LDK102059802.11a radio module

Cisco Systems Inc
802.11a radio module - FCC ID LDK102059 - Cisco Systems Inc
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Aug 24, 2006
Application Purpose
Original Equipment
Date of Application
Mar 01, 2006
Equipment Note
802.11a radio module
Frequency Range
5745.00000000 - 5825.00000000
Company
Cisco Systems Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CISCO CONFIDENTIAL - Draft 1 Corporate Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 526-4100 Cisco Aironet 1250AG Series Access Point Hardware Installation Guide June 2006 Text Part Number: OL-8247-01 CISCO CONFIDENTIAL - Draft 1 THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY. The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. The following information is for FCC compliance of Class B devices: The equipment described in this manual generates and may radiate radio-frequency energy. If it is not installed in accordance with Cisco’s installation instructions, it may cause interference with radio and television reception. This equipment has been tested and found to comply with the limits for a Class B digital device in accordance with the specifications in part 15 of the FCC rules. These specifications are designed to provide reasonable protection against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. Modifying the equipment without Cisco’s written authorization may result in the equipment no longer complying with FCC requirements for Class A or Class B digital devices. In that event, your right to use the equipment may be limited by FCC regulations, and you may be required to correct any interference to radio or television communications at your own expense. You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Cisco equipment or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: • Turn the television or radio antenna until the interference stops. • Move the equipment to one side or the other of the television or radio. • Move the equipment farther away from the television or radio. • Plug the equipment into an outlet that is on a different circuit from the television or radio. (That is, make certain the equipment and the television or radio are on circuits controlled by different circuit breakers or fuses.) Modifications to this product not authorized by Cisco Systems, Inc. could void the FCC approval and negate your authority to operate the product. The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Cisco Aironet 1250AG Series Access Point Hardware Installation Guide © 2006 Cisco Systems, Inc. All rights reserved. CCSP, CCVP, the Cisco Square Bridge logo, Follow Me Browsing, and StackWise are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn, and iQuick Study are service marks of Cisco Systems, Inc.; and Access Registrar, Aironet, BPX, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, FormShare, GigaDrive, GigaStack, HomeLink, Internet Quotient, IOS, IP/TV, iQ Expertise, the iQ logo, iQ Net Readiness Scorecard, LightStream, Linksys, MeetingPlace, MGX, the Networkers logo, Networking Academy, Network Registrar, Packet, PIX, Post-Routing, Pre-Routing, ProConnect, RateMUX, ScriptShare, SlideCast, SMARTnet, The Fastest Way to Increase Your Internet Quotient, and TransPath are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries. All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnershi…

Text truncated - open the document above for the full version.

Cover Letter(s)

Cisco Systems, Inc. 4125 Highlander Parkway Richfield, Ohio 44286 Phone: 330 523-2094 Fax: 330 523-2002 http://www.cisco.com Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] March 1, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: LDK102059 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential documents from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Software Theory of Operation Best Regards, Jim Nicholson EMC Compliance Engineer

Cover Letter(s)

Cisco Systems, Inc. 4125 Highlander Parkway Richfield, Ohio 44286 Phone: 330 523-2094 Fax: 330 523-2002 http://www.cisco.com Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] May 22, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: CRN 30856 Reply FCC ID: LDK102059 To Whom It May Concern: The information requested in CRN 30856 was has already been supplied as part of the LDK102059 approval package. Best Regards, Jim Nicholson EMC Compliance Engineer

Cover Letter(s)

Cisco Systems, Inc. 4125 Highlander Parkway Richfield, Ohio 44286 Phone: 330 523-2094 Fax: 330 523-2002 http://www.cisco.com Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] June 19, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: CRN 31107 Reply FCC ID: LDK102059 To Whom It May Concern: Question 1) This is a DTS application. However you have submitted the UNII and DFS Test Report. In addition there are frequencies in this application that are a duplicate of the UNII frequencies. There is no 2.4 GHz data but the User's Manual indicates that the device has this capability. Submit a list of frequencies and power to be listed on the Grant for the DTS portion of this composite application. Submit a DTS Test Report. Response: This device is a composite UNII/DTS device. The UNII frequencies supported are 5180-5320 MHz and 5500-5700 MHz. The DFS frequencies are 5745-5825MHz. The test report included data for both the UNII and DTS frequencies. The user manual includes 2.4GHz information because the access point (host) for this module also supports an additional 2.4GHz radio module approved under a separate FCC ID (LDK102060). Question 2) The User's Manual indicated operation on a channel frequency of 5825 MHz. The UNII test report only has power measured at this frequency. This frequency is not in the UNII band. If 5825 MHz is to be used it must be included in the DTS application. Please explain and include data as appropriate in the Test Report. Response: 5825MHz should be included in the DTS portion of the application. All required data for 5825MHz is included in the test report. Question 3) The UNII portion of this composite application requested unlimited Modular Approval. However there is no information in this application to support this. What is your intent? Response: This module is used in the AIR-AP1251access point in combination with an additional 2.4GHz radio module. The intent is to offer either one or the other, or both, radio modules in the access point either as a factory configuration or as field upgrades. Question 4) This is a new original software defined radio (SDR) application. Is this your intent? Note that this limits you to one Class 2 permissive change in the future. Response: Yes this is the intent. Cisco Systems, Inc. 4125 Highlander Parkway Richfield, Ohio 44286 Phone: 330 523-2094 Fax: 330 523-2002 http://www.cisco.com Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] Best Regards, Jim Nicholson EMC Compliance Engineer

Cover Letter(s)

Cisco Systems, Inc. 4125 Highlander Parkway Richfield, Ohio 44286 Phone: 330 523-2094 Fax: 330 523-2002 http://www.cisco.com Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] August 7, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: CRN 31352 Reply FCC ID: LDK102059 (EA459777) To Whom It May Concern: Question 1) This is a composite application with the UNII/DTS application. In the UNII/DTS application you requested modular approval. However there is no information in this application regarding modular approval. It is my understanding that this will be a Limited Modular Approval. What host device restrictions are to be placed on this device? Response: LDK102059 was configured and tested in the Cisco Systems AIR-AP1250 series host. At this time this is the only intended host for this radio module. Best Regards, Jim Nicholson EMC Compliance Engineer

External Photos

AIR-RM23A Photos Top with shields removed Bottom with shields removed Top with Shields Bottom with Shields Disassembled radio module Module assembly less covers Module Assembly (showing regulatory label location) Module Assembly (End View) Regulatory Label AIR-RM23A-A-K9 Installed in AIR-AP1250 (with collocated AIR-RM23G-A-K9) AIR-RM23A-A-K9 Radio Moduleprior to installation in AIR-AP1250 (with collocated AIR-RM23G-A-K9)

ID Label/Location Info

AIR-RM23A Photos Top with shields removed Bottom with shields removed Top with Shields Bottom with Shields Disassembled radio module Module assembly less covers Module Assembly (showing regulatory label location) Module Assembly (End View) Regulatory Label AIR-RM23A-A-K9 Installed in AIR-AP1250 (with collocated AIR-RM23G-A-K9) AIR-RM23A-A-K9 Radio Moduleprior to installation in AIR-AP1250 (with collocated AIR-RM23G-A-K9)

Internal Photos

AIR-RM23A Photos Top with shields removed Bottom with shields removed Top with Shields Bottom with Shields Disassembled radio module Module assembly less covers Module Assembly (showing regulatory label location) Module Assembly (End View) Regulatory Label AIR-RM23A-A-K9 Installed in AIR-AP1250 (with collocated AIR-RM23G-A-K9) AIR-RM23A-A-K9 Radio Moduleprior to installation in AIR-AP1250 (with collocated AIR-RM23G-A-K9)

Test Report

EMC Test Report No: EDCS - 501969 Page No: 1 of 174 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential EMC Test Report: EDCS - 501969 For AIR-RM23A-A-K9 5GHz Radio Module (FCC ID: LDK102059) Against the following Specifications : FCC CFR 47 Part 15.247 and FCC CFR 47 Part 15.407 Cisco Systems EMC Laboratory 170 West Tasman Drive San Jose, CA 95134 Certificate Number : 1178-01 Author: James Nicholson Approved By: Title: EMC Test Report No: EDCS - 501969 Page No: 2 of 174 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential This test report has been electronically authorized and archived using the CISCO Engineering Document Control system. SECTION 1: OVERVIEW .........................................................................................................................................3 SECTION 2: ASSESSMENT INFORMATION......................................................................................................4 SECTION 3: SAMPLE DETAILS.............................................................................................................................7 APPENDIX A: FORMAL EMISSION TEST RESULTS.................................................................................8 AVERAGE OUTPUT POWER......................................................................................................................................8 6DB BANDWIDTH......................................................................................................................................................9 99% BANDWIDTH...................................................................................................................................................11 PEAK OUTPUT POWER...........................................................................................................................................16 POWER SPECTRAL DENSITY..................................................................................................................................22 PEAK OUTPUT POWER...........................................................................................................................................28 CONDUCTED SPURIOUS EMISSIONS......................................................................................................................32 RADIATED TRANSMITTER SPURIOUS EMISSIONS..................................................................................................37 COLOCATED TRANSMITTER SPURIOUS EMISSIONS..............................................................................................99 MAXIMUM PERMISSIBLE EXPOSURE (MPE) CALCULATIONS..............................................................................118 30MHZ-1GHZ RADIATED SPURIOUS EMISSIONS................................................................................................120 AC MAINS .150-30MHZ CONDUCTED EMISSIONS..............................................................................................122 DFS TEST RESULTS..........................................................................................................................................1224 APPENDIX C: ABBREVIATION KEY AND DEFINITIONS ....................................................................164 THE FOLLOWING TABLE DEFINES ABBREVIATIONS USED WITHIN THIS TEST REPORT............164 APPENDIX D: RADIATED EMISSIONS TEST PROCEDURE ................................................................165 APPENDIX E: CONDUCTED EMISSIONS TEST PROCEDURE ...........................................................168 APPENDIX F: TEST PROCEDURES..........................................................................................................170 APPENDIX G: SCOPE OF ACCREDITATION: A2LA CERTIFICATE NUMBER 1178-01 ................171 APPENDIX H: TEST EQUIPMENT/SOFTWARE USED TO PERFORM THE TEST ..........................173 APPENDIX H: TEST EQUIPMENT/SOFTWARE USED TO PERFORM THE TEST ..........................173 SOFTWARE USED IN THE TESTS....................................................................................................................174 SOFTWARE USED IN THE TESTS....................................................................................................................174 A: VASONA FILE VERSION ...........................................................................................................................174 B: OTHER SOFTWARE USED........................................................................................................................174 EMC Test Report No: EDCS - 501969 Page No: 3 of 174 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential Section 1: Overview Test Summary The samples were assessed against the tests detailed in section 3 under the requirements of the following standards: Emissions: CFR47 Parts 15.247 ,15.249, 15.407. Notes: 1) Where a specification listed on the front cover of this report has deviations from the basic standards listed above, the additional technical requirements of the specification were also assessed. 2) Where appropriate, Cisco may have substituted a later revision of a basic standard to those referenced in the specification on the front sheet of this test report. This decision was based upon improved test methodology and repeatability and/or where the newer revision represented a more stringent test. 3) Where relevant, testing has been carried out to the requirements of both EN and IEC Specifications. This was possible because of the similarities of the test methods involved and the Cisco EMC test procedures. 4) For Radiated and Conducted emissions results refer to section 2.9 for measurement …

Text truncated - open the document above for the full version.

Test Setup Photos

Cisco Systems, Inc. 4125 Highlander Parkway Richfield, Ohio 44286 Phone: 330 523-2094 Fax: 330 523-2002 http://www.cisco.com Phone: (330) 523-2094 Fax: (330) 523-2002 E-Mail: [email protected] May 9, 2006 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Grant Deferral FCC ID: LDK102059 To Whom It May Concern: Cisco Systems requests deferral of the grant under FCC ID LDK102059 until June 23, 2006. Best Regards, Jim Nicholson EMC Compliance Engineer

Contact Information

Applicant

Samuel Kim(Manager, Engineering)
[email protected]408-527-1446Fax: 408-527-1446

Technical Contact

Cisco SystemsJim Nicholson
[email protected]330-523-2094

4125 Highlander Parkway · Richfiels, Ohio · United States

Test Firm

Cisco Systems, Inc.Dave Wilson
[email protected]408-525-0324Fax: 4085264184

Technical Specifications

#Rule PartsFrequency RangePower Output
115C5.75 GHz - 5.83 GHz47.00 mW
Software Defined Radio
Yes
Confidentiality
Long Term
