LPT-SCORPIONUsed by Police For Surveillence

March 31, 2003 Applicant: Tektron Micro Electronics Inc. Equipment: FCC ID: LPT-SCORPION EA296277 Reference: Correspondence Number 24983 1) (a) Radiated Power MHz Dbm 907.5 -11.1 915.4 -3 923.65 -9.5 Limit = 50 milliwatts/meter @ 3 m = -13 dbm (b) Radiated Emissions Emission Tuned dbμν CF dbμν/m @ 3m EIRP, dbm EIRP, dbc 1816 907.5 43.0 7.5 335.0 -56.5 ≤ -66.5 2718 907.5 36.0 11.5 237.1 -59.5 ≤ -66.5 3620 907.5 34.0 14.5 266.1 -58.4 ≤ -66.5 4523 907.5 33.0 15.0 251.2 -53.9 ≤ -66.5 5425 907.5 28.0 18.0 199.5 -61.2 ≤ -66.5 6328 907.5 28.0 18.5 211.3 -50.4 ≤ -66.5 7229 907.5 24.0 20.0 158.5 -63.1 ≤ -66.5 8131 907.5 24.0 21.0 177.8 -62.2 ≤ -66.5 9033 907.5 21.0 22.0 141.3 -63.9 ≤ -66.5 1847.3 923.65 42.0 7.5 298.5 -52.8 ≤ -62.8 2770.95 923.65 37.0 11.5 266.1 -58.5 ≤ -62.8 3694.6 923.65 32.0 14.5 211.3 -60.5 ≤ -62.8 4618.25 923.65 33.0 15.2 251.2 -59.0 ≤ -62.8 5541.9 923.65 27.0 18.3 177.8 -62.0 ≤ -62.8 6465.55 923.65 28.0 18.4 211.3 -60.5 ≤ -62.8 7389.2 923.65 23.0 19.9 141.3 -64.0 ≤ -62.8 8312.85 923.65 21.0 21.0 125.9 -65.0 ≤ -62.8 9236.5 923.65 20.0 -21.8 125.9 -65.0 ≤ -62.8 2) Please see 3kHz Power Spectral Density Plots, uploaded to the Test Report Exhibit.

PARTS LIST: PL001059X002 REVISION - TEKTRON MICRO ELECTRONICS, INC. (410-850-4200 - HANOVER, MD) FSCM 6W848 DRAWING: 001059X002 TITLE: ASSEMBLY, PC BOARD, SCORPION TRANSMITTER RF (900 MHz,10 mW) PAGE 2 OF 3 ITEM NO. QTY REQ'D UM M B TEKTRON PART NUMBER REFERENCE DESIGNATIONS FULL DESCRIPTIONNOTES 0011EABPCFAB001059X001FABRICATION, PC BOARD, SCORPION TRANSMITTER RF 0025EABC00104X4020Z16YTC1,C5,C7,C8,C9CAPACITOR, 0.1uF, +80/-20%, 40x20, SOLDER TINNED, Y5V, 16V 0020EAB 0034EABC00153X4020Z16YTC2,C3,C14,C28CAPACITOR, .015uF, +80/-20%, 40x20, SOLDER TINNED, Y5V, 16V 0051EABC002R5X4020B50NTC16CAPACITOR, 2.5pF, +/-.1pF, 40x20, RF/HIGH-Q, NPO, 50V 0062EABC00680X4020J50NTC4,C15CAPACITOR, 68pF, +/-5%, 40x20, SOLDER TINNED, NPO, 50V 0071EABC000R5X4020C50NTC10CAPACITOR, .5pF, +/-.25pF, 40x20, SOLDER TINNED, NPO, 50V 0081EABC002R4X4020B50NTC11CAPACITOR, 2.4pF, +/-.1pF, 40x20, RF/HIGH-Q, NPO, 50V 0091EABC002R7X4020B50NTC12CAPACITOR, 2.7pF, +/-.1pF, 40x20, RF/HIGH-Q, NPO, 50V 0101EABC00336DA260K04TTC13CAPACITOR, 33uF, +/-10%, 120x60, TANT, 4V, PRECISION MOLDED 0112EABC000R3X4020B50RTC16A, C17CAPACITOR, .3pF, +/-.1pF, 40x20, RF/HIGH-Q, NPO, 50V 0122EABC001R8X4020B50RT C20.C25CAPACITOR, 1.8pF, +/-.1pF, 40x20, RF/HIGH-Q, NPO, 50V 0132EABC002R2X4020B50RTC22,C23CAPACITOR, 2.2pF, +/-.1pF, 40x20, RF/HIGH-Q, NPO, 50V 0131EABC00181X6030J50NT C24CAPACITOR, 180pF, +/-5%, 60x30, SOLDER TINNED, NPO, 50V 0141EABC001R5X4020BB0NTC26CAPACITOR, 1.5pF, +/-.1pF, 40x20, RF/HIGH-Q, COG, 25V 0152EABA0101024XHSCDD1,D2DIODE, BBY52-02W, VARACTOR, 1.35pF/3V, SCD-80 PKG (INFINEON) 0172EABA0100454CJL1INDUCTOR, 6.8nH, +/-10%, SMT, 60x30, 0603CS-6N8XKBC (COILCR) 0181EABA0100454APL2, L5INDUCTOR, 82nH, CERAMIC SMT, 80x50, LL2012-F82NK (TOKO) 0191EABA0100454DRL3INDUCTOR, 15nH, +/-2%, SMT, 60x30, 0603CS-15NXGBU (COILCRFT) 0201EABA0100454xxL3AINDUCTOR, 33nH, +/-5%, SMT, 40x20, LL1005-FH33NJ (TOKO) 0211EABA0100454CWL4INDUCTOR, 18nH, +/-5%, SMT, 60x30, 0603CS-18NXJBB (COILCRFT) 0221EABA0100454XBL6INDUCTOR, 9.5nH, +/-2%, SMT, 60x30, 0603CS-9N5XGBC 0231EABA0101199XXS343Q1TRANSISTOR, NE34018, HJ-FET, L TO S BAND, S0T-343 PKG (NEC) 0241EABA0101263XXS343Q2E-PHEMT, ATF-55143, LOW CURRENT/NOISE, SOT-343 PKG (AGILENT) 0251EABR00331X4020J62DTR1RESISTOR, 330 ohm, +/-5%, 40x20, SOLDER TINNED, 62mW 0261EABR00103X4020J62DTR2RESISTOR, 10K, +/-5%, 40x20, SOLDER TINNED, 62mW 0272EABR00431X4020J62DTR3. R5RESISTOR, 430 ohm, +/-5%, 40x20, SOLDER TINNED, 62mW 0281EABR00121X4020J62DTR4RESISTOR, 120 ohm, +/-5%, 40x20, SOLDER TINNED, 62mW 1/8/03 11:50 AM PARTS LIST: PL001059X002 REVISION - TEKTRON MICRO ELECTRONICS, INC. (410-850-4200 - HANOVER, MD) FSCM 6W848 DRAWING: 001059X002 0291EABR00201X4020J62DTR6RESISTOR, 200 ohm, +/-5%, 40x20, SOLDER TINNED, 62mW 0301EABR00472X4020G62DTR7RESISTOR, 4.7K, +/-2%, 40x20, SOLDER TINNED, 62mW PAGE 3 OF 3 ITEM NO. QTY REQ'D UM M B TEKTRON PART NUMBER REFERENCE DESIGNATIONS FULL DESCRIPTIONNOTES 0321EABA0100943BER11POTENTIOMETER, 1M, +/-25%, SMT, EVM-2WSX80B16 (PANASONIC) 0331EABA0100936BZS1SWITCH, BINARY, 8 POS., VERTICAL ADJ., 7744J-1-008E (BOURNS) 0341EABA0101233XXTSOPU1I.C., LMX2316TM, SYNTHESIZER, 1.2 GHz, 16 PIN TSSOP (NATIONAL) 0351EABA0101268XXPSOIU2I.C., PIC12LC508A-04/SN, 8 BIT CMOS MICRO, 8 PIN SOIC (MICR)PGM 0361EABA0100951DQCONNECTOR, SSMC, STR. BULKHEAD, FRT. MNT RECEPT., #4-48 THD 0370GMXA0100775XBINK, MARKING, WHITE (MARKEM 7254) 0380LBXA0100120A6WIRESOLDER, WIRE SN63 0391EAXPCSCH001059X002SCHEMATIC, PC BOARD, SCORPION TRANSMITTER RF (100mW) 0401EAXATP001059X005ACCEPTANCE TEST PROCEDURE, SCORPION TRANSMITTER RF (10mW) 1/8/03 11:50 AM

PARTS LIST: PL001060X001 REVISION - TEKTRON MICRO ELECTRONICS, INC. (410-850-4200 - HANOVER, MD) FSCM 6W848 DRAWING: 001060X001 TITLE: ASSEMBLY, PC BOARD, SCORPION TRANSMITTER DIGITAL PAGE 2 OF 3 ITEM NO. QTY REQ'D UM M B TEKTRON PART NUMBER REFERENCE DESIGNATIONS FULL DESCRIPTIONNOTES 0011EABPCFAB001060X001FABRICATION, PC BOARD, SCORPION TRANSMITTER DIGITAL 0024EABC00684C8050M16TTC1,C2,C3,C4CAPACITOR, .68uF, +/-20%, 80x50, TANTALUM, 16V, .040 MX THK 0033EABC00241X4020J16NTC5,C6,C22CAPACITOR, 240pF, +/-5%, 40x20, SOLDER TINNED, NPO, 16V 0047EABC00224X6030K10XTC8,C9,C10,C11,C14,CAPACITOR, 0.22uF, +/-10%, 60x30, SOLDER TINNED, X5R, 10V 0040EABC00224X6030K10XTC15,C16CAPACITOR, 0.22uF, +/-10%, 60x30, SOLDER TINNED, X5R, 10V 0054EABC00104X4020Z16YTC13,C30,C31,C37CAPACITOR, 0.1uF, +80/-20%, 40x20, SOLDER TINNED, Y5V, 16V 0062EABC00100X4020D50NTC18,C19CAPACITOR, 10pF, +/-.5pF, 40x20, SOLDER TINNED, NPO, 50V 0071EABC00270X4020J50NTC20CAPACITOR, 27pF, +/-5%, 40x20, SOLDER TINNED, NPO, 50V 0081EABC00240X4020J50NTC21CAPACITOR, 24pF, +/-5%, 40x20, SOLDER TINNED, NPO, 50V 0091EABC00680X4020J50NTC23CAPACITOR, 68pF, +/-5%, 40x20, SOLDER TINNED, NPO, 50V 0105EABC00225C8050M04TTC24,C25,C27,C28,CAPACITOR, 2.2uF, +/-20%, 80x50, TANTALUM, 4V, .040 MX THK 0100EABC00225C8050M04TTC29CAPACITOR, 2.2uF, +/-20%, 80x50, TANTALUM, 4V, .040 MX THK 0111EABC00104X6030Z16YTC32CAPACITOR, .1uF, +80/-20%, 60x30, SOLDER TINNED, Y5V, 16V 0121EABC00226XA4A1M16TTC33CAPACITOR, 22uF, +/-20%, 140x110, SOLDER TIN, TANTALUM, 16V 0131EABC00476JA4A1M06TTC34CAPACITOR, 47uF, +/-20%, 140x110, TANTALUM , 6.3V, ESR=0.070 0141EABC00151X4020J50NTC35CAPACITOR, 150pF, +/-5%, 40x20, SOLDER TINNED, NPO, 50V 0151EABC00105X6030Z10YTC36CAPACITOR, 1uF, +80/-20%, 60x30, SOLDER TINNED, Y5V, 10V 0162EABA0101252XXS123D1,D2DIODE, MBR0520LT1, SCHOTTKY PWR RECT, 20V, PLASTIC SOD-123 0171EABA0100454CTL1INDUCTOR, 27uH, +/-20%, SMT, 60x30, LK1608270M (TAIYO YUDEN) 0181EABA0100454CUL2INDUCTOR, 33uH, +/-20%, SMT, 60x30, LK1608330M (TAIYO YUDEN) 0191EABA0100454EDL3INDUCTOR, 47uH, +/-20%, SMT, SHIELDED, DT1608C-473 (COILCRA)1 0203EABR00202X4020J62DTR1,R4,R16RESISTOR, 2K, +/-5%, 40x20, SOLDER TINNED, 62mW 0212EABR00243X4020J62DTR2,R3RESISTOR, 24K, +/-5%, 40x20, SOLDER TINNED, 62mW 0228EABR00104X4020F62DTR5,R6,R7,R8,R11,RESISTOR, 100K, +/-1%, 40x20, SOLDER TINNED, 62mW 0220EABR00104X4020F62DTR18,R22,R23RESISTOR, 100K, +/-1%, 40x20, SOLDER TINNED, 62mW 0232EABR05111X4020F62DTR9,R10RESISTOR, 5.11K, +/-1%, 40x20, SOLDER TINNED, 62mW 0247EABR00102X4020J62DTR12,R20,R21,R24,RESISTOR, 1K, +/-5%, 40x20, SOLDER TINNED, 62mW 0240EABR00102X4020J62DTR25,R26,R27RESISTOR, 1K, +/-5%, 40x20, SOLDER TINNED, 62mW 0251EABA0100943BCR15POTENTIOMETER, 1K, +/-25%, SMT, EVM-2WSX80B13 (PANASONIC) 1/8/03 11:50 AM PARTS LIST: PL001060X001 REVISION - TEKTRON MICRO ELECTRONICS, INC. (410-850-4200 - HANOVER, MD) FSCM 6W848 DRAWING: 001060X001 0261EABR00561X4020J62DTR17RESISTOR, 560 ohm, +/-5%, 40x20, SOLDER TINNED, 62mW 0271EABR08662X4020F62DTR19RESISTOR, 86.6K, +/-1%, 40X20, SOLDER TINNED, 62mW PAGE 3 OF 3 ITEM NO. QTY REQ'D UM M B TEKTRON PART NUMBER REFERENCE DESIGNATIONS FULL DESCRIPTIONNOTES 0281EABR00132X4020J62DTR28RESISTOR, 1.3K, +/-5%, 40x20, SOLDER TINNED, 62mW 0291EABA0101212XX8UMXU1I.C., MAX4252EUA, OP AMP, 8 uMAX PKG (MAXIM) 0301EABA0101196XES235U2I.C., MIC5205-2.5BM5, LINEAR VOLT REG, 2.5V, SOT23-5 (MICRE) 0311EABA0101251XXTSOPU3I.C., AK4550VT, LOW VOLT, A/D & D/A CONV, 16 PIN TSSOP (AKM) 0321EABA0500062U4ALTERED ITEM, FEC CHIP, PROGRAMMED TO A2100110 (CUSTOM) 0331EABA0101249XXSO23U5I.C., MAX6326-UR23T, RESET CIRCUIT, 3 PIN SOT-23 (MAXIM) 0341EABA0101253XXQSOPU6I.C., MAX1684EEE, PWM STEP-DOWN CONVERTER, 16 PIN QSOP (MAX) 0351EABA0100145BJY1CRYSTAL, 16.384 MHz, +/-10ppm, FMXMCS118DDA-16.384M (FREQ.) 0360GMXA0100775XBINK, MARKING, WHITE (MARKEM 7254) 0370LBXA0100120A6WIRESOLDER, WIRE SN63 0380EAXATP001060X001ACCEPTANCE TEST PROCEDURE, SCORPION TRANSMITTER DIGITAL 0390EAXPCSCH001060X001SCHEMATIC, PC BOARD, SCORPION TRANSMITTER DIGITAL NOTES: 1. ITEM NO. 019 - (A0100454ED) L3 - REMAINS AT TEKTRON FOR MANUFACTURING 1/8/03 11:50 AM

PARTS LIST: PL001059X002 REVISION - TEKTRON MICRO ELECTRONICS, INC. (410-850-4200 - HANOVER, MD) FSCM 6W848 DRAWING: 001059X002 ACTIVE DEVICES, PL001059X005 REV -, SCORPION TRANSMITTER RF (900 MHz,10 mW) PCB ITEM NO. QTY REQ'D UM M B TEKTRON PART NUMBER REFERENCE DESIGNATIONS FULL DESCRIPTIONNOTES 0231EABA0101199XXS343Q1TRANSISTOR, NE34018, HJ-FET, L TO S BAND, S0T-343 PKG (NEC) 0241EABA0101263XXS343Q2E-PHEMT, ATF-55143, LOW CURRENT/NOISE, SOT-343 PKG (AGILENT) 0341EABA0101233XXTSOPU1I.C., LMX2316TM, SYNTHESIZER, 1.2 GHz, 16 PIN TSSOP (NATIONAL) 0351EABA0101268XXPSOIU2I.C., PIC12LC508A-04/SN, 8 BIT CMOS MICRO, 8 PIN SOIC (MICR)PGM ACTIVE DEVICES, PL001060X001 REV -, SCORPION TRANSMITTER DIGITAL PCB ITEM NO. QTY REQ'D UM M B TEKTRON PART NUMBER REFERENCE DESIGNATIONS FULL DESCRIPTIONNOTES 0162EABA0101252XXS123D1,D2DIODE, MBR0520LT1, SCHOTTKY PWR RECT, 20V, PLASTIC SOD-123 0291EABA0101212XX8UMXU1I.C., MAX4252EUA, OP AMP, 8 uMAX PKG (MAXIM) 0301EABA0101196XES235U2I.C., MIC5205-2.5BM5, LINEAR VOLT REG, 2.5V, SOT23-5 (MICRE) 0311EABA0101251XXTSOPU3I.C., AK4550VT, LOW VOLT, A/D & D/A CONV, 16 PIN TSSOP (AKM) 0321EABA0500062U4ALTERED ITEM, FEC CHIP, PROGRAMMED TO A2100110 (CUSTOM) 0331EABA0101249XXSO23U5I.C., MAX6326-UR23T, RESET CIRCUIT, 3 PIN SOT-23 (MAXIM) 0341EABA0101253XXQSOPU6I.C., MAX1684EEE, PWM STEP-DOWN CONVERTER, 16 PIN QSOP (MAX) 0351EABA0100145BJY1CRYSTAL, 16.384 MHz, +/-10ppm, FMXMCS118DDA-16.384M (FREQ.) 1/8/03 11:50 AM

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size B Date: 7-Jan-2003 Sheet of File: C:\_1 Acad WIP\_1-Individual Numbers\001059\001059PCFABX005-.DDB Drawn By: PCSCH001059X005 VIN2 DATA IN SCHEMATIC SCORPION TRANSMITTER RF ( 900 MHz, 10mW) 1 OF 1 R. MOYER - R1 330 R2 10K R5 430 C1 0.1uF C10 0.5pF 1248 C S1 ROT SW 8 POS +2.5 V +2.5 V LE 13 Data 12 Clock 11 OSCin 8 GND 9 GND 4 GND 3 CPo 2 fIN 6 fIN 5 CE 10 Vcc2 15 Vcc1 7 Vp 16 FLo 1 Fo/LD 14 U1LMX2316TM +2.5 V + C13 33uF GND 2.048 MHz C2 15nF C11 2.4pF C3 15nF C14 15nF C4 68pF C16 2.5pF C5 .1uF C6 TBD D1 BBY 52-02W D2BBY 52-02W L1 6.8nH L2 82nH L3 15nH Q1 NE34018 R8 TBD R6 200 +2.5 V GP5 2 GP4 3 GP3 4 GP2 5 GP1 6 GP0 7 VSS 8 VDD 1 U2 PIC12LC508A RF OUTPUT G(2) D(4) S1(1) S2(3) G(2) D(4) S1(1) S2(3) Q2 ATF-55143 C7 .1uF C122.7pF C18TBD C80.1uF C19TBD C20 1.8pF C21 TBD L4 18nH L5 82nH L6 9.5nH C22 2.2pF VIN1 C15 68pF R9TBD C232.2pF R11 1M +2.7 V C24 180pF R12 TBD +2.7 V R3 430 C9 0.1uF R13 TBD C25 1.8pF C261.5pF R4 120 R7 4.7K R. MOYER C170.3pF D3 TBD C27 TBD JP1CJP1DJP1EJP1FJP1IJP1GJP1HJP1AJP1B JP2 CHIN1CHIN2CHIN3CHIN4 R15TBD R14TBD +2.5 V C2815nF C29 TBD L3a 33nH C16a 0.3pF JUMPER TO B E PLACED ON PCB SCORPION TRANSMITTER RF (900 MHz, 10mW)

1 2 3 4 56 ABCD 6 5 4 3 2 1 D CBA Title Number Revision Size Orcad B Date: 7-Jan-2003 Sheet of File: C:\_1 Acad WIP\_1-Indi vidual Numbers\trash\001060A.DDB Drawn By: RIGHT MIC 13 Y1 16.384 MHz CX5 CRYSTAL PCSCH001060X001 PRINTED CIRCUIT SCHEMATICDMT-1 TRANSMITTER DIGITAL A JP3B SIGNAL JP3C GND JP3A SUPPLY JP1B SIGNAL JP1C GND JP1A SUPPLY JP4A V OUT 1 JP2A GND JP2B V IN +2.5V A 56 7 +- U1:2 MAX4252EUA +2.5V A Vin 1 GND 2 EN 3 BYP 4 Vout 5 U2MIC5205-2.5BM5 +2.5V D +2.5V A VPP(VCC) 20 VCC 13 PRA 59 DCLK 58 GND 7 GND 47 VCC 53 P_CDATAB 9 CLK 50 MODE 52 SDI 57 PRB 61 P_RESET 56 P_XTLA 44 P_XTLB 41 P_SDATA 51 P_LRCK 45 P_SCLK 43 P_MCLK 46 P_X2048B 14 P_LEFTIN 16 P_RIGHTIN 17 P_NOFRAME 18 P_INVERT 19 P_CDATAA 8 GND 11 U4 A40MX04 JP4I 2.048 MHz GND 1 VCC 3 RESET 2 U5MAX6326_UR23T R12K R2 24K R3 24K R42K R5 100K 1% R9 5.11K 1% R10 5.11K 1% R6 100K 1% R7 100K 1% R8 100K 1% R11 100K1% * R12 1K C5240pF NPO C6240pFNPOC80.22uF X7R C90.22uFX7R C18 10pFNPO C20 27pF NPO C21 27pFNPO C23 68pFNPO C19 10pF NPO + C24 2.2uF TANT + C252.2uF TANT + C27 2.2uFTANT + C282.2uFTANT + C292.2uFTANT LEFT MIC POWER U4 1.13V 14V (MAX) 1.024 MHz WHEN ROUTING PCB MANUALLY CONNECT WHEN ROUTING PCBMANUALLY CONNECT R13 TBD 1% JP4G DATA OUT R14 TBD 1% R151K L127uH L233uH C35 150pFNPO C22 240pF NPO R162K JU2 JU1 R17390 JP2C EXT 1 JP2D EXT 2 TP1DATA TEST + C1 .68uFTANT + C2 .68uFTANT + C3 .68uFTANT + C4.68uF TANT +3.0 - 14 V +2.7 V C11 0.22uFX7R C14 0.22uFX7R C15 0.22uF X7R C160.22uFX7R C13 .1uF Y5V C10 0.22uFX7R D. Sloan 1 1 VCOM 1 AINR 2 AINL 3 VDD 5 VSS 4 SDTI 9 SDTO 8 LRCK 10 MCLK 11 SCLK 12 PWAD 13 PWDA 14 AOUTL 15 AOUTR 16 DEM1 7 DEM0 6 U3AK4550VT JU4 JU3 JP4C CHOUT1 JP4D CHOUT2 JP4E CHOUT3 JP4F CHOUT4 JP2E CHIN1 JP2F CHIN2 JP2G CHIN3 JP2H CHIN4 CVH 1 AIN 2 IN 3 AGND 5 CVL 4 SYNC/PWM 9 CC 8 ILIM/SS 10 STBY 11 BOOT 12 LX 13 LX 14 SHDN 15 PGND 16 FB 7 REF 6 U6 MAX1684EEE + C33 22uF TANT + C34 22uFTANT R18 100K 1% R1982K1% C37 .1uF Y5V C31 .1uF Y5V C32 .1uF Y5V L3 47uH COILCRAFT DT1608C-473 C30 .1uF Y5V +2.5V A +2.5V D +2.5V D +2.5V D +2.5V D +2.5V D +2.5V D +2.5V D +2.5V D +2.5V A 23 1 84 - + U1:1 MAX4252EUA JP4H GND JP4B V OUT 2 +2.5 V 8.192 MHz 32 KHz R22 100K 1% * R24 1K R23 100K 1% * R25 1K +2.5V D R20 1K R21 1K R26 1K R27 1K C36 1uFY5V 1 2 D1MBR0520LT1 R28TBD 1 2 D2 MBR0520LT1

FCC ID: LPT-SCORPION MFA p0310001, d0320004 Date of Report: Date of Submission: February 5, 2003 February 11, 2003 Federal Communications Commission Via: Electronic Filing Attention: Authorization & Evaluation Division Applicant: Tektron Micro Electronics, Inc. Equipment: 4464A-SCORPION FCC ID: LPT-SCORPION FCC Rules: 15.249 Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Morton Flom, P. Eng. enclosure(s) cc: Applicant MF/cva FCC ID: LPT-SCORPION MFA p0310001, d0320004 LIST OF EXHIBITS (FCC CERTIFICATION (TRANSMITTERS) - REVISED 9/28/98) APPLICANT: Tektron Micro Electronics, Inc. FCC ID: LPT-SCORPION BY APPLICANT: 1. LETTER OF AUTHORIZATION x 2. IDENTIFICATION DRAWINGS x LABEL x LOCATION OF LABEL x COMPLIANCE STATEMENT x LOCATION OF COMPLIANCE STATEMENT 3. DOCUMENTATION: 2.1033(b) (3) USER MANUAL x (4) OPERATIONAL DESCRIPTION x (5) BLOCK DIAGRAM x (5) SCHEMATIC DIAGRAM x (7) PHOTOGRAPHS x BLOCK DIAGRAM x PARTS LIST x ACTIVE DEVICES x BY M.F.A. INC. A. TESTIMONIAL & STATEMENT OF CERTIFICATION B. STATEMENT OF QUALIFICATIONS FCC ID: LPT-SCORPION MFA p0310001, d0320004 T R A N S M I T T E R C E R T I F I C A T I O N of FCC ID: LPT-SCORPION MODEL: 4464A-SCORPION to FEDERAL COMMUNICATIONS COMMISSION Rule Part(s) 15.249 DATE OF REPORT: February 5, 2003 ON THE BEHALF OF THE APPLICANT: Tektron Micro Electronics, Inc. AT THE REQUEST OF : P.O. Letter 01/06/2003 Tektron Micro Electronics, Inc. 7483B Candlewood Road Hanover, MD 21076 Attention of: (410) 850-4200; FAX: -4209 Bill Heineman [email protected] and/or Bill Meyn [email protected] SUPERVISED BY: Morton Flom, P. Eng. FCC ID: LPT-SCORPION MFA p0310001, d0320004 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21 INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a) SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: LPT-SCORPION MFA p0310001, d0320004 TABLE OF CONTENTS RULE DESCRIPTION PAGE . Test Report 1 2.1033(c) General Information Required 2 . Standard Test Conditions and Engineering Practices 6 2.1053(a) Field Strength of Spurious Radiation 8 2.1049(c)(1) Emission Masks (Occupied Bandwidth) 14 15.207 A/C Powerline Conducted Emissions 18 FCC ID: LPT-SCORPION MFA p0310001, d0320004 PAGE NO. 1 of 21. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a) TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number: d0320004 d) Client: Tektron Micro Electronics, Inc. 7483B Candlewood Road Hanover, MD 21076 e) Identification: 4464A-SCORPION FCC ID: LPT-SCORPION Description: Low Power Transceiver for Law Enforcement f) EUT Condition: Not required unless specified in individual tests. g) Report Date: February 5, 2003 EUT Received: January 02, 2003 h, j, k): As indicated in individual tests. i) Sampling method: No sampling procedure used. l) Uncertainty: In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results: The results presented in this report relate only to the item tested. o) Reproduction: This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: LPT-SCORPION MFA p0310001, d0320004 PAGE NO. 2 of 21. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 15.249 Sub-part 2.1033 (c)(1): NAME AND ADDRESS OF APPLICANT: Tektron Micro Electronics, Inc. 7483B Candlewood Road Hanover, MD 21076 MANUFACTURER: Tektron Micro Electronics, Inc. 7483 Candlewood Road Hanover, MD 20874 (c)(2): FCC ID: LPT-SCORPION MODEL NO: 4464A-SCORPION (c)(3): INSTRUCTION MANUAL(S): PLEASE SEE ATTACHED EXHIBITS (c)(4): TYPE OF EMISSION: 1M88F1D (c)(5): FREQUENCY RANGE, MHz : 902 to 928 (c)(6): POWER RATING, Watts: 10 mw Switchable Variable x N/A (c)(7): MAXIMUM POWER RATING, Watts: 50 mv/m @ 3m 15.203: ANTENNA REQUIREMENT: x The antenna is permanently attached to the EUT The antenna uses a unique coupling The EUT must be professionally installed The antenna requirement does not apply FCC ID: LPT-SCORPION MFA p0310001, d0320004 PAGE NO. 3 of 21. Subpart 2.10…

Text truncated - open the document above for the full version.

FCC ID: LPT-SCORPION MFA p0310001, d0320004 TEST SETUP : Radiated Emissions FCC ID: LPT-SCORPION MFA p0310001, d0320004 TEST SETUP : Radiated Emissions FCC ID: LPT-SCORPION MFA p0310001, d0320004 TEST SETUP : A/C Powerline Conducted Emissions
