LU9365488Bratz Movie Theme Rock Star Headset (Transmitter)

Item no. 365488 www.bratz.com TM & © MGA Entertainment, Inc. BRATZ™, BRATZ PETZ™, LIL’ BRATZ™, BRATZ BABYZ™, BRATZ KIDZ™ and all related logos, names, characters, distinctive likenesses and slogans, as well as the packaging and images appearing thereon, are the exclusive property of MGA. 16300 Roscoe Blvd. Van Nuys, CA 91406 USA (800) 222-4685 Printed in China. 0507-0-E The preferred method of contact for Customer Service is through our e-mail contact form at www.mgae.com Please keep this manual as it contains important information. FCC Compliance NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Modifications not authorized by the manufacturer may void users authority to operate this device. Look and sound like a rock star with this awesome headset microphone! Just attach your MP3 player to the transmit module and hook it to your belt. Both your MP3 player’s music and your voice will come out through the radio together! Sing along with your fav MP3’s and belt it out like the pros! FCC STATEMENT 14 AGES 4+ ADULT BATTERY INSTALLATION REQUIRED. ‘Let’s care for the environment!’ The wheelie bin symbol indicates that the product must not be disposed of with other household waste. Please use designated collection points or recycling facilities when disposing of the item. INTRODUCTION CONTENTS • 1 Bratz Movie Headset Boom Mic • 1 Audio Cable • 1 Microphone Transmit Module with the following parts: a) MP3 Player Holder b) On/Off Switch c) Microphone Volume Dial d) MP3 Player Volume Dial e) Headphone Cord Jack f) Audio Input Jack g) Antenna h) Belt Clip NOTE: MP3 Player and FM radio not included. MP3/audio in Microphone volume decrease MP3/audio in volume decrease MP3/audio in volume increase Microphone volume increase Bottom Front Headset in On/Off Switch 11. Turn On your MP3 Player and play your favorite music track. You will hear it through the radio! 12. Talk through your headset microphone and your voice will also come through the radio! 13. Turn the Microphone Volume Dial clockwise and the MP3/Audio In volume counter-clockwise until both are at a comfortable listening level. (Fig. 3). 14. Now you can sing into your microphone and you will hear your voice through the radio along with music from your MP3 Player! Rock on! • Your FM Microphone has been fully tested and adjusted prior to shipment. Do not attempt to touch, replace or service any of components inside. • After use, turn your microphone OFF to save the batteries. • Use alkaline batteries for best performance and longer life • Use only the type battery recommended for the unit. • Batteries should be replaced only by an adult. • Insert batteries with the correct polarity ( + and – ). • Do not mix different types of batteries or old and new batteries. • Do not short-circuit batteries. • When not used for an extended time, remove batteries to prevent possible leakage and damage to the unit. • Do not mix rechargeable and non-rechargeable batteries. • Rechargeable batteries are to be removed from the toy before charging. • Rechargeable batteries are to be recharged only under adult supervision. • Do not recharge non-rechargeable batteries. • Exhausted batteries are to be removed from the toy. • Do not dispose of batteries in fire as they may leak or explode. NOTE: The voltage of a fully-charged, rechargeable battery is often lower than that of a fresh alkaline battery. Therefore, it is recommended that alkaline batteries be used instead of rechargeable batteries for best performance and for longest play time. • If the microphone’s transmission begins to weaken, replace the batteries. • Under an environment with electrostatic discharge, this product may malfunction and require user to reset the unit by changing the batteries. 5. Clip the Transmit Module to your belt or waistband. 6. Place the Headset on your head and adjust it to fit. (Fig. 2). NOTE: This FM Wireless Microphone operates at approximately 100Mhz and will transmit your voice and MP3 Player through any FM radio. 7. On the Transmit Module, turn the On/Off Switch to ON. 8. Turn on a nearby radio (not included) and select the FM band. 9. Tune your radio to 100MHz. If there is a radio station at 100MHz with a strong signal, it may overpower your microphone. If so, move the tuner slightly to either side of 100 (99.9 or 100.1). 10. Hold your headset microphone close to the radio while your radio is tuned to about 100MHz 1. Attach your MP3 Player (not included) to the Holder on the side of the Transmit Module. NOTE: If your MP3 Player does not fit in the holder, you can clip it to your belt or place it in a pocket. 2. Attach the Audio Cable to the Headphone jack in your MP3 Player. 3. Attach the other end of …

Text truncated - open the document above for the full version.

Jennifer Sanchez Inquiry: ---Reply from Customer on 07/12/2007--- Response: Based on the test report, this device is acceptable for Certification. Do not reply to this message. Please select the Reply to an Inquiry Response link from the OET Inquiry System to add any additional information pertaining to this inquiry. From: Generic Office of Engineering Technology [[email protected]] Sent: Mon 7/23/2007 11:35 AM To: Jennifer Sanchez Cc: Subject: Response to Inquiry to FCC (Tracking Number 570431) Attachments: Page 1 of 1 7/23/2007https://metlabs.com/exchange/jsanchez/Inbox/Response%20to%20Inquiry%20to%20FCC...

PHOTOGRAPH OF THE PRODUCT FRONT VIEW OF THE PRODUCT PHOTOGRAPH OF THE PRODUCT REAR VIEW OF THE PRODUCT

FCC ID: LU9365488 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT TOP VIEW PHOTOGRAPH OF THE PRODUCT INNER CIRCUIT BOTTOM VIEW

FCC ID: LU9365488 Circuit Description The RLC oscillator drives the base of Q1 the final/buffer amplifier. The modulation provided by IC. The output of Q1 has the matching network consisting of L4, L5 and C9, C10, C12 that limit the harmonic content and effect the proper coupling of the antenna to the output stage. Antenna, Ground and Power Source The antenna consists of a 3.5 cm long Metal antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 3 Volt (“AAA” size battery x 2) primary battery Operation Descriptions The transmitter is a voice transmitter operating at 100.1MHz band. The transmitter is powered by a 3V battery (“AAA” size battery x 2) and the transmitting frequency is crystal controlled. The operation is achieved by different combinations of form pulse modulating signal on the 100.1 MHz carrier frequency. Remarks: The transmitter is a 1 button transmitter. The EUT continues to transmit while button is being pressed. It is button transmitter, Modulation by IC; and type is Frequency modulation.

ItemStandardQuantityLocationParameterNote PCB365488R21PCS CEM-1 AU 45.5*57*1.6mm PCBCK-R11PCS CEM-1 CU 20*12*1.6mm ICHT92741PCSU1SOP-14 Chip Cap1UF/50V4PCSC1-C4 Error margin5% SMD 0603 Chip Cap10PF/50V2PCSC5/C6 Error margin5% SMD 0603 Chip Cap100PF/50V1PCSC7 Error margin5% SMD 0603 Chip Cap30PF/50V1PCSC8 Error margin5% SMD 0603 Chip Cap33PF/50V1PCSC15 Error margin5% SMD 0603 Chip Cap3PF/50V1PCSC9 Error margin5% SMD 0603 Chip Cap10PF/50V1PCSC10 Error margin5% SMD 0603 Chip Cap104PF/50V3PCS C13/C17/C16 Error margin5% SMD 0603 Chip Cap47PF/50V1PCSC14 Error margin5% SMD 0603 Chip Diode1N4148 1/2W2PCSD1/D2SMD 1206 Audio-jackCK-3.5-012PCSDC1/DC2 Mini E.Cap10UF/6.3V4PCSE1-E4 Error margin5% Mini E.Cap100UF/10V1PCSE5 Error margin5% Ship SwitchRS-11221PCSK1 Color Inductance1.5UH/EC241PCSL4 Pillar Inductance5.5T1PCSL2 Color Inductance0.56UH/EC241PCSL1 Chip TransistorR251PCSQ1SOT-23 Chip TransistorKEY1PCSQ2SOT-23 Chip Transistor90141PCSQ3SOT-23 Chip TransistorKIY3PCSQ4/Q5/Q6SOT-23 Chip Resistor15K1PCSR4 Chip Resistor100K1PCSR11 Error margin5% SMD 0603 Chip Resistor1.2K2PCSR1/R2 Error margin5% SMD 0603 Chip Resistor100K4PCSR3/R5/R6 Error margin5% SMD 0603 Chip Resistor620K1PCSR8 Error margin5% SMD 0603 FORM NOPE0006 REV0 Autited ByApproved BOM Remarks Prepared By FIEL NOPEWI 00451 REVISION1 PAGE1 OF 3 DATE2007/05/09 PRODUCT NAME365488Bratz Rock Star Headset PRODUCT NO365488 NAME OF PART Mainboard COMPANYMGA Entertainment (H.K.) Ltd. ItemStandardQuantityLocationParameterNote Chip Resistor10K1PCSR9 Error margin5% SMD 0805 Chip Resistor180K2PCSR12 Error margin5% SMD 0805 Chip Resistor120K1PCSR13 Error margin5% SMD 0603 Chip Resistor20K1PCSR14 Error margin5% SMD 0603 Chip Resistor33K1PCSR15 Error margin5% SMD 0603 Chip Resistor560K1PCSR16 Error margin5% SMD 0603 Chip Resistor10K2PCSR17/R24 Error margin5% SMD 0603 Chip Resistor470R2PCSR19/R20 Error margin5% SMD 0603 Chip Resistor47K1PCSR21 Error margin5% SMD 0603 Chip Resistor180R1PCSR22 Error margin5% SMD 0603 Chip Resistor0R1PCSR23 Error margin5% SMD 0603 Chip Resistor620K1PCSR7 Error margin5% SMD 0805 Chip Resistor1.2K1PCSR10 Error margin5% SMD 0805 Chip Resistor0R1PCSR0 Error margin5% SMD 0805 Chip ResistorWH9011-1 50K 1PCSVR2 Error margin5% Chip ResistorWH9011-1 10K1PCSVR1 Error margin5% Jump-lead3+11+3mm1PCS11mm Jump-lead3+5.5+3mm1PCS6.5mm Pin Wire3P 3+55+3mm1PCS MP3/-1.5V/MI Red Lead Wire UL 28# 3+90+3mm 1PCS+1.5V Black Lead Wire UL 28# 3+140+3mm 1PCS-1.5V Black Lead Wire UL 28# 3+40+3mm 1PCSLED- Black Lead Wire UL 28# 3+100+3mm 1PCS-1.5V Orange Lead Wire UL 28# 3+120+3mm 1PCSGND Yellow Lead Wire UL 28# 3+110+3mm 1PCSLED+ White LED 5AR3SCOO-B 5mm 1PCSLED1 A780mm0.6mm3.5mm0.3mm 1PCSRF Headphone MicrophoneMHR-2631PCS Chip Cap1UF/50V1PCSC11 Error margin5% SMD 0603 FORM NOPE0006 REV0 B.O.M Remarks 1 2 OF 2 2007/03/30 FIEL NOPEWI 00451 REVISION1 PAGE2 OF 3 ATE2007/05/09 PRODUCT NAME365488Bratz Rock Star Headset PRODUCT NO365488 NAME OF PART Mainboard COMPANYMGA Entertainment (H.K.) Ltd. Prepared ByAutited ByApproved ItemStandardQuantityLocationParameterNote Chip Inductance100R3PCSL1/L2/L3 Error margin5% SMD 0603 Chip Cap12PF1PCSC12 Error margin0.25PF SMD 0603 InductanceEC 24 1.8uH1PCSL5 Chip Resistor800R1PCSR01 Error margin5% SMD 0603 Chip Resistor2.2R1PCSR23 Error margin5% SMD 0603 FORM NOPE0006 REV0 Prepared ByAutited ByApproved B.O.M Remarks 1 2 OF 2 2007/03/30 PRODUCT NAME365488Bratz Rock Star Headset PRODUCT NO365488 NAME OF PART Mainboard COMPANYMGA Entertainment (H.K.) Ltd. FIEL NOPEWI 00451 REVISION1 PAGE3 OF 3 ATE2007/05/09

FCC ID: LU9365488 Antenna, Ground and Power Source The antenna consists of a 3.5 cm long metal antenna. There is no external ground connection. The ground is only that of the printed circuit board. Electric current is supplied by a 3 Volt (“AAA” size battery x 2) primary battery Antenna

1234 A B C D 4321 D C B A Revision File Name File No Page Prepared By Autited By Approved Date OF COMPANY 365488 2007/05/24 PEWI00451 MGA Entertainment (H.K.) Ltd. 1 11 365488Bratz Rock Star Headset Product No 1OUT 1 1IN- 2 1IN+ 3 VDD 4 2IN+ 5 2IN- 6 2OUT 7 3OUT 8 3IN- 9 3IN+ 10 VSS 11 4IN+ 12 4IN- 13 4OUT 14 U1 HT9274 DC1 DC2 C1 1UF C2 1UF R1 1.2K R2 1.2K VR1 10K C3 1UF C5 10PF R3100K C13 104PF R9 10K R5 100K +1.5V R16 560K C7100PF +1.5V VR2 50K -1.5V R6100K C4 1UF C6 10PF R8 620K R12 180K R13 120K -1.5V R7 620K R14 20K R15 91K E1 10UF/6.3V E2 10UF/6.3V R21 47K R19 470R R20 470R R22 180R E5 100UF/10V Q3 9014 Q2 KEY Q4 KIY D1 1N4148 D2 1N4148 +1.5V -1.5V -1.5V R4 15K L1 0.56UH L4 1.5UH C8 30P C9 3P Q1 R25 -1.5V +1.5V C10 10PF C14 47PF L2 5.5T E3 10UF/6.3V E4 10UF/6.3V +1.5V -1.5V 365488 Bratz Rock Star Headset Circuit Diagram Q5 8550 Q6 8550 R24 10K R17 10K K1 VCC C15 33PF R10 470R LED1 VCC R11 100K R23 2.2R V1 R0 0R R02 0R R03 0R 1 2 3 Headphone Microphone plug Microphone input Headphone Output -1.5V Headphone electret condenser C11 1uF * * L5 1.8uH C12 22PF C16 104PF R01 820R C17 104PF L3 100R L7 100R L6 100R

Prepared By Autited By Approved Date2007/05/09 CompanyMGA Entertainment (H.K.) Ltd. File NoPEWI00451 Page1 OF 1 TitaleMainboard MaterialCEM-1 AU 1.6mm Revision1 LayerTOP Routing File Name365488 Bratz Rock Star HeadsetProduct No365488

STC Test Report Date : 2007-06-20 Page 1 of 16 No. : HM158803 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from the Hong Kong Standards and Testing Centre Ltd. For full text of “Conditions of Issuance of Test Report”, please refer to overleaf or refer to the website of Homepage. Applicant (MGE001) MGA Entertainment (H.K.) Ltd. 9 th Floor, Tower 6, The Gateway, Harbour City, 9 Canton Road, Tsimshatsui, Kowloon, Hong Kong. Manufacturer: N/A Description of Samples: Product: Bratz Movie Theme Rock Star Headset – Transmitter Brand Name: N/A Model Number: 365488 FCC ID: LU9365488 Date Samples Received: 2007-05-15 Date Tested: 2007-05-22 to 2007-05-29 Investigation Requested: Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2006 and ANSI C63.4:2003 for FCC Certification. Conclusions: The submitted product COMPLIED with the requirements of Federal Communications Commission [FCC] Rules and Regulations Part 15. The tests were performed in accordance with the standards described above and on Section 2.2 in this Test Report. Remarks: --- LEE Kam Chuen, ElectroMagnetic Compatibility Department For and on behalf of The Hong Kong Standards and Testing Centre Ltd. STC Test Report Date : 2007-06-20 Page 2 of 16 No. : HM158803 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage CONTENT: Cover Page 1 of 16 Content Page 2-3 of 16 1.0 General Details 1.1 Test Laboratory Page 4 of 16 1.2 Applicant Details Page 4 of 16 Applicant HKSTC Code Number for Applicant Manufacturer 1.3 Equipment Under Test [EUT] Page 5 of 16 Description of EUT operation 1.4 Date of Order Page 5 of 16 1.5 Submitted Samples Page 5 of 16 1.6 Test Duration Page 5 of 16 1.7 Country of Origin Page 5 of 16 2.0 Technical Details 2.1 Investigations Requested Page 6 of 16 2.2 Test Standards and Results Summary Page 6 of 16 3.0 Test Results 3.1 Emission Page 7-10 of 16 3.2 Bandwidth Measurement Page 11-12 of 16 3.3 Operation Description Page 13 of 16 STC Test Report Date : 2007-06-20 Page 3 of 16 No. : HM158803 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage Appendix A List of Measurement Equipment Page 14 of 16 Appendix B Photographs Page 15-16 of 16 STC Test Report Date : 2007-06-20 Page 4 of 16 No. : HM158803 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.0 General Details 1.1 Test Laboratory The Hong Kong Standards and Testing Centre Ltd. EMC Laboratory 10 Dai Wang Street, Taipo Industrial Estate New Territories, Hong Kong Telephone: 852 2666 1888 Fax: 852 2664 4353 1.2 Applicant Details Applicant MGA Entertainment (H.K.) Ltd. 9 th Floor, Tower 6, The Gateway, Harbour City, 9 Canton Road, Tsimshatsui, Kowloon, Hong Kong. Manufacturer N/A STC Test Report Date : 2007-06-20 Page 5 of 16 No. : HM158803 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 1.3 Equipment Under Test [EUT] Description of Sample Model Name: Bratz Movie Theme Rock Star Headset – Transmitter Manufacturer: N/A Brand Name: N/A Model Number: 365488 Input Voltage: 3Vd.c. (“AAA” size battery x 2) 1.3.1 Description of EUT Operation The Equipment Under Test (EUT) is a MGA Entertainment (H.K.) Ltd., Bratz Movie Theme Rock Star Headset – Transmitter. The transmitter is a 1 button transmitter. The EUT continues to transmit while button is being pressed, Modulation by IC. and type is frequency modulation. 1.4 Date of Order 2007-05-15 1.5 Submitted Sample(s): 1 Sample 1.6 Test Duration 2007-05-22 to 2007-05-29 1.7 Country of Origin N/A STC Test Report Date : 2007-06-20 Page 6 of 16 No. : HM158803 The Hong Kong Standards and Testing Centre Ltd. 10 Dai Wang Street, Taipo Industrial Estate, N.T., Hong Kong Tel: (852) 2666 1888 Fax: (852) 2664 4353 Homepage: www.hkstc.org E-mail: [email protected] This report shall not be reproduced unless with prior written approval from The Hong Kong Standards and Testing Centre Ltd. For Conditions of Issuance of this test report, please refer to the overleaf or Homepage 2.0 Technical Details 2.1 Investigations Requested Perform ElectroMagnetic Interference measurement in accordance with FCC 47CFR [Codes of Federal Regulations] Part 15: 2006 and ANSI C63.4: 2003 for FCC Certification. 2.2 Test Standards and Results Summary Tables EMISSION Results Summary Test Condition Test Requirement Test Method Class / Test Result Severity Pass Failed N/A F…

Text truncated - open the document above for the full version.

PHOTOGRAPH OF THE PRODUCT MEASUREMENT OF RADIATED EMISSION TEST SET UP
