M5X-ACT80TCDigital Transmitter

ACT-80TC DIGITAL TRANSMITTER All rights reserved. Do not copy or forward without prior approvals MIPRO. Specifications and design subject to change without notice. MN 015/01 User Guide 2 CE5 1 5 A 1 0 1Bodypack Controls and Indicators 4O Display Screen How to Setup Transmitter Parameters 19Battery Status 21 25AF attery Removal and Installation perating Instructions 5LCD 6 MUTE Control Set-Up Input Connections 26B ContentsBodypack Controls and Indicators ONMODE SET 2 3 4 5 13 15 14 1 10 9 8 6 12 11 7 485.000MHz FREQUENCY Rechargeable Digital Wideband Bodypack TransmitterRechargeable Digital Wideband Bodypack Transmitter 32 Rechargeable Digital Wideband Bodypack TransmitterRechargeable Digital Wideband Bodypack Transmitter MUTE Button: To mute and un-mute the audio signal temporary. Antenna: Flexible 1/ 4 wave transmitting antenna. Transmitter Housing: Holds PCB board and wires. LCD Panel: Display transmitter parameters. SET Button: Parameter selection button. MODE Button: Allows access to available functions displaying in LCD panel. ACT IR Port: Align and syncs the transmitter and receiver frequency automatically. Power Button: Press and hold 2 seconds to power ON or OFF. Battery Circuitry Protection Reset Button Battery Compartment: Accommodates one 18500 rechargeable battery. Battery Cover: Hinged cover opens to provide access to one 18500 rechargeable battery. External Mute Connector: When an external mute switch cable, MJ-70 (optional) is connected , user can manually mute and un-mute the audio temporary. Battery Charging Contact: Align contacts during charging. Audio Input Connector: TA4F mini 4-pin connector accepts any MIPRO lavalier, instrument and headset microphones and cables. (See 5 ways of connection on AF Input Connections) Belt Clip: Detachable and reversible design allows the transmitter to be worn on a belt, waistband, or guitar strap (.Figure 1) 4 5 6 7 8 9 10 11 12 13 14 3 2 1 15 (Figure 1) (Positive Wear) (Opposite Wear) 5 4 Operating Instructions ! ! !Please make sure sensitivity level is set at proper level. Insert the lavalier, headset microphone or instrument cable into the audio input connector before power ON the transmitter. Tighten the connector screw clockwise direction as shown in (Figure 2) for a secured fit. (Figure 2) The ridge on the connector must align and match the indentation on the socket when inserting for a proper fit. Capsule Connector Headset Lavalier ONMODE SET LCD Display Screen LCD Screen Parameters Screen AF (audio) MUTE Transmitter Battery Meter 14 15 16 17 14 17 15 16 Fully Lit LCD Display 0 1 0 2 GRP CH Rechargeable Digital Wideband Bodypack TransmitterRechargeable Digital Wideband Bodypack Transmitter 7 6 Group and Channel Frequency Sensitivity Level AF Low Cut Encryption RF Output Power AF Phase AF Limit Parameters Lock & Unlock Status MUTE MODE B A C D E F G H I J A F G B E H C D I J N O ENCRYPTION Y E S AF LIMIT INVERT AF PHASE 485.000MHz FREQUENCY 0 dB AF GAIN LOW CUT AF LOW-CUT RF-LOW RF POWER UNLOCK SET LOCK 0 1 0 2 GRP CH MAN UAL MUTE MODE Rechargeable Digital Wideband Bodypack TransmitterRechargeable Digital Wideband Bodypack Transmitter How to Setup Transmitter Parameters !MODE Button: Press “MODE” button to access one of the NINE functions below. !SET Button: Press “SET” button and LCD wills start flashing. During flashing, press SET button to change parameters. 485.000MHz FREQUENCY MODE SET ONMODE SET 9 8 485.000MHz FREQUENCY FREQUENCY: Displays Transmitter Frequency Information a. Press MODE and stop on the FREQUENCY function; the display showing the current frequency will be flashing. After 5 seconds, the display will stop flashing. b. The frequency information is now shown on the display. Changing the current frequency must be done on the receiver. **Note: To modify the transmitter's group, channel and frequency, all three must be set at the receiver and the new setting transmitted to the transmitter via the ACT function. Rechargeable Digital Wideband Bodypack TransmitterRechargeable Digital Wideband Bodypack Transmitter **Note: When programming a special frequency via monitoring software, the LCD screen cannot display the number. This is because this special channel is not in the preset group and channel. RF, the LCD panel will look like the illustration below. GRP CH: Displays Group and Channel Information a. Press MODE and stop on the GRP CH function; the display showing the current group and channel will be flashing. After 5 seconds, the display will stop flashing and the current group and channel selection will be set. b. The group and channel information is now shown on the display. Changing the current group and channel must be done on the receiver. 0 1 0 2 GRP CHGRP CH GRP CH 11 10 AF LOW-CUT: Setup and Change of Low Frequency Cut Off a. Press MODE and stop on the AF LOW-CUT function; the display showing the current status will be flashing and is ready to be modified. b. Press the SET button while the display is flashing to change to LOW CUT or FLAT as desired. LOW CUT AF LOW-CUT FLAT AF LOW-CUT **Note: When the AF LOW-CUT function is LOW CUT, the frequency response below 100Hz will decrease about 3dB with a slope of - 6dB/Octave. Rechargeable Digital Wideband Bodypack TransmitterRechargeable Digital Wideband Bodypack Transmitter **Note: 1. The higher the gains are set, the lower the dynamic range for signal input and the greater the danger of unwanted noises and feedback getting into the system. 2. When using electronic guitar, gain should set at 0dB. 3. Please make sure input signal strength does not exceed 2 Vrms (gain=6dB) as it is the maximum input strength allowed for transmitter without causing distortion. AF GAIN: Setup and Change of Input Sensitivity a. Press MODE and stop on the AF GAIN function; the display showing the current status will be flashing and is ready to be modified. b. Every push of the SET button increases the dB value by 6dB to a maximum of 18dB. 0 dB 6 dB -6 dB 12 dB -12 dB 18 dB AF GAI…
