LDK102040

TAKE OUT WHAT YOU NEED INSTALL THE PC CARD CLIENT ADAPTER INSTALL THE APPROPRIATE DRIVER AND UTILITIES 1 2 3 Quick Start Guide CISCO AIRONET 350 SERIES PC CARD C LIENT ADAPTERS Laptops with PC card client adapters Access Point 1 Take Out What You Need If any item is missing or damaged, contact your Cisco representative or reseller for support. Note: The integrated antenna on PC models of the Aironet PC Client Card Adapter is permanently attached; LM models are shipped with no antenna. Additional Requirements •A computing device (desktop personal computer, notebook, laptop computer, portable or hand-held device) equipped with an internal or external PC Card Type II or Type III slot. All drivers and supporting software (card and socket services) for the PC card slot must be loaded and configured. •The following information from your system administrator: —your wireless client name —the (case-sensitive) wireless service set identification (SSID) for your radio network —for Microsoft Windows networking, your computer name and workgroup name —the username and password for your network account —if you are not connected to a DHCP server, the IP address, default gateway address, and subnet mask of your computer —for Windows NT systems, an available IRQ number (interrupt address) in your system Cisco Aironet 350 Series PC Card Client Adapter (labeled Wireless LAN Adapter) Cisco Aironet 350 Series PC Card Client Adapter CDs for Windows 95 and Windows NT or Windows 98 and Windows 2000 with software and product documentation CISCO AIRONET 340 SERIES 11 Mbps WIRELESS LAN ADAPTER 2 Install the PC Card Client Adapter CautionThe following procedures and physical connections apply generally to normal and conventional PC card slots. In cases of custom or non-conventional equipment, be alert to possible differences in PC card slot configurations. 1 Before you begin, examine the PC card client adapter. One end is a dual-row, 68-pin PC card connector. The card is keyed so that it can be inserted only one way into the PC card slot. The slot in your computing device must be a PC card Type II slot (this includes slots that support both the Type II and Type III cards). Note: The PC card slot will be on the left or right side of the computer, depending on the model. 2 For Windows 95 and Windows 98 systems, remove any other PC card from the card slot. 3 For Windows 95 or Windows 98 systems, turn the computer on before inserting the PC card client adapter. For Windows NT systems, turn the computer off before inserting the client adapter. CautionNever force the PC card client adapter into the PC card slot. Forcing it will damage both the PC card and the slot. If the PC card does not easily insert, remove the card and re-insert it. 4 Hold the PC card client adapter with the logo facing up and insert the card into the slot, applying just enough pressure to make sure it is fully seated. Proceed to the appropriate driver installation for your operating system. 3 Note: The following procedures assume you are installing the driver from the CD provided. If your PC does not have a CD-ROM drive, download the driver from Cisco’s web site. Install the Appropriate Driver and Utilities Windows 98 Systems Note: The Windows 98 driver also works with the Windows 2000 operating system. In Windows 98 systems, after you have installed the PC card client adapter, the system automatically detects it, opens a New Hardware Found window, and starts collecting information for a driver database. 1 When the Add New Hardware Wizard dialog box opens, it is searching for new drivers. Click Next. 2 From the next dialog box, select Search for the best driver for your device (Recommended) and click Next. 3 Select CD-ROM drive, deselect all other options, insert the Cisco Aironet 350 Series Client Adapter CD for Windows 98, and click Next. 4 The hardware wizard will find the installation files on the CD and display the search results. When the PCMCIA adapter driver is displayed, click Next to copy the required files. 5 During driver installation, you may be prompted to enter a path to the required client adapter or Windows 98 files: (a) Windows 98 files installed on your PC are usually located in the folder C:\Windows\Options\Cabs. Click OK to install. (b) If the system prompts you for the Windows CD and the CD-ROM drive on your PC is drive D, the path should be D:\WIN98. Click OK to copy the required files. 6 The Add New Hardware Wizard window again opens indicating that the installation is complete. Click Finish. 7 Remove the CD and restart your laptop. 8 When the computer restarts, double-click My Computer, Control Panel, and Network. 9 Select the PCMCIA adapter and click Properties. 10 In the Properties window, click Advanced. 11 In the Advanced window, select Client Name and enter your computer’s unique name in the Value dialog box. 12 Select SSID. Enter your Access Point’s (case-sensitive) SSID in the Value dialog box. Click OK. 4 13 If you are not connected to a DHCP server, double-click My Computer, Control Panel, and Network. Click the Protocols tab and select TCP/IP and Properties. Select Specify an IP address and enter the IP Address, Subnet Mask, and Default Gateway address of your computer. Click OK. 14 In the Network window, click OK. 15 When prompted, click Ye s to reboot the laptop. Windows 95 Systems In Windows 95 systems, after you have installed the PC card client adapter, the system automatically detects it, opens a New Hardware Found window, and starts collecting information for a driver database. 1 The Update Device Driver Wizard dialog box opens and indicates that Windows will complete the installation of the PCMCIA adapter. 2 Insert the Client Adapter CD for Windows 95 and NT, and click Next. 3 When the Update Device Driver Wizard indicates that it is unable to locate a driver, click Other Locations. 4 In the Select other Location window, click Browse. 5 Select the CD-ROM drive and click OK. 6 In the Select other Location win…

Text truncated - open the document above for the full version.

May 31, 2000 Sincerely yours, Morton Flom, P. Eng.

BOM-200-004994 This document includes the followin g assembl y variations: Variation Title Descri p tion -002 5V, A PHY, REV. A0 BDS. ONLY -006 5V, A PHY, LED MOD, PCI MOD -008 5V, B PHY, LED MOD, PCI MOD 05-May-00 BOM-200-004994 PAGE 1 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -002: 5V, A PHY, REV. A0 BDS. ONLY Doc Cell TESTED MECH. ASSY , PLUTO LM SERIES RADIO 5V , A PHY 421-004994-002 1 1 05-May-00 BOM-200-004994 PAGE 2 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -006: 5V, A PHY, LED MOD, PCI MOD Doc Cell TESTED MECH. ASSY , PLUTO LM SERIES RADIO 5V , A PHY , LED MOD , PCI M 421-004994-006 1 1 05-May-00 BOM-200-004994 PAGE 3 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -008: 5V, B PHY, LED MOD, PCI MOD Doc Cell TESTED MECH. ASSY , PLUTO LM SERIES RADIO 5V , B PHY , LED MOD , PCI M 421-004994-008 1 1 05-May-00 BOM-200-004994 PAGE 4 OF 4 RUN PRODUCT ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 01-May-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2382 INCORPORATED ECN REVISIONS A PPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333 h a a a a NOTE: SEE SOURCE CONTROL DRAWINGS FOR ORDERING INFORMATION.

BOM-410-004994 This document includes the followin g assembl y variations: Variation Title Description -005 3V,HFA3861A,LED INV,PCI MOD INCORPORATED -006 5V,HFA3861A,LED INV,PCI MOD INCORPORATED -007 3V,HFA3861B,LED INV,PCI MOD INCORPORATED -008 5V,HFA3861B,LED INV,PCI MOD INCORPORATED 19-Jan-00 BOM-410-004994 PAGE 1 OF 17 RUN PCA, PLUTO LM, PCMCIA RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Nahra 18-Jan-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN B0 2262 PRODUCTION REL EASE REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -005: 3V,HFA3861A,LED INV,PCI MOD INCORPORATED Doc Cell PCB1 PCB , PLUTO LM , PCMCIA RADIO PCB 510-004994 B 1B0 1 SHLD1 SHIELD, POWER AMP SHIELD 530-004913 A1 1 2 SHIELD SHLD6 SHIELD, I/Q MODEM SHIELD 530-004919 A1 1 3 SHIELD SHLD3 SHIELD , RF/IF SHIELD 530-004939 B0 1 4 SHIELD SHLD2 SHIELD , 2GHZ VCO SHIELD 530-005061 A0 1 5 SHIELD SHLD8 SHIELD , TX BPF SHIELD 530-005062 B0 1 6 SHIELD U704 IC, UHS INVERTER, TINYLOGIC ( TM ) UHS SINGLE INV 601-004165 1 7 USV U500 U501 VOLTAGE REGULATOR , 150MA CMOS LDO TC1185-2.8VCT 601-004325-0280 2 8 SMV U700 IC , UHS BUFFER , TINYLOGIC ( TM ), GROUP IC , UHS BUFFER 601-004565 1 9 USV U400 IC , RF/IF CONVERTER & SYNTHESIZER 2.4GHZ HFA3683A 601-004748 1 10 LQFP64 U503 IC, I/Q MODULATOR/DEMOD & SYNTHESIZER HFA3783IN 601-004749 1 11 TQFP48 U101 IC , POWER AMPLIFIER & DETECTOR , 2.4GHZ HFA3983IV 601-004802 1 12 TSSP29 U401 IC , SILICON MMIC WIDEBAND AMP , 3V , 2.7GHZ UPC2745TB 601-004866 1 13 SMM6 U1 U100 IC , GAAS RF SWITCH , SPDT , 2.5GHZ AS179-92 601-004904 2 14 SOT363 U701 U705 U708 LMOS, 2-INPUT AND GATE TC7S08FU 604-002976 3 15 USV U600 IC,2MBIT BOTTOM SECTOR, LO VOLTAGE FLASH AM29LV002BB-120EC 605-003571-120C 1 16 TSOP40 U706 IC , SRAM , 128K X 16 , 3.3V , CMOS SRAM 128Kx16 15ns , C 605-004901-015 1 17 TQFP44 U710 IC , SILICON SERIAL NUMBER DS2401AP 606-002904 1 18 TSOC6 U707 IC , DSSS BASEBAND PROCESSOR , 11MB , CCK HFA3861AIN 607-004752 1 19 LQFP64 U601 PROCESSOR, A503 CUSTOM EMBEDDED ASIC A503 608-004808 1 20 TQ128W CR700 DIODE , ZENER , LOW LEVEL 500UA , 250MW CMDZ7L5 610-004951-7.5V 1 21 SOD323 Q700 Q701 TRANSISTOR , SILICON NPN W/BUILTIN RESIS B=10K/BE=NONE 611-002986-14T 2 22 SSM R302 R413 R415 R417 R418 R420 R509 RESISTOR , 1/16W , 5% - SMD 0.0 620-003251-000 20 23 0402 R511 R520 R608 R616 R707 R711 R715 R721 R727 R728 R729 R733 R742 R400 R501 R508 R737 RESISTOR , 1/16W , 5% - SMD 100 620-003251-100 4 24 0402 R613 R617 R618 R700 R701 R702 R732 RESISTOR , 1/16W , 5% - SMD 10K 620-003251-10K 7 25 0402 R105 R107 R308 R414 R516 R600 R612 RESISTOR, 1/16W, 5% - SMD 10 620-003251-10R 7 26 0402 R305 R403 R411 RESISTOR, 1/16W, 5% - SMD 18 620-003251-18R 3 27 0402 R101 RESISTOR , 1/16W , 5% - SMD 1.0K 620-003251-1K0 1 28 0402 R412 R416 RESISTOR , 1/16W , 5% - SMD 1.1K 620-003251-1K1 2 29 0402 19-Jan-00 BOM-410-004994 PAGE 2 OF 17 RUN PCA, PLUTO LM, PCMCIA RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Nahra 18-Jan-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN B0 2262 PRODUCTION REL EASE REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -005: 3V,HFA3861A,LED INV,PCI MOD INCORPORATED (Cont’d) Doc Cell R306 R610 RESISTOR , 1/16W , 5% - SMD 1.5K 620-003251-1K5 2 30 0402 R402 RESISTOR, 1/16W, 5% - SMD 20 620-003251-20R 1 31 0402 R500 R506 RESISTOR , 1/16W , 5% - SMD 2.0K 620-003251-2K0 2 32 0402 R301 R304 R401 R404 R409 R410 RESISTOR , 1/16W , 5% - SMD 300 620-003251-300 6 33 0402 R505 R748 RESISTOR , 1/16W , 5% - SMD 3.9K 620-003251-3K9 2 34 0402 R709 R741 R743 RESISTOR, 1/16W, 5% - SMD 470 620-003251-470 3 35 0402 R611 R744 R745 R746 R747 RESISTOR, 1/16W, 5% - SMD 47K 620-003251-47K 5 36 0402 R1 R100 R104 R106 R2 R50 R51 R517 RESISTOR , 1/16W , 5% - SMD 51 620-003251-51R 9 37 0402 R522 R307 R725 RESISTOR , 1/16W , 5% - SMD 680 620-003251-680 2 38 0402 R601 R602 R603 R604 R605 R606 R708 RESISTOR, 1/16W, 5% - SMD 68K 620-003251-68K 16 39 0402 R719 R720 R722 R724 R730 R731 R735 R736 R740 R309 R310 RESISTOR , 1/16W , 5% - SMD 82 620-003251-82R 2 40 0402 R311 RESISTOR, 1/16W, 5% - SMD 91 620-003251-91R 1 41 0402 R406 RESISTOR, 1/16W 1% -SMD 11.5K 620-003521-11K5 1 42 0402 R705 R712 R716 R718 RESISTOR , 1/16W 1% -SMD 124 620-003521-124R 4 43 0402 R706 RESISTOR , 1/16W 1% -SMD 12.1K 620-003521-12K1 1 44 0402 R713 R714 RESISTOR , 1/16W 1% -SMD 19.1K 620-003521-19K1 2 45 0402 R407 RESISTOR, 1/16W 1% -SMD 1.50K 620-003521-1K50 1 46 0402 R510 RESISTOR , 1/16W 1% -SMD 2.87K 620-003521-2K87 1 47 0402 R102 R103 RESISTOR , 1/16W 1% -SMD 3.74K 620-003521-3K74 2 48 0402 R704 R717 RESISTOR , 1/16W 1% -SMD 536 620-003521-536R 2 49 0402 R726 RESISTOR, 1/16W 1% -SMD 976 620-003521-976R 1 50 0402 R408 RESISTOR , 1/16W 1% -SMD 9.53K 620-003521-9K53 1 51 0402 C518 CAPACITOR X7R 25V 10% - SMD 220nF 622-000677-U22 1 52 0805 C513 CAPACITOR X7R 50V 10% 220pF 622-001699-N22 1 53 0603 C715 CAPACITOR, TANT 10V 20%, LOW PROFILE 1.0uF 622-002996-1U0 1 54 3216L C612 CAPACITOR, TANT 10V 20%, LOW PROFILE 10uF 622-002997-10U 1 55 3528L C502 C505 C520 C527 CAPACITOR , TANT 10V 20% , LOW PROFILE 4.7uF 622-002997-4U7 4 56 3528L C101 C102 C109 C110 C111 C112 C116 CAPACITOR , X7R , 50V , 10% TOL. CLASS 2 1.0nF 622-003315-1N0 16 57 0402 19-Jan-00 BOM-410-004994 PAGE 3 OF 17 RUN PCA, PLUTO LM, PCMCIA RADIO BILL OF MATERIALS…

Text truncated - open the document above for the full version.

BOM-411-004994 This document includes the followin g assembl y variations: Variation Title Description -002 5V, A PHY, REV A0 BOARDS ONLY -004 5V, A PHY, PCI MOD, REV A0 BOARDS ONLY -006 5V, A PHY, LED MOD, PCI MOD -008 5V, B PHY, LED MOD, PCI MOD 11-Feb-00 BOM-411-004994 PAGE 1 OF 5 RUN TESTED PCA, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -002: 5V, A PHY, REV A0 BOARDS ONLY Doc Cell PCA , PLUTO LM , PCMCIA RADIO 5V , A PHY 410-004994-002 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS, PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-411-004994 PAGE 2 OF 5 RUN TESTED PCA, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -004: 5V, A PHY, PCI MOD, REV A0 BOARDS ONLY Doc Cell PCA , PLUTO LM , PCMCIA RADIO 5V , A PHY , PCI MOD 410-004994-004 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS , PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-411-004994 PAGE 3 OF 5 RUN TESTED PCA, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -006: 5V, A PHY, LED MOD, PCI MOD Doc Cell PCA , PLUTO LM , PCMCIA RADIO 5V , A PHY , LED MOD , PCI M 410-004994-006 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS , PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-411-004994 PAGE 4 OF 5 RUN TESTED PCA, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -008: 5V, B PHY, LED MOD, PCI MOD Doc Cell PCA , PLUTO LM , PCMCIA RADIO 5V , B PHY , LED MOD , PCI M 410-004994-008 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS , PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-411-004994 PAGE 5 OF 5 RUN TESTED PCA, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION.

BOM-420-004994 This document includes the followin g assembl y variations: Variation Title Description -002 5V, A PHY, REV. A0 BOARD ONLY -004 5V, A PHY, PCI MOD,REV. A0 BOARD ONLY -006 5V, A PHY, LED MOD, PCI MOD -008 5V, B PHY, LED MOD, PCI MOD 11-Feb-00 BOM-420-004994 PAGE 1 OF 5 RUN MECHANICAL ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -002: 5V, A PHY, REV. A0 BOARD ONLY Doc Cell MA1 TESTED PCA , PLUTO LM SERIES RADIO 5V , A PHY 411-004994-002 1 1 MF2 MF3 LIGHT PIPE, PCMCIA LM3000/LM3500 LIGHT PIPE 530-002985 2 2 N/A MF1 CARD FRAME, LM3000 5 VOLT 535-002940-5V 1 3 MF4 LABEL , BAR CODE , PLUTO LM SERIES RADIO 550-005136 1 4 11-Feb-00 BOM-420-004994 PAGE 2 OF 5 RUN MECHANICAL ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -004: 5V, A PHY, PCI MOD,REV. A0 BOARD ONLY Doc Cell MA1 TESTED PCA , PLUTO LM SERIES RADIO 5V , A PHY , PCI MOD 411-004994-004 1 1 MF2 MF3 LIGHT PIPE, PCMCIA LM3000/LM3500 LIGHT PIPE 530-002985 2 2 N/A MF1 CARD FRAME , LM3000 5 VOLT 535-002940-5V 1 3 MF4 LABEL , BAR CODE , PLUTO LM SERIES RADIO 550-005136 1 4 11-Feb-00 BOM-420-004994 PAGE 3 OF 5 RUN MECHANICAL ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -006: 5V, A PHY, LED MOD, PCI MOD Doc Cell MA1 TESTED PCA , PLUTO LM SERIES RADIO 5V , A PHY , LED MOD , PCI M 411-004994-006 1 1 MF2 MF3 LIGHT PIPE, PCMCIA LM3000/LM3500 LIGHT PIPE 530-002985 2 2 N/A MF1 CARD FRAME , LM3000 5 VOLT 535-002940-5V 1 3 MF4 LABEL , BAR CODE , PLUTO LM SERIES RADIO 550-005136 1 4 11-Feb-00 BOM-420-004994 PAGE 4 OF 5 RUN MECHANICAL ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -008: 5V, B PHY, LED MOD, PCI MOD Doc Cell MA1 TESTED PCA , PLUTO LM SERIES RADIO 5V , B PHY , LED MOD , PCI M 411-004994-008 1 1 MF2 MF3 LIGHT PIPE, PCMCIA LM3000/LM3500 LIGHT PIPE 530-002985 2 2 N/A MF1 CARD FRAME , LM3000 5 VOLT 535-002940-5V 1 3 MF4 LABEL , BAR CODE , PLUTO LM SERIES RADIO 550-005136 1 4 11-Feb-00 BOM-420-004994 PAGE 5 OF 5 RUN MECHANICAL ASSEMBLY , PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION.

BOM-421-004994 This document includes the followin g assembl y variations: Variation Title Description -002 5V, A PHY, REV. A0 BOARDS ONLY -004 5V,A PHY, PCI MOD, REV. A0 BOARDS ONLY -006 5V, A PHY, LED MOD, PCI MOD -008 5V, B PHY, LED MOD, PCI MOD 11-Feb-00 BOM-421-004994 PAGE 1 OF 5 RUN TESTED MECH. ASSY, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -002: 5V, A PHY, REV. A0 BOARDS ONLY Doc Cell MECHANICAL ASSY , PLUTO LM SERIES RADIO 5V , A PHY 420-004994-002 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS, PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-421-004994 PAGE 2 OF 5 RUN TESTED MECH. ASSY, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -004: 5V,A PHY, PCI MOD, REV. A0 BOARDS ONLY Doc Cell MECHANICAL ASSY , PLUTO LM SERIES RADIO 5V , A PHY , PCI MOD 420-004994-004 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS , PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-421-004994 PAGE 3 OF 5 RUN TESTED MECH. ASSY, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -006: 5V, A PHY, LED MOD, PCI MOD Doc Cell MECHANICAL ASSY , PLUTO LM SERIES RADIO 5V , A PHY , LED MOD , PCI M 420-004994-006 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS , PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-421-004994 PAGE 4 OF 5 RUN TESTED MECH. ASSY, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION. Part Number Value/Item Description Reference Designator Rev Item Qty Fab Assy -008: 5V, B PHY, LED MOD, PCI MOD Doc Cell MECHANICAL ASSY , PLUTO LM SERIES RADIO 5V , B PHY , LED MOD , PCI M 420-004994-008 1 1 AUTOMATED TEST ENVIRONMENT 740-004746 1 2 AUTOMATED TESTS , PLUTO SERIES RADIO 741-005193 1 3 n/a 11-Feb-00 BOM-421-004994 PAGE 5 OF 5 RUN TESTED MECH. ASSY, PLUTO LM SERIES RADIO BILL OF MATERIALS THE INFORMATION CONTAINED HEREIN IS PROPRIETARYANY REPRODUCTION OR DISCLOSURE OF THIS DRAWN: Julie Hawk APPROVAL: Jim Friedmann 10-Feb-00 CHECKED: DOCUMENT IS FORBIDDEN, EXCEPT WITH WRITTENTO AIRONET WIRELESS COMMUNICATIONS INC.PERMISSION FROM AIRONET WIRELESS COMMUNICATIONS. REV DESCRIPTION ECN A1 2333 INCORPORATED ECN REVISIONS APPROVED Aironet Wireless Communications, Inc. Fairlawn, Ohio 44333   NOTE: SEE SO URCE CONTROL DRAWINGS FOR ORDERING INFORMATION.

SAR COMPLIANCE TESTING OF CISCO/AIRONET MODEL LDK102040 WIRELESS PC April 28, 2000 Submitted to: Mr. David A. Case NCE Senior Compliance Engineer Cisco Systems 3875 Embassy Parkway Akron, OH 44333 Submitted by: Om P. Gandhi Professor of Electrical Engineering University of Utah 50 S Central Campus Dr., Rm. 3280 Salt Lake City, UT 84112-9206 2 SAR COMPLIANCE TESTING OF CISCO/AIRONET MODEL LDK102040 WIRELESS PC I. Introduction The U.S. Federal Communications Commission (FCC) has adopted limits of human exposure to RF emissions from mobile and portable devices that are regulated by the FCC [1]. The FCC has also recently issued Supplement C (Edition 97-01) to OET Bulletin 65 defining both the measurement and the computational procedures that should be followed for evaluating compliance of mobile and portable devices with FCC limits for human exposure to radiofrequency emissions [2]. We have used the measurement procedure given in [2] to obtain peak 1-g SARs for the Cisco/Aironet Model LDK102040 Wireless PC. A photograph of this unit is shown in Fig. 1. As seen in Fig. 1, the RF antenna operating in the ISM frequency band 2412-2462 MHz is mounted at the back of the right-hand side of the keyboard. The Cisco/Aironet Model LDK102040 operates with a transmit power of up to 100 mW radiated from a printed patch antenna. Since the wireless PC may also be potentially placed on the lap where the RF antenna would be the closest to the body, a planar phantom model was used for all SAR measurements. II. The Tissue-Simulant Model The testing for the SAR distribution for the Cisco/Aironet Model LDK102040 Wireless PC was done with a planar rectangular box phantom model shown in Fig. 2. This box phantom of external…

Text truncated - open the document above for the full version.
