MAA-PW8540IM802.11 b/g Access Point Router

User’s Guide Wireless LAN AP-Router Model: PW8540IM IEEE 802.11b/g Table of Contents INSTALLING YOUR ROUTER------ 3 System Requirement----------------- 3 Installation Instructions------------- 3 PREPARING YOUR NETWORK---- 4 Configuring Windows for IP Networking---------------------------- 4 Collecting ISP Information---------- 7 BASIC FUNCTIONS-------------- 9 Setup---------------------------------- 11 Global Address----------------------- 15 Wireless------------------------------ 19 Tools---------------------------------- 28 Status--------------------------------- 32 DHCP---------------------------------- 35 Log------------------------------------ 38 Statistics------------------------------ 42 Printer-------------------------------- 44 ADVANCED FUNCTION---------- 47 Virtual Servers---------------------- 48 Filters--------------------------------- 51 IP/URL Block------------------------ 55 Special Apps------------------------- 59 DMZ Host----------------------------- 63 MAC Clone---------------------------- 65 Dynamic DNS------------------------ 66 Proxy DNS--------------------------- 68 SNMP--------------------------------- 70 Static Routing----------------------- 73 INSTALLING YOUR ROUTER Chapter 1 Installing Your Router In this chapter you’l learn how to connect your rou er. ,lt System Requirement ▪ Broadband Internet access ▪ Ethernet cables ▪ Wireless interface, if you want to use wireless functions ▪ Desktop or Laptop PCs with Ethernet interface Installation Instructions To Connect the Router: 1. Make sure all equipments are turned off, including the router, Desktop or Laptop PCs, the cable and DSL modem, and so on. 2. Connect the WAN Port of the router to the cable and DSL modem, Ethernet Server or the hub. 3. Connect your client PCs to the LAN Ports. 4. Connect the Power Adaptor (5VDC) to the power jack of the router and plug the power cable into the outlet. 5. Turn on our PCs. Page 3 of 77 PREPARING YOUR NETWORK Page 4 of 77 Chapter 2 Preparing Your Network In this chapter you’l learn what to do beore configurng your network. ,lfi B efore configuring your router, you need set up the computers in your network for TCP/IP networking and collect relevant ISP information if necessary. Configuring Windows for IP Networking Each computer in your network should be configured for TCP/IP networking. There are two ways to configure your computers: ▪ You are commended to use DHCP, then you can simply choose to receive an IP address automatically. For detailed instructions, see Configure Windows to Receive Dynamic IP Address. ▪ If you don’t use DHCP, you need assign an IP address to each computer manually. For detailed instructions, refer to your Windows Documentation. To Configure Windows to Receive Dynamic IP Address: 1. Click Start, then choose Settings > Network and Dial-up Connections. 2. Select the name of your ISP connection. The Local Area Connection Status dialog box appears, seen in FIGURE 2-1: PREPARING YOUR NETWORK FIGURE 2-1: Local Area Connection Status dialog box 3. Click Properties. The Local Area Connection Properties dialog box appears, seen in FIGURE 2-2: Page 5 of 77 PREPARING YOUR NETWORK FIGURE 2-2: Local Area Connection Properties dialog box. 4. Click Internet Protocol (TCP/IP), then click Properties. The Internet protocol (TCP/IP) Properties dialog box appears, seen in FIGURE 2-3: Page 6 of 77 PREPARING YOUR NETWORK FIGURE 2-3: Internet Protocol (TCP/IP) Properties dialog box 5. Click Obtain an IP address automatically and Obtain DNS server address automatically. 6. Click OK. You need restart your computer now or at a later time. Note - The procedural steps above apply to Windows 2000 only. For Windows 95/98/ME/NT/XP, refer to your Windows Documentation. Collecting ISP Information You need query the relevant information from your ISP before configuring your router, for example: ▪ Has your ISP assigned you a static or dynamic IP address? If you have obtained one static IP address, what is it? ▪ Does your ISP use PPPoE? If so, what is your PPPoE user name and password? Page 7 of 77 PREPARING YOUR NETWORK If you are not sure of the above questions, call your ISP to clarify them. Page 8 of 77 BASIC FUNCTIONS Page 9 of 77 Chapter 3 Basic Functions In this chapter you will learn how to use basic functions that the Company AP Router provides, including Setup, Global Address, Wreless Tools, Sa us, DHCP, Log and Printer. , it t T he Company AP Router provides you a Web-based Administration Tool with which you can easily set up the router and customize the basic router settings. You can use this Web-based Tool from any computer in your network. Notes ▪ Microsoft Internet Explorer 5.0 or later is highly recommended for using this Web-based Tool. ▪ Graphics sampled in this chapter are provided for illustrations only. They may slightly differ from your own router screens. To Open the Web-based Administration Tool: 1. Open the browser on your PC. 2. Type http://192.168.62.1 in the Address bar. The Logon dialog box appears, seen in FIGURE 3-1: BASIC FUNCTIONS ] FIGURE 3-1: Logon dialog box 3. Type admin in the User Name box. 4. Type the password in the box. Note - The default password is 1234. You can change the password on the Tools page. For detailed instructions, see To Change the Administrative Password for Your Router. 5. Optional. To log on to the Administration Tool once for all, select the check box of Save this password in your password list. 6. Click OK. The Company AP Router Administration Tool appears. Note - The Administration Tool will time out after a period of idling, the Router may ask you to log on again. Page 10 of 77 BASIC FUNCTIONS: SETUP Page 11 of 77 ³ Setup The Setup page allows you to edit the basic configuration parameters for your router, such as Host Name, Domain Name, LAN IP Address, WAN IP Address, PPPoE Login, UPNP, and so on. In most cases, the default settings will be Okay for you. However, different ISPs (Internet Service Provider) may ask for speci…

Text truncated - open the document above for the full version.

Procomp Informatics Ltd 5F,,69-10,SEC.2,CHUNG CHENG E. RD.,TAMSHUI TAIPEI HSIEN,TAIWAN,R.O.C . TEL:886-2-2809-5230 FAX:886-2-2809-7811 htt p://www.procomp.com.tw May 31, 2004 Federal Communications Commission Authorization and Evaluation Division FCC ID: MAA-PW8540IM Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: 1. Schematics 2. Operational description 3. Block diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, ______________________________ Name: Mike Lee Title : Senior Engineer / Mobile Solution Business Center Company name: Compliance Certification Services Inc. Tel: 886-2-2809-5230 Fax: 886-2-2809-7811 E-Mail: [email protected]

Procomp Informatics Ltd 5F,,69-10,SEC.2,CHUNG CHENG E. RD.,TAMSHUI TAIPEI HSIEN,TAIWAN,R.O.C . TEL:886-2-2809-5230 FAX:886-2-2809-7811 htt p://www.procomp.com.tw Power of Attorney Date: May 31, 2004 We, the undersigned, hereby authorize Compliance Certification Services, Inc. to act on our behalf in all matters relating to all processes related to FCC applications and communications issue. Any and all acts carried out by Compliance Certification Services, Inc. on our behalf shall have the same effects as acts of our own. If you have any questions regarding this authorization, please don’t hesitate to contact us. Thank you. Sincerely yours, ______________________________ Name: Mike Lee Title : Senior Engineer / Mobile Solution Business Center Company name: Procomp Informatics Ltd. Tel: 886-2-2809-5230 Fax: 886-2-2809-7811 E-Mail: [email protected]

Mike Kuo From: [email protected] Sent: June29 2004 Tuesday 3:14 AM To: Mike Kuo Cc: [email protected]; Lai, Harris (E-mail); CCS-Taiwan, Ting (E-mail) Subject: RE: RE: Procomp InformaticsFCC ID:MAA-PW8540IM, AN04T3988 ( AN04T3974) 7/1/2004 Hi Mike, The theory of operation is revised to meet the FCC rules. Please refer to Table 1 on Page 4 of the attached file. You might pay attention to the first entry of the table. Best Rgds, WK Hi Amanda : Second reply to Question #3 still is not acceptable. Please take a look FCC policy on this issue. Best Regards Mike Kuo -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Wednesday, June 23, 2004 1:56 AM To: Mike Kuo Cc: Lai, Harris (E-mail); Mike Kuo; CCS-Taiwan, Ting (E-mail); [email protected] Subject: RE: Procomp Informatics FCC ID:MAA-PW8540IM, AN04T3988 ( AN04T3974) Hi Mike, Mike Kuo <[email protected]> 2004/06/25 10:53 AM "'[email protected]'" <[email protected]>, Mike Kuo <[email protected]> "Lai, Harris (E-mail)" <[email protected]>, Mike Kuo <[email protected]>, "CCS-Taiwan, Ting (E- mail)" <[email protected]>, [email protected] Please refer to the attached for the replies to your questions. Best Rgds, WK Hi W. K. : Reply to Question #1: O.K. Reply to Question #2: The main question is for internal photos but external photos were provided. Please provide internal photos with clear images. Re-reply #2: The internal photos are attached. Reply to Question #3: It is not acceptable. Based upon revised theory of operation, " The XWL-11GRIX product is in compliance with WLAN11g standards which specify the channel allocations in various regulatory domains. For each supported regulatory domain, all channels in Table 2 marked with an “ x ” shall be supported. A desired regulatory domain can be selected to operate in a designated country." Once again, the manufacturer is allowing the end user to select regulatory domain during the operation. Such practice does not address the concerns in question #3. Once again, manufacturer can not rely on the end user to comply the FCC regulatory requirements. Please take a look question #3 and provide technical information to address this requirement. Re-reply #3: The manufacturer has stated in the revised theory of operation its mechanism of limiting its product to be operated only in the appropriate frequency range. Please refer to Page 4. Best Regards Mike Kuo -----Original Message----- From: [email protected] [mailto:[email protected]] Sent: Monday, June 21, 2004 12:08 AM To: Mike Kuo Cc: Lai, Harris (E-mail); CCS-Taiwan, Ting (E-mail) Subject: Procomp Informatics FCC ID:MAA-PW8540IM, AN04T3988 ( AN04T3974) HI Mike, Attached please find our repleies. Best Rgds, Mike Kuo <[email protected]> 2004/06/22 05:35 AM "'[email protected]'" <[email protected]>, Mike Kuo <[email protected]> "Lai, Harris (E-mail)" <[email protected]>, "CCS-Taiwan, Ting (E-mail)" <[email protected]> 7/1/2004 WK Question #1: In the test report, there are three power adapters are listed and included in the photo files. However, there is only one set of AC line conducted test plots are provided with indication which power adapter was tested. Please provide additional power adapter AC line conducted test plots. Answer #1: Please refer to the following file for additional power adapter AC line conducted test plots. Question #2: The internal photos are not clear. Please retake internal photos to show the component values on the PCB. ( Please note : Please improve your photo qualities on the internal, external and test setup photos, some of photos can not clear ). Answer #2: The photos are re-taken as attached, Question #3: In the theory of operation, the radio is capable of operating with frequency range from 2412-2484MHz. Please explain how the device will be limited to be operated only in the authorized frequency range ( 2412- 2462MHz). Answer #3: A revised theory of operation is attached. Best Regards Mike Kuo The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e- mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. Mike Kuo <[email protected]> 2004/06/15 06:22 AM "CCS-Taiwan, Wklo (E-mail)" <[email protected]>, "CCS-Taiwan, Ting (E-mail)" <[email protected]> "Lai, Harris (E-mail)" <[email protected]> 7/1/2004

Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 1 EXTERNAL PHOTOGRAPHS OF EUT Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 2 Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 3 Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 4

X-Micro ������������ ����������������������� ��������������������� ���� ���� Rating: 5V ������������������������ � ��������������������� ���� ���� ������� �������������������� ������������������������ ���������� ������������������ ��������������������� ���� ���� �������������� WLAN 11g Broadband Router (E) Model Name: XWL-11GRIX EAN: S/N: From: To: Q‘TY: N.W.: G.W.: 20 18.0 19.0 PCS KGS KGS Frank Chang WLAN Product Manager Mobile Solution Business Center Procomp Informatics Ltd. [email protected] T: +886-2-2809-5230 ext 1624 F: +886-2-8809-6111 AP-Router 70 x 42mm USB Dongle 20 x 14mm Cardbus 42 x 70mm Box AP-Router 130 x 190mm

Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 4 Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 5 INTERNAL PHOTOGRPHS OF EUT Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 6 Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 7 Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 8 Compliance Certification Services Inc. Report No: A40415003 Date of Issue: June 3, 2004 Page 9

NO: SPECIFICATIONS BI-TEK CO.,LTD12F,-2,NO,700, Jhongheng Rd., Jhonghe City, Taipei County 235, TaiwanTEL:886-2-82278533 FAX:886-2-82278535 CUSTOMER:PRODUCT:PART NO: 2004/05/21 APPROVED BY SALES BY ֆ׹ࢭᎁີ ড়֪ࢭᎁີ DIVISION SIGNATURE ໑ ሒ ઝ ݾ ै ٝ ڶ ૻ ֆ ׹ ANTENNA RFA-02-C2H1-16W-120 ****************************************************** I N D E X ****************************************************** RFA-02-C2H1-16W-120 1.Specification 2.Radiation Pattern 2.1E-plane pattern 2.2H-plane pattern 3.VSWR Test Data 1. Specification 03-11-02 DESCRIPTION : Swivel Access Point Antenna MODEL NO : RFA-02-C2H1-16W-120 1.1 ELECTRICAL Frequency Range: 2400~2500 MHZ Gain: 2.5dBi (min.) VSWR: Љ 2 Polarization: Linear, Vertical ImpedanceΚ 50Ө Connector: IPEX MHF Cable: RG178W 1.2 MECHANICAL ConditionΚNon operating during test. Material : PCABS(UL94V-0) Endurance Number of 90° rotation of the connectorΚ1000 cycles (min.) MandatoryΚGuaranty of functionalities after test. Bending: Number of 90̓at the hinge parts and bending on one direction with1 ц forceΚ1000 cycles MandatoryΚNo mechanical damage tolerated. Guaranty of functionalities after test. Antenna resistance Tests are applicable to all parts and both sides. Traction: Tractions force applied 3 times on plugs during 15 secondΚ5ц MandatoryΚNo mechanical damage tolerated. Guaranty of functionalities after test. 1.3 ENVIROMENTAL Storage ConditionΚNon operating during test. Cold: -40к during 72h (IEC 68-2-1 standard Ab/Ad test) Dry heat: +80к during 96h (IEC 68-2-2 standard Bb/Bd test) Humidity: +40к at 95%R.H. during 4 days (IEC 68-2-56 standard Cb test) MandatoryΚNo mechanical or visible damage tolerated. Guaranty of functionalities after test. Operation ConditionΚOperating during test. Cold: -10к during 48h (IEC 68-2-1 standard Ab/Ad test) Dry heat: +55к during 48h (IEC 68-2-2 standard Bb/Bd test) Composite: -10кto +55к 95%R.H 4 cycles(IEC 68-2-30 standard Nb test) MandatoryΚNo mechanical or visible damage tolerated. Guaranty of functionalities during and after test.














































































































SPECIFICATION FOR APPROVAL ˗ˢ˖˨ˠ ̆ˡ˧ˍ A30178B001 ˦˧ˬ˟ ̆Κʳ 200к 30V RG-178B/U SIZE: ʳʳʳ 7/0.102 SCCS RECOGNIZED: SPECIFICATION STYLE 200к 30V COAXIAL DOCUMENT NO : A30178B001 SIZERG-178B/U ESTABLISHED DATE: 2000/06/29 STANDARD : MIL-C-17 SizeAWG30 Material---- Silver-Coated Copper Clad Steel Conductors No.----7 Conductors Sizemm0.102 Conductor O.D.mm0.30 Average Thicknessmm0.28 Diametermm0.86 Material----FEP Insulation Color----Clear Material----Silver-Coated Copper Constructionmm16 / 3 / 0.10 Braid Coverage%95 Average Thicknessmm0.25 Diameter mm 1.80̈́0.05 Material----FEP Jacket Color----Brown Marking M17/93-RG178B/U WONDERFUL Drawing AK001/210X297/1.0 PAGE : 1 EDITION:1.0 REVISEDDATE: MAKER: CONFIRM: APPROVAL: ΓWONDERFUL WIRE CABLE CO., LTD SPECIFICATION Electrical & Physical Properties ItemRG-178B/U Rating Temp Voltage 200к 30V Conductor Resistance 838.0 OHM/KM/20к MAX. Insulation Resistance 100 MEGA OHM/KM MIN. Dielectric Strength AC 1.0 KV/Minute Spark Test 0.5 KV Tensile Strength 2500 PSI MIN.( 1.76 Kg / Ӄф) Unaged Elongation200% MIN. Tensile StrengthUNAGED MIN.75%(168HRS×232к) Insulation Aged Elongation UNAGED MIN.75%(168HRS×232к) Tensile Strength 2500 PSI MIN.( 1.76 Kg / Ӄф) Unaged Elongation200% MIN. Tensile StrengthUNAGED MIN.75%(168HRS×232к) Jacket Aged Elongation UNAGED MIN.75%(168HRS×232к) Nom. Impedance 50 Ohms VSWRMAX. 1.3 at 0.4G~3GHz Nom. Vel. of Prop. 69.5% Flame Test VW-1 OK 50MHz 100MHz 400MHz 900MHz 1.8GHz3GHz Attenuation (dB/100m) 34.445.991.8139.4207.5308.2 AK001/210X297/1.0 PAGE : 2 EDITION : 1.0 REVISED DATE : MAKER : CONFIRM : APPROVAL :

Compliance Certification Services Inc. Report No: A40415003-RP FCC ID: MAA-PW8540IM Date of Issue: June 3, 2004 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 of 68 FCC 47 CFR PART 15 SUBPART C TEST REPORT For Procomp Informatics Ltd. IEEE 802.11 b/g Access Point Router Model: PW8540IM Trade Name: Procomp Prepared for Procomp Informatics Ltd. 5F, No. 69-10, Chung Cheng E Rd., Ta m s h u i Ta i p e i H s i e n , Ta i w a n , R . O . C . Prepared by Compliance Certification Services Inc. No. 81-1, Lane 210, Bade Rd. 2, Luchu Hsiang, Taoyuan Hsien, (338) Taiwan, R.O.C. TEL: 886-3-324-0332 FAX: 886-3-324-5235 Compliance Certification Services Inc. Report No: A40415003-RP FCC ID: MAA- PW8540IM Date of Issue: June 3, 2004 Page 2 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION....................................................................................................3 2. EUT DESCRIPTION ...........................................................................................................................4 3. TEST METHODOLOGY ....................................................................................................................5 3.1 EUT CONFIGURATION........................................................................................................................5 3.2 EUT EXERCISE....................................................................................................................................5 3.3 GENERAL TEST PROCEDURES.............................................................................................................5 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS........................................................6 3.5 DESCRIPTION OF TEST MODES...........................................................................................................6 4. INSTRUMENT CALIBRATION........................................................................................................7 5. FACILITIES AND ACCREDITATIONS ..........................................................................................8 5.1 FACILITIES....................................................................................................................................... 8 5.2 EQUIPMENT........................................................................................................................................8 5.3 LABORATORY ACCREDITATIONS AND LISTING..................................................................................8 5.4 TABLE OF ACCREDITATIONS AND LISTINGS.......................................................................................9 6. SETUP OF EQUIPMENT UNDER TEST .......................................................................................10 6.1 SETUP CONFIGURATION OF EUT.......................................................................................................10 6.2 SUPPORT EQUIPMENT ...............................................................................................................10 7. FCC PART 15.247 REQUIREMENTS.............................................................................................11 7.1 6DB BANDWIDTH.............................................................................................................................11 7.2 PEAK POWER....................................................................................................................................16 7.3 BAND EDGES MEASUREMENT ................................................................................................21 7.4 PEAK POWER SPECTRAL DENSITY....................................................................................................30 7.5 RADIO FREQUENCY EXPOSURE........................................................................................................35 7.6 SPURIOUS EMISSIONS ................................................................................................................38 7.7 POWERLINE CONDUCTED EMISSIONS...............................................................................................60 APPENDIX 1 PHOTOGRPHS OF TEST SETUP .................................................................................67 Compliance Certification Services Inc. Report No: A40415003-RP FCC ID: MAA- PW8540IM Date of Issue: June 3, 2004 Page 4 2. EUT DESCRIPTION Product IEEE 802.11 b/g Access Point Router Trade Name Procomp Model Number PW8540IM Model Discrepancy N/A Manufacture: SINCHO INTERNATIONAL INC. Model Number: SW12-050U I/P: AC 100-240V, 50-60Hz, 260mA, O/P: DC 5V, 2A, 12VA MAX Manufacture: ENTERPRISE CO., LTD. Model Number: SL15A205-R I/P: AC 100-240V, 50-60Hz, 0.5A, O/P: DC +5V, 2.5A Power Supply Manufacture: HJC Model Number: HAPU05B1 I/P: AC 100-240V, 50-60Hz, 260mA, O/P: DC 5.0V, 2.6A Frequency Range 2412 ~ 2462 MHz Transmit Power 802.11b mode: 18.84dBm 802.11g mode: 13.51dBm Modulation Technique 802.11b: DSSS (CCK; DQPSK; DBPSK) 802.11g: OFDM Transmit Data Rate 802.11b: 11Mbps(CCK) with fall back rates of 5.5, 2, and 1Mbps 802.11g: 54Mbps with fall back rates of 48/36/24/18/12/9/6 Mbps (OFDM) Number of Channels 11 Channels Antenna Specification Dipole Antenna / Gain: 2.09 dBi (Max) Note: This submittal(s) (test report) is intended for FCC ID: MAA-PW8540IM filing to comply with Section 15.207, 15.209 and 15.247 of the FCC Part 15, Subpart C Rules. Compliance Certification Services Inc. Report No: A40415003-RP FCC ID: MAA- PW8540IM Date of Issue: June 3, 2004 Page 5 3. TEST METHODOLOGY The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 2.1046, 2.1047, 2.1049, 2.1051, 2.1053, 2.1055, 2.1057, 15.207, 15.209 and 15.247. 3.1 EUT CONFIGURATION T…
