M3T-EBT-00201Bluetooth Wireless Speaker

Project No.: 1404134 Page 2 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 3 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 4 of 11 Neutron Engineering Inc.

Project No.: 1404134 Page 5 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 6 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 7 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 8 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 9 of 11 Neutron Engineering Inc. Printed Antenna Project No.: 1404134 Page 10 of 11 Neutron Engineering Inc. Project No.: 1404134 Page 11 of 11 Neutron Engineering Inc.

Neutron Engineering Inc. FCC RF EXPOSURE REPORT FCC ID: M3T-EBT-00201 Project No. : 1404134 Equipment : Bluetooth Wireless Speaker Model : EBT-00201 Applicant : Elytone Electronic Co., Ltd. Address : 218,Sec,2,Chung Cheng Road,San-Hsia, Taipei Hsien, Taiwan According: : FCC Guidelines for Human Exposure IEEE C95.1 Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan TEL : (0769) 8318-3000 FAX : (0769) 8319-6000 Neutron Engineering Inc. GENERAL CONCULUSION: Table for Field Antenna: Ant Brand Model Name Antenna TypeConnector Gain (dBi) 1 N/A N/A Printed N/A -0.50 Maximum measured transmitter power: Mode Output Power (dBm) Output Power (mW) Limit (mW) 3 MHz 3.03 2 10 According to FCC KDB447498 V05, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The maximum measured output peak power of this EUT is 2 mW, less than 10mW at 5mm distance. Conclusion: No SAR evaluation required since transmitter power is below FCC threshold

RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 1 of 104 Neutron Engineering Inc. FCC Radio Test Report FCC ID: M3T-EBT-00201 This report concerns (check one) : Original Grant Class II Change Issued Date : Apr. 28, 2014 Project No. : 1404134 Equipment : Bluetooth Wireless Speaker Model Name : EBT-00201 Applicant : Elytone Electronic Co., Ltd. Address : 218, Sec.2, Chung Cheng Road, 23742 San-Hsia, New Taipei City,TAIWAN Tested by: Neutron Engineering Inc. EMC Laboratory Date of Receipt: Apr. 08, 2014 Date of Test: Apr. 08, 2014 ~ Apr. 25, 2014 Testing Engineer : (Gary Chou) Technical Manager : (Jeff Yang) Authorized Signatory : (Andy Chiu) Neutron Engineering Inc. B1, No. 37, Lane 365, YangGuang St., NeiHu District 114, Taipei, Taiwan. TEL: +886-2-2657-3299 FAX: +886-2-2657-3331 RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 2 of 104 Neutron Engineering Inc. Declaration Neutron represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with the standards traceable to National Measurement Laboratory (NML) of R.O.C., or National Institute of Standards and Technology (NIST) of U.S.A. Neutron's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. Neutron shall have no liability for any declarations, inferences or generalizations drawn by the client or others from Neutron issued reports. Neutron’s reports must not be used by the client to claim product endorsement by the authorities or any agency of the Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and Neutron-self, extracts from the test report shall not be reproduced except in full with Neutron’s authorized written approval. Neutron’s laboratory quality assurance procedures are in compliance with the ISO Guide 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 3 of 104 Neutron Engineering Inc. Table of Contents REPORT ISSUED HISTORY 6 1 CERTIFICATION 7 2 . SUMMARY OF TEST RESULTS 8 2.1 TEST FACILITY 9 2.2 MEASUREMENT UNCERTAINTY 9 3 GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 14 3.5 DESCRIPTION OF SUPPORT UNITS 15 4 CONDUCTED EMISSION 16 4.1 LIMIT 16 4.2 MEASUREMENT INSTRUMENTS LIST 16 4.3 TEST PROCEDURES 17 4.4 TEST SETUP LAYOUT 17 4.5 DEVIATION FROM TEST STANDARD 17 4.6 EUT OPERATING CONDITIONS 18 4.7 TEST RESULTS 19 5 ANTENNA CONDUCTED SPURIOUS EMISSION 21 5.1 LIMIT 21 5.2 MEASUREMENT INSTRUMENTS LIST 21 5.3 TEST PROCEDURES 21 5.4 TEST SETUP LAYOUT 21 5.5 DEVIATION FROM TEST STANDARD 21 5.6 EUT OPERATING CONDITIONS 21 5.7 TEST RESULTS 22 6 HOPPING CHANNEL SEPARATION 30 6.1 LIMIT 30 6.2 MEASUREMENT INSTRUMENTS LIST 30 6.3 MEASURING INSTRUMENTS SETTING 30 6.4 TEST PROCEDURES 30 6.5 TEST SETUP LAYOUT 30 6.6 DEVIATION FROM TEST STANDARD 30 6.7 EUT OPERATING CONDITIONS 30 6.8 TEST RESULTS 31 7 MAXIMUM PEAK CONDUCTED OUTPUT POWER 39 7.1 LIMIT 39 RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 4 of 104 Neutron Engineering Inc. Table of Contents 7.2 MEASUREMENT INSTRUMENTS LIST 39 7.3 TEST PROCEDURES 39 7.4 TEST SETUP LAYOUT 39 7.5 DEVIATION FROM TEST STANDARD 39 7.6 EUT OPERATING CONDITIONS 39 7.7 TEST RESULTS 40 8 RADIATED SPURIOUS EMISSION (9 KHZ TO 1 GHZ) 44 8.1 LIMIT 44 8.2 MEASUREMENT INSTRUMENTS LIST 45 8.3 MEASURING INSTRUMENTS SETTING 45 8.4 TEST PROCEDURES 46 8.5 DEVIATION FROM TEST STANDARD 46 8.6 TEST SETUP LAYOUT 46 8.7 EUT OPERATING CONDITIONS 47 8.8 TEST RESULTS 48 9 RADIATED SPURIOUS EMISSION (ABOVE 1 GHZ) 50 9.1 LIMIT 50 9.2 MEASUREMENT INSTRUMENTS LIST 51 9.3 MEASURING INSTRUMENTS SETTING 51 9.4 TEST PROCEDURES 52 9.5 DEVIATION FROM TEST STANDARD 52 9.6 TEST SETUP LAYOUT 52 9.7 EUT OPERATING CONDITIONS 53 9.8 TEST RESULTS 54 9.9 TEST RESULTS (RESTRICTED BANDS) 78 10 NUMBER OF HOPPING FREQUENCY 86 10.1 LIMIT 86 10.2 MEASUREMENT INSTRUMENTS LIST 86 10.3 MEASURING INSTRUMENTS SETTING 86 10.4 TEST PROCEDURES 86 10.5 TEST SETUP LAYOUT 86 10.6 DEVIATION FROM TEST STANDARD 86 10.7 EUT OPERATING CONDITIONS 86 10.8 TEST RESULTS 87 11 AVERAGE TIME OF OCCUPANCY 89 11.1 LIMIT 89 11.2 MEASUREMENT INSTRUMENTS LIST 89 11.3 TEST PROCEDURES 89 RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 5 of 104 Neutron Engineering Inc. Table of Contents 11.4 TEST SETUP LAYOUT 89 11.5 DEVIATION FROM TEST STANDARD 89 11.6 EUT OPERATING CONDITIONS 90 11.7 TEST RESULTS 91 12 EUT TEST PHOTO 103 RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 6 of 104 Neutron Engineering Inc. REPORT ISSUED HISTORY Issue No. Description Issued Date NEI-FCCP-1-1404134 Original Issue. Apr. 28, 2014 RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 7 of 104 Neutron Engineering Inc. 1 CERTIFICATION E q u i p m e n t : Bluetooth Wireless Speaker Brand Name : Elytone Model Name : EBT-00201 A p p l i c a n t : Elytone Electronic Co., Ltd. Date of Test : Apr. 08, 2014 ~ Apr. 25, 2014 Standards : FCC Part 15, Subpart C: 2013 ANSI C63.4: 2009 The above equipment has been tested and found compliance with the requirement of the relative standards by Neutron Engineering Inc. EMC Laboratory. The test data, data evaluation, and equipment configuration contained in our test report (Ref No. NEI-FCCP-1-1404134) were obtained utilizing the test procedures, test instruments, test sites that has been accredited by the Authority of TAF according to the ISO-17025 quality assessment standard and technical st…

Text truncated - open the document above for the full version.

RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 103 of 104 Neutron Engineering Inc. 12 EUT TEST PHOTO Conducted emission test photos RV-0000000 Report No.: NEI-FCCP-1-1404134 Page 104 of 104 Neutron Engineering Inc. Radiated spurious emission test photos
