FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 1 of 8 Report No. : SF191004C33A Issued Date : Dec. 20, 2019 Reference No. : 191025C22 FCC SAR Exclusion Report Report No. : SF191004C33A Applicant : CISCO SYSTEMS INC Address : 125 W TASMAN DR, SAN JOSE, CA, 95134, USA Product : Bluetooth USB Adapter Brand : CISCO FCC ID : LDK700BA2137 Model No. : HS-WL-700-BA Standards : FCC 47 CFR Part 2 (2.1093), IEEE C95.1:1992, IEEE Std 1528:2013 KDB 865664 D01 v01r04, KDB 865664 D02 v01r02 KDB 447498 D01 v06, KDB 447498 D02 v02r01 Sample Received Date : Oct. 25, 2019 Date of Evaluation : Dec. 16, 2019 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location : No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City, Taiwan CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Lena Wang / Specialist Approved By : Gordon Lin / Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 2 of 8 Report No. : SF191004C33A Issued Date : Dec. 20, 2019 Reference No. : 191025C22 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement Evaluation .............................................................................................................................................. 6 3.1 Maximum Output Power ............................................................................................................................................... 6 3.1.1 Maximum Target Conducted Power ................................................................................................................... 6 3.1.2 Measured Conducted Power Result ................................................................................................................... 6 3.2 SAR Testing Exclusions ............................................................................................................................................... 7 4. Information on the Testing Laboratories ............................................................................................................................. 8 Appendix A. Photographs of EUT and Setup FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 3 of 8 Report No. : SF191004C33A Issued Date : Dec. 20, 2019 Reference No. : 191025C22 Release Control Record Issue No. Reason for Change Date Issued SF191004C33A Initial release Dec. 20, 2019 FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 4 of 8 Report No. : SF191004C33A Issued Date : Dec. 20, 2019 Reference No. : 191025C22 1. Summary of Maximum SAR Value Equipment Class Mode Highest Reported SAR 1g (W/kg) DSS Bluetooth Not Required Note: 1. The SAR limit (Head & Body: SAR 1g 1.6 W/kg) for general population / uncontrolled exposure is specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEE C95.1-1992. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 5 of 8 Report No. : SF191004C33A Issued Date : Dec. 20, 2019 Reference No. : 191025C22 2. Description of Equipment Under Test EUT Type Bluetooth USB Adapter Brand Name CISCO FCC ID LDK700BA2137 Model Name HS-WL-700-BA Tx Frequency Bands (Unit: MHz) Bluetooth : 2402 ~ 2480 Uplink Modulations Bluetooth : GFSK, π/4-DQPSK, 8-DPSK Maximum Tune-up Conducted Power (Unit: dBm) Please refer to section 3.1 of this report Antenna Type PCB Antenna EUT Stage Engineering Sample Note: 1. The above EUT information is declared by manufacturer and for more detailed features description please refers to the manufacturer's specifications or User's Manual. FCC SAR Exclusion Report Report Format Version 5.0.0 Page No. : 6 of 8 Repor…

Text truncated - open the document above for the full version.

Report No.: RF191004C33-1 Page No. 1 / 51 Report Format Version: 6.1.1 FCC Test Report Report No.: RF191004C33-1 FCC ID: LDK700BA2137 Test Model: HS-WL-700-BA Received Date: Oct. 04, 2019 Test Date: Nov. 25 ~ Dec. 25, 2019 Issued Date: Dec. 26, 2019 Applicant: CISCO SYSTEMS INC Address: 125 W TASMAN DR, SAN JOSE, CA, 95134, USA Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan FCC Registration / Designation Number: 788550 / TW0003 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF191004C33-1 Page No. 2 / 51 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ........................................................................................................................... 5 2 Summary of Test Results ........................................................................................................................... 6 2.1 Measurement Uncertainty ..................................................................................................................... 6 2.2 Modification Record .............................................................................................................................. 6 3 General Information ................................................................................................................................... 7 3.1 General Description of EUT .................................................................................................................. 7 3.2 Description of Test Modes ..................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail .................................................................... 9 3.3 Duty Cycle of Test Signal ..................................................................................................................... 11 3.4 Description of Support Units ............................................................................................................... 12 3.4.1 Configuration of System under Test ......................................................................................... 12 3.5 General Description of Applied Standards and References ............................................................... 12 4 Test Types and Results ............................................................................................................................ 13 4.1 Radiated Emission and Bandedge Measurement .............................................................................. 13 4.1.1 Limits of Radiated Emission and Bandedge Measurement ..................................................... 13 4.1.2 Test Instruments ....................................................................................................................... 14 4.1.3 Test Procedures ........................................................................................................................ 15 4.1.4 Deviation from Test Standard ................................................................................................... 15 4.1.5 Test Set Up ............................................................................................................................... 16 4.1.6 EUT Operating Conditions ........................................................................................................ 17 4.1.7 Test Results .............................................................................................................................. 18 4.2 Conducted Emission Measurement .................................................................................................... 28 4.2.1 Limits of Conducted Emission Measurement ........................................................................... 28 4.2.2 Test Instruments ....................................................................................................................... 28 4.2.3 Test Procedures ........................................................................................................................ 28 4.2.4 Deviation from Test Standard ..............................................................................…

Text truncated - open the document above for the full version.

FCC SAR Exclusion Report Report Format Version 5.0.0 Report No. : SF191004C33A Reference No. : 191025C22 <Photographs of EUT> <Antenna Location> The separation distance for antenna to edge: Antenna To Top Side (mm) To Bottom Side (mm) To Left Side (mm) To Right Side (mm) BT Antenna 0 21 0 0 Top Side Left Side Right Side Bottom Side <EUT Front View>

FCC ID: LDK700BA2137 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: LDK700BA2137 2 FCC ID: LDK700BA2137 3 RADIATED EMISSION TEST BELOW 1GHz (Z-Plane) FCC ID: LDK700BA2137 4 FCC ID: LDK700BA2137 5 RADIATED EMISSION TEST ABOVE 1GHz (Z-Plane)
