LU9657917Pelican Explore & Fit Cycle

1 SKU: 657917 ADULT ASSEMBLY REQUIRED ASSEMBLY INSTRUCTIONS Thank you for choosing the Little Tikes® Pelican Explore & Fit Cycle™. We strive to provide a durable, easy-to-assemble toy that is made to last, giving your child years of imaginative, engaging fun! AGES 3-7 12 Pelican Explore & Fit Cycle ™ ADULT BATTERY INSTALLATION REQUIRED FREE T rainer & A dventure V ideos FREE T rainer & A dventure V ideos Watch on Watch on 2 11 CONSUMER SERVICE LIMITED WARRANTY IMPORTANT INFORMATION YOU SHOULD KNOW! • Read through all the instructions first. • Clear a flat surface to lay out all the materials so that everything is close at hand. • Illustrations are for reference only. Styles may vary from actual contents. • Please remove all packaging including tags, ties & tacking stitches before giving this product to a child. • Make sure you have all contents before assembling. If anything is missing or if you have questions, we’re here to help. Give our consumer service team a call at 1-800-321-0183. © The Little Tikes Company, an MGA Entertainment company. LITTLE TIKES® is a trademark of Little Tikes in the U.S. and other countries. All logos, names, characters, likenesses, images, slogans, and packaging appearance are the property of Little Tikes. The Little Tikes Company makes fun, high quality toys. We warrant to the original purchaser that this product is free of defects in materials or workmanship for one year * from the date of purchase (dated sales receipt is required for proof of purchase). At the sole election of The Little Tikes Company, the only remedies available under this warranty will be the replacement of the defective part or replacement of the product. This warranty is valid only if the product has been assembled and maintained per the instructions. This warranty does not cover abuse, accident, cosmetic issues such as fading or scratches from normal wear, or any other cause not arising from defects in material and workmanship. *The warranty period is three (3) months for daycare or commercial purchasers. U.S.A and Canada: For warranty service or replacement part information, please visit our website at www.littletikes.com, call 1-800-321-0183 or write to: Consumer Service, The Little Tikes Company, 2180 Barlow Road, Hudson OH 44236, U.S.A. Some replacement parts may be available for purchase after warranty expires—contact us for details. Outside U.S.A and Canada: Contact place of purchase for warranty service. This warranty gives you specic legal rights, and you may also have other rights, which vary from country/state to country/state. Some countries/states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. Printed in China • 0321-0-E/INT MGA Entertainment (Netherlands) B.V. Baronie 68-70 2404 XG Alphen a/d Rijn The Netherlands Tel: +31 (0) 172 758038 Little Tikes Consumer Service www.littletikes.com 2180 Barlow Road Hudson, Ohio 44236 U.S.A. Email: [email protected] 1-800-321-0183 Monday-Friday MGA Entertainment UK Ltd. www.littletikes.co.uk 50 Presley Way, Crownhill, Milton Keynes, MK8 0ES, Bucks, UK [email protected] Tel: +0 800 521 558 Imported by MGA Entertainment Australia Pty Ltd www.littletikes.com.au Suite 2.02, 32 Delhi Road Macquarie Park NSW 2113 1300 059 676 • ADULT ASSEMBLY REQUIRED. • Prior to assembly, this package contains small parts: hardware which is a choking hazard and may contain sharp edges and sharp points. Keep away from children until assembled. • Please keep this manual as it contains important information. • This product is intended for indoor use only. • This product is intended for use by children ages 3-7. • Place on flat, level surfaces free of objects that could cause the cycle to tip over. Also, place out of the way of household traffic. • Never use near staircase, steps, pools, hot surfaces, or areas that may be hazardous to a child. • Do not use if damaged or broken. • Maximum weight limit: 70 lbs (23 Kg) WARNING! Let’s be careful! Your cycle’s fun features! Connect your smart device to the cycle. 1. Move the dial on the handlebar’s board to the Bluetooth® symbol. 2. Open the settings menu on your device. 3. Select Bluetooth® on your device and make sure it is on. 4. Your device will search for the cycle. 5. Select the name “Little Tikes Explore&FitCycle” to connect to your device. Rocking Cycle! Your cycle is spring loaded. Kids can shift their weight back and forth to move the cycle and enhance the adventures they go on! Move the dial on the handlebar’s board to number 1 and explore the jungle. Move the dial on the handlebar’s board to number 2 and sail the seven seas. Move the dial on the handlebar’s board to number 3 and take a trip to the ice cream shop. Built-in Audio Adventures FREE Trainer & Adventure Videos! Use your smart device to scan the code and easily access tons of fun videos as your kid pedals along! IMPORTANT BLUETOOTH® INFORMATION • To turn off Bluetooth®, move the dial to any of the audio files. Move it back to the Bluetooth® icon to connect it again. • To disconnect the device or to connect another device, move the language switch to reset the Bluetooth®. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by MGA Entertainment, Inc. is under license. Other trademarks and trade names are those of their respective owners. 310 Battery Safety Information. This is serious! • Keep these instructions for future reference. • Requires 3 “AA” (LR6) alkaline batteries (not included). (Rechargeable batteries may be substituted.) • The voltage of a fully-charged, rechargeable battery is often lower than that of a fresh alkaline battery. Therefore, it is recommended that alkaline batteries be used instead of rechargeable batteries for best performance and longer play time. • Install batteries with the correct polarity (+ and -). • To avoid battery leakage: 1. Foll…

Text truncated - open the document above for the full version.

Page 1 of 1 Block Diagram 2.4G BT Module (TIDBT008: U3) Transmitter IC U1 Oscillator Y1: 24M Flash IC U2, U6 Voltage-Stabilizing IC U5 MCU U1 Audio power amplifier IC U4 ANT 2402MHz to 2480MHz

MGA Entertainment (H.K.) Limited Suite 301, 3/F., Chinachem Golden Plaza, No.77 Mody Road, Tsim Sha Tsui East, Kowloon. H.K. Tel: (852) 2732 9200 Fax: (852) 2732 9242 2021/05/06 Federal Communications Commission 445 12 th Street SW Washington, DC 20554 Subject: Limited Agency Agreement (MGA Entertainment (H.K) Ltd.) FCC ID: LU9657917 To Whom It May Concern: We, (MGA Entertainment (H.K) Ltd.), hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number (LU9657917) under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is (2021/04/06). The Limited Agency Agreement expires on (2023/05/06), unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely,

Page 1 of 3 External Photos Page 2 of 3 Page 3 of 3

Page 1 of 2 Label Artwork and Location SIZE: 28mm (W) x10mm (H) SIZE: 48mm (W) x18mm (H) Page 2 of 2

Page 1 of 5 Internal Photos Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

The normal conducted output power is -1.42dBm (to Technical Description The equipment under test (EUT) is a Pelican Explore & Fit Cycle with Bluetooth function operating in 2402-2480MHz. The EUT is powered by DC 4.5V (3 x 1.5V AA batteries). For more detail information pls. refer to the user manual. Antenna Type: Integral antenna Modulation Type: GFSK, π/4-DQPSK and 8-DPSK Antenna Gain: -0.58dBi Max Bluetooth Version: 5.0 single mode The normal radiated output power (e.i.r.p) is: -2.0dBm (tolerance: +/- 3dB). lerance: +/- 3dB). Channel List： 2402MHz – 2480MHz with 1 MHz channel spacing. Main Chip Function: 1. U3 is BT Module. 2. U5 is regulator IC. 3. U1 is MCU. 4. U2 & U6 are Flash IC. 5. U4 is Audio power amplifier IC. BT Module: 1, U1 is RF transceiver IC. 2, Y1 is 24MHz oscillator for U1.

The normal conducted output power is -1.42dBm (to Page 1 of 1 INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is a Pelican Explore & Fit Cycle with Bluetooth function operating in 2402-2480MHz. The EUT is powered by DC 4.5V (3 x 1.5V AA batteries). For more detail information pls. refer to the user manual. Antenna Type: Integral antenna Modulation Type: GFSK, π/4-DQPSK and 8-DPSK Antenna Gain: -0.58dBi Max Bluetooth Version: 5.0 single mode The normal radiated output power (e.i.r.p) is: -2.0dBm (tolerance: +/- 3dB). lerance: +/- 3dB). According to the KDB 447498: The Maximum peak radiated emission for the EUT is 93.2 dBμV/m at 3m in the frequency 2480MHz The EIRP = [(FS*D) ^2 / 30] mW = -2.03dBm which is within the production variation. The Minimum peak radiated emission for the EUT is 92.4dBμV/m at 3m in the frequency 2441MHz The EIRP = [(FS*D) ^2 / 30] mW = -2.83dBm which is within the production variation. The maximum conducted output power specified is 1.58dBm= 1.439mW The source- based time-averaging conducted output power =1.439* Duty cycle mW <1.439 mW(Duty cycle <100%) The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.53 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: LU9657917

1 2 3 4 ABCD 4 3 2 1 D CBA Teamway LTD Project Name: 657917 pelican bike ICE_DATICE_CLK EC5 10UF16V ICE_RST 12345 J1 Nuy-Link Interface C6104 EC447uF VCC R510K VSSA VSSD VSSPST C4104 EC310uF VCCA VSSSPK VSSSPK 1234 UARTCON4 VCCD GPA10GPA11 ICE_DATICE_CLK C2104 VCCD C3104 C8 1uF VCCB RESETB 30 ICE_CLK 26 ICE_DAT 25 GPA9/X32O 23 GPA8/X32I 24 VSSD 13 VSSPST 12 VSSA 44 VSSSPK 18 VSSSPK 19 GPA15/PGCVMID 45 GPA14/MICN 46 GPA13/MICP 47 GPA12/MICBIAS 48 SPKN 21 SPKP 16 VCCSPK 15 VCCA 49 VCCB 2 VCCFS 1 VCCPST 33 VCCD 32 GPB0/SPIM_CLK 3 GPB1/SPIM_MOSI 4 GPB2/SPIM_SIO3 5 GPB3/SPIM_SIO2 6 GPB4/SPIM_MISO 7 GPB5/SPIM_SS 8 GPB6/UARTTX 9 GPB7/UARTRX 10 GPB8/SPI_MISO 11 GPB9/SPI_SS0 27 GPB10/SPI_SS1/Touch5 28 GPB11/IR/Touch6 29 GPA11/Touch4 34 GPA10/Touch3 35 GPA7/Touch2/PWM13 36 GPA6/Touch1/PWM12 37 GPA5/Touch0/PWM11 38 GPA4/AIN4//PWM10 39 GPA3/AIN3//PWM3 40 GPA2/AIN2/PWM 41 GPA1/AIN1/PWM1 42 GPA0/AIN0/PWM0 43 VPP(NC) 14 SPKP 17 SPKN 20 VCCSPK 22 VDDL 31 U1 SPIM_CLK SPIM_MOSISPIM_MISO SPIM_SS C91uF VCCD ICE_RST Nuy-Link Interface RXTX VCCD _ + GPA10GPA11 GPB10 GPB9GPB8GPB7 GPB9 GPB8GPB7 For reference only UART GPA0 NTDP090 SPKN SPKP Op EN GPB6 GPB6 C11104 EC2 100uF DACL GNDSPI_CSSPI_CLKSPI_DISPI_DOVBAT DACL U3 TIDBT008 VCC Q1 PNP R1110K R12 1K R13 5.1R GPA1 GPB11 GPA5GPA4GPA3GPA2 GPA6 R1610K GPA8GPA9 GPA12GPA13GPA14GPA15 214 3 Language Select GPA14GPA15 USFRSPA Op EN C26100uF VCC C28 104/NC R15 10K/NC EN 1 NC 2 IN+ 3 IN- 4 OUT- 8 GND 7 VDD 6 OUT+ 5 U4 Omp888 1 1 2 2 SPK 3W FB2 0R C10 NC C13 NC FB3 0R C20104 R10 5.1K C5 0.1UF R933K? C18 0.1UF C24 0.1UF R21 20K C21 332 R7 51K R8 51K R3 10K SPKN SPKP R14 47K? C25 0.1UF DACL Option DATA3 DATA0 DATA2GND CMD CLK DATA1 VDD U6 C14 104 SPI_3V3 R20 47K R22 47K R2347K SPI_3V3 NAND-FLASH Q3PNP VCCB R191K SPIM_CLK SPIM_MOSI SPIM_MISO SPIM_SS GPA11 GPA4GPA3 4.5V VCC EC6 200UF R10R R2 0R FB1 VCCD R410R VCCA C12 104 PTC1PTCR OFF Sound 1 R633R GPA2GPA1 BT Connect 3 2 1 4 5 10 11 12 9 8 7 6 SW1 Sound 2Sound 3 Option 1:Hardware OFF Vbat Vbat1 Vin Vout GND U5 GBY0029C EC1 200UF C1 104 3 21456 Q2SW-1P5T GPA4GPA3 OFF Sound 1 GPA2GPA1 BT Connect Sound 2Sound 3 Option 2:Software OFF Vbat Vbat1 GPA10 R2433R VCCD C7104 /CS 1 DO 2 /WP 3 VSS 4 DI 5 CLK 6 /HOLD 7 VDD 8 U2SPI FLASH SPIM_CLK SPIM_MOSI SPIM_MISO SPIM_SS VCCB VCCB Option:1 Option:2 V33 C15 105 Q4 NPN R11 100R 1 2 3 4 ABCD 4 3 2 1 D CBA Title Number Revision Size A4 Date: 26-Oct-2020 Sheet of File: D:\WORK\TIDB83 Teamway_BLE(TIDBT008)\Teamway_B LE_V1.DDB Drawn By: Teamway LTD TIDBT008 C1 105C2 105C8 105 SPI_DI USBDP MIC Y124M C11 NCC12 NC L1 0R L2 NC C32.7P 23 E1 ANT1 C6 105C7 104C9 105 RTCVDD DACLDACVDD VBAT VDDIO BT_AVDD PC5/SD1CLK 1 PC4/SD1CMD/ADC4 2 USBDM/PC3/SD1DAT/ADC10 3 USBDP/PA4/AUX1R/ADC1 4 PA0/MIC/PA3/AUX1L/ADC0 5 DACL 6 DACVDD 7 VCOM 8 VSSIO 9 VDDIO 10 PWMH2H/ADC9/AUX0R/PB5 11 VBAT 12 RTCVDD 13 ADC12/PR1 14 ADC12/PR2 15 BT_AVDD 16 BT_RF 17 FMIP 18 BT_OSCI 19 BT_OSCO 20 U1H04J28B SPI_DOSPI_CLK SPI_CS R1 1KR3 1KR2 1K R4 1K V1.2 123789 10 11 12 13 14 15 16 171819232425 TIDBT008_Module VBATVDDIO DM(SPI_DI) DP GND SPI_DO SPI_CSSPI_CLK MIC DACL DACVDD

MGA Entertainment (HK) Ltd. TEST REPORT SCOPE OF WORK FCC TESTING–657917 REPORT NUMBER SZHH01556026-007 ISSUE DATE [REVISED DATE] May 6, 2021 [---------------------] PAGES 24 DOCUMENT CONTROL NUMBER FCC ID 249_C © 2017 INTERTEK Intertek Report No.: SZHH01556026-007 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 24 FCC ID 249_C Test Report MGA Entertainment (HK) Ltd. Application For Certification FCC ID: LU9657917 Pelican Explore & Fit Cycle Model: 657917 Brand Name: Little Tikes 2.4GHz Transceiver Report No.: SZHH01556026-007 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-19] Prepared and Checked by: Approved by: Sign on file Terry Tang Assistant Supervisor Kidd Yang Technical Supervisor Date: May 6, 2021 Intertek Report No.: SZHH01556026-007 Version: 01-November-2017 Page: 2 of 24 FCC ID 249_C Test Report MEASUREMENT/TECHNICAL REPORT This report concerns (check one:) Original Grant X Class II Change Equipment Type: DXX - Part 15 Low Power Communication Device Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator − the new 47 CFR [10-1-19 Edition] provision. Report prepared by: Terry Tang Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel / Fax: 86-755-8614 0743/86-755-8601 6661 Intertek Report No.: SZHH01556026-007 Version: 01-November-2017 Page: 3 of 24 FCC ID 249_C Test Report Table of Contents 1.0 Summary of Test Result ................................................................................................. 4 2.0 General Description ...................................................................................................... 5 2.1 Product Description .................................................................................................... 5 2.2 Related Submittal(s) Grants ......................................................................................... 5 2.3 Test Methodology ...................................................................................................... 5 2.4 Test Facility ............................................................................................................... 5 3.0 System Test Configuration ............................................................................................. 6 3.1 Justification ............................................................................................................... 6 3.2 EUT Exercising Software .............................................................................................. 6 3.3 Special Accessories ..................................................................................................... 6 3.4 Equipment Modification .............................................................................................. 6 3.5 Measurement Uncertainty .......................................................................................... 7 3.6 Support Equipment List and Description ........................................................................ 7 4.0 Emission Results ........................................................................................................... 8 4.1 Radiated Test Results .................................................................................................. 8 4.1.1 Field Strength Calculation ......................................................................................... 8 4.1.2 Radiated Emission Configuration Photograph .............................................................. 9 4.1.3 Radiated Emissions .................................................................................................. 9 4.1.4 Transmitter Spurious Emissions ............................................................................... 12 5.0 Equipment Photographs .............................................................................................. 16 6.0 Product Labelling ........................................................................................................ 16 7.0 Technical Specifications ............................................................................................... 16 8.0 Instruction Manual ..................................................................................................... 16 9.0 Miscellaneous Information .....................................................................…

Text truncated - open the document above for the full version.

Page 1 of 1 Radiated Photos (The EUT placed at the center of the turntable)
