M7C-MID116MID

USER'S MANUAL MID-7317CM MID-7317CM AMLOGIC-8726-MXS 4.2 HDMI ENGLISH MANUAL，70g,135x102mm, Table of Contents Table of Contents......................................P1 Features..................................................P2 Unit at a Glance .......................................P3 Getting Started....................................P4-P5 About Applications...............................P5-P6 Preinstalled Applications...........................P6 Connect to a Wi-Fi network...................P7-P8 Optional Connections................................P9 Specifications.........................................P10 Troubleshooting...............................P11-P12 1 Features 2 Browse the Web. Visit your favorite websites Check your e-mail Keep in touch with friends and family Watch YouTube™ videos Browse the world’s most popular video- sharing community Read your favorite books Download thousands of books with the included E-book reader * Discover thousands of apps for Android™ Games, applications, and more with marketplace(need for customer installed) Connect to the Internet wirelessly High-speed Wi-Fi 802.11 b/g/n networking Enjoy your media library anywhere Portable powerhouse plays popular music, video,and photo formats microSD memory card reader Increase your storage capacity (up to 32 GB supported) Built-in camera Convenient front-facing camera(0.3MP), rear 2MP Automatic orientation detection Read any way you want; the display adjusts automatically! Reading books in the ePub format requires the included E-book reader application. 3 1.POWER Press to turn the unit on, or to turn the screen on or off. Press and hold to access the Power Off menu. 2. Headphone Audio output connection for headphones. 3.USB OTG / HOST Connect to a USB device or a computer to transfer data (e.g. music, videos,photos, files). 1 4.DC IN 5V Change and power the tablet with the included power adapter. 5. TF CARD Load external microSD memory cards here. 6.HDMI Connect to a TV or other displays. 2 3 4 5 6 Unit at a Glance Getting Started Turning the Tablet on or off 2. Touch ok the screen to turn off the tablet. Turning the Screen On or off (Standby) When the tablet is on, you can turn off the screen to conserve battery power. Simply press the Power key once to turn the screen off. Press the Power key again to turn the screen back on. To turn the tablet on: Press and hold the Power key until the LCD screen turns on. Wait until the Home screen appears; the tablet is now ready for use. To turn the tablet off: 1.Press and hold the Power key until the Device Options menu appears. To conserve battery power, the screen can be set to turn off automatically when the tablet is not in use (between 15 seconds and 30 minutes). This Screen timeout option can be found in the Display menu. 4 Getting Started 5 Unlocking the Screen About Applications To open an application, touch the application icon on the home screen or in the Launcher where you can tap the icon right up on the home screen to get in.. Launcher screen: The screen shown above is for illustrative purposes only. Reserves the right to modify and improve the final list of applications available on the tablet. When the screen turns off, you will have to unlock the screen when you turn it back on. To unlock the screen, drag the lock icon across the screen towards the lock icon. . About Applications 6 Preinstalled Applications Some applications have been installed on your tablet for your convenience. These applications include: Browse the web. Perform simple mathematical operations. Take pictures or videos with the frontfacing camera. Check your e-mail. Play music. Access the Settings menu to adjust the tablet’s options. Preinstalled Applications Installing Applications You can also download an install additional applications from the device’s applications marketplace, the web browser, or other sources. The tablet must be set to allow installation of applications from non-Market sources. The Unknown sources option can be set in the Application settings menu. 7 Connect to a Wi-Fi network The Notification bar displays icons that indicate your tablet’s Wi-Fi status. Notification that an open Wi-Fi network is in range. Connected to a Wi-Fi network (waves indicate connection strength). When Wi-Fi is on, the tablet will look for and display a list of available Wi-Fi networks. [no icon] There are no Wi-Fi networks in range, or the Wi-Fi radio is off. 1. Turn on the Wi-Fi radio if it is not already on. To turn on Wi-Fi: a.Go to the Home screen: Press the Home key. b.Open the Settings menu: tap the icon right up on the home screen to get into the launcher, then touch Settings icon. c.Open the Wireless & networks menu: Slide the icon to ON status. If a network that you have connected to previously is found, the tablet will connect to it.If you don’t see your network in the list, you can force the tablet to re-scan. To scan for networks, tap the Menu key, and then touch Scan. 8 Connect to a Wi-Fi network To learn about how to add a Wi-Fi network when it is not in range or when the router is set to obscure the network name (SSID); or to configure advanced Wi-Fi options, please refer to the manual. When you have successfully connected to a Wi-Fi network, the Notifications bar at the the low of the screen will show a Wi-Fi signal indicator. 2. Select an available Wi-Fi network to connect to: In the same Wi-Fi settings menu above,touch a network in the list. If the network is open,the tablet will prompt you to confirm connection to the network. Touch Connect to confirm. If the network is secured (as indicated by a Lock icon),the tablet will prompt you to enter a password or other credentials.Touch the Wireless password box to show the on-screen keyboard and then use it to enter the password. Touch Connect to confirm. 9 Optional Connections Connecting to a Computer 3.Mount the storage. Touch button Turn on USB storage to mount the tablet’s built-in storage. When it is mounted, you ca…

Text truncated - open the document above for the full version.

Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EXHIBIT 2 - EUT EXTERNAL PHOTOGRAPHS EUT View 1 EUT View 2 Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EUT View 3 EUT View 4 Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EUT View 5 EUT View 6 Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EUT View 7 Antenna View WIFI Antenna

Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: M7C-MID116 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. ` Proposed Label Location on EUT FCC ID Label Location

Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EXHIBIT 1 - PRODUCT LABELING Proposed FCC ID Label Format FCC ID: M7C-MID116 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Specifications: Text is Black in color and justified. Labels are printed in indelible ink on permanent adhesive silk-screened onto the EUT or shall be affixed at a conspicuous location on the EUT. ` Proposed Label Location on EUT FCC ID Label Location

Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 EXHIBIT 3 - EUT INTERNAL PHOTOGRAPHS EUT Housing and Board View Solder Board-Component View 1 Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-1 FCC PART 15.247 Solder Board-Component View 2 Solder Board-Component View 3

RF Exposure Requirements Product Description: MID Model No.:MID7317CM FCC ID: M7C-MID116 Acorrding to the KDB-447498 D01 V05, the following RF exposure evaluation shall to demonstrate RF exposure compliance. Wi-Fi (802.11b/g/n) Tx frequency range: 2412~2472MHz Device category: Portable Device (Distance: 5mm) Maximum Conducted Output Power: 5.99 dBm Maximum Antenna Gain: 2.0 dBi Maximum EIRP Output Power: 6.2951mW (7.99 dBm) Limit: 10mW Source-based time-averaged EIRP output power is 6.2951 mW < 10 mW So the transmitter complies with the RF exposure requirements and the SAR is not required.

Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-2 PAGE 1 OF 16 FCC PART 15B FCC Part 15B Measurement and Test Report For Hena Digital Technology (Shenzhen) Co., Ltd 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen, China FCC ID: M7C-MID116 Test Rule(s): FCC Part 15 Subpart B Product Description: MID Tested Model: MID7317CM Report No.: STR13128171I-2 Tested Date: 2013-12-12 to 2013-12-31 Issued Date: 2013-12-31 Tested By: Lebron Wang / Engineer Reviewed By: Lahm Peng / EMC Manager Approved & Authorized By: Jandy so / PSQ Manager Prepared By: Shenzhen SEM.Test Technology Co., Ltd. 1/F, Building A, Hongwei Industrial Park, Liuxian 2nd Road, Bao'an District, Shenzhen, P.R.C.（518101） Tel.: +86-755-33663308 Fax.: +86-755-33663309 Website: www.semtest.com.cn Note: This test report is limited to the above client company and the product model only. It may not be duplicated without prior permitted by Shenzhen SEM.Test Technology Co., Ltd. Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-2 PAGE 2 OF 16 FCC PART 15B TABLE OF CONTENTS 1. GENERAL INFORMATION ................................................................................................................................... 3 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 3 1.2 TEST STANDARDS ................................................................................................................................................... 4 1.3 TEST METHODOLOGY ............................................................................................................................................. 4 1.4 TEST FACILITY ....................................................................................................................................................... 4 1.5 EUT SETUP AND OPERATION MODE ...................................................................................................................... 5 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 6 3. CONDUCTED EMISSIONS .................................................................................................................................... 7 3.1 MEASUREMENT UNCERTAINTY .............................................................................................................................. 7 3.2 TEST EQUIPMENT LIST AND DETAILS ..................................................................................................................... 7 3.3 TEST PROCEDURE ................................................................................................................................................... 7 3.4 BASIC TEST SETUP BLOCK DIAGRAM ..................................................................................................................... 7 3.5 ENVIRONMENTAL CONDITIONS .............................................................................................................................. 8 3.6 SUMMARY OF TEST RESULTS/PLOTS ...................................................................................................................... 8 3.7 CONDUCTED EMISSIONS TEST DATA ...................................................................................................................... 8 4. RADIATED EMISSIONS ....................................................................................................................................... 11 4.1 MEASUREMENT UNCERTAINTY ............................................................................................................................ 11 4.2 TEST EQUIPMENT LIST AND DETAILS ................................................................................................................... 11 4.3 TEST PROCEDURE ................................................................................................................................................. 11 4.4 TEST RECEIVER SETUP ......................................................................................................................................... 12 4.5 CORRECTED AMPLITUDE & MARGIN CALCULATION ............................................................................................ 12 4.6 ENVIRONMENTAL CONDITIONS ............................................................................................................................ 12 4.7 SUMMARY OF TEST RESULTS/PLOTS .................................................................................................................... 12 Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-2 PAGE 3 OF 16 FCC PART 15B 1. GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) Client Information Applicant: Hena Digital Technology (Shenzhen) Co., Ltd Address of applicant: 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen, China Manufacturer: Hena Digital Technology (Shenzhen) Co., Ltd Address of manufacturer: 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen, China General Description of EUT Product Name: MID Trade Name: / Model No.: MID7317CM Adding Model(s): NID-7011,MID7317HCM,MID7317CE,MID7317HCE, MY7317P,MW-7317,MY73**P,MY73*G,MY73**E,MY73**S, MW73**P,MW73**G,MW73**E,MW73**S,MID73**CM, MID73**CE, MID73**HCM, MID73**HCE(** Can be 01-99) Note: The test data is gathered from a production sample, provided by the manufacturer. The appearance of others models listed in the report is different from main-test model MID7317CM, but the circuit and the electronic construction do not change, declared by the manufacturer. Technical Cha…

Text truncated - open the document above for the full version.

Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-2 FCC PART 15B EXHIBIT 4 - TEST SETUP PHOTOGRAPHS Conducted Emission Test Setup Radiation Emission Test Setup(Below 30MHzz) Charging & Playing mode Hena Digital Technology (Shenzhen) Co., Ltd Model: MID7317CM REPORT NO.: STR13128171I-2 FCC PART 15B Radiation Emission Test Setup (Below 30MHz to 1GHz) Charging & Playing Mode Radiation Emission Test Setup(Above 1GHz) Charging & Playing Mode
