LDK102075Cisco Aironet 802.11n Dual Band Access Points

GETTING STARTED GUIDE Cisco Aironet 3600 Series Lightweight Access Points 1About this Guide 2Safety Instructions 3Unpacking 4Overview 5Configuring the Access Point 6Mounting the Access Point 7Deploying the Access Point on the Wireless Network 8Troubleshooting 9Declarations of Conformity and Regulatory Information 10Configuring DHCP Option 43 and DHCP Option 60 11Access Point Specifications ap3600getstart.fm Page 1 Wednesday, January 26, 2011 8:51 AM 2 1 About this Guide This Guide provides instructions on how to install and configure your Cisco Aironet 3600 Series Access Point. This guide also provides mounting instructions and limited troubleshooting procedures. 2 Safety Instructions Translated versions of the following safety warnings are provided in the translated safety warnings document that is shipped with your access point. The translated warnings are also in the Translated Safety Warnings for Cisco Aironet Access Points, which is available on Cisco.com. WarningIMPORTANT SAFETY INSTRUCTIONS This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device. Statement 1071 SAVE THESE INSTRUCTIONS WarningRead the installation instructions before you connect the system to its power source. Statement 1004 WarningThis product must be connected to a Power-over-Ethernet (PoE) IEEE 802.3af compliant power source or an IEC60950 compliant limited power source. Statement 353 WarningInstallation of the equipment must comply with local and national electrical codes. Statement 1074 ap3600getstart.fm Page 2 Wednesday, January 26, 2011 8:51 AM 3 WarningThis product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 20A. Statement 1005 WarningDo not operate your wireless network device near unshielded blasting caps or in an explosive environment unless the device has been modified to be especially qualified for such use. Statement 245B WarningIn order to comply with FCC radio frequency (RF) exposure limits, antennas should be located at a minimum of 7.9 inches (20 cm) or more from the body of all persons. Statement 332 CautionThe fasteners you use to mount an access point on a ceiling must be capable of maintaining a minimum pullout force of 20 lbs (9 kg) and must use all 4 indented holes on the mounting bracket. CautionThis product and all interconnected equipment must be installed indoors within the same building, including the associated LAN connections as defined by Environment A of the IEEE 802.af Standard. NoteThe access point is suitable for use in environmental air space in accordance with section 300.22.C of the National Electrical Code and sections 2-128, 12-010(3), and 12-100 of the Canadian Electrical Code, Part 1, C22.1. You should not install the power supply or power injector in air handling spaces. NoteUse only with listed ITE equipment. ap3600getstart.fm Page 3 Wednesday, January 26, 2011 8:51 AM 4 3 Unpacking Follow these steps: Step 1Unpack and remove the access point and the accessory kit from the shipping box. Step 2Return any packing material to the shipping container and save it for future use. Step 3Verify that you have received the items listed below. If any item is missing or damaged, contact your Cisco representative or reseller for instructions. –3600 series access point –Mounting bracket (selected when you ordered the access point) –Adjustable ceiling-rail clip (selected when you ordered the access point) ap3600getstart.fm Page 4 Wednesday, January 26, 2011 8:51 AM 5 4 Overview The following illustrations show the access point connections and features. The 3600e access point has external antenna connectors; the 3600i access point has integrated antennas and does not have external connectors. Figure 1Access Point Ports and Connections (top) 1 Dual-band antenna connector A 3 Dual-band antenna connector C 2 Dual-band antenna connector B 4 Dual-band antenna connector D A D U A L B A N D B D U A L B A N D C D U A L B A N D D D U A L B A N D 1 4 2 3 ap3600getstart.fm Page 5 Wednesday, January 26, 2011 8:51 AM 6 Figure 2Access Point Ports and Connections (bottom) 1 Kensington lock slot 4 Console port 2 Power connection 5 Security padlock and hasp (padlock not included) 3 Ethernet port 6 Mounting bracket pins (feet for desk or table-top mount) 272377 234 15 66 ap3600getstart.fm Page 6 Wednesday, January 26, 2011 8:51 AM 7 5 Configuring the Access Point This section describes how to connect the access point to a wireless LAN controller. Because the configuration process takes place on the controller, see the Cisco Wireless LAN Controller Configuration Guide for additional information. This guide is available on Cisco.com. The Controller Discovery Process The 3600 series access point uses the IETF standard Control and Provisioning of Wireless Access Points Protocol (CAPWAP) to communicate between the controller and other wireless access points on the network. CAPWAP is a standard, interoperable protocol which enables an access controller to manage a collection of wireless termination points. The discovery process using CAPWAP is identical to the Lightweight Access Point Protocol (LWAPP) used with previous Cisco Aironet access points. LWAPP-enabled access points are compatible with CAPWAP and conversion to a CAPWAP controller is seamless. Deployments can combine CAPWAP and LWAPP software on the controllers. The functionality provided by the controller does not change except for customers who have Layer 2 deployments, which CAPWAP does not support. In a CAPWAP environment, a wireless access point discovers a controller by using CAPWAP discovery mechanisms and then s…

Text truncated - open the document above for the full version.

Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134 December 8, 2010 Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Ms. Claire Hoque/Application Examiner of Compliance Engineering Services, Inc., d.b.a. Compliance Certification Services and hereafter referred to as CCS, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Ms. Claire Hoque of CCS on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing CCS as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134 e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jim Nicholson Compliance Engineer Cisco Systems, Inc

March 2, 2011 Federal Communications Commission Equipment Authorization branch 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: In reference to the application under FCC ID: LDK102075 and pursuant to Sections 0.457(d)(l)(ii) and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of the accompanying information as outlined below: Schematics Block Diagram Hardware Theories of Operation Software Theory of Operation Antenna Specifications These documents contain detailed system and equipment description and related information about the product that Cisco considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Cisco considers that this information would be of benefit to its competitors, and that disclosure of the information in these documents would give competitors an unfair advantage in the market. Best Regards, Jim Nicholson EMC Compliance Engineer 4125 Highlander Parkway Richfield, Ohio 44286 Email: [email protected] Direct: (330)523-2094

AIR‐CAP3602E‐A‐K9 Top AIR‐CAP3602I‐A‐K9 Top AIR‐CAP3602E‐A‐K9 Bottom AIR‐CAP3502I‐A‐K9 Bottom

Regulatory Label Artwork

Internal Assembly Shielded Radio Board Top Unshielded Radio Board Top Shielded Radio Board Bottom Unshielded Radio Board Bottom Motherboard Top Motherboard Bottom

Custom EMC Test Report No: EDCS - 1034054 Page No: 1 of 123 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential Test Report AIR-CAP3602y-A-K9 Cisco Aironet 802.11n Dual Band Access Points FCC ID: LDK102075 IC: 2461B-102075 (Also covers AIR-CAP3602y-N-K9, AIR-CAP3602y-T-K9) y = E (External Antenna) or I (Internal Antenna) 2400-2483.5 MHz Against the following Specifications: CFR47 Part 15.247 RSS210 Cisco Systems 170 West Tasman Drive San Jose, CA 95134 Custom EMC Test Report No: EDCS - 1034054 Page No: 2 of 123 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential This test report has been electronically authorized and archived using the CISCO Engineering Document Control system. SECTION 1: OVERVIEW ......................................................................................................................................... 3 1.1 TEST SUMMARY ...................................................................................................................................................... 3 SECTION 2: ASSESSMENT INFORMATION ...................................................................................................... 4 2.1 GENERAL ................................................................................................................................................................. 4 2.4 TESTING FACILITIES ............................................................................................................................................... 5 2.6 EUT DESCRIPTION .................................................................................................................................................. 6 SECTION 4: SAMPLE DETAILS ............................................................................................................................. 8 APPENDIX A: EMISSION TEST RESULTS .................................................................................................. 9 AVERAGE OUTPUT POWER ........................................................................................................................................... 9 6DB BANDWIDTH ......................................................................................................................................................... 10 99% AND 26DB BANDWIDTH ....................................................................................................................................... 20 PEAK OUTPUT POWER ................................................................................................................................................ 30 POWER SPECTRAL DENSITY ....................................................................................................................................... 59 CONDUCTED SPURIOUS EMISSIONS ........................................................................................................................... 69 APPENDIX B: EMISSION TEST RESULTS ................................................................................................ 80 RADIATED BANDEDGE .................................................................................................................................................. 80 RADIATED SPURIOUS EMISSIONS ................................................................................................................................ 107 2.4GHZ 5.2DBI OMNICONDUCTED EMISSIONS ........................................................................................................... 116 CONDUCTED EMISSIONS ............................................................................................................................................. 117 RADIATED EMISSIONS ................................................................................................................................................. 119 MAXIMUM PERMISSIBLE EXPOSURE (MPE) CALCULATIONS ................................................................................... 121 APPENDIX C: TEST EQUIPMENT/SOFTWARE USED TO PERFORM THE TEST ............................. 123 Custom EMC Test Report No: EDCS - 1034054 Page No: 3 of 123 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential Section 1: Overview 1.1 Test Summary samples were assessed against the tests detailed in section 3 under the requirements of the following specifications: Emission Immunity CFR47 Part 15.247 RSS210 N/A The specifications listed above represent actual tests performed to demonstrate compliance against the specifications and basic standards listed on the front cover of this report. This list is not a one to one match to the front cover for one or more of the following reasons. 1. Basic standards call up many different test phenomena specifications such as the 61000-4-X series. The basic standards define which elements and levels shall be applied from these specifications and as such it is not appropriate to list the individual specifications on the front cover. 2. A Standard listed on the front cover may be required in a particular country but is not appropriate for the particular technologies included in the equipment under test. E.g. You cannot test a DC product to the mains Harmonics requirements in EN61000-3-2. See section 3.2. 3. Test results against a particular standard or specification may be included in a different test report. See section 3.2 for an EDCS reference of this data. 4. Where appropriate, Cisco may have substituted a later revision of a basic standard to those referenced in the specification on the front sheet of this test report. This decision was based upon improved test methodology and repeatability and/or where the newer …

Text truncated - open the document above for the full version.

Custom EMC Test Report No: EDCS - 1034060 Page No: 1 of 68 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential Test Report AIR-CAP3602y-A-K9 Cisco Aironet 802.11n Dual Band Access Points FCC ID: LDK102075 IC: 2461B-102075 (Also covers AIR-CAP3602y-N-K9, AIR-CAP3602y-T-K9) y = E (External Antenna) or I (Internal Antenna) 5725-5850 MHz Against the following Specifications: CFR47 Part 15.247 RSS210 Cisco Systems 170 West Tasman Drive San Jose, CA 95134 Custom EMC Test Report No: EDCS - 1034060 Page No: 2 of 68 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential This test report has been electronically authorized and archived using the CISCO Engineering Document Control system. SECTION 1: OVERVIEW ......................................................................................................................................... 3 1.1 TEST SUMMARY ...................................................................................................................................................... 3 SECTION 2: ASSESSMENT INFORMATION ...................................................................................................... 4 2.1 GENERAL ................................................................................................................................................................. 4 2.4 TESTING FACILITIES ............................................................................................................................................... 5 2.6 EUT DESCRIPTION .................................................................................................................................................. 6 SECTION 4: SAMPLE DETAILS ............................................................................................................................. 8 APPENDIX A: EMISSION TEST RESULTS .................................................................................................. 9 AVERAGE OUTPUT POWER ........................................................................................................................................... 9 6DB BANDWIDTH ......................................................................................................................................................... 10 99% AND 26DB BANDWIDTH ....................................................................................................................................... 17 PEAK OUTPUT POWER ................................................................................................................................................ 24 POWER SPECTRAL DENSITY ....................................................................................................................................... 36 CONDUCTED SPURIOUS EMISSIONS ........................................................................................................................... 43 APPENDIX B: EMISSION TEST RESULTS ................................................................................................ 56 RADIATED BANDEDGE ............................................................................................... ERROR! BOOKMARK NOT DEFINED. RADIATED SPURIOUS EMISSIONS .................................................................................................................................. 56 2.4GHZ 5.2DBI OMNICONDUCTED EMISSIONS ............................................................................................................. 61 CONDUCTED EMISSIONS ............................................................................................................................................... 62 RADIATED EMISSIONS ................................................................................................................................................... 64 MAXIMUM PERMISSIBLE EXPOSURE (MPE) CALCULATIONS ..................................................................................... 66 APPENDIX C: TEST EQUIPMENT/SOFTWARE USED TO PERFORM THE TEST ............................... 68 Custom EMC Test Report No: EDCS - 1034060 Page No: 3 of 68 This document is uncontrolled. Please refer to the electronic copy within EDCS for the most up to date version. Cisco Systems, Inc. Company Confidential Section 1: Overview 1.1 Test Summary samples were assessed against the tests detailed in section 3 under the requirements of the following specifications: Emission Immunity CFR47 Part 15.247 RSS210 N/A The specifications listed above represent actual tests performed to demonstrate compliance against the specifications and basic standards listed on the front cover of this report. This list is not a one to one match to the front cover for one or more of the following reasons. 1. Basic standards call up many different test phenomena specifications such as the 61000-4-X series. The basic standards define which elements and levels shall be applied from these specifications and as such it is not appropriate to list the individual specifications on the front cover. 2. A Standard listed on the front cover may be required in a particular country but is not appropriate for the particular technologies included in the equipment under test. E.g. You cannot test a DC product to the mains Harmonics requirements in EN61000-3-2. See section 3.2. 3. Test results against a particular standard or specification may be included in a different test report. See section 3.2 for an EDCS reference of this data. 4. Where appropriate, Cisco may have substituted a later revision of a basic standard to those referenced in the specification on the front sheet of this test report. This decision was based upon improved test methodology and repeatability and/or where the newer revision represented a m…

Text truncated - open the document above for the full version.

Refer to test report for setup photos

Refer to test report for setup photos
