LZX39237Cordless Telephone

Note: This report may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product endorsement by NVLAP or any agency of the U.S. Government. FCC Part 15 Subpart C EMI Measurement and Test eport (EUT External Photo) FOR UNICAL ENTERPRISES, INC. 16960 Gale Avenue City of Industry, CA 91745 FCC ID: LZX39237 November 9, 1999 This Report Concerns: Original Report Equipment Type: 900 MHz Cordless Phone – Household Appliances Test Engineer:Sayed K. Test Date:November 4, 1999 Reviewed By: John Y. Chan – Engineering Manager Prepared By:Bay Area Compliance Laboratory Corporation 230 Commercial Street, Suite 2 Sunnyvale, CA 94086 (408) 732-9162 Unical Enterprises, Inc. FCC ID: LZX39237 Report # EUT external photo.docFCC Part 15 Subpart C Test Report Page 2 of 10 TABLE OF CONTENTS 1 - GENERAL INFORMATION.................................................................................................................................3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)..............................................................................3 1.2 PURPOSE...............................................................................................................................................................4 1.3 RELATED SUBMITTAL(S)/GRANT(S)......................................................................................................................4 1.4 TEST METHODOLOGY............................................................................................................................................4 1.5 TEST FACILITY......................................................................................................................................................4 1.6 TEST EQUIPMENT LIST..........................................................................................................................................5 1.7 EQUIPMENT UNDER TEST (EUT)...........................................................................................................................5 2 – EUT EXTERNAL PHOTOGRAPHS...................................................................................................................6 2.1 EUT – OVERALL VIEW.........................................................................................................................................6 2.2 EUT HANDSET - FRONT VIEW..............................................................................................................................7 2.3 EUT HANDSET – REAR VIEW...............................................................................................................................8 2.4 EUT BASE TOP VIEW............................................................................................................................................9 2.5 EUT BASE BOTTOM VIEW .................................................................................................................................10 Unical Enterprises, Inc. FCC ID: LZX39237 Report # EUT external photo.docFCC Part 15 Subpart C Test Report Page 3 of 10 1 - GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) The Unical Enterprises, Inc., model 39237 or the "EUT" as referred to in this report is a 900 MHz Analog w/Call Waiting Caller ID Cordless phone measuring 8.50”L x 4.50”W x 3.50”H. It has following features: • 900 MHz Operation. • 40 Channel Autoscan. • 40 Number Memory. • Noise Compander. • Digital Security Coding. • 65536 Random Security Codes. • Handset Page/Locator. • Handset Hi/Lo Volume Control. • Out-of-Range Warning. • In-Use LED and the Battery Low Indicator • Headphone Jack. • Flash. • Charge Indicators. • Last Number Redial • Power Save. • Auto Anser/Auto Standby. • Battery Quick Charge. • Mixed Mode Dialing, Tone/Pulse Dialing. • Ringer On/Off Switch. • Desk/Wall Use. • Hearing Aid Compatible. • Belt Clip. Unical Enterprises, Inc. FCC ID: LZX39237 Report # EUT external photo.docFCC Part 15 Subpart C Test Report Page 4 of 10 1.2 Purpose This document is a qualification test report based on the Electromagnetic Interference (EMI) tests performed on the 900 MHz 40 Channel Cordless Phone, FCC ID is LZX39237. The EMI measurements were performed according to the measurement procedure described in ANSI C63.6: 1992. The tests were performed in order to determine whether the electromagnetic emissions from the equipment under test, referred to as EUT hereafter, are within the specification limits defined by FCC Title 47, Part 15, Subpart C, section 15.205, 15.207, and 15.249. 1.3 Related Submittal(s)/Grant(s) No Related Submittals 1.4 Test Methodology All measurements contained in this report were conducted with ANSI C63.4 –1992, American National Standard for Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the range of 9 kHz to 40 GHz. All radiated and conducted emissions measurement was performed at Bay Area Compliance Laboratory, Corp. The radiated testing was performed at an antenna-to-EUT distance of 3 meters. 1.5 Test Facility The Open Area Test site used by Bay Area Compliance Laboratory Corporation to collect radiated and conducted emission measurement data is located in the back parking lot of the building at 230 Commercial Street, Suite 2, Sunnyvale, California, USA. Test sites at Bay Area Compliance Laboratory Corporation has been fully described in reports submitted to the Federal Communication Commission (FCC) and Voluntary Control Council for Interference (VCCI). The details of these reports has been found to be in compliance with the requirements of Section 2.948 of the FCC Rules on February 11 and December 10, 1997 and Article 8 of the VCCI regulations on December 25, 1997. The facility also complies with the radiated and AC line conducted test site criteria set forth in ANSI C63.4-1992. The Federal Commun…
