M7CMID010MID

Date:2012-10-27 FCC ID: M7CMID010 Subject: Ad Hoc Mode Function Declaration To Whom it may concern, This device is acting as slave and operating in the 2.4 GHz (2412 – 2462 MHz) band. Ad Hoc function is supported but not able to operate on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, Yours sincerely, Signatory Signature Name: Chen Yong Title: Manager Tel: 0755-27820019 Company : Hena Digital Technology (Shenzhen) Co., Ltd. Add: 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd,High-tech Industrial Park, Nanshan District, Shenzhen, China

Authorization Letter We, (the approval holder) Com pany name Hena Digital Technology (Shenzhen) Co., Ltd. Addresss 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen City Shenzhen Country China declare that the following representative (agent): Name (person) Bovey.yang Company name NTEK Testing Technology Co., Ltd. Addresss 1/F, Building E, Fenda Science Park Sanwei Community, Xixiang Street, Baoan District City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to PHOENIX TEST-LAB for product certification below Product Description MID Type or Model(s) MID7326CM Tradename or Brand(s) HENA,GPX Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) China 2012/10/22 Chen Yong Manager

FCC Confidentiality Request To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Hena Digital Technology (Shenzhen) Co., Ltd. Addresss 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen City Shenzhen Country China request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: M7C MID010 of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) x Operational Description x Block Diagrams x Schematics Diagrams Bill of Materials Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) China 2012/10/22 Chen Yong Manager

Page 27 of 33 Report No.: NTEK-2012NT1009053E ATTACHMENT PHOTOGRAPHS OF EUT Photo 1 Photo 2 Page 28 of 33 Report No.: NTEK-2012NT1009053E Photo 3 Photo 4 Page 29 of 33 Report No.: NTEK-2012NT1009053E Photo 5 Photo 6

9*3

Page 30 of 33 Report No.: NTEK-2012NT1009053E Photo 7 Photo 8 Page 31 of 33 Report No.: NTEK-2012NT1009053E Photo 9 Photo 10 Page 32 of 33 Report No.: NTEK-2012NT1009053E Photo 11 WiFi Module Photo 12 WiFi Module Page 33 of 33 Report No.: NTEK-2012NT1009053E Photo 13 WiFi Antenna

Letter of Certification This is to formally certify that: The tune up procedures of MID (MID7326CM, MID7326RM, MID7326CE, MID7326RE, MID73**CM, MID73**RM, MID73**CE, MID73**RE (**can be 01-99))is not open to end user. The end user is not allowed to perform finaltune. All the power and frequency set up were finished at the manufacturer stage. IEEE 802.11b max possible output power (PK,conducted) ：9±1dbm IEEE 802.11g/n max possible output power(PK, conducted) ：9±1dbm Regards, Yours sincerely, Signatory Signature Name: Chen Yong Title: Manager Tel: 0755-27820019 Company : Hena Digital Technology (Shenzhen) Co., Ltd. Add: 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd,High-tech Industrial Park, Nanshan District, Shenzhen, China

RF EXPOSURE TEST Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB 447498 (2)(a)(i) For portable device,the power limit is 60/f(in GHz) mW For limit 60/f is equal: 60/2.412=24.87mW 60/2.437=24.62 mW 60/2.462=24.37mW Maximum measured transmitter power TX 802.11b Mode Te s t Channe Frequency Peak output power. Antenna Gain EIRP LIMIT (MHz) (dBm) dBi dBm mW CH01 2412 8.74 2.0 10.74 11.85 CH06 2437 9.10 2.0 11.10 12.88 CH11 2462 8.46 2.0 10.46 11.12 TX 802.11g Mode CH01 2412 8.59 2.0 10.59 11.45 CH06 2437 8.28 2.0 10.28 10.66 CH11 2462 8.81 2.0 10.81 12.05 TX 802.11n/20M Mode CH01 2412 8.79 2.0 10.79 11.99 CH06 2437 8.64 2.0 10.64 11.58 CH11 2462 9.27 2.0 11.27 13.39 TX 802.11n/40M Mode CH03 2422 9.04 2.0 11.04 12.70 CH06 2437 7.93 2.0 9.93 9.84 CH11 2452 8.57 2.0 10.57 11.40 To Tune Up information max possible output power (PK)：10±1dbm MAX possible Conducted Power (dBm) Max Antenna Gain (dBi) EIRP (dBm) EIRP (mW) limit(mW) 11 2 13 19.95 24.37 The max.output power E.I.R.P is 19.95mW<24.19mW Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: M7CMID010 Product： MID Trade Name： HENA,GPX Model Name： MID7326CM Serial Model： MID7326RM, MID7326CE, MID7326RE, MID73**CM, MID73**RM, MID73**CE, MID73**RE (**can be 01-99) Report No.： NTEK- 2012NT1009053F Prepared for Hena Digital Technology (Shenzhen) Co., Ltd. 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao’an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 78 Report No.: NTEK-2012NT1009053F TEST RESULT CERTIFICATION Applicant’s name................. : Hena Digital Technology (Shenzhen) Co., Ltd. Address ................................. : 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen, China Manufacture's Name............ : Hena Digital Technology (Shenzhen) Co., Ltd. Address ................................. : 3F, South Tower, Jiuzhou Electric Building, Southern No, 12Rd, High-tech Industrial Park, Nanshan District, Shenzhen, China Product description Product name ........................... : MID Model and/or type reference : MID7326CM Serial Model .............................. : MID7326RM, MID7326CE, MID7326RE, MID73**CM, MID73**RM, MID73**CE, MID73**RE (**can be 01-99) Standards............................. : FCC Part15.247 Test procedure .............................. ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test............................................: Date (s) of performance of tests .............: 09 Oct. 2012 ~22 Oct. 2012 Date of Issue...........................................: 22 Oct. 2012 Test Result...............................................: Pass Testing Engineer : (Jason Chen) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 78 Report No.: NTEK-2012NT1009053F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BETWEEN 9KHZ – 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30MHZ – 1GHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 4 . POWER SPECTRAL DENSITY TEST 56 4.1 APPLIED PROCEDURES / LIMIT 56 4.1.1 TEST PROCEDURE 56 4.1.2 DEVIATION FROM STANDARD 56 4.1.3 TEST SETUP 56 4.1.4 EUT OPERATION CONDITIONS 56 4.1.5 TEST RESULTS 57 5 . BANDWIDTH TEST 65 5.1 APPLIED PROCEDURES / LIMIT 65 5.1.1 TEST PROCEDURE 65 Page 4 of 78 Report No.: NTEK-2012NT1009053F Table of Contents Page 5.1.2 DEVIATION FROM STANDARD 65 5.1.3 TEST SETUP 65 5.1.4 EUT OPERATION CONDITIONS 65 5.1.5 TEST RESULTS 66 6 . PEAK OUTPUT POWER TEST 74 6.1 APPLIED PROCEDURES / LIMIT 74 6.1.1 TEST PROCEDURE 74 6.1.2 DEVIATION FROM STANDARD 74 6.1.3 TEST SETUP 74 6.1.4 EUT OPERATION CONDITIONS 74 6.1.5 TEST RESULTS 75 7 . ANTENNA REQUIREMENT 76 7.1 STANDARD REQUIREMENT 76 7.2 EUT ANTENNA 76 8 . EUT TEST PHOTO 77 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 78 Report No.: NTEK-2012NT1009053F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 78 Report No.: NTEK-2012NT1009053F 1.1 TEST FACILITY Shenzhen NTEK Testing Technology Co., Ltd Add.:1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao’an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 78 Report No.: NTEK-2012NT1009053F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment MID Trade Name HENA,GPX Model Name MID7326CM Serial Model MID7326RM, MID7326CE, MID7326RE, MID73**CM, MID73**RM, MID73**CE, MID73**RE (**can be 01-99) Model Difference Only Model name is different. Product Description The EUT is a MID Operation Frequency: 2412~2462 MHz Modulation Type: CCK/OFDM/DBPSK/DAPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6 Mbps 802.11n(20MHz):150/144.44/130/11 7/115.56/104/86.67/78/52/6.5 Mbps …

Text truncated - open the document above for the full version.

Page 77 of 78 Report No.: NTEK-2012NT1009053F 8. EUT TEST PHOTO Radiated Measurement Photos Page 78 of 78 Report No.: NTEK-2012NT1009053F Conducted Measurement Photos
