LU9253976PTX27RC Toy Transmitter

TO INSTALL/REPLACE BATTERIES IN MOTOR SCOOTER 1. The battery compartment is located on the bottom of the Scooter. Slide the switch to "OFF" position. Loosen the screw on battery compartment door with a Phillips screwdriver and remove door. (see Fig.A, B) 2. Install / Replace with 5 "AA" batteries. Replace battery compartment door and tighten screw. (see Fig.C) 0402-0 Ages 6 & up Please keep this manual. It contains important INTRODUCTION Motor Scooter Samantha is the fully articulated doll that rides her motor Scooter via a special remote control-shaped like a Motor Scooter. You can also remove Scooter Samantha (the Doll) from her Scooter and play with her separately! She looks great in her bike outfit! When she's back on her Motor Scooter, ahe turns her handlebars by your control. She comes with a detachable helmet for looking her best and staying safe on and off her Motor Scooter. INSTALLATION OF BATTERIES Fig. B Battery compartment on bottom of scooter Fig. C Insert 5 "AA" batteries Operating Instructions Fig. A On/Off switch on the bottom of scooter. LIMITED 90 DAY WARRANTY MGA Entertainment warrants to the original consumer purchaser this product that the product will be free from defects in material or workmanship for a period of 90 days from the date of original purchase. This warranty does not cover damages resulting from misuse, improper or abnormal usage, negligence, leaking batteries, improper service or other causes not arising from defects in material or workmanship. During this 90 day warranty period, the product will be either repaired or replaced (at MGA's option) at no charge to the purchaser, when returned to either the retailer with it's original sales receipt (containing date of purchase) or to MGA. The foregoing states the purchaser's sole and exclusive remedy for any breach of warranty with respect to the product. All product returned to MGA must be shipped prepaid and insured for loss or damage to: MGA Entertainment Repair Department 16730 Schoenborn Street North Hills, CA 91343-6122 Any returned product should be carefully packed in packing material sufficient to avoid damage during shipment. Please include a written description of the defect, a copy of the original sales receipt (containing date of purchase) and your printed name, address and telephone number. Some states do not allow limitations on how long an implied warranty last or the exclusion of incidental or consequential damages, so the above limitations may not apply to you. This warranty gives you specific rights and you may also have other rights which vary from state to state. This warranty is only valid within the United States and Canada. TO INSTALL/REPLACE BATTERIES IN REMOTE CONTROL 1. The battery compartment is located on the bottom of the controller. Turn the switch to "OFF" position. Loosen screw on battery compartment door with a Phillips screwdriver and remove door. (see Fig.D, E) 2. Install / Replace with a 9V battery. Replace battery compartment door and tighten screw. (see Fig.F) Fig. F Insert 1 "9V" battery Fig. E Battery compartment on bottom of R/C Fig. D On/Off switch on the bottom of the R/C TM, ® & © 2002 MGA Entertainment All Rights Reserved. 16730 Schoenborn Street North Hills, CA 91343 USA (818) 894-2525 PRINTED IN CHINA 1.5V AA/LR6 1.5V AA/LR6 1.5V AA/LR6 1.5V AA/LR6 1.5V AA/LR6 6LR61 006P 9V 6LR61 006P 9V 1 4

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT REAR VIEW OF THE PRODUCT

FCC ID: LU9253976PTX27 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC ID: LU9253976PTX27 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Made in China FCC ID label for item 253976P, 27 MHz Transmitter

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW INNER CIRCUIT BOTTOM VIEW

FCC ID: LU9253976PTX27 Circuit Description The 27.145MHz crystal oscillator drives the base of Q2 the final/buffer amplifier. The modulation provided by IC1 S8P602H. The output of Q2 has the matching network consisting of L1 and C7 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source There is no external antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 9 Volt (“6F22” size battery x 1) primary battery

Date: 2002-06-21 TEST REPORT Page 1 of 20 No.: HM108059 FCC PART 15 SUBPART C CERTIFICATION REPORT FOR LOW POWER TRANSMITTER TEST REPORT No.:HM108059 Equipment Under Test [EUT]:Motor Scooter Samantha Model Number:253976PTX27 Applicant:MGA Entertainment (HK) Ltd. FCC ID :LU9253976PTX27 Date: 2002-06-21 TEST REPORT Page 2 of 20 No.: HM108059 CONTENT: Cover Page 1 of 20 Content Page 2-3 of 20 Conclusion Page 4 of 20 1.0General Details 1.1Test Laboratory Page 5 of 20 1.2Applicant Details Page 5 of 20 Applicant HKSTC Code Number for Applicant Manufacturer 1.3Equipment Under Test [EUT] Page 6 of 20 Description of EUT operation 1.4Date of Order Page 6 of 20 1.5Submitted Sample Page 6 of 20 1.6Test Duration Page 6 of 20 1.7Country of Origin Page 6 of 20 1.8 Additional Information of EUT Page 7 of 20 2.0Technical Details 2.1Investigations Requested Page 8 of 20 2.2Test Standards and Results Summary Page 8 of 20 3.0Test Results 3.1Emission Page 9-13 of 20 3.2Bandwidth Measurement Page 14-15 of 20 Date: 2002-06-21 TEST REPORT Page 3 of 20 No.: HM108059 Appendix A List of Measurement Equipment Page 16 of 20 Appendix B Duty Cycle Correction During 100 msec Page 17-18 of 20 Appendix C Photographs Page 19-20 of 20 Date: 2002-06-21 TEST REPORT Page 4 of 20 No.: HM108059 CONCLUSION The submitted product was deemed to have COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Verify byPatrick Wong for Chief Executive Date: 2002-06-21 TEST REPORT Page 5 of 20 No.: HM108059 1.0General Details 1.1Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone:852 2666 1888 Fax:852 2664 4353 1.2Applicant Details Applicant MGA ENTERTAINMENT (HK) LTD. Room 1001, 10/F., Empire Centre, 68 Mody Road, Tsimshatsui East, Kowloon, Hong Kong. Telephone:852 2732 9220 Fax:852 2312 0101 HKSTC Code Number for ApplicantMGE001 Manufacturer EARLY LIGHT INDUSTRIAL CO., LTD. No. 9, Ka Fu Close, Sheung Shui, New Territories Telephone:852 2493 8267 Fax:852 2413 6147 Date: 2002-06-21 TEST REPORT Page 6 of 20 No.: HM108059 1.3Equipment Under Test [EUT] Description of Sample Product:Motor Scooter Samantha Manufacturer:Early Light Industrial Co., Ltd. Brand Name:MGA Model Number:253976PTX27 Input Voltage:9Vd.c (“6F22” size battery x 1) 1.3.1Description of EUT Operation The Equipment Under Test(EUT) is an MGA Entertainment (HK) Ltd., Motor Scooter Samantha. The transmitter is a 2 button transmitter. The EUT continues to transmit while button is being pressed. It is voice transmission, Modulation by Mic. and tape is frequency modulation. 1.4Date of Order 2002-06-13 1.5Submitted Sample(s): 1 Sample per model 1.6Test Duration 2002-06-20 1.7Country of Origin China Date: 2002-06-21 TEST REPORT Page 7 of 20 No.: HM108059 1.8Additional Information of EUT SubmittedNot Available User Manual Part List Circuit Diagram Printed Circuit Board [PCB] Layout Block diagram FCC ID Label Date: 2002-06-21 TEST REPORT Page 8 of 20 No.: HM108059 2.0Technical Details 2.1Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15 and ANSI C63.4:2000 for FCC Certification. 2.2Test Standards and Results Summary Tables EMISSION Results Summary Test ConditionTest RequirementTest MethodClass /Test Result SeverityPassFailedN/A Field Strength of Fundamental Emissions & Spurious Emissions FCC 47CFR 15.227ANSI C63.4:2000N/A Radiated Emissions, 30MHz to 1GHz FCC 47CFR 15.209ANSI C63.4:2000Class B Conducted Emissions on AC, 0.45MHz to 30MHz FCC 47CFR 15.207ANSI C63.4:2000Class B Note: N/A - Not Applicable Date: 2002-06-21 TEST REPORT Page 9 of 20 No.: HM108059 3.0Test Results 3.1Emission 3.1.1Radiated Emissions Test Requirement:FCC 47CFR 15.227 Test Method:ANSI C63.4:2000 Test Date:2002-06-20 Mode of Operation:On mode Test Method: The sample was placed 0.8m above the ground plane on the OATS *. Measurements in both horizontal and vertical polarities were performed. During the test, each emission was maximized by: having the EUT continuously working, investigate all operating modes, rotated about all 3 axis (X, Y & Z) to obtain worst position, manipulating interconnecting cables, rotating turntable, varying antenna height from 1m to 4m in both horizontal and vertical polarizations. The emissions worst-case are shown in Test Results of the following pages. *:OATS [Open Area Test Site] located at HKSTC with a metal ground plane on filed with the FCC pursuant to section 2.948 of the FCC rules, with Registration Number: 90657. Test Setup: EUT distance = 3m Pre -Amplifier Receiver Turn Table Computer Ground plane Date: 2002-06-21 TEST REPORT Page 10 of 20 No.: HM108059 Limits for Field Strength of Fundamental Emissions [FCC 47CFR 15.227]: Frequency Range of Fundamental Field Strength of Fundamental Emission [Peak] Field Strength of Fundamental Emission [Average] [MHz][μV/m][μV/m] 26.96-27.28100,00010,000 Results: FrequencyCorrectionLimit @3mAntenna FactorPolarity MHzdB μ V/m μ V/m 27.1549.318.267.52,371.4100,000Vertical dB μ V/m Field Strength Field Strength of Fundamental Emissions Peak Value Measured Level @3m dB μ V/m Field Strength μ V/m FrequencyCorrectionLimit @3mAntenna FactorPolarity MHzdB μ V/m μ V/m 27.1542.318.260.51,059.3100,00Vertical μ V/mdB μ V/m Field Strength Field Strength of Fundamental Emissions Average Measured Level @3m dB μ V/m Field Strength According to FCC 47CFR15.35, the limit on the radio frequency emissions as measured using instrumentation with a peak detector function, corresponding to 20dB above the maximum permitted average limit for the frequency being investigated unless a different peak emission limit is otherwise specified in the rules. Remarks: *: Adjusted by Duty Cycle = -7dB *:Linear interpolations C…

Text truncated - open the document above for the full version.

TEST SET UP PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
