MCL60519WWireless USB Station

USB Wireless Card Ambit Model Name : 60519W AMBIT Wireless High Rate USB station complied with IEEE 802.11b 11Mbps Standard, it can be used to provide a variety of low-cost wireless network interface card to connect your wireless LAN via fitting into the USB 1.1 connector. The Wireless High Rate USB station that complies with this specification and combines networking with high-speed Internet access will let people connect to the Internet anywhere, anytime. With seamless roaming, fully interoperability and advanced security with WEP standard, Wireless High Rate USB station can allow user to switch to different vendors’ Access Points through the wireless networks and to prevent from eavesdropping. Function l Compatible with IEEE 802.11b high rate standard to provide wireless Ethernet speeds of 11Mbps data rate l Dynamic data rate switching with 11, 5.5, 2 and 1Mbps l Allows auto fallback data rate for optimized reliability, throughput and transmission range l Supports wireless data encryption with 64/128-bit WEP standard for security l Integrated Microstrip dual diversity antennas for the multipath environment l USB station fully support USB 1.1 defined mechanical and environmental stress conditions l Drivers supports Windows 95, 98, 98SE, ME, 2000, NT l WIFI Certified Specification Dynamic rate shifting1, 2, 5.5, 11Mbit (Auto-selects highest usable rate) Network standard(s)IEEE 802.11b High rate Frequency 2.4 ISM band Wireless MediumDirect sequence spread spectrum EncryptionEncryption option; 64bit encryption option; 128bit encryption option ModulationDBPSK @ 1Mbps; DQPSK @ 2Mbps; CCK @ 5.5Mbps and 11Mbps Operating channel11 channels (U.S. and Canada); 13 channels (Europe); 14 channels (Japan) RoamingIAPP CertificationFCC Part 15 class B US Unintentional Emissions; FCC Part 15.247, 15.205, 15.209 US Spread Spectrum; DOC RSS-210 Canadian spread spectrum; Europe ETS 300 328, ETS 300 826, CE marked; Japan RCR STD-33; Contact US for other information outside the U.S. Environmental operating ranges Operating temperature: 0 to 55 o C; Storage –20 to 70 o C; Operating Humidity: 90% maximum non-condensing; Notebook slot TypeUSB 1.1 interface Device DriversNDIS 4 Software DriverWindows 95, 98, 98SE, ME, 2000, NT Software UtilityLocation profiles “Current station status”; “Link Test”; Real-time Link Quality & Signal Strength”; ”Configuration NIC”. Network Architecture TypesSupports peer to peer and communication to wired networks via Access Point Operating Range Indoorup to 50M(165ft.) @ up to 11Mbps up to 70M(230ft.) @ up to 5.5Mbps up to 90M(296ft.) @ up to 2Mbps up to 100M(328ft.) @ up to 1Mbps Outdoorup to 152M(500ft.) @ up to 11Mbps up to 270M(885ft.) @ up to 5.5Mbps up to 396M(1300ft.) @ up to 2Mbps up to 457M(1500ft.) @ up to 1Mbps AntennaIntegrated internal diversity antenna. LED IndicatorsLink Activity Receive Sensitivity-90dbm @ 1Mbps; -88dbm @ 2Mbps; -86dbm @ 5.5bps; -84dbm @ 11bps Output power Typical 13dbm. Power 5V DC;Transmit 380mA typical (500mA max); Receive 215mA typical (300mA max); Sleep 90mA typical (100mA max). Safety complianceUSA/Canada: UL1950/CSA 22.2; Europe: CE marked DimensionsLength 11.02cm/4.34inch; Width 5,66cm/2.23inch; Thickness 5mm/0.20inch; Weigh 1.6oz/45.35g Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution:. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. RF Exposure Warning: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device is provided with an internal antenna and minimum 20 cm spacing must be maintained between this PC C Card and all person’s body (excluding extremities of hands, wrist and feet) during wireless mode of operation. Further, this transmitter must not be co- located or operated in conjunction with any other antenna or transmitter.

From: Country Huang [[email protected]] Sent: Thursday, May 02, 2002 6:46 PM To: Mike Kuo Cc: [email protected] Subject: Fw: FCC ID:MCL60519W, Assessment No:AN02T1981 ----- Original Message ----- From: TECH To: Country Huang Sent: Saturday, April 27, 2002 11:23 PM Subject: Fw: FCC ID:MCL60519W, Assessment ----- Original Message ----- From: Country Huang To: '[email protected]' Sent: Saturday, April 27, 2002 11:00 PM Subject: FCC ID:MCL60519W, Assessment > Notice_content > ------------- > Question #1:Schematic Diagram provided are not readable. Please provide a > clear copy of schematic diagram. > The docus were updated on 4/26. > Question #2: Internal Photos: Please remote the shilding plate on the PCB > and take another photos to show the internal components under the shilding > plate. The docus were updated on 4/26. > Question #3: Please provide MPE data to demonstrate that this device comply > with RF separation distance as mobile device ( 20 cm ). The docus were sent out on 4/26. > Question #4: Output power : The output power indicates in the product > brochure has max. output of 13dBm. However, the highest measured conducted > output reported in the test report is 16.1dBm. Please explain the > difference. The normal max output power of the product is 13dBm which is fixed by manufactor, but we usually ask our client setup the output power reach the max limit. So please kindly let us know if you would like to our client amend their product specialty same as measurement result. > > Question #5: Out of band conducted spurious emission: Please provide antenna> conducted spectrum plots from 30MHz upto 10th harmonics of fundamental > frequency. All harmonics and spurious emission must be at least 20dB below> from the highest emission level within the authorized band as measured with> RBW=100kHz. Please make sure to provide specturm plots for low, middle and> high channel. Please find the modification report sent out on 4//26 which test item was added as you request. > > Question #6: Radiated Bandedge measurement : Please tune the fundamental > frequency at the low channel and measured the the restricted band at > 2390MHz. This is radiated filed strength tests, when you provide the > specturm plots, make sure the marker is positioned on 2390MHz to show the > field strength. Same tests should be done when device is tuned to highest > channel and measured the bandedge requirement at 2483.5MHz. Please find the modification report sent out on 4//26 which test item was added as you request. > > Question #7: Please provide operational description to demonstrate that this> device is complied with Direct Sequence Spread Specturm definition. The docus were sent out on 5/3. > > Question #8: Please provide user manual with information required under > 15.21, 15.105 and RF exposure warning statement. Please refer the last page of our user manual. And we also sent out the warning statement for your evaluation on 4/26. > > Best Regards > > Mike Kuo / TCB Certifier > The items indicated above must be submitted before processing can continue > on the above referenced application. Failure to provide the requested > information within 60 days of the original e-mail date may result in > application dismissal and forfeiture of the filing fee. Also, please note > that partial responses increase processing time and should not be submitted. > Any questions about the content of this correspondence should be directed to > the e-mail address listed below the name of the sender. Dear Mike, Regarding your questions as above mentioned, we provide the answers which red letters. Hope everything is clear now. Whatever, please don't be hestiated to let us know if you have any question. Thanks. Best Regards, Country Huang

From: Country Huang [[email protected]] Sent: Monday, May 06, 2002 6:38 AM To: Mike Kuo Subject: Re: Ambit Microsystems Corporation, FCC ID:MCL60519W, AN02T1981 Notice #2 ----- Original Message ----- From: "Mike Kuo" <[email protected]> To: "Mike Kuo" <[email protected]>; <[email protected]> Sent: Saturday, May 04, 2002 7:10 AM Subject: RE: Ambit Microsystems Corporation, FCC ID:MCL60519W, AN02T1981 Notice #2 > > > -----Original Message----- > From: Mike Kuo > Sent: Friday, May 03, 2002 4:05 PM > To: '[email protected]' > Subject: FW: Ambit Microsystems Corporation, FCC ID:MCL60519W, AN02T1981 > Notice #2 > > > > > -----Original Message----- > From: CERTADM > Sent: Friday, May 03, 2002 4:04 PM > To: '[email protected]' > Subject: Ambit Microsystems Corporation, FCC ID:MCL60519W, AN02T1981 Notice > #2 > > > Notice_content > ------------- > Question #9: Page 27-32 of revised test report, you indicated the technical > limits above 1GHz is 74dBuV/m which is the peak limits. For spurious > emission above 1GHz is 54 dBuV/m with average detector. Since the radiated > emission data you reported are the peak reading, you need to compare the > peak readings with 54 dBuV/m average limits. Only when the peak readings > are under the average limits, you are not required to report the average > readings. Otherwise, you need to use peak readings to compare with the > average limits+20dB for peak limits. Please update these pages with average > limits. O.K! The docus were updated on 5/6. > Question #2: Page 60 of revised test report, the band edge measurement shall > be made on those restricted band close to the fundamental frequencies. The > frequencies that investigated are 23891.5MHz, 24840.76MHz which are not the > closest restricted band. Please redo the measurement. Sorry !!! We have checked the Page 60 and found that TYPE Error . Could you let us correct the mistake ? (23891.5MHz --> 2389.1MHz(right)) The docus were updated on 5/6. > > Best Regards > > Mike Kuo / TCB Certifier > The items indicated above must be submitted before processing can continue > on the above referenced application. Failure to provide the requested > information within 30 days of the original e-mail date may result in > application dismissal and forfeiture of the filing fee. Also, please note > that partial responses increase processing time and should not be submitted. > Any questions about the content of this correspondence should be directed to > the e-mail address listed below the name of the sender. Dear Mike: Sorry!! I correct our mistake and send updata test report to you. I shall be very gratefull indeed for your help!!! Best Regards. Country Huang

MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab

MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab Label Format: Label Position: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference,and (2) This device must accept any interference received ,including. Interference that may cause undesired operation. Model : 60519W FCC ID : MCL60519W MADE IN TAIWAN Rear View Equipment Lable 4.5cmX3.0cm

MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCLT60H519 Technology Lab MAX LIGHT Report Number: MLT0202P15004 FCC ID: MCLT60H519 Technology Lab

60519W Antenna Specification Antenna 1: Wire length: 1006.9mils Wire width: 42mils 60519W Antenna Specification Antenna 2: Wire length: 1118.6mils Wire width: 42mils

MAX LIGHT MEASUREMENT REPORT Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab M M a a x x i i m m u u m m P P e e r r m m i i s s s s i i b b l l e e E E x x p p o o s s u u r r e e EUT : USB Wireless Applicant : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No : 60519W FCC ID : MCL60519W Basis of Calculations: E^2/3770 = S, mW/cm2 E, V/ m = (Pwatts*Ggai n*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5 Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) Test Result: Max RF Power (dBm) TX Antenna Gain (dBi) MPE Safe Distance(cm) 16.10 -0.41 1.72 NOTE: For mobile or fixed location transmitters, minimum separation distance is 20cm, even if calculations indicate MPE distance is less.

1 2 3 4 5 6 7 8 ABCD 8 7 6 5 4 3 2 1 D CBA Title Doc.No. Data:File: REV Rev.Note View Page of 09/07/2000 F:\CHT\T60H519\Circuit\T60H51900.DDB - Documents\WLAN.PRJ Time 13:03:40 SCHEMATIC AMBIT PreparedCheckedApproved T62H209T00 S0 Paul.Chang 8 /UB 40 /LB 39 /WE 17 /OE 41 /CE 6 A0 5 A1 4 A2 3 A3 2 A4 1 A5 44 A6 43 A7 42 A8 27 A9 26 A10 25 A11 24 A12 22 A13 21 A14 20 A15 19 A16 18 GND 12 GND 34 NC 28 NC 23 I/O0 7 I/O1 8 I/O2 9 I/O3 10 I/O4 13 I/O5 14 I/O6 15 I/O7 16 I/O8 29 I/O9 30 I/O10 31 I/O11 32 I/O12 35 I/O13 36 I/O14 37 I/O15 38 VCC 11 VCC 33 U4U/IS62LV12816LL/TSOP44 MA1MA2MA3MA4MA5MA6MA7MA8MA9MA10MA11MA12MA13MA14MA15MA16MA17 MD0MD1MD2MD3MD4MD5MD6MD7MD8MD9MD10MD11MD12MD13MD14MD15 RAMCS* RAMCS* MOE* MOE* MWEL* MWEL* MLBE* MLBE* MWEH MA0 MWEH MA0 MWEH MA0 NVCS* NVCS* MOE*MWEL* MA1MA2MA3MA4MA5MA6MA7MA8MA9MA10MA11MA12MA13MA14MA15MA16MA17 MD0MD1MD2MD3MD4MD5MD6MD7MD8MD9MD10MD11MD13MD14MD15 +3.3V VCCS VCCS VCCS +3.3V +3.3V A11 1 A9 2 A8 3 A13 4 A14 5 NC 6 WE 7 VCC 8 NC 9 A16 10 A15 11 A12 12 A7 13 A6 14 A5 15 A4 16 A3 17 A2 18 A1 19 A0 20 CE 30 A10 31 OE 32 I/O0 21 I/O1 22 I/O2 23 GND 24 I/O3 25 I/O4 26 I/O5 27 I/O6 28 I/O7 29 U2 U/SSTA39VF010/128K*8/TSOP32 MA15MA14MA13MA12MA11MA10MA9MA8MA7MA6MA5MA4MA3MA2MA1MA16 MD0MD1MD2MD3MD4MD5MD6MD7 VCCS VCCS VREF TXQ+TXQ-TXI+TXI-RXQ+RXQ-RXI+RXI-SCLK_RF_IFT/R_SWT/R_SW*RX_IF_AGCRX_RF_AGC ANTSELANTSEL* MD12 MD(0..15) MD(0..15) MA(1..17) MA(0..17) MA(1..17) 44MHZ_REF 44MHZ_REF 2 MA19 A6 MA18 B6 MA17 D5 MA16 A4 MA15 C4 MA14 D4 MA13 A3 MA12 B4 MA11 C3 MA10 A2 MA9 B3 MA8 D2 MA7 D3 MA6 C1 MA5 F4 MA4 E2 MA3 D1 MA2 G4 MA1 F2 MWEH-MA0 F3 MD14 G2 MD0 N2 MD1 P1 MD2 N4 MD3 N3 MD4 N1 MD5 M1 MD6 M4 MD7 L2 MD8 L1 MD9 L4 MD10 L3 MD11 H3 MD12 G1 MD13 H4 MD15 F1 MLBE H2 MOE K2 MWEL K3 RAMCS J3 NVCS J4 VRFE P11 IRFE N12 HA9 A13 HA8 B12 HA7 C12 HA6 A15 HA5 D13 HA4 B14 HA3 E13 HA2 F15 HA1 F16 HA0 H15 VDD T2 VDD M16 VDD M2 VDD K16 VDD J14 VDD H1 VDD G3 VDD E14 VDD B10 VDD B5 VDD B1 VDD A14 VDD A8 VDD N11 VDDA M13 VDDA P12 VDDA R11 VDDA T8 VDDA R8 VDDA N8 RX_IF_AGC N15 RX_RF_AGC L14 RX_IF_DET R10 RXI+ R7 RXI- T7 RXQ+ R9 RXQ- T9 TXI+ R12 TXI- T12 TXQ+ R14 TXQ- T14 TX_IF_AGC N16 ANT_SEL L15 ANT_SEL L16 VSSA N13 VSSA T13 VSSA T11 VSSA N9 VSUB N10 VSUB P10 GND K15 GND K14 HD0 G15 HD1 H14 HD2 H13 HD3 A9 HD4 C7 HD5 D8 HD6 C8 HD7 C11 HD8 H16 HD9 F13 HD10 F14 HD11 C10 HD12 B8 HD13 C6 HD14 C9 HD15 A12 HOE D11 HREG D16 HIORD B11 HIOWR D10 HCE1 B9 HCE2 A10 HINPACK E15 HRDY/HIREQ D9 HSTSCHG G14 HWAIT D14 HWE B13 RESET C16 DBG0 D6 DBG1 B7 DBG2 A7 DBG3 C14 DBG4 B16 TESTMODE K13 TCLKIN(CS) EEPROM P3 PJ2(MISO) EEPROM P2 PJ6(LED1) T3 PJ0(SCLK) EEPROM T1 PJ1(SDATA) EEPROM R1 COMPCAP1 M14 COMPRES1 T15 COMPRES2 P13 COMPCAP2 R13 CLKOUT C5 CLKIN K1 XTALIN J1 XTALOUT J2 BBP_CLK G16 NC E4 NC C2 NC R2 NC N5 NC R3 NC P14 NC R15 NC T16 NC P15 NC R16 NC N14 NC P16 NC C15 NC A16 NC B15 NC D12 NC A1 NC B2 GND P9 GND P5 GND M15 GND M3 GND L13 GND K4 GND G13 GND E16 GND E3 GND E1 GND D7 GND C13 GND A11 GND A5 USB_DET J13 PL6 USB- J15 PL5 USB+ J16 PK3(PA_PE) R6 PK2(SYNTHDATA) N7 PK4(PE2) T5 PJ4(PE1) R4 PJ0(LE_RF) R5 PJ5(LE_IF) P4 PJ7(RADIO_PE) N6 PK7(CAL_EN) P7 TX_AGC_IN T10 PL3(TR_SW) T6 PL7(TR_SW) P6 PK1(SYNTHCLK) T4 VDDA P8 SUPPLY/5V D15 U1ISL3873 PA_PESD_RF_IFPE2PE1LE_RFLE_IFRADIO_PECAL_ENTX_DETIF_DETTX_IF_AGC TXQ+TXQ-TXI-TXI+RXQ+RXQ-RXI+RXI-SCLK_RF_IFT/R_SWT/R_SW*RX_IF_AGCRX_RF_AGC CLKINBBP_CLK IRFE NC 1 A 2 GND 3 Y 4 VCC 5 U177S14 VCCS TP16ICTPOINT TP24ICTPOINT TP1 TP2 TP3 TP4 TP5 TP25 1 2 CASE 3 X1 CMR200T XTAL_OUTXTAL_IN EN 1 VIN 2 VOUT 3 BYP 4 5 6 7 8 (GND) U5MIC5209-3.3BM +3.3V VCCS TP20 +5V USB_D-USB_D+USB_DET +5V USB- USB-USB+USB_DET USB+ VCCS SI 1 SCK 2 RESET 3 CS 4 WP 5 VCC 6 GND 7 SO 8 U3NI AT45DB011 VCCS IF_DET TX_DET CAL_EN RADIO_PE LE_IF LE_RF PE1PE2 SD_RF_IF PA_PE ANTSEL ANTSEL* USB+ USB- USB_DET WLAN1WLAN1.Sch USB_D+USB_D-GND 12 R27 NI R/10K/0402 12 R41 NI R/10K/0402 12 R26 NI R/10K/0402 12 R11 R/10K/0402/5% 12 R29 NI R/10K/0402 12 R42 NI R/10K/0402 12 R46 R/10K/0402/5% 12 R23 NI R/10K/0402/5% 12 C25C/103K/16V/X7R/0402 12 R32R/12.1K/0402/1% 1 2 R30 R/976/0402/1% 1 2 R28 R/619/0402/1% 12 C32 C/104K/16V/X7R/0402 12 C26 C/104K/16V/X7R/0402 12 C30 C/104K/16V/X7R/0402 12 C21 C/104K/16V/X7R/0402 12 C20 C/104K/16V/X7R/0402 12 C10 C/104K/16V/X7R/0402 12 C17 C/104K/16V/X7R/0402 12 C4 C/104K/16V/X7R/0402 12 C8 C/104K/16V/X7R/0402 12 C5 C/104K/16V/X7R/0402 12 C3 C/104K/16V/X7R/0402 12 C14 C/104K/16V/X7R/0402 12 C9 C/106M/6.3V/X5R/0805 12 C81C/104K/16V/X7R/0402 12 C142 C/270K/16V/X7R/0402 12 C31 C/104K/16V/X7R/0402 12 C34 C/106M/6.3V/X5R/0805 1 2 L3 B/BLM21P300S 1 2 L17B/BLM21P300S 12 C102 C/106M/6.3V/X5R/0805 12 R1 R/47K/0402/5% 12 R5 R/47K/0402/5% 12 R7 R/47K/0402/5% 12 R8 R/47K/0402/5% 12 R4 R/47K/0402/5% 12 R10 R/47K/0402/5% 12 R12 R/47K/0402/5% 12 C15C/104K/16V/X7R/0402 12 C2 C/106M/6.3V/X5R/0805 12 C64 C/104K/16V/X7R/0402 12 C37 C/101J/50V/COG/0402 1 2 R85R/47K/0402/5% 1 2 R92 R/20/0402/5% 1 2 R91 R/20/0402/5% 1 2 R93R/1.5K/0402/5% 1 2 C7 C/104K/16V/X7R/0402 1 2 C122 C/104K/16V/X7R/0402 1 2 C1 C/104K/16V/X7R/0402 12 C11 NI C/104K/16V/X7R/0402 1 2 R33 R/19.1K/0402/5% 1 2 R34 R/19.1K/0402/5% 1 2 R2 R/10M/0402/5% 12 R3R/220K/0402/5% 12 C6 C/100J/50V/COG/0402 12 C56C/221K/50V/X7R/0402 1 2 C18 C/104K/16V/X7R/0402 1 2 R14 R/560/0402/5% R9 R/560/0402/5% 1 2 C55 C/104K/16V/X7R/0402 48MHZ_REF 48MHZ_REF R22R/10K/0402/5% 12 C152 C/104K/16V/X7R/0402 12 R21 NI R/47K/0402/5% 12 R54NI R/47K/0402/5% 12 R94 R/220K/0402/5% 12 R13R/47K/0402/5% +5V D+ 2 D- 3 GND 1 VCC 4 D3SR05 V1 VC06LC18X500 VCC 1 D- 2 D+ 3 GND 4 shell 5 shell 6 J3 USB CONNECTOR VCCS 1 2 R16 R/470/0402/5% 1 2 D1D/LED +5VUSB_D+USB_D-GND VCC 1 D- 2 D+ 3 GND 4 shell 5 shell 6 J4 NC/USB CONNECTOR 1 2 3 4 5 6 78 ABCD 8 7 6 5 4 3 2 1 D CBA Title Doc.No. Data:File: REV Rev.Note View Page of 09/03/2001 F:\CHT\T60H519\Circui t\T60H51900.DDB - Documents\WLAN1.Sch Time 13:03:27 SCHEMATIC AMBIT PreparedCheckedApproved S0 Paul.Chang 2 12 R24 R/0/0402/5% 1 2 R15 R/1.5K/0402/1% 12 L1 L/0.56UH/1008 12 R82 R/0/0402/5% 1 2 C27 C/102K/50V/X7R/0402 12 C24 C/220J/50V/…

Text truncated - open the document above for the full version.

P P a a r r t t 1 1 5 5 S S u u b b p p a a r r t t B B & & C C ( ( 1 1 5 5 . . 2 2 4 4 7 7 ) ) Product : USB Wireless Manufacture : AMBIT Microsystems Corporation. FCC ID : MCL60519W Model : 60519W Report No. : MLT0202P15004 Test Date : February 19.2002 Test By Max Light Technology Co.,Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 T T h h e e t t e e s s t t r r e e p p o o r r t t c c o o n n s s i i s s t t s s o o f f 4 4 4 4 p p a a g g e e s s i i n n t t o o t t a a l l . . I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . MAX LIGHT MEASUREMENT REPORT Page: 2/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab Table of Contents : MAX LIGHT MEASUREMENT REPORT Page: 3/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4-1992. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B & C (15.247). EUT : USB Wireless Applicant : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No : 60519W FCC ID : MCL60519W Prepared by : Approved by : MAX LIGHT MEASUREMENT REPORT Page: 4/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 1.1 Introduction The following measurement report is submitted on behalf of AMBIT Microsystems Corporation. . In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart A And B&C of the Commission’s and Regulations. 1.2 Description of EUT EUT : USB Wireless Applicant : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Manufacturer : AMBIT MICROSYSTEMS CORPORATION. 5F-1, 5 Hsin-An Road, Hsinchu Scicnce-Based Industrial Park, Taiwan Model No : 60519W FCC ID : MCL60519W Power Type : Powered by PC Frequency of Channel: See Next page Type of Modulation : Direct Sequence Spread Spectrum Type of Antenna : Printed Antenna During testing the EUT was operated at Tx or Rx mode for each emission measured. This was done in order to ensure that maximum emission levels were attained. MAX LIGHT MEASUREMENT REPORT Page: 5/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab Frequency of Each Channel (Working Frequency) Channel No. Frequency (MHz) 01 2412 02 2417 03 2422 04 2427 05 2432 06 2437 07 2442 08 2447 09 2452 10 2457 11 2462 MAX LIGHT MEASUREMENT REPORT Page: 6/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 1.3 Summary Of Tests 47 CFR Part 15 Subpart C Reference Test Results Note 15.107 AC Power Conducted Emission PASS 15.247(c) Transmitter Radiated Emissions PASS 15.247(b) Max. Output Power PASS 15.247(a)(2) 6dB RF Bandwidth PASS 15.247(d) Max. Power Density PASS 15.247(c) Out of Band Conducted Spurious Emission PASS 15.247(c) Band Edge Measurement PASS 15.247(e) Processing Gain of Direct Sequence PASS Provided by Applicant 15.203 Antenna Requirement PASS MAX LIGHT MEASUREMENT REPORT Page: 7/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 1.4 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4-1991, following equipments were used as the support units. Computer : IBM Model No. : 16W Serial No. : BNC345M FCC ID : FCC(DOC) Keyboard : IBM Model No. : KB-9930 Serial No. : 09N5395 FCC ID : FCC(DOC) Monitor : IBM Model No. : 10L6145 030 Serial No. : 23-092079 FCC ID : ARSCM569N Mouse : IBM Model No. : 0180-05N Serial No. : 23-092079 FCC ID : JNZ211220 Printer : PANASONIC Model No. : KX-P1080I Serial No. : 7CKAKE98933 FCC ID : ACJ5Z6KX-P10801 MAX LIGHT MEASUREMENT REPORT Page: 8/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab Modem : Askey (External Fax / Data Modem) Model No. : WS1414VE Serial No. : IAH-10811 FCC ID : H8N1414VE MAX LIGHT MEASUREMENT REPORT Page: 9/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 1.5 Configuration of System Under Test During testing the EUT(USB Wireless)’s USB port connected to the USB port of IBM computer. So there is No need for additional Ethernet card. A mouse was connected to the mouse port of IBM PC. and A keyboard was connected to the mouse port of IBM PC. And a printer was connected to the parallel port. A external modem connected the serial port and the external modem connected with two unterminated telephone cables on the line and phone jack. TEST SITE Power Supply PC Monitor Printer Modem Keyboard Mouse EUT RJ11C Cables RS-232 RS-232 USB Cable MAX LIGHT MEASUREMENT REPORT Page: 10/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 1.6 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4-1992 "Measurement of unIntentional Radiators." 1.7 General Test Condition The conditions under which the EUT operates were varie…

Text truncated - open the document above for the full version.

MAX LIGHT MEASUREMENT REPORT Page: 12/44 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 2.3 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 13/44 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab Rear View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 22/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab 3.3 Test Configuration: Front View of The Test Configuration MAX LIGHT MEASUREMENT REPORT Page: 23/46 Report Number: MLT0202P15004 FCC ID: MCL60519W Technology Lab Rear View of The Test Configuration
