M6UDSR-500SDVB Set Top Box

zˆ›—™–š†kzyT\WWz†thu|hs†jv}lyU—‹GGGYWW\TXXTXXGGG㝘㤸GXXaX_aZYzˆ›—™–š†kzyT\WWz†thu|hs†jv}lyU—‹GGGYWW\TXXTXXGGG㝘㤸GXXaX_aZY G 2 CONTENTS 1. Introduction ················································································· 5 1-1 Overview 1-2 Main Features 2. Safety/Precaution ········································································ 6 2-1 Safety 2-2 Precaution 3. Check Point before Use ······························································ 8 3-1 Accessories 3-2 The Satellite dish 4. Controls/Functions ····································································· 9 4-1 Front Panel 4-2 Rear Panel 4-3 Remote Control 5. Getting Started ·········································································· 14 5-1 Basic Functions 5-2 System Parameters Set-up 6. Installation ················································································· 17 6-1 Satellite Collection 6-2 LNB Configuration 6-3 Motor Setup 6-4 Satellite Scan 7. Channel Edit ·············································································· 20 7-1 Sorting channels 7-2 editing Channels 7-3 Display Mode 7-4 Sorting Satellites GG 3 8. System ······················································································· 24 8-1 Parameters 8-2 Factory Set 8-3 Local Time/ Timer 8-4 Parental Control 9. Transponder ·············································································· 27 9-1 TP Add/Modify 9-2 TP Delete 9-3 Manual TP Scan 10. EPG (Electronic Program Guide) ··········································· 29 10-1 Current/Next Information 10-2 Schedule Information 10-3 Extended Information 10-4 Program Reservation 11. Other Functions ······································································ 30 12. Troubleshooting ······································································ 32 13. Specifications ···········································································33 G 4 NOTE ; ---------------------------------------------------------------------------------------------This equipment has been tested and found to comply with the limit for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential Installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interf erence will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encourage to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected - Consult the dealer or an experience radio/TV technician for help Change or modification not expressly approved by the party res ponsible for Compliance could void the user’s authority to operate the equipment GG 5 1. Introduction 1-1 Overview This Receiver is your “Window to the World” giving you the opportunity to enjoy both Free-To-Air and encrypted programs. Enjoy the rich choice of more than 4,000 different channels, broadcasting a large range of culture, sports, cinema, news, events, etc and the advanced functions of channel editing as your pleasure. 1-2 Main Features Ɣ Xcrypt CAS Embedded Ɣ Closed-Caption Support Ɣ S/PDIF (Digital AC-3 Audio) Output Ɣ Universal Remote Control – Infrared (IR) 4 component Ɣ Fully compliant with MPEG-2 and DVB standards Ɣ User friendly operating Menu and On-Screen Graphic Menu Ɣ 4000 channels, 40 satellite programmable Ɣ Multi Languages (Menu) : English, French, German, etc Ɣ Easy to use EPG(Electronic Program Guide) on screen Ɣ Extended EPG and Program reservation through EPG Ɣ Name Changeable 5 Favorite groups Ɣ Fast Channel Change Ɣ Each Channel Volume Saving Function Ɣ 4 Color buttons for rapid selection and convenience Ɣ Age protection lock function Ɣ Tele-text encoding Ɣ Manual PID control Ɣ DiSEqC 1.0 &1.2 compatible Ɣ Zoom Function G 6 2. Safety & Precaution 2-1 Safety Be sure read the user’s manual before starting the operation of the unit. Do not touch the cord with wet hands as it may cause electric shock. The STB shall not be exposed to dripping or splashing and that no objects filled with liquids, such as base, shall be placed on the apparatus. Never open the cover. It is very dangerous to touch the inside of the unit due to possible electric shock. Place the unit a well ventilated and no-heat enviroment. When you do not use this unit for a long time, make sure that power cord is pulled out from the outlet. Also do not use a damaged power cord as it may cause fire or electric shock. A professional installation is required. If reception is interrupted, contact your local service centre. GG 7 2-2 Precaution When installing the unit ····································································· Install the unit horizontally, An uneven installation may cause the unit be damaged. Do not put heavy items such as a TV on the unit. That may cause the unit to be damaged. Do not install the unit. Ɣ Where it is subject to vibrations. Ɣ Where it is exposed to direct sunlight. Ɣ Where there is humidity. Ɣ Where the temperature is too high or too low. Ɣ Where there is no ventilation. Moving the unit to a hot area from a cold one will cause condensation. Do not operate the unit for one or two hours or until it has dried completely. G 8 3. Check Points before Use 3-1. Accessories Accessories of this are as below ······················································ 3-2 The Satellite Dish Your dish should be properly installed. …

Text truncated - open the document above for the full version.

Appendix E. Block Diagram E05.1111.FCC.697N, Page 1 of 1 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea / Tel : 82-2-858-0786, Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea /Tel:82-31-885-0072, Fax:82-31-885-0074 Form NO: ETL(E)004A4001201-0 DSR - 500S/F Block Diagram

Appendix C. External Photographs File No. E05.1111.FCC.697N, Page 1 of 1 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Front side View of The EUT Rear side View of The EUT

Appendix A. FCC ID Label and Location File No. E05.1111.FCC.697N, Page 1 of 2 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Product Label Sample with FCC Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC ID Label and compliance statement are marked in the product label. Ajin Vision Co., Ltd.. DVB Set Top Box FCC ID : M6UDSR-500S Model No : DSR-500S/F POWER : AC 90 – 250 V 50/60 Hz, Max. 20 W Serial No : N/A This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation Manufacturer : Ajin Vision Co., Ltd. Made in Korea Appendix A. FCC ID Label and Location File No. E05.1111.FCC.697N, Page 2 of 2 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Label here

Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 1 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Inside View of The EUT Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 2 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Component side view of Main board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 3 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Solder side view of Main board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 4 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Component side view of Power board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 5 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Solder side view of Power board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 6 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Component side view of Smart card board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 7 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Solder side view of Smart card board

Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 8 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Component side view of Front board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 9 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Solder side view of Front board Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 10 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Component side view RF Modulator Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 11 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Inside View of The EUT of RF Modulator(1) Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 12 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Inside View of The EUT of RF Modulator(2) Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 13 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 View of Bottom cover View of Top cover Appendix D. Internal Photographs File No. E05.1111.FCC.697N, Page 14 of 14 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 View of Front Cover

OPERATIONAL DESCRIPTION MPEG-2 Digital and DVB Compliant Extended EPG Program Reservation through EPG Teletext decoding 14Event Timers Digital AC-3 audio output Parantal Control Renameable 5 Favorite Groups DiSEqC 1.0/1.2 Supported 3600 Channels Programmable Full Menu Picture – in Graphic Automatic NIT Scan Multi Language Support OSD Software Upgrading Specifications ● LNB / Tuner Input Connector : F-type, female Frequency range : 950Mhz ~ 2150Mhz LNB Supply : 14 / 18V. max 500mA DiSEqC : Ver 1.2 & Ver 1.0 Compatible ● Demodulator Front end : QPSK Symbol rate : 2MSps ~ 45MSps FEC Modes Rate : 1/2, 2/3, 3/4, 5/6, 7/8 and auto ● System resource Processor : 32bit processor (80Mhz) SDRAM : 8Mbyte Flash : 2Mbyte EEPROM : 256byte ● Video Decoder MPEG 2 : Main Profile @ Main Level Data Rate : Max 90M bits/s Resolution : 720 X 480 Video format : NTSC Aspect Ratio : 4:3 , 16:9 ● Teletext DVB Compliant ● MPEG Audio MPEG 1 layer 1 & 2 Type : Mono, Left, Right, Stereo Sampling rates : 32, 44.1 and 48Khz ● Serial port Connector : 9pin D-sub male, max 115K bps ● Remote control Code format : NEC-IR Control Device : TV, VCR, DVD ● Power supply Power consumption : Max 20W Supply voltage : 90V ~ 250V Supply frequency : 50Hz ~ 60Hz ● Rear Pannel Connectors Video Out : 1 X RCA cinch (Composite) Audio L/R : 2 X RCA cinch S/PDIF : 1 X RCA cinch Serial port : 9pin D-sub male Digital tuner input : F-type, female Loop-through digital tuner : F-type, female Terrestrial ant input : F-type, female RF modulator output : F-type, female ● RF modulator Connector : F-type, female TV Standard : NTSC Output channel number : Ch3, Ch4 ● Physical Specification Case Size (W x H x D) ; 260 x 44.5 x 221(mm) Weight (Net) : 1.9Kg

www.etl.re.kr E-RAE Testing Laboratory This report only responds to the tested sample and may not be reproduced, except in full, without written approval of the ETL,Inc. Electromagnetic Emission FCC MEASUREMENT REPORT CERTIFICATION OF COMPLIANCE FCC Part 15 Certification Measurement This DVB Set Top Box, Model DSR-500S/F has been tested in accordance with the measurement procedures specified in ANSI C63.4-2001 at the ETL/EMC Test Laboratory and has been shown to complied with the electromagnetic radiated emission limits specified in FCC Rule Part15 Subpart B: TV interface device. I attest to the accuracy of data. All measurement here in was performed by me or was made under my supervision and is correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results of testing in this report apply to the product/system, which was tested only. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Hyung Seok, Lee / Chief Engineer ETL Inc. #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea PRODUCT : DVB Set Top Box MODEL/TYPE NO : DSR-500S/F FCC ID : M6UDSR-500S APPLICANT / ADDRESS : Ajin Vision Co., Ltd. 242-5, Yumchang-Dong, Kangseo-Ku, Seoul,157-861 Korea Attn.: Woo-Jin, Ji / Engineer MANUFACTURER Same as applicant FCC CLASSIFICATION : HID : TV interface device FCC RULE PART(S) : FCC Part 15 Subpart B FCC PROCEDURE : Certification TRADE NAME : SATPROS TEST REPORT No. : E05.1111.FCC.697N DATES OF TEST : November 2 - 10, 2005 DATES OF ISSUE : November 11, 2005 TEST LABORATORY : ETL Inc. (FCC Registration Number: 95422) #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel: 82-31- 885-0072 Fax: 82-31-885-0074 FCC TEST REPORT File No. E05.1111.FCC.697N, Page of 18 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Table of Contents ATTACHMENT A: COVER LETTER(S) FCC Measurement Report 1. Introduction 2. Product Information 3. Description of Tests 4. Test Condition 5. Test Results 5.1 Summary of Test Results 5.2 Conducted Emission Test 5.3 Radiated Emission Test 5.4 Antenna Power Conduction Meaurement 5.5 Output Signal Level Measurement 5.6 Output Terminal Conducted Spurious Emission Measurement 5.7 Transfer Switch Measurement 6. Sample Calculation 7. List of test Equipment used for Measurements Appendix A. FCC ID Label and Location Appendix B. Test Setup Photographs Appendix C. External Photographs Appendix D. Internal Photographs Appendix E. Block Diagram Appendix F. Operating Manual FCC TEST REPORT File No. E05.1111.FCC.697N, Page 3 of 22 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 FCC MEASUREMENT REPORT Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) General Information l EUT Type : DVB Set Top Box l Model Number : DSR-500S/F l FCC Identifier : M6UDSR-500S l S/N : N/A l Freq. Range : 61.25 MHz – 71.75 MHz l FCC Rule Part(s) : Part 15 Subpart B l Test Procedure : ANSI C63.4-2001 l FCC Classification : TV Interface Device l RF Channels : Ch. 3 / Ch. 4 l Dates of Tests : November 2 - 10, 2005 l Place of Tests : ETL Inc. 584, Sangwhal-Ri, Kanam-Myun, Yoju-Kun, Kyounggi-Do, Korea Tel : 82-31- 885-0072 Fax : 82-31- 885-0074 l Test Report No. : E05.1111.FCC.697N Applicant Name : Ajin Vision Co., Ltd. Address : 242-5, Yumchang-Dong, Kangseo-Ku, Seoul,157-861 Korea Attention : Attn.: Woo-Jin, Ji / Engineer FCC TEST REPORT File No. E05.1111.FCC.697N, Page 4 of 22 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 The measurement test for radiated and conducted emission test were conducted at the shielded anechoic chamber room and open area test site of E-RAE Testing Laboratory Inc. facility located at 584, Sangwhal-ri, Ganam-myun, Youju-kun, Kyoungki-do, Korea. The site is constructed in conformance with the requirements of the ANSI C63.4-2001 and CISPR Publication 16. The ETL has site descriptions on file with the FCC for 3 and 10 meter site configurations. Detailed description of test facility was found to be in compliance with the requirements of Section 2.948 FCC Rules according to the ANSI C63.4-2001 and registered to the Federal Communications Commission(Registration Number : 95422 ). The measurement procedure described in American National Standard for Method of Measurement of Radio-Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C.63.4-2001) was used in determining radiated and conducted emissions from the Ajin Vision Co., Ltd. DVB Set Top Box , Model : DSR-500S/F FCC TEST REPORT File No. E05.1111.FCC.697N, Page 5 of 22 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 2.1 Equipment Description The Equipment Under Test(EUT) is the Ajin Vision Co., Ltd.DVB Set Top Box Model : DSR-500S/F 2.2 General Specification - Chassis Type : Metal - List of Each OSC. Or X-Tal. Freq.(>=1MHz) : 27.00 MHz FCC TEST REPORT File No. E…

Text truncated - open the document above for the full version.

Appendix B. Test Setup Photographs File No. E05.1111.FCC.697N, Page 1 of 4 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Radiated Emission Test Setup Appendix B. Test Setup Photographs File No. E05.1111.FCC.697N, Page 2 of 4 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Conducted Emission Test Setup Appendix B. Test Setup Photographs File No. E05.1111.FCC.697N, Page 3 of 4 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Antenna Power Conduction Measurement Test Setup Output Signal Level Measurement Test Setup Appendix B. Test Setup Photographs File No. E05.1111.FCC.697N, Page 4 of 4 Head Office : # 371-51 Kasan-Dong, Keumcheon-ku, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 EMC Lab : #584 Sangwhal-ri, Kanam-myon, Yoju-kun, Kyounggi-do, 469-885, Korea Tel:82-31-885-0072, Fax:82-31-885-0074 ETL(E)004A4001201-0 Output Terminal Conducted Spurious Emission Measurement Test Setup Antenna Transfer Switch Measurement
