ACCEPTANCE SPEC 95-0669-XX, 4. ASSEMBLY SEQUENCE; ATTACH COVER (ITEM 6) TO CHASSIS 1. ASSEMBLY USING 4X M8 BOLTS AND WASHERS. FOLLOW TORQUE SEQUENCE SHOWNPG13.5 PLUG (ITEM 20) 2. ATTACH ORING (ITEM 14) TO LIGHTPIPE 3. (ITEM 13), CAREFULLY THREAD INTO CHASSIS, TOP OF LIGHTPIPE SHOULD BE FLUSH TO SLIGHTLY RECESSED WHEN FULLY INSTALLEDATTACH LABELS AS SHOWN 4. INSTALL VENT (ITEM 16) AFTER PRESSURE 5. TEST. ADDED LABELS AND INSUL. 8 D C B A 8 7 6 5 4 3 2 1 A B C D 1 2 3 4 5 6 7 MATERIAL: FINISH: 5/20 DIMENSIONS ARE IN INCHES:UNLESS OTHERWISE SPECIFIED TS 03 UPDATED TORQUE LEVELS 3/24 TS 02 UPDATED CISCO SYSTEMS. APPROVAL DATE DES: ENG:MFG: T. Spivey 1/27/14 SIZE DWG NO. B 62-26779- SCALE: 1:1 DO NOT SCALE DRAWING SHT 1 OF 7 CAD TYPE: SOLIDWORKS REV04 REV 01 DESCRIPTION ---REVISION--- ECN APPROVE MECH MFG PRELIMINARY RELEASE Exxxxxx TPS MODEL FILE: 62-26779-XX 01 REFDWG, FINAL, ASSY ADVANCED, BR-RE 3RD ANGLE PROJECTION DRAWING IS CONFIDENTIALPRIOR WRITTEN CONSENT OFCISCO SYSTEMS. THISBE DISCLOSED WITHOUTPROPRIETARY PROPERTY OFAND ITS CONTENTS MAY NOTINFORMATION WHICH IS THE ANGULAR = 30' TOLERANCES: .015 .005 .030 TS 3/5/14 THIS DRAWING CONTAINS X.X = X.XX = X.XXX = 0 04 14 TORQUE 72-84 IN-LBS 4 TORQUE 3-3.5 IN-LBS 13 6 4X 21 4X 1112 4X 20 REPEATE SEQUENCE TO FULL VALUE 2 ENSURE THAT O-RING IS FULLY SEATED 1 3 5. TORQUE 72-84 IN-LBS TORQUE TO 1/2 FINAL VALUE THEN VENT PORT (ITEM 16) USED FOR PRESSURE TESTINGAT COMPLETION OF ASSEMBLY, THE UNIT WILL NEED TO BE VERIFIED FOR PRESSURE SUSTAINABILITY. THE PROCEDURE IS AS FOLLOWS; USE "VENT" PORT TO PRESSURIZE UNIT 1. PRESSURIZE UNIT TO 5 0.2 PSI 2. UNIT MUST NOT SHOW ANY PRESSURE DROP 3. IN 15 SECONDS.IF UNIT DOES NOT PASS PRESSURE TEST, 4. ISOLATE SOURCE OF LEAKAGE AND DOCUMENT. THEN VERIFY THAT GASKET IS IN PLACE AT LEAKAGE SOURCE AND IF APPLICABLE THE PLUG OR SCREWS HAS/HAVE SUFFICIENT TORQUE.INSTALL VENT (ITEM 6) TORQUE TO 5-7 IN-LB WARNING ! IF UNIT NEEDS TO BE OPENED, WAIT A MINIMUM OF 5 MINUTES AFTER REMOVING AC POWER TO OPEN 32 32 TORQUE SEQUENCE NOTE ORIENTATION OF POWER CONNECTOR 33 32 32 32 32

Page 1 of 8 Report No: 95599-18A RADIO FREQUENCY ADDENDUM EXPOSURE REPORT TO 95599-18 FOR THE IR509 915MHz WPAN Router w/2 Serial, 1 FE LAN IR529 915MHz WPAN IP67 Range Ext. BBU Adv PS Single Antenna IR529 915MHz WPAN IP67 Range Ext. BBU Adv PS Dual Antenna Models: IR509UWP-915/K9, IR529UBWP-915S/K9 and IR529UBWP-915D/K9 Report No.: 95599-18A Date of issue: November 4, 2014 PREPARED FOR: Cisco Systems, Inc. 170 W. Tasman Dr. San Jose, CA 95134-1706 PREPARED BY: Eddie Mariscal CKC Laboratories, Inc. 5046 Sierra Pines Drive Mariposa, CA 95338 The test data contained in this report documents the observed testing parameters pertaining to and are relevant for only the sample equipment tested in the agreed upon operational mode(s) and configuration(s) as identified herein. Compliance assessment remains the client’s responsibility. This report may not be used to claim product endorsement by A2LA or any government agencies. This test report has been authorized for release under quality control from CKC Laboratories, Inc. Steve Behm Director of Quality Assurance & Engineering Services CKC Laboratories, Inc. Page 2 of 8 Report No: 95599-18A Revision History Original: Testing of the Devices: IR509 915MHz WPAN Router w/2 Serial, 1 FE LAN, IR529 915MHz WPAN IP67 Range Ext. BBU Adv PS Single Antenna, IR529 915MHz WPAN IP67 Range Ext. BBU Adv PS Dual Antenna, Models: IR509UWP-915/K9, IR529UBWP-915S/K9 and IR529UBWP-915D/K9 to FCC Part 2.1091 and RSS-102. Addendum A: 1) Changed the limits from “Occupational / Controlled Exposure” to “General Population / Uncontrolled Exposure”, 2) Added notes and manufacturer declarations to the “Device and Antenna Operating Configuration” section and 3) Recalculated the Power Density and exposure limits. Purpose: To demonstrate compliance with United States, Canada and/or European Union RF Exposure requirements for Portable equipment (devices used ≤20cm from the body) or Mobile equipment (devices used >20cm from the body) with power output below exemption levels and Mobile equipment, where Maximum Permissible Exposure (MPE) Calculations apply. United States Compliance Requirements (1.1310): RF Exposure Evaluation Limits Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-3.0 614 1.63 *(100) 6 3.0-30 1842/f 4.89/f *(900/f 2 ) 6 30-300 61.4 0.163 1 6 300-1500 --- --- f/300 6 1500-100,000 --- --- 5.0 6 RF Exposure Evaluation Limits General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f 2 ) 30 30-300 27.5 0.073 0.2 30 300-1500 --- --- f/1500 30 1500-100,000 --- --- 1.0 30 * Plane wave equivalent power density Limit is calculated based on the mid-band frequency used in the operating frequency range. Exemption Level: Power output <60/f GHz (mW) Page 3 of 8 Report No: 95599-18A Canadian Compliance Requirements (RSS-102): RF Exposure Evaluation Limits Occupational / Controlled Exposure: Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (W/m 2 ) Averaging Time (minutes) 0.003-1.0 600 4.9 --- 6 1.0-10 600/f 4.9/f --- 6 10-30 60 4.9/f --- 6 30-300 60 0.163 10 6 300-1500 3.54 f 0.5 0.0094*f 0.5 f/3 6 1500-15,000 137 0.…

Text truncated - open the document above for the full version.
