LMZ-19078BTBluetooth Speaker

Batteries: 9V DC 1.5 x 6 R14 (Size C) (Batteries does not included in the package) Batteries operation: Disconnect the AC adaptor. Insert the batteries 9V DC 1.5 x 6 R14 (Size C) into the battery compartment (Batteries does not included in the package) REMOTE CONTROL STANDBY Press this button to turn the radio on or off MODE MODE press to toggle between the DAB/FM/Bluetooth (BT) and AUX modes INFO INFO In DAB FM mode, while receiving a broadcast signal, press this button to display information about the selected station EQ EQ Press to access the preset equalization or to create a customized one. SCAN SCAN Allows you to run a full scan of the radio in DAB mode. Press to search for the next available station in FM mode Buttons to browse the menu in the various modes.Increases or decreases the frequency in the FM mode, or selects the next or previous DAB station available. PLAY/PAUSE/PAIR During playback via Bluetooth, press to start or pause listening to the associated device. Hold for pairing a Bluetooth device. MENU MENU Press this button to access the menu settings VOLUME + Press to increase the listening volume. VOLUME - Press to decrease the listening volume. MUTE Press this button to select or deselect the mute function. 1/6 2/7 3/8 4/9 5/10 Buttons to store or retrieve the set radio stations (only in DAB and FM modes) ALARM1 & 2 1 Press this button to set the alarm (Alarm 1/Alarm 2) SNOOZE SNOOZE This button has three different functions:1. it stops the alarm when it is active. 2. it sets the dimmability of the LCD when the unit is off (4 levels of brightness). 3. it sets the time interval for repeating the alarm when the unit is on PAIR IMPORTANT The lightning bolt arrow located within an equilateral triangle is intended to alert the user of the presence of non-insulated "dangerous voltage" within the product that may be of suffi cient magnitude to cause electric shock to the user. WARNINGS ABOUT THE USE AND THE OPERATION OF THE UNITWARNING:The main switch does not completely shut off all power from the AC outlet. Since the power cord serves as the main disconnecting device for the unit from the power source, the cord should be unplugged from the AC outlet to shut down all current fl ow. Then, verify that the unit has been installed so as to easily unplug the power cord from the wall outlet, if necessary. In addition, to avoid fi re hazard, the power cord should be unplugged from the AC outlet if the unit is not going to be used for relatively long periods of time (for example, when on vacation). VENTILATION WARNINGInstall the unit ensuring to leave room around it for proper air circulation and for improving heat radiation (at least 10 cm from top, 10 cm from rear, and 10 cm from each side).CAUTION• The product case is equipped with small openings which also serve for ventilation, in order to ensure reliable operation and to protect it from overheating. To prevent fi re hazard, the openings should never be blocked or covered during operation (by objects such as newspapers, tablecloths, curtains, or drapes, etc.) and the device should not be placed on thick carpet or on the bed. • If the plug of the power cord of this unit does not match the AC outlet into which you want to insert the plug itself, it must be replaced with one fi t for the purpose. The replacement of the plug of the power cord must be performed only by qualifi ed service personnel. After replacement, the old plug cut off from the power cord must be properly disposed of, to avoid possible severe electrical shock due to accidental insertion of the plug itself into a live power outlet. If you do not plan to use the unit for a relatively long period (e.g. during a holiday), unplug the power cord from the AC outlet. To avoid the risk of electric shock, do not remove the screws located on the back of the product. There are no parts whose maintenance can be performed by the user. If necessary, contact qualifi ed service personnel. The exclamation point within an equilateral triangle is intended to alert the user of the presence of important operating and maintenance instructions in the literature accompanying the product. ENGLISH ENVIRONMENT AND DISPOSALIt may contain materials which constitute a health and environmental hazard. To prevent harmful materials from being released into the environment, BV Srl provides the following information regarding the disposal and recycling, following the decommissioning of the product.You can give your contribution to the environment by following these simple steps:When you no longer wish to use your electrical and electronic equipment, take it to your local waste disposal facility for recycling.You may return your old equipment to your dealer free of charge when you buy a new product which is equivalent to or has the same functions as the old one. Contact BV Srl to fi nd your local dealer.If you need more information regarding recycling, reuse, and product exchanges, please contact our customer service at the number provided in the manual.Lastly, we suggest further measures to safeguard the environment, such as recycling of internal and external packaging (including the one used for shipping) the product was delivered in. With your help, we can reduce the amount of environmental resources required to manufacture electric and electronic equipment, reduce the use of waste landfi lls for used equipment and, in general, improve our quality of life by ensuring that hazardous materials are correctly disposed of. Incorrect treatment of the product at the end of life and failure to follow the above disposal instructions are punishable under local legislation.CAUTIONThis unit is not waterproof. To prevent fi re or shock hazards, do not place this unit near water-fi lled containers (such as fl ower pots, or similar), and do not expose it to dripping, splashing, rain, or moisture. Waste electrical and electronic materials (WEEE) should never be disposed of in normal urban waste disposal facilities…

Text truncated - open the document above for the full version.

Ocean Star Electronics Limited Unit 7, 3/F., WAH LAI INDUSTRIAL CENTRE, 10-14 KWEI TEI STREET, FO TAN, HK. Tel: (852) 2670 2341Fax: (852) 2798 0858www.os-hk.com Date : 20-8-2014 PHOENIX TESTLAB GmbH Königswinkel 10 D-32825 Blomberg Dear Sirs, Re. : Letter of Appointment This is the letter of authorization to accept our appointment of The Hong Kong Standards and Testing Centre Ltd. Mr. KC Lee as agent for Ocean Star Electronics Limited Address: Unit 7, 3/F., Wah Lai Industrial Centre, 10-14 Kwei Tei Street, Fo Tan, HK to sign applications before the Commission on our behalf, to make representations to you on our behalf, and to receive and exchange data between our company and the Commission in connection with Certification of the following product of Ocean Star Electronics Limited. Product name :DAB+/FM BT Speaker Model:TS522D+ This authorization will expire one year from the date of this letter. Jacky Chan Product Manager

Ocean StarElectronics Limited Unit 7, 3/F., WAH LAI INDUSTRIAL CENTRE, 10-14 KWEI TEI STREET, FO TAN, HK. Tel: (852) 2670 2341Fax: (852) 2798 0858www.os-hk.com Date : 20-Oct-2014 Ocean Star Electronics Limited Unit 7, 3/F., Wah Lai Industrial Centre, 10-14 Kwei Tei Street, Fo Tan, Hong Kong FCC ID:LMZ-19078BT To Whom It May Concern: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Specifically, Ocean Star Electronics Limitedrequests that the following materials be withheld from public inspection under 47CFR0.459 because they are confidential trade secrets and technical data which would be guarded from competitors. (1)detailed circuit schematic of unit under test (2)parts list (3)block diagram (4)Circuit Description Therefore, in accordance with 47CFR Sections 0.457 and 0.459 we request that the above listed materials, copies of which are attached here, be withheld from public inspection. Sincerely, Jacky Chan ProductManager (5)All module specifications (6)All Antenna specifications

LMZ-19078BT PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT LMZ-19078BT PHOTOGRAPH OF THE PRODUCT LEFT VIEW OF THE PRODUCT RIGHT VIEW OF THE PRODUCT LMZ-19078BT PHOTOGRAPH OF THE PRODUCT TOP VIEW OF THE PRODUCT BTTOM VIEW OF THE PRODUCT

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT

STC Test Report Date: 2014-08-21 Page 1 of 90 No.: DM116492 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant : Ocean Star Electronics Ltd. Unit 07, 3/F., Wah Lai Industrial Center, 10-14 Kwei Tei Street, Fo Tan, Hong Kong Manufacturer: Dongguan Ocean Sound Technology Ltd. Dai Hong Industrial Park, Chajiao Village, Zhongtang Zhen, Dongguan City, Guangdong, China. Zip Code:523231 Description of Sample(s): Product: DAB+/FM BT Speaker Brand Name: radio.cubo Model Number: TS522D+ FCC ID: LMZ-19078BT Date Sample(s) Received: 2014-08-11 Date Tested: 2014-08-11 to 2014-08-18 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2013 and ANSI C63.4: 2009 for FCC Certification. Conclusion(s): The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remark(s): --- LONG Yun Jian, Along Authorized Signatory ElectroMagnetic Compatibility Department For and on behalf of STC (Dongguan) Company Limited STC Test Report Date: 2014-08-21 Page 2 of 90 No.: DM116492 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 90 Content Page 2-3 of 90 1.0 General Details 1.1 Test Laboratory Page 4 of 90 1.2 Equipment Under Test [EUT] Page 4 of 90 Description of EUT operation 1.3 Date of Order Page 4 of 90 1.4 Submitted Sample Page 4 of 90 1.5 Test Duration Page 4 of 90 1.6 Country of Origin Page 4 of 90 1.7 RF Module Details Page 5 of 90 1.8 Antenna Details Page 5 of 90 2.0 Technical Details 2.1 Investigations Requested Page 6 of 90 2.2 Test Standards and Results Summary Page 6 of 90 2.3 Table for Test Modes Page 7 of 90 3.0 Test Results 3.1 Emission Page 8 - 83 of 90 STC Test Report Date: 2014-08-21 Page 3 of 90 No.: DM116492 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage Appendix A List of Measurement Equipment Page 84 of 90 Appendix B Ancillary Equipment Page 84 of 90 Appendix C Photographs Page 85- 90 of 90 STC Test Report Date: 2014-08-21 Page 4 of 90 No.: DM116492 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory STC (Dongguan) Company Limited EMC Laboratory 68 Fumin Nan Road, Dalang, Dongguan, Guangdong, China Telephone: (86 769) 81119888 Fax: (86 769) 81116222 1.2 Equipment Under Test [EUT] Description of Sample(s) Product: DAB+/FM BT Speaker Manufacturer: Dongguan Ocean Sound Technology Ltd. Brand Name: radio.cubo Model Number: TS522D+ Rating: 9Vd.c.(Size C battery 1.5V*6 ) / 12.0Vd.c. with Jack The AC/DC adaptor was provided by the applicant with following details:- Brand name: N/A, Model no.: QX30W120200FU; Input: 100-240Va.c. 50/60Hz 0.8A, Output: 12.0Vd.c. 2000mA. 1.2.1 Description of EUT Operation The Equipment Under Test (EUT) is a DAB+/FM BT Speaker of Ocean Star Electronics Ltd. , it is Audio System, modulation by IC; and type is frequency hopping speed spectrum Modulation. 1.3 Date of Order 2014-08-11 1.4 Submitted Sample(s): 1 Sample 1.5 Test Duration 2014-08-11 to 2014-08-18 1.6 Country of Origin China STC Test Report Date: 2014-08-21 Page 5 of 90 No.: DM116492 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.7 RF Module Details Module Model Number: GWB5G_V1.0 Module FCC ID: N/A Module Transmission Type: Bluetooth V2.0+EDR Modulation: FHSS (GFSK / π/4-DQPSK / 8DPSK) Data Rates: 1MBps: GFSK 2 MBps: π/4-DQPSK 3 MBps: 8DPSK Frequency Range: 2400-2483.5MHz Carrier Frequencies: 2402MHz – 2480MHz Module Specification (specification provided by manufacturer) 1.8 Antenna Details Antenna Type: PCB Layout Inverted antenna Antenna Gain: 2dBi STC Test Report Date: 2014-08-21 Page 6 of 90 No.: DM116492 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test r…

Text truncated - open the document above for the full version.

Photographs of EUT FCC ID: LMZ-19078BT Measurement of Radiated Emission Test Set Up Measurement of Radiated Emission Test Set Up Photographs of EUT FCC ID: LMZ-19078BT Measurement of Radiated Emission Test Set Up Measurement of Conducted Emission Test Set Up
