MCDFFPA8689-120Model FFPA8689-120 Feed-Forward Multi-Channel

Microwave Power Devices Inc

Click to zoom

Application Details

Equipment Class: AMP - Amplifier
Date of Grant: Apr 17, 2000
Application Purpose: Original Equipment
Date of Application: Nov 18, 1999
Equipment Note: Model FFPA8689-120 Feed-Forward Multi-Channel
Frequency Range: 869.00000000 - 894.00000000
Company: Microwave Power Devices Inc
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

M P D T E C H N O L O G I E S , I N C . 49 WIRELESS BOULEVARD HAUPPAUGE, NEW YORK 11788 (516)231-1400 FAX (516)231-8081 MODEL HPC8689-400 INSTALLATION AND OPERATION INSTRUCTIONS FOR COMBINER SHELF ASSEMBLY PREPARED SEPTEMBER 1, 1999 NOTICE PROPRIETARY AND PRIVATE The information contained in this document is the property of Microwave Power Devices, Inc. (MPD), and shall be kept in strict confidence. Except with the written permission of MPD, such information shall not be published, or disclosed to others, or used for manufacture or sale or for any other purpose. This document shall not be duplicated in whole or in part. Any recipient so agrees by acceptance of this document. MPD TECHNOLOGIES, INC. Model HPC8689-400 PM/HPC8689400R1.DOC-9911012 © 1999 - MPD TECHNOLOGIES, INC. Publication # & Edition MPD Technologies Incorporated 49 Wireless Boulevard Hauppauge NY USA 11788. MPD Technologies Incorporated provides this manual “as is” without warranty of any kind, either expressed or implied. MPD Technologies may make improvements or changes in the product and manual at any time without notice. This manual may include technical inaccuracies or typographical errors. Changes are periodically made to the information herein, these changes may be incorporated in new editions of this publication. MPD Technologies is interested in receiving comments from the users of this manual in order to improve its usefulness. All comments should directed to the address listed below. MPD Technologies may use or distribute any of the information supplied in any way it believes appropriate, without incurring any obligations. All specifications are subject to change without notice. Warning - If the equipment appears to be damaged in any way, remove all power to the unit and it serviced as soon thereafter as possible. The use of an earth ground is required to ensure safety. MPD TECHNOLOGIES, INC. Model HPC8689-400 PM/HPC8689400R1.DOC-9911013 © 1999 - MPD TECHNOLOGIES, INC. Warranty MPD Technologies offers a Limited Warranty of 12 months from the date of original shipment unless otherwise agreed to in writing. Any warranty is void (1) if the equipment has been subject to unauthorized alteration, modification or repair or (2) defects or failures resulting from improper handling, storage, operation, interconnection or installation; failure to continually provide a suitable installation and operational environment; or any other cause beyond the range of normal usage for the equipment (except, in all of the foregoing cases, when caused by MPD). Return Procedures Your MPD amplifier has been extensively tested and inspected prior to shipment to ensure proper operation at time of delivery and beyond. However, should your equipment fail to operate properly, return the failed unit to MPD using a Return Authorization number. To obtain a Return Authorization number, contact the customer service department during business hours 8 A.M. to 5 P.M. Eastern Standard Time. The customer shall be responsible for the return of the equipment to MPD and packed to ensure safe arrival. MPD shall return repaired, amended or altered equipment, packed to ensure safe arrival to the Customer’s designated location. Limitation of Liability In no event will MPD Technologies be liable to customer or anyone else for special collateral, exemplar, indirect, incidental or consequential damages, loss of goodwill, loss of profits or revenues, loss of savings, loss of life, interruptions of business, and claims of customers, whether such damages occur prior or subsequent to or are alleged as a result of tortuous conduct, even if MPD Technologies has been advised of the possibility of such damages. Table of Contents 1. GENERAL DESCRIPTION.......................................................................................................5 1.1 Introduction...........................................................................................................................................5 MPD TECHNOLOGIES, INC. Model HPC8689-400 PM/HPC8689400R1.DOC-9911014 © 1999 - MPD TECHNOLOGIES, INC. 1.2 General Description..............................................................................................................................5 1.3 Equipment Functional and Physical Specifications...........................................................................7 2. INSTALLATION........................................................................................................................8 2.1 Introduction...........................................................................................................................................8 2.2 Electrical Service Recommendations..................................................................................................8 2.3 Receiving, Unpacking and Inspection.................................................................................................8 2.4 Repackaging for Shipment...................................................................................................................8 2.5 Environmental Limitations..................................................................................................................9 2.6 Installation.............................................................................................................................................9 2.7 Cable Interconnections.......................................................................................................................12 2.8 DC Power Wiring................................................................................................................................12 2.9 I/O Connector......................................................................................................................................12 2.10 RF In/Out Connections.....................................................................................................................12 2.11…

Text truncated - open the document above for the full version.

Users Manual

M P D T E C H N O L O G I E S , I N C . 49 WIRELESS BOULEVARD HAUPPAUGE, NEW YORK 11788 (516)231-1400 FAX (516)231-8081 MODEL FFPA8689-120 INSTALLATION, OPERATION AND MAINTENANCE INSTRUCTIONS FOR FEED FORWARD POWER AMPLIFIER PREPARED SEPTEMBER 1, 1999 NOTICE PROPRIETARY AND PRIVATE The information contained in this document is the property of Microwave Power Devices, Inc. (MPD), and shall be kept in strict confidence. Except with the written permission of MPD, such information shall not be published, or disclosed to others, or used for manufacture or sale or for any other purpose. This document shall not be duplicated in whole or in part. Any recipient so agrees by acceptance of this document. MPD TECHNOLOGIES, INC. Model FFPA8689-120 PM/8689120R1.DOC-9911012 © 1999 - MPD TECHNOLOGIES, INC. 1. Publication # & Edition MPD Technologies Incorporated 49 Wireless Boulevard Hauppauge NY USA 11788. MPD Technologies Incorporated provides this manual “as is” without warranty of any kind, either expressed or implied. MPD Technologies may make improvements or changes in the product and manual at any time without notice. This manual may include technical inaccuracies or typographical errors. Changes are periodically made to the information herein, these changes may be incorporated in new editions of this publication. MPD Technologies is interested in receiving comments from the users of this manual in order to improve its usefulness. All comments should directed to the address listed below. MPD Technologies may use or distribute any of the information supplied in any way it believes appropriate, without incurring any obligations. All specifications are subject to change without notice. Warning - If the equipment appears to be damaged in any way, remove all power to the unit and it serviced as soon thereafter as possible. The use of an earth ground is required to ensure safety. MPD TECHNOLOGIES, INC. Model FFPA8689-120 PM/8689120R1.DOC-9911013 © 1999 - MPD TECHNOLOGIES, INC. Warranty MPD Technologies offers a Limited Warranty of 12 months from the date of original shipment unless otherwise agreed to in writing. Any warranty is void (1) if the equipment has been subject to unauthorized alteration, modification or repair or (2) defects or failures resulting from improper handling, storage, operation, interconnection or installation; failure to continually provide a suitable installation and operational environment; or any other cause beyond the range of normal usage for the equipment (except, in all of the foregoing cases, when caused by MPD). Return Procedures Your MPD amplifier has been extensively tested and inspected prior to shipment to ensure proper operation at time of delivery and beyond. However, should your equipment fail to operate properly, return the failed unit to MPD using a Return Authorization number. To obtain a Return Authorization number, contact the customer service department during business hours 8 A.M. to 5 P.M. Eastern Standard Time. The customer shall be responsible for the return of the equipment to MPD and packed to ensure safe arrival. MPD shall return repaired, amended or altered equipment, packed to ensure safe arrival to the Customer’s designated location. Limitation of Liability In no event will MPD Technologies be liable to customer or anyone else for special collateral, exemplar, indirect, incidental or consequential damages, loss of goodwill, loss of profits or revenues, loss of savings, loss of life, interruptions of business, and claims of customers, whether such damages occur prior or subsequent to or are alleged as a result of tortuous conduct, even if MPD Technologies has been advised of the possibility of such damages. Table of Contents 1. GENERAL DESCRIPTION.......................................................................................................5 1.1 Introduction...........................................................................................................................................5 MPD TECHNOLOGIES, INC. Model FFPA8689-120 PM/8689120R1.DOC-9911014 © 1999 - MPD TECHNOLOGIES, INC. 1.2 General Description..............................................................................................................................6 1.3 Equipment Functional and Physical Specifications...........................................................................8 1.4 Mechanical Description........................................................................................................................8 2. INSTALLATION........................................................................................................................9 2.1 Introduction...........................................................................................................................................9 2.2 Electrical Service Recommendations................................................................................................10 2.3 Receiving, Unpacking and Inspection...............................................................................................10 2.4 Repackaging for Shipment.................................................................................................................11 2.5 Environmental Limitations................................................................................................................11 2.6 Installation...........................................................................................................................................11 2.7 Cable Interconnections.......................................................................................................................12 2.8 I/O Connector Wiring.........................................................................................................................12 2.9 Verify Connections.............................................................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

List of Enclosures Enclosure 1 FCC Part 2 FFPA 8689-120 Information Enclosure 1A Confidentiality Enclosure 2 Comparison of Amplifier Input to Output for Distortion Enclosure 3 Comparison of Amplifier Input to Output for Distortion Part 2 Enclosure 4 Conducted and Radiated Spurious and Harmonic Emissions Measurements Enclosure 5 Two Signal Inter-modulation Distortion Measurements Enclosure 6 General manual Combiner shelf assembly 2 Enclosure 7 General manual G8 120w b Enclosure 8 Pictures and Labels Enclosure 9 Test Setup Photos Enclosure 10 IEEE C95.1 Enclosure 11 Schematics and drawings Enclosure 12 Test Equipment List

Cover Letter(s)

This document is MPD propriety and its use is governed by all applicable non-disclosure agreements ENCLOSURE #1 2.983 (a)NAME of MANUFACTURER MPD Technologies, Inc. 49 Wireless Boulevard Hauppauge, New York 11788-3935 2.983 (b)IDENTIFICATION of EQUIPMENT Feed Forward Power Amplifier, Model FFPA 8689-120, Part Number EB501420. Combiner Shelf Assembly, Model HPC8689-400 Part Number EB501095. 2.983 (c)QUANTITY PRODUCTION Quantity production is planned. 2.983 (d)TECHNICAL DESCRIPTION of EQUIPMENT The FFPA 8689-120 is a multi-carrier feed forward power amplifier designed for cellular base station application. It is entirely solid-state and powered by an external 27 VDC power supply. A complete technical description is provided in the Installation, Operation, and Instructions Manuals {Enclosure 6&7}, and Detailed Circuit Diagrams {Enclosure 11}. 2.983 (d1)TYPES of EMISSION The emissions designators are TBD. 2.983 (d2)FREQUENCY RANGE 869-894 MHz 2.983 (d3)RANGE of OPERATING POWER The amplifier has a fixed gain of 60 ±0.25 dB. The output power is dependent on the applied input power. Under normal operating conditions the maximum average output power of 120 watts is not exceeded. The amplifier’s dynamic range is 20 dB. 2.983 (d4)MAXIMUM POWER RATING The maximum RF output power rating is 120 watts average. 2.983 (d5)DC VOLTAGE & CURRENT of FINAL TRANSISTOR STAGE See enclosure 11 2.983 (d6)FUNCTION of ACTIVE DEVICES Refer to Enclosures 6,7 & 11. This document is MPD propriety and its use is governed by all applicable non-disclosure agreements 2.983 (d7)COMPLETE CIRCUIT DIAGRAMS Refer to Enclosure 11. 2.983 (d8)INSTRUCTION BOOKS Refer to Enclosures 6&7. 2.983 (d9)Tune-Up Procedure The unit is aligned to specifications after being manufactured at the factory. There are no user adjustments or tune-up procedures. 2.983 (d10)Description of Frequency Determining/Stabilizing Circuits and Devices The power amplifier does not affect the frequency characteristics of the signals that it amplifies. 2.983 (d11)Description of Circuits Suppressing Spurious & Limiting Power The unit is a solid-state linear power amplifier; no special or unusual circuitry is utilized to suppress spurious or limit power. 2.983 (d12)Description of Digital Modulation Methods Used The power amplifier does not modulate the external signals applied to it. 2.983 (e)Test and Measurement Data Underwriter Laboratories is providing all required test data. 2.983 (f)Photograph/Drawing of Equipment Identification Plate/Label Refer to Enclosure 8, Figures 8 & 12. 2.983 (g)Photographs of Equipment Refer to Enclosure 8, Figures 1-7 & 9-11 pictures. 2.983 (h)Encoder Devices Not applicable. 2.983 (i)Equipment for Use in Amateur Radio/RF Power Amplifier Kit Not applicable. The equipment is not available as a kit. 2.983 (j)AM Broadcast Stereophonic Exciter-Generator Not applicable.

Cover Letter(s)

a subsidiary of Microwave Power Devices, Inc. 49 WIRELESS BOULEVARD HAUPP AUGE, NEW YORK 11788-3935 (516) 231- 1400 Fax: ( 516) 231-8081 MPD TECHNOLOGIES, INC. November 9, 1999 Federal Communications Commission Office of Engineering Technology 7435 Oakland Mills Road Columbia Maryland 21046 Gentlemen: In applying for certification (type acceptance) for the Feed Forward Power Amplifier FFPA8689-120, and Combiner Shelf Assembly HPC8689-400, MPD requests that certain items be withheld from public inspection. This request is made in accordance with FCC section 0.459 (a) & (b). The documentation submitted for review with the request for type certification includes trade secrets, which if made publicly available would seriously injure MPD’s competitive advantage. MPD’s competition could gain advantage by studying these documents and acquire the unique design features of our amplifier. These unique design features are MPD’s trade secrets that allow MPD to competitively produce an amplifier with respect to the number of carriers, modulation standards, and power level(s), etc.,. The documents that MPD requests confidentiality (Non-disclosure) are: Enclosure Two &Three:Specific description of circuits in the Feed Forward Power Amplifier and Shelf Assembly. Enclosure Four:Detailed circuit diagrams and assembly drawings in the Feed Forward Power Amplifier and Shelf Assembly. Regards, Murat Ero n, Ph.D., Director of Engineering Wireless Products

Cover Letter(s)

a subsidiary of Microwave Power Devices, Inc. 49 WIRELESS BOULEVARD HAUPP AUGE, NEW YORK 11788-3935 (516) 231- 1400 Fax: ( 516) 231-8081 MPD TECHNOLOGIES, INC. March 7, 2000 Federal Communications Commission Office of Engineering Technology 7435 Oakland Mills Road Columbia Maryland 21046 Gentlemen: This document is in response to FCC Correspondence Reference Number 12090 & 12479. These FCC references concern emissions classification designators and MPE limits for FCC ID MCDFFPA8689-120, 731 Confirmation # EA96034. The following are the emissions classification designators for the MPD ampilifier: Type Emission Designator AMPSF8W {conventional AMPS} AMPSF1D {wideband data of conventional AMPS} TDMADXW CDMAF9W MPE levels are not needed at the amplifier level for the MPE is considered after the amplifier gets integrated into the base statio n and the base statio n is certified. 2FSK modulation type is not needed for this amplifier at this time. MPD’s request for Confidentiality letter is being submitted along with this document. According to Mr. Frank Coperich, this co nfidentiality request letter was missing. Best Regards, Patrick K. Madigan Application & Project Engineer Wireless Products

External Photos

Enclosure #5 Pictures and Marketing Labels Figure 1. Front of FFPA8689-120 Figure 2. Side View #1 of FFPA8689-120 Figure 3. Back View of FFPA8689-120 Figure 4. Side View #1 of FFPA8689-120 Figure 5. Side View #2 of FFPA8689-120 Figure 6. Side View #1 Model FFPA8689-120 Figure 7. Side View #2 Model FFPA8689-120 MPD TECHNOLOGIES, INC. a subsidiary of Microwave Power Devices, Inc. Hauppauge, NY 11788 Feed Forward Amplifier AssyMODEL FFPA8689-120 PART NO.: DB501420SERIAL NO. xxxxxx-xx FCC ID: MCDFFPA8689-120 Figure 8. Proposed Marketing Label Figure 9. Front View of HPC8689-400 Figure 10. Back View of HPC8689-400 Figure 11. Bottom View of HPC8689-400 MPD TECHNOLOGIES, INC. a subsidiary of Microwave Power Devices, Inc. Hauppauge, NY 11788 Combiner Shelf AssyMODEL HPC8689-400 PART NO.: EB501095SERIAL NO. xxxxxx-xx FCC ID: MCDHPC8689-400 Figure 12. Proposed Marketing label

ID Label/Location Info

a subsidiary of Microwave Power Devices, Inc. 49 WIRELESS BOULEVARD HAUPPAUGE, NEW YORK 11788-3935 (631) 231-1400 Fax: (631) 231-4084 MPD TECHNOLOGIES, INC. May 15, 2001 Ms. Juanice Green Federal Communications Commission Office of Engineering & Technology 7435 Oakland Mills Road Columbia MD 21046 Dear Ms. Juanice Green: The following page of this enclosure contains the drawing and sketch where the identification label will be placed on the MPD amplifier. The FCC ID number of the MPD amplifier is MCDFFPA8689-120. If there are any other questions, please feel free to contact us. Best Regards, Patrick K. Madigan Application & Project Engineer Wireless Products MPD Technologies Inc. 49 Wireless Boulevard Hauppauge NY 11788 Phone: 1 631 231 1400 ext 610 Fax: 1 631 231 4084 E-Mail: [email protected] a subsidiary of Microwave Power Devices, Inc. 49 WIRELESS BOULEVARD HAUPPAUGE, NEW YORK 11788-3935 (631) 231-1400 Fax: (631) 231-4084 MPD TECHNOLOGIES, INC. MPD TECHNOLOGIES, INC. a subsidiary of Microwave Power Devices, Inc. Hauppauge, NY 11788 Feed For ward Amplifier Assy Model FFPA8689-120 PART NO.: DB501420 Serial No. xxxxxx- xx FCC ID: MCDFFPA8689-120 Figure 1. Model FFPA8689-120 Label Location

ID Label/Location Info

a subsidiary of Microwave Power Devices, Inc. 49 WIRELESS BOULEVARD HAUPPAUGE, NEW YORK 11788-3935 (631) 231-1400 Fax: (631) 231-4084 MPD TECHNOLOGIES, INC. May 8, 2001 Ms. Juanice Green Federal Communications Commission Office of Engineering & Technology 7435 Oakland Mills Road Columbia MD 21046 Dear Ms. Juanice Green: The following page of this enclosure contains the drawing and sketch where the identification label will be placed on the MPD amplifier. The FCC ID number of the MPD amplifier is MCDFFPA8689-120. If there are any other questions, please feel free to contact us. Best Regards, Patrick K. Madigan Application & Project Engineer Wireless Products MPD Technologies Inc. 49 Wireless Boulevard Hauppauge NY 11788 Phone: 1 631 231 1400 ext 610 Fax: 1 631 231 4084 E-Mail: [email protected] a subsidiary of Microwave Power Devices, Inc. 49 WIRELESS BOULEVARD HAUPPAUGE, NEW YORK 11788-3935 (631) 231-1400 Fax: (631) 231-4084 MPD TECHNOLOGIES, INC. MPD TECHNOLOGIES, INC. a subsidiary of Microwave Power Devices, Inc. Hauppauge, NY 11788 Feed For ward Amplifier Assy Model FFPA8689-120 PART NO.: DB501420 Serial No. xxxxxx- xx FCC ID: MCDFFPA8689-120 Figure 1. Model FFPA8689-120 Label Location

ID Label/Location Info

Internal Photos

Enclosure #8 Pictures and Marketing Labels Figure 1. Front of FFPA8689-120 Figure 2. Side View #1 of FFPA8689-120 Figure 3. Back View of FFPA8689-120 Figure 4. Side View #1 of FFPA8689-120 Figure 5. Side View #2 of FFPA8689-120 Figure 6. Side View #1 Model FFPA8689-120 Figure 7. Side View #2 Model FFPA8689-120 MPD TECHNOLOGIES, INC. a subsidiary of Microwave Power Devices, Inc. Hauppauge, NY 11788 Feed Forward Amplifier AssyMODEL FFPA8689-120 PART NO.: DB501420SERIAL NO. xxxxxx-xx FCC ID: MCDFFPA8689-120 Figure 8. Proposed Marketing Label Figure 9. Front View of HPC8689-400 Figure 10. Back View of HPC8689-400 Figure 11. Bottom View of HPC8689-400 MPD TECHNOLOGIES, INC. a subsidiary of Microwave Power Devices, Inc. Hauppauge, NY 11788 Combiner Shelf AssyMODEL HPC8689-400 PART NO.: EB501095SERIAL NO. xxxxxx-xx FCC ID: MCDHPC8689-400 Figure 12. Proposed Marketing label

Test Report

10/5/99 MPD Test Equipment TEST EQUIPMENTMODEL #S/NUL# HP Power MeterEPM-441AGB37481498 Rohde & Schwarz Sig. Gen. SMT03DE24645 RDL Distortion Simulators IMD-803D-02018 Rohde & Schwarz Sig. Gen. SMIQ 03EDE24310 Rohde & Schwarz Sig. Gen. SMIQ 03BDE26726 HP System DC Power Supply 6673A3501A-00887 Bird Electronic Termaline Coaxial Resistor 825114207 CelwaveCV90-1434Q-12-95-A003 Bandpass Filter869-894 MHz (2) Narda 30 dB Directional Couplers CEL304707480 HP 30 dB Attn.331BA064055A-368 JFN Industries (2) Variable Attenuators 50BR-017239162 JFN Industries50BR-017168188 2 Way Divider Mini Circuits Zadd-960-20W 1554209739 Toshiba Laptop PA1215UV01642492 HP 11692D Directional Coupler 2-18 GHz 1212A00834 Advantest Spectrum Analyzer R3261CJ0025035A-229 Advantest PreselectorR3551J0025675A-228 View Sonic MonitorP655EB80102503 Texas Micro CompitorVPR-MB980952 HP Printer 1600cmC3541AUSB85025

Test Report

Project Number: 99ME45100Issue Date: November 19, 1999 File Number: NC3932 Model: FFPA-8689-120 (Amplifier) and HPC8689-400 (Shelf) FCC ID: MCD FFPA8689-120 Underwriters Laboratories Inc. 1285 Walt Whitman Road Melville, New York 11747-3081 (516) 271-6200 Report of Measurements of Electromagnetic Compatibility Testing Test Report File No.:NC3932Date of issue: November 19, 1999 Applicant:Microwave Power Devices Model / Serial No.:FFPA8689-120-8(Amplifier) and HPC8689- 400(Shelf) Product Type:Amplifier and Sub-Assembly Shelf Power Supply:-48Vdc Manufacturer:Same as Applicant License holder:Same as Applicant Address:49 Wireless Blvd. :Hauppauge, NY 11788 Test Result:x Positive® Negative Test Project Number:99ME45100 References(s) Underwriters Laboratories Inc. authorizes the above-named company to reproduce this Report provided it is reproduced in its entirety. Underwriters Laboratories Inc. reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. Underwriters Laboratories Inc. shall have no liability for any deductions, inferences or generalizations drawn by the client or others from Underwriters Laboratories Inc. issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. Project Number: 99ME45100Issue Date: November 19, 1999 File Number: NC3932 Model: FFPA-8689-120 (Amplifier) and HPC8689-400 (Shelf) FCC ID: MCD FFPA8689-120 Report Directory TitleSection x General Product Description1.0 x Device Configuration During Test1.1 xAmplifier Input/Output Distortion2.1.1 x Conducted and Radiated Spurious Emissions2.2.2 x Intermodulation Distortion2.2.3 x IEEE C95.1 Full Body Exposure Measurements2.2.4 x Photograhps and Diagrams Project Number: 99ME45100Issue Date: November 19, 1999 File Number: NC3932 Model: FFPA-8689-120 (Amplifier) and HPC8689-400 (Shelf) FCC ID: MCD FFPA8689-120 1.0G E N E R A L - Product Description The unit under test is a high power cellular amplifier. The unit can be operated as a stand-alone device or installed in a distribution rack that allows for multiple amplifiers to be installed for greater power. The unit under test has a maximum output power of 120 watts. 1.1 Device Configuration During Test The unit under test was configured and operated by the manufacturer throughout the tests. The unit was configured to produce a maximum output for all signaling techniques. The following is a list of available signaling techniques: CW, TDMA, CDMA, 2 FSK, and modulated CW Project Number: 99ME45100Issue Date: November 19, 1999 File Number: NC3932 Model: FFPA-8689-120 (Amplifier) and HPC8689-400 (Shelf) FCC ID: MCD FFPA8689-120 Comparison of Amplifier Output to Amplifier Input for Distortion The amplifier, which was tested both installed in a distribution rack and as a stand-alone device, was injected with a CW signal at the fundamental frequency. The input was adjusted to produce and output of 50.8dBm when the unit was tested as a stand-alone amplifier and 50dBm when tested in the shelf. These values produced the maximum power at the amplifiers output connector. Prior to injecting the signal into the amplifier, the input was examined and printed for comparison purposes. The signal was then injected into the amplifier and the output was analyzed to detect any distortion produced by the amplifier. The amplifier, which was tested both installed in a distribution rack and as a stand-alone device, was injected with a CW signal modulated with 1-kHz with a deviation of 5kHz at the fundamental frequency. . The input was adjusted to produce and output of 50.8dBm when the unit was tested as a stand-alone amplifier and 50dBm when tested in the shelf. These values produced the maximum power at the amplifiers output connector. Prior to injecting the signal into the amplifier, the input was examined and printed for comparison purposes. The signal was then injected into the amplifier and the output was analyzed to detect any distortion produced by the amplifier. The amplifier, which was tested both installed in a distribution rack and as a stand-alone device, was injected with a CDMA signal at the fundamental frequency. The input was adjusted to produce and output of 50.8dBm when the unit was tested as a stand-alone amplifier and 50dBm when tested in the shelf. These values produced the maximum power at the amplifiers output connector. Prior to injecting the signal into the amplifier, the input was examined and printed for comparison purposes. The signal was then injected into the amplifier and the output was analyzed to detect any distortion produced by the amplifier. The amplifier, which was tested both installed in a distribution rack and as a stand-alone device, was injected with a TDMA signal at the fundamental frequency. The input was adjusted to produce and output of 50.8dBm when the unit was tested as a stand-alone amplifier and 50dBm when tested in the shelf. These values produced the maximum power at the amplifiers output connector. Prior to injecting the signal into the amplifier, the input was examined and printed for comparison purposes. The signal was then injected into the amplifier and the ou…

Text truncated - open the document above for the full version.
