1 Cisco Systems, Inc.www.cisco.com IG21, IG21R and IG31R Hardware Installation Guide First Published: 07-16-2020 Last Updated: 01-07-2020 Organization This guide includes the following sections: Cautions and Warnings, page 2Summary of relevant cautions or warnings to adhere to when installing and using the product. Conventions, page 2Details on style conventions used in the guide. Before You Begin, page 3Provides a general overview of the IG21, IG21R and IG31R Gateways. It also provides important site preparation and safety measures to follow before installing the system.s IG21, IG21R and IG31R Part Numbers, page 3Provides a summary of the systems and part numbers. DIN Rail Mounting Instructions for IG21, IG21R and IG31R, page 4 Provides instructions on how to attach a DIN rail for horizontal and vertical mounting. Mounting the Router on a Wall Using Mounting Brackets, page 7 Provides instructions on how to attach a mounting bracket to the IG21, IG21R and IG31R for horizontal and vertical mounting. Mounting the Router on a Wall Using Two KeyHoles, page 9 Provides instructions on how to mount the router on drywall. 2 IG21, IG21R and IG31R Hardware Installation Guide Cautions and Warnings Cautions and Warnings CAUTION : Do not place anything on top of the router that weighs more than 10 pounds (4.5 kilograms), and do not stack routers on a desktop. Excessive weight on top of the router could damage the chassis. CAUTION: Do not install the router or power supplies next to a heat source of any kind, including heating vents. WA RNING : Read the installation instructions before connecting the system to the power source. Statement 1004 WA RNING : This product relies on the building’s installation for short-circuit (over current) protection. Ensure that the protective device is rated not greater than: 5 Amps. Statement 1005 WA RNING :This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security. Statement 1017 WA RNING :This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available. Statement 1024 WA RNING : Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement 1030 WA RNING: Ultimate disposal of this product should be handled according to all national laws and regulations. Statement 1040 WA RNING:To prevent the system from overheating, do not operate it in an area that exceeds the maximum recommended ambient temperature of: 60C Statement 1047 WA RNING: No user-serviceable parts inside. Do not open. Statement 1073 WA RNING: This product is not intended to be directly connected to the Cable Distribution System. Additional regulatory compliance and legal requirements may apply for direct connection to the Cable Distribution System. This product may connect to the Cable Distribution System ONLY through a device that is approved for direct connection. Statement 1078 Conventions This document uses the following conventions. Front Panel and LED Definition, page 10Provides an overview of key components on the front panel and LEDs. IG21R and IG31R Overview, page 13Provides an overview of the feature set of the IG systems and LED definitions. FCC and ISED Interference Statement, page 16Please review this statement regarding Radio Frequency ConventionsIndication bold fontCommands and keywords and user-entered text appear in bold font. italic fontDocument titles, new or emphasized terms, and arguments for which you supply values are in italic font. [ ]Elements in square brackets are optional. {x | y | z }Required alternative keywords are grouped in braces and separated by vertical bars. [ x | y | z ]Optional alternative keywords are grouped in brackets and separated by vertical bars. stringA nonquoted set of characters. Do not use quotation marks around the string or the string will include the quotation marks. courier fontTerminal sessions and information the system displays appear in courier font. 3 IG21, IG21R and IG31R Hardware Installation Guide Before You Begin Note: Means reader take note. Notes contain helpful suggestions or references to material not covered in the manual. CAUTION: Means reader be careful. In this situation, you might perform an action that could result in equipment damage or loss of data. WARNING: IMPORTANT SAFETY INSTRUCTIONS Means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device. CAUTION: Cable distribution system should be grounded (earthed) in accordance with ANSI/NFPA 70, the National Electrical Code (NEC), article 800, Grounding of Outer Conductive Shield of a Coaxial Cable. Wa r n i n g : Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement 1030 SAVE THESE INSTRUCTIONS Regulatory: Provided for additional information and to comply with regulatory and customer requirements. Before You Begin Because the IG21, IG21R and IG31R are radio devices, they are susceptible to common causes of interference that can reduce throughput and range. Follow these basic guidelines to ensure the best possible performance: Review the FCC guidelines for installing and operating outdoor wireless LAN devices at: https://www.cisco.com/c/en/us/products/collateral/routers/3200-series-rugged-integrated-services-routers-isr/data_sheet_c78-647116 .html Perform a site survey before beginning the installation. Install the IG21, IG2…
