LLA-TC4000THINCLIENT

Winlinx Thin Client Family TC 4000 Series Hardware User’s Guide VXL Instruments Ltd. Winlinx - Hardware User’s Guide Copyright and Trademark Notices Copyright and Trademark notices Copyright © 2000 VXL Instruments Limited. ALL RIGHTS RESERVED. Information in this document is subject to change without notice and does not represent a commitment on the part of the manufacturer. No part of this manual may be reproduced or transmitted in any form or means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of the manufacturer. VXL, Winlinx, Winlinx Pro, Winlinx Lite, Netica, EaziTC, SmartAX-S, the VXL logo and the SmartAX-S logo are registered trademarks of VXL Instruments Limited. All other Trademarks are acknowledged. Document Number: 600 0101 290 27 A00 1 st Edition, August 2000 Printed in INDIA Winlinx - Hardware User’s Guide Preface Federal Communication Commission (FCC) statement FCC Certification awaited. Warnings • Only equipment certified to comply with Class B (computer input/output devices, terminals, printers etc.) should be attached to this equipment, and they must have shielded interface cables. • Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. • This equipment should not be used in electro-medical applications. • There are no user serviceable parts inside. • DO NOT disassemble the equipment as this can nullify your warranty • DO NOT operate this equipment in a corrosive or explosive atmosphere. • DO NOT operate this equipment outside specified temperature limits. Winlinx - Hardware User’s Guide Preface Preface Thank you for purchasing the Winlinx Thin Client Terminal. This manual contains information to setup and use the hardware of Winlinx. The manual consists of the following chapters: • Introduction : provides an overview of Winlinx. • Installation : contains the procedure to setup the hardware. • Specifications : provides hardware, mechanical, electrical, interface and operating environment specifications. • Connectors and Cables : provides detailed specifications for connectors and cables used with Winlinx. • Troubleshooting : provides solutions to problems that you may encounter while using Winlinx. N OTE : CONSISTENT WITH OUR POLICY OF CONTINUOUS PRODUCT DEVELOPMENT , THE PRODUCT YOU RECEIVED MAY HAVE FEATURES IN ADDITION TO THOSE DESCRIBED IN THIS MANUAL . P LEASE VISIT OUR WEB - SITE www.vxl.net FOR CURRENT INFORMATION ON THE FEATURES AND FUNCTIONS OF W INLINX . Winlinx - Hardware User’s Guide Table of Contents Table of Contents INTRODUCTION ........................................................................................................................................... 1 Overview......................................................................................................................................................................... 1 Standard Features ............................................................................................................................................................ 2 Optional Features ............................................................................................................................................................ 2 INSTALLATION............................................................................................................................................. 3 Step One: Unpack ........................................................................................................................................................... 3 Step Two: Prepare the site............................................................................................................................................... 3 Step Three: Connect accessories and power ................................................................................................................... 4 Step Four: Connect to the Server .................................................................................................................................... 5 LAN connection: ......................................................................................................................................................... 5 Direct connection ........................................................................................................................................................ 6 Dial-in remote connection ........................................................................................................................................... 6 Step Five: Secure the unit to the desk or table ................................................................................................................ 6 Step Six: Start Winlinx.................................................................................................................................................... 7 SPECIFICATIONS ......................................................................................................................................... 8 Hardware ......................................................................................................................................................................... 8 Mechanical ...................................................................................................................................................................... 8 Operating Environment ................................................................................................................................................... 8 Electrical ......................................................................................................................................................................... 8 External Interfaces ...........................................................................…

Text truncated - open the document above for the full version.

AA BB CC DD EE 4 4 3 3 2 2 1 1 1 OF 1 POWER SUPPLY ANDRESET CI RCUIT BLOCK DIAGRAM CYRIX MEDIAGXM CPU SO-DIMM CX 5530 I/OCOMPANION ETHERNET10/100DP83815 PCI BUS AUDIOAD1819 USB VGA LCD/FLATPANELINTERFACE FLASH DISK (SSD) BIOSPROM SUPER I/O PC 97317 ISA BUS MEMORY BUS COM2 PRINTER COM1 MOUSE KBD SPEAKER MIC Z00 C.S.MOHAN V9 LOGIC BOARD C.S.MOHAN PCI INTERFACE 600 2701 910 32 (WITH NS LAN CONTROLLER) CLOCKGENERATOR 14.318 MHzCRYSTAL SYSCLK - 33 MHzPCICLK1 - 33 MHzPCICLK2 - 33 MHzREFCLK1 - 14.318 MHzREFCLK2 - 14.318 MHzUSBCLK - 48 MHz SYSCLK - 33 MHz PCICLK1 - 33 MHz PCICLK2 - 33 MHz PCICLK2 - 33 MHz 25 MHzCRYSTAL REFCLK1 -14.318 MHz REFCLK2 -14.318 MHz32.768 KHzCRYSTAL 24.576 MHzCRYSTAL USBCLK - 48 MHz DESIGNED BY DRAWN BY CHKD DESIGN CHKD REGL APPD BY PART NO: SHEET:REV: VXL Instruments Limited Bangalore

Federal Communications CommissionDate: Sept. 22, 2000 Authorization and Evaluation Division 7435 Oakland Mills Rd. Columbia, MD. 21046 Attention: Authorization and Evaluation Division Subject: Application for Certification on Thinclient (EUT) with FCC ID: LLA-TC4000 Dear Sir: We would like to apply for FCC certification of the EUT. Enclosed please find all required documents of the EUT listed below: 1. Exhibit 1 : The Authorization Letter signed by the applicant 2. Exhibit 2 : The FCC Label of EUT 3. Exhibit 3 : The modification List Letter signed by the applicant 4. Exhibit 4 : The RFI/EMI Test Report issued by ADT Corp. 5. Exhibit 5 : The photographs of EUT 6. Exhibit 6 : The Block Diagram & Schematic Diagram of EUT 7. Exhibit 7 : The User’s Manual of EUT Please review the information we submitted and issue us a grant for the EUT. If you have any questions or comments, please do not hesitate to contact Mr. Mike Su of ADT Lab. at fax no.: 886-2-2602-2943 or e-mail: [email protected] Sincerely yours,

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14

(Fig. 1) FCC ID: LLA-TC4000 SAMPLE OF FCC LABEL The label will be permanently affixed at a conspicuous location on the device. Label 95.5 Bangalore-561229INDIA VXLInstrumentsLimited 361070100024A00 Sl.No. Model:TC4000Series Site01: IN5VD.C2.5A12W LISTED I.T.E. 4Z52 E162104 MadeinIndia 361070100024A00 1.THISDEVICEMAYNOTCAUSEHARMFULINTERFERENCE. 2.THISDEVICEMUSTACCEPTANYINTERFERENCERECEIVED INCLUDINGINTERFERENCETHATMAYCAUSEUNDESIREDOPERATION. FCCID:LLA-TC4000 TÜVRheinland TYPE APPROVED GEPRÜFT TITLE REV NXTASY. ECA/PCADATEAPPD. VXLInstrumentsLimited BANGALORE MATERIAL SEEABOVE TOLERANCE LIN:SEEABOVE ANG:SEEABOVE SCALE DIMENSIONSINMM. GROUP GENERAL APPROVED NAMEDATE CHKDREGL CHKDDESIGN DRAWN FINISH SEEABOVE DRG.No. 1:1 SIZEA4 SHEET20F2 STKRPCSL.NO.&CERTIFICATIONCLASS-B TC4000(V9) A00 C:\DOCUMENT\STICKERS\36107PCR\0100024.CDR MATERIAL FINISH TOLERANCE NOTEBLACK "COOLGREY2C" 3M467MP NOGUMTRANSPARENTAREA 363081036067A00 :POLYCARBONATE0.25THICK SELFADHESIVE,ADHESIVEONNON-READABLESIDE :MATTFINISH :FORDETAILREFERDRG.No.600210001044(LATESTREVISION) :1.CHARACTERSANDLOGOSAREINCOLOURWITH COLOURBACKGROUND,REVERSEPRINTING. 2.USEHI-PERFORMANCEADHESIVEOREQUIVALENT. 3.*REQUIREDON. 4.FORPRINTINGREFERBROMIDENO: +0.02 -0.00 *TRANSPARENTAREA 361070100024 1.5 1.8 3.5 1.75 43.05 43.05

ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89083101 Page 1 FCC ID: LLA-TC4000 EMC TEST REPORT REPORT NO.: F89083101 MODEL NO.: TC4000 Series DATE OF TEST : Aug. 31 ~ Sept. 2, 2000 PREPARED FOR: VXL INSTRUMENTS LIMITED ADDRESS : "HOUSE OF EXCELLENCE", #17, ELECTRONICS CITY, HOSUR ROAD, BANGALORE 561229, INDIA PREPARED BY:ADVANCE DATA TECHNOLOGY CORPORATION 11F, NO.1, SEC.4, NAN-KING EAST RD., TAIPEI, TAIWAN, R.O.C. This test report consists of 16 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of our laboratory. It should not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. government. The test result in the report only applies to the tested sample. Accredited Laboratory ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89083101 Page 2 FCC ID: LLA-TC4000 TABLE OF CONTENTS 1. CERTIFICATION..................................................................................................................3 2. GENERAL INFORMATION ................................................................................................4 2.1GENERAL DESCRIPTION OF EUT .......................................................................4 2.2DESCRIPTION OF SUPPORT UNITS ....................................................................5 2.3TEST METHODOLOGY AND CONFIGURATION...............................................6 3. TEST INSTRUMENTS .........................................................................................................7 3.1TEST INSTRUMENTS (EMISSION).......................................................................7 3.2LIMITS OF CONDUCTED AND RADIATED EMISSION ....................................8 4. TEST RESULTS (EMISSION) ..........................................................................................9 4.1RADIO DISTURBANCE ..........................................................................................9 4.2EUT OPERATING CONDITION .............................................................................9 4.3TEST DATA OF CONDUCTED EMISSION ........................................................10 4.4TEST DATA OF RADIATED EMISSION.............................................................12 5. PHOTOGRAPHS OF THE TEST CONFIGURATION WITH MINIMUM MARGIN .....14 6. APPENDIX - INFORMATION OF THE TESTING LABORATORY ..............................16 ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89083101 Page 3 FCC ID: LLA-TC4000 1. CERTIFICATION Issue Date: Sept. 6, 2000 Product:THINCLIENT Trade Name :VXL Model No.:TC4000 Series Applicant:VXL INSTRUMENTS LIMITED Standard:FCC Part 15, Subpart B, Class B CISPR 22: 1997, Class B ANSI C63.4-1992 We hereby certify that one sample of the designation has been tested in our facility from Aug. 31 ~ Sept. 2, 2000. The test record, data evaluation and Equipment Under Test (EUT) configurations represent herein are true and accurate representation of the measurements of the sample's EMC characteristics under the conditions herein specified. The test results show that the EUT as described in this report is in compliance with the Class B limits of conducted and radiated emission of applicable standards. ADVANCE DATA TECHNOLOGY CORPORATION Accredited Laboratory ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89083101 Page 4 FCC ID: LLA-TC4000 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Product:THINCLIENT Model No.:TC4000 Series Power Supply Type:DC 5V (from power adapter) Power Cord:Nonshielded (1.8m) Data Cable:NA Note: The EUT is a terminal device that connect to multi-user application servers operating under the Citrix MetaFrame, Citrix WinFrame amd Windows NT operating system. It is an aesthetically and ergonomically designed ultra-thin “Bookend” desktop. It provides simultaneously full screen connectivity to Windows NT and UNIX application servers – a powerful business alternative to Users migrating to Win32 applications while continuing access to legacy UNIX applications. It is equipped with a 10/100 Base-T Ethernet port that gives an instant connection to a multi-user Windows NT application server. It also has serial, parallel and video display ports along with PS/2 compatible keyboard and mouse ports, allowing quick setup and use. Its has a 200 MHz National Geode GXLV processor, 32MB SO-DIMM memory (expandable to 128MB). It also has an integrated smart card reader. The EUT was tested with DVE power adapter, model: DSA-0301-05. Its rating: Input: 100-240 Vac 0.7A 47-63 Hz Output: DC +5V, 4.0A This power adapter will be sold together with the EUT. For more detailed features description, please refer to ATTACHMENT 1 - TECHNICAL DESCRIPTION OF EUT and User's Manual. ADVANCE DATA TECHNOLOGY CORPORATION REPORT NO.: F89083101 Page 5 FCC ID: LLA-TC4000 2.2 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories are used to form representative test configuration during the tests. No.ProductBrandModel No.Serial No.FCC ID 121" COLOR MONITOR HPD2846JP74912250FCC DoC APPROVED 2PRINTERHP2225C2923S47245DSI6XU2225 3MODEMACEEX1414980020508IFAXDM1414 4MODEMACEEX1414980020503IFAXDM1414 5PS/2 KEYBOARD FORWARD FDA-104GA FDKB8110111F4ZDA-104G 6USB KEYBOARD BTC7932178190030E5XKBUCP1041 0 7USB MOUSEDEXINA2U800A71001829NIYA2U800A 8MOUSELOGITECHM-S43LZE00703123DZL211106 9SPEAKERJAZZJ-008J786800NA 10 MICROPHONELUDM-535S/NNA 11PERSONAL COMPUTER IBM6560-T7T9983708AN06260F 1221" COLOR MONITOR HPD2846JP74912250FCC DoC APPROVED 13MOUSELOGITECHM-S43LZE00703078DZL211106 14LAN CARDINTELS8255700A0C9A6CB5 252713 EJMNPDSPD035 No. Signal cable description 11.8 m braid shielded wire, terminated with VGA connector via metallic frame, w/o core. 21.2m braid shielded wire, terminated with DB25 and Centronic connector via metallic frame, w/o core. 31.2 m braid s…

Text truncated - open the document above for the full version.
