LDK88752517Video Phone

REVIEW DRAFT - CISCO CONFIDENTIAL Cisco Video Phone 8875 Documentation First Published:2021-11-18 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 USA http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883 THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUALARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS. THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY. The following information is for FCC compliance of Class A devices: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio-frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmfulinterference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case users will be required to correct the interference at their own expense. The following information is for FCC compliance of Class B devices: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If the equipment causes interference to radio or television reception, which can be determined by turning the equipment off and on, users are encouraged to try to correct the interference by using one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Modifications to this product not authorized by Cisco could void the FCC approval and negate your authority to operate the product. The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part ofUCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California. NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED "AS IS" WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE. IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples,command display output, network topologydiagrams,andotherfiguresincludedinthedocumentareshownforillustrativepurposesonly.AnyuseofactualIPaddressesorphonenumbersinillustrativecontentisunintentional and coincidental. All printed copies and duplicate soft copies of this document are considered uncontrolled. See the current online version for the latest version. Cisco has more than 200 offices worldwide. Addresses and phone numbers are listed on the Cisco website at www.cisco.com/go/offices. Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this URL: https://www.cisco.com/c/en/us/about/legal/trademarks.html. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1721R) © 2021 Cisco Systems, Inc. All rights reserved. CONTENTS Get Started1 CHAPTER 1 Your Cisco Video Phone 88751 Hardware and buttons2 Connect your phone5 Wired Network5 Wireless Network7 Wall Mount9 Non-Lockable Wall Mount Components9 Install the Non-Lockable Wall Mount Kit for Phone10 Remove the Phone from the Non-Lockable Wall Mount15 Adjust the Handset Rest16 Calls19 CHAPTER 2 Calls19 Make a Call19 Single Line19 Multiple Lines19 Make an Emergency Call20 Answer a call20 Single incoming call21 Multiple incoming calls21 Put a call on hold21 Silence the incoming call ring22 Mute yourself during calls and meetings22 Adjust audio volume23 Switch the phone audio path24 Cisco Video Phone 8875 Documentation iii Swap between active and held calls25 Meetings27 CHAPTER 3 Meetings27 Join a meeting on your phone27 Turn your video stream on or off28 Contacts29 CHAPTER 4 Contacts29 Search for a Contact29 Add a ontact to Favorites30 Add a Contact to Your Personal Directory30 Directories30 Recents31 Dialing31 Edit a C…

Text truncated - open the document above for the full version.

Page 1 of 1 FCC, Request for non-di sclosure RF_501, Issue 8 To : Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: LDK88752517 Reference number: ###### Dear FCC TCB, 1. L ong-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-T erm Confid entiality (STC) P ursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, a pplicant hereby requests Short-Term Confidential treatment of the following materials (See notes below): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: This document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor unfair advantage in the market. Name and sig nature of applicant: Samuel Kim Date: 14 February 2022 Company Name: Cisco Systems Inc Address:125 West Tasman Drive City:San Jose State:CA 95134-1706 Country:United States Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Sh ort-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max. )! Th e planned date should stated in the RF731 application form. 3) F CC must be informed when marketing begins earlier. 4) R elease takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 1 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 2 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 3 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 4 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 5 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 6 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 7 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 8 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 9 of 29 ADP-50GR B Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 10 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 11 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 12 of 29 AM50U-480A Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 13 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 14 of 29

Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 15 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 16 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 17 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 18 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 19 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 20 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 21 of 29 Antenna RF Module Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 22 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 23 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 24 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 25 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 26 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 27 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 28 of 29 Appendix No.: EP-2112T026-1 APPENDIX-EUT PHOTOS Project No.: 2112T026 Page 29 of 29

Report No.: BTL-FCCP-6-2112T026 Project No.: 2112T026 Page 1 of 4 Report Version: R00 Maximum Permissible Exposure Report FCC ID: LDK88752517 Report No. : BTL-FCCP-6-2112T026 Equipment : Video Phone Model Name : CP-8875 Brand Name : CISCO Applicant : Cisco Systems Inc Address : 125 West Tasman Drive San Jose, CA 95134-1706 United States FCC Rule Part(s) : FCC CFR Title 47, Part 2 (2.1091) FCC Guidelines for Human Exposure IEEE C95.1 Date of Receipt : 2021/12/6 Date of Test : 2021/12/6 ~ 2022/1/21 Issued Date : 2022/2/7 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Eric Lee, Engineer Approved by : Jerry Chuang, Supervisor BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-6-2112T026 Project No.: 2112T026 Page 2 of 4 Report Version: R00 REVISION HISTORY Report No. Version Description Issued Date BTL-FCCP-6-2112T026 R00 Original Report. 2022/2/7 Report No.: BTL-FCCP-6-2112T026 Project No.: 2112T026 Page 3 of 4 Report Version: R00 Table for Filed Antenna Antenna Manufacture Part number Type Connector Frequency (MHz) Gain (dBi) 1 WA-P-LB-02-885 PCB I-PEX 2400-2500 1.79 5150-5850 2.27 Maximum RF OUTPUT POWER Mode Maximum Average Power (dBm) WLAN 2.4 GHz IEEE 802.11b 19.79 IEEE 802.11g 24.38 IEEE 802.11n (HT20) 24.69 RLAN 5 GHz IEEE 802.11a 13.59 IEEE 802.11n (HT20) 13.55 IEEE 802.11n (HT40) 12.09 IEEE 802.11ac (VHT20) 11.23 IEEE 802.11ac (VHT40) 10.97 IEEE 802.11ac (VHT80) 11.03 BT 4.20 BLE 4.09 MPE CALCULATION METHOD: Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Report No.: BTL-FCCP-6-2112T026 Project No.: 2112T026 Page 4 of 4 Report Version: R00 CALCULATED RESULT Band Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Pow er (dBm) Max. Output Pow er ( mW ) Pow er Density (S) (mW/cm 2 ) Limit of Pow er Density (S) (mW/cm 2 ) Result BT 1.79 1.5101 4.20 2.6303 0.00079059 1 Pass Band Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Pow er (dBm) Max. Output Pow er ( mW ) Pow er Density (S) (mW/cm 2 ) Limit of Pow er Density (S) (mW/cm 2 ) Result BLE 1.79 1.5101 4.09 2.5645 0.00077082 1 Pass Band Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Pow er (dBm) Max. Output Pow er ( mW ) Pow er Density (S) (mW/cm 2 ) Limit of Pow er Density (S) (mW/cm 2 ) Result WLAN 2.4 GHz 1.79 1.5101 24.69 294.4422 0.08850145 1 Pass Band Antenna Gain (dBi) Antenna Gain (numeric) Max. Output Pow er (dBm) Max. Output Pow er ( mW ) Pow er Density (S) (mW/cm 2 ) Limit of Pow er Density (S) (mW/cm 2 ) Result RLAN 5 GHz 2.27 1.6866 13.59 22.8560 0.00767274 1 Pass Note: 1. The calculated distance is 20 cm. End of Test Report

Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 1 of 25 Report Version: R00 FCC Radio Test Report FCC ID: LDK88752517 Report No. : BTL-FCCP-5-2112T026 Equipment : Video Phone Model Name : CP-8875 Brand Name : CISCO Applicant : Cisco Systems Inc Address : 125 West Tasman Drive San Jose, CA 95134-1706 United States Radio Function : RLAN 5 GHz (U-NII 2A, U-NII 2C) FCC Rule Part(s) : FCC Part 15, Subpart E (15.407) / FCC 06-96 Measurement Procedure(s) : FCC KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 FCC KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02 FCC KDB 905462 D03 UNII Clients Without Radar Detection New Rules v01r02 Date of Receipt : 2021/12/6 Date of Test : 2021/12/6 ~ 2022/1/21 Issued Date : 2022/2/7 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Eric Lee, Engineer Approved by : Jerry Chuang, Supervisor BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 2 of 25 Report Version: R00 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 3 of 25 Report Version: R00 CONTENTS REVISION HISTORY 4 1 SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 TEST ENVIRONMENT CONDITIONS 5 2 EUT INFORMATION 6 2.1 EUT SPECIFICATION TABLE 6 2.2 EIRP POWER 8 3 U-NII DFS RULE REQUIREMENTS 9 3.1 WORKING MODES AND REQUIRED TEST ITEMS 9 3.2 TEST LIMITS AND RADAR SIGNAL PARAMETERS 10 4 DYNAMIC FREQUENCY SELECTION (DFS) TEST 13 4.1 DFS MEASUREMENT SYSTEM 13 4.2 CALIBRATION OF DFS DETECTION THRESHOLD LEVEL 16 4.3 DEVIATION FROM TEST STANDARD 16 5 LIST OF MEASURING EQUIPMENTS 17 6 TEST RESULTS 18 6.1 SUMMARY OF TEST RESULT 18 6.2 TEST MODE: DEVICE OPERATING IN MASTER MODE. 18 6.3 DFS DETECTION THRESHOLD 19 6.4 CHANNEL CLOSING TRANSMISSION AND CHANNEL MOVE TIME WLAN TRAFFIC 21 7 EUT TEST PHOTO 25 8 EUT PHOTOS 25 Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 4 of 25 Report Version: R00 REVISION HISTORY Report No. Version Description Issued Date BTL-FCCP-5-2112T026 R00 Original Report. 2022/2/7 Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 5 of 25 Report Version: R00 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards. FCC Part 15, Subpart E (15.407) Standard(s) Section Description Test Result Judgement Remark 15.407(h) Dynamic Frequency Selection (DFS) ------ Pass ------ NOTE: (1) The report format version is TP.1.1.1. 1.1 TEST FACILITY The test facilities used to collect the test data in this report: No. 68-1, Ln. 169, Sec. 2, Datong Rd., Xizhi Dist., New Taipei City 221, Taiwan The test sites and facilities are covered under FCC RN: 674415 and DN: TW0659. ☐ C05 ☐ CB08 ☐ CB11 ☐ CB15 ☐ CB16 ☒ SR05 1.2 TEST ENVIRONMENT CONDITIONS Test Item Environment Condition Test Voltage Tested by Dynamic Frequency Selection (DFS) 23.5 °C, 51 % AC 120V Tim Lee Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 6 of 25 Report Version: R00 2 EUT INFORMATION 2.1 EUT SPECIFICATION TABLE Equipment Video Phone Model Name CP-8875 Brand Name CISCO Model Difference N/A Power Source #1 DC voltage supplied from AC/DC Adapter. (1) DELTA / ADP-50GR B (2) CISCO / AM50U-480A #2 DC Voltage supplied from PoE Adapter. Power Rating #1 (1) I/P: 100-240V~1.3A, 50-60Hz O/P: 48V −−− 1.042A, 50.1W MAX. (2) I/P: 100-240V~1.2A, 50-60Hz O/P: 48V − − − 1.042A, 50.016W #2 I/P: 48V Products Covered 2 * AC/DC Adapter (1) Delta / ADP-50GR B (2) Cisco / AM50U-480A 1 * Wall bracket 1 * Phone bracket 1 * 6-inch Ethernet cable Operational Mode Master Slave with radar detection Slave without radar detection Operation Band UNII-2A: 5250 MHz to 5350 MHz UNII-2C: 5470 MHz to 5725 MHz Operating Frequency UNII-2A: 5260 MHz to 5320 MHz UNII-2C: 5500 MHz to 5700 MHz Modulation OFDM Test Model CP-8875 Sample Status Engineering Sample EUT Modification(s) N/A NOTE: (1) For a more detailed features description, please refer to the manufacturer’s specifications or the user's manual. Report No.: BTL-FCCP-5-2112T026 Project No.: 2112T026 Page 7 of 25 Report Version: R00 (2) Channel List: IEEE 802…

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 1 of 186 Report Version: R00 FCC Radio Test Report FCC ID: LDK88752517 Report No. : BTL-FCCP-4-2112T026 Equipment : Video Phone Model Name : CP-8875 Brand Name : CISCO Applicant : Cisco Systems Inc Address : 125 West Tasman Drive San Jose, CA 95134-1706 United States Radio Function : RLAN 5 GHz (U-NII 1, U-NII 2A, U-NII 2C, U-NII 3) FCC Rule Part(s) : FCC Part15, Subpart E (15.407) Measurement Procedure(s) : ANSI C63.10-2013 Date of Receipt : 2021/12/6 Date of Test : 2021/12/6 ~ 2022/1/21 Issued Date : 2022/2/7 The above equipment has been tested and found in compliance with the requirement of the above standards by BTL Inc. Prepared by : Eric Lee, Engineer Approved by : Jerry Chuang, Supervisor BTL Inc. No.18, Ln. 171, Sec. 2, Jiuzong Rd., Neihu Dist., Taipei City 114, Taiwan Tel: +886-2-2657-3299 Fax: +886-2-2657-3331 Web: www.newbtl.com Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 2 of 186 Report Version: R00 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 3 of 186 Report Version: R00 CONTENTS REVISION HISTORY 5 1 SUMMARY OF TEST RESULTS 6 1.1 TEST FACILITY 7 1.2 MEASUREMENT UNCERTAINTY 7 1.3 TEST ENVIRONMENT CONDITIONS 7 1.4 TABLE OF PARAMETERS OF TEST SOFTWARE SETTING 8 1.5 DUTY CYCLE 10 2 GENERAL INFORMATION 12 2.1 DESCRIPTION OF EUT 12 2.2 TEST MODES 15 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 16 2.4 SUPPORT UNITS 17 3 AC POWER LINE CONDUCTED EMISSIONS TEST 18 3.1 LIMIT 18 3.2 TEST PROCEDURE 18 3.3 DEVIATION FROM TEST STANDARD 18 3.4 TEST SETUP 19 3.5 TEST RESULT 19 4 RADIATED EMISSIONS TEST 20 4.1 LIMIT 20 4.2 TEST PROCEDURE 21 4.3 DEVIATION FROM TEST STANDARD 21 4.4 TEST SETUP 22 4.5 EUT OPERATING CONDITIONS 23 4.6 TEST RESULT – BELOW 30 MHZ 23 4.7 TEST RESULT – 30 MHZ TO 1 GHZ 23 4.8 TEST RESULT – ABOVE 1 GHZ 23 5 BANDWIDTH TEST 24 5.1 LIMIT 24 5.2 TEST PROCEDURE 24 5.3 DEVIATION FROM TEST STANDARD 24 5.4 TEST SETUP 24 5.5 EUT OPERATING CONDITIONS 24 5.6 TEST RESULT 24 6 OUTPUT POWER TEST 25 6.1 LIMIT 25 6.2 TEST PROCEDURE 25 6.3 DEVIATION FROM TEST STANDARD 25 6.4 TEST SETUP 25 6.5 EUT OPERATING CONDITIONS 25 6.6 TEST RESULT 25 7 POWER SPECTRAL DENSITY 26 7.1 LIMIT 26 7.2 TEST PROCEDURE 26 7.3 DEVIATION FROM TEST STANDARD 26 7.4 TEST SETUP 26 7.5 EUT OPERATING CONDITIONS 26 Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 4 of 186 Report Version: R00 7.6 TEST RESULT 26 8 LIST OF MEASURING EQUIPMENTS 27 9 EUT TEST PHOTO 29 10 EUT PHOTOS 29 APPENDIX A AC POWER LINE CONDUCTED EMISSIONS 30 APPENDIX B RADIATED EMISSIONS - 30 MHZ TO 1 GHZ 35 APPENDIX C RADIATED EMISSIONS - ABOVE 1 GHZ 38 APPENDIX D BANDWIDTH 144 APPENDIX E CONDUCTED OUTPUT POWER 169 APPENDIX F POWER SPECTRAL DENSITY 173 Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 5 of 186 Report Version: R00 REVISION HISTORY Report No. Version Description Issued Date BTL-FCCP-4-2112T026 R00 Original Report. 2022/2/7 Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 6 of 186 Report Version: R00 1 SUMMARY OF TEST RESULTS Test procedures according to the technical standards. FCC Part 15, Subpart E (15.407) Standard(s) Section Description Test Result Judgement Remark 15.207 AC Power Line Conducted Emissions APPENDIX A Pass ------ 15.205 15.209 15.407(b) Radiated Emissions APPENDIX B APPENDIX C Pass ------ 15.407(a) Bandwidth APPENDIX D Pass ------ 15.407(a) Output Power APPENDIX E Pass ------ 15.407(a) Power Spectral Density APPENDIX F Pass ------ 15.203 Antenna Requirement ------ Pass ------ 15.407(c) Automatically Discontinue Transmission ------ Pass NOTE (3) NOTE: (1) ”N/A” denotes test is not applicable in this Test Report. (2) The report format version is TP.1.1.1. (3) The EUT can detect the controlling signal of ACK message transmitting from remote device and verify whether it shall resend or discontinue transmission. Report No.: BTL-FCCP-4-2112T026 Project No.: 2112T026 Page 7 of 186 Report Version: R00 1.1 TEST FACILITY The test facilities used to collect the test data in this report: No. 68-1, Ln. 169, Sec. 2, Datong Rd., Xizhi Dist., New Taipei City 221, Taiwan The test sites and facilities are covered under FCC RN: 674415 and DN: TW0659. ☒ C05 …

Text truncated - open the document above for the full version.

Appendix No.: TP-2112T026-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2112T026 Page 1 of 6 AC Power Line Conducted Emissions test photos Appendix No.: TP-2112T026-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2112T026 Page 2 of 6 Radiated emissions test photos 30 MHz to 1 GHz Footstand Appendix No.: TP-2112T026-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2112T026 Page 3 of 6 Radiated emissions test photos 30 MHz to 1 GHz Wall bracket Appendix No.: TP-2112T026-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2112T026 Page 4 of 6 Radiated emissions test photos Above 1 GHz Footstand Appendix No.: TP-2112T026-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2112T026 Page 5 of 6 Radiated emissions test photos Above 1 GHz Wall bracket Appendix No.: TP-2112T026-FCCP-1 APPENDIX-TEST PHOTOS Project No.: 2112T026 Page 6 of 6 DFS test photos
