MCL74487604802.11 a/b/g/n MiniPCI module

Marvell. Moving Forward Faster Doc. No. MV-S800477-00, Rev. B August 14, 2007 CONFIDENTIAL Document Classification: Proprietary Information Cover CB-85/MB-85/EC-85/MC-85 WLAN Client Cards User Guide Document Conventions Note: Provides related information or information of special importance. Caution: Indicates potential damage to hardware or software, or loss of data. Warning: Indicates a risk of personal injury. Document Status Doc Status: 2.00 Technical Publication: 0.x For more information, visit our website at: www.marvell.com Disclaimer No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose, without the express written permission of Marvell. Marvell retains the right to make changes to this document at any time, without notice. Marvell makes no warranty of any kind, expressed or implied, with regard to any information contained in this document, including, but not limited to, the implied warranties of merchantability or fitness for any particular purpose. Further, Marvell does not warrant the accuracy or completeness of the information, text, graphics, or other items contained within this document. Marvell products are not designed for use in life-support equipment or applications that would cause a life-threatening situation if any such products failed. Do not use Marvell products in these types of equipment or applications. With respect to the products described herein, the user or recipient, in the absence of appropriate U.S. government authorization, agrees: 1) Not to re-export or release any such information consisting of technology, software or source code controlled for national security reasons by the U.S. Export Control Regulations ("EAR"), to a national of EAR Country Groups D:1 or E:2; 2) Not to export the direct product of such technology or such software, to EAR Country Groups D:1 or E:2, if such technology or software and direct products thereof are controlled for national security reasons by the EAR; and, 3) In the case of technology controlled for national security reasons under the EAR where the direct product of the technology is a complete plant or component of a plant, not to export to EAR Country Groups D:1 or E:2 the direct product of the plant or major component thereof, if such direct product is controlled for national security reasons by the EAR, or is subject to controls under the U.S. Munitions List ("USML"). At all times hereunder, the recipient of any such information agrees that they shall be deemed to have manually signed this document in connection with their receipt of any such information. Copyright © 2007. Marvell International Ltd. All rights reserved. Marvell, the Marvell logo, Moving Forward Faster, Alaska, Fastwriter, Datacom Systems on Silicon, Libertas, Link Street, NetGX, PHYAdvantage, Prestera, Raising The Technology Bar, The Technology Within, Virtual Cable Tester, and Yukon are registered trademarks of Marvell. Ants, AnyVoltage, Discovery, DSP Switcher, Feroceon, GalNet, GalTis, Horizon, Marvell Makes It All Possible, RADLAN, UniMAC, and VCT are trademarks of Marvell. All other trademarks are the property of their respective owners. CB-85/MB-85/EC-85/MC-85 User Guide Doc. No. MV-S800477-00 Rev. B CONFIDENTIAL Copyright © 2007 Marvell Page 2Document Classification: Proprietary InformationAugust 14, 2007, 2.00 Table of Contents Copyright © 2007 MarvellCONFIDENTIALDoc. No. MV-S800477-00 Rev. B August 14, 2007, 2.00Document Classification: Proprietary InformationPage 3 Table of Contents Table of Contents ....................................................................................................................................... 3 List of Figures ............................................................................................................................................. 5 List of Tables .............................................................................................................................................. 7 1Introduction.................................................................................................................................... 9 1.1Overview ...........................................................................................................................................................9 1.2Wireless Networks ............................................................................................................................................9 1.2.1Ad-Hoc Mode ......................................................................................................................................9 1.2.2Infrastructure Mode.............................................................................................................................9 2Marvell Wireless Configuration Utility Overview ...................................................................... 11 2.1Overview .........................................................................................................................................................11 2.2Marvell Wireless Configuration Utility..............................................................................................................11 2.2.1Windows XP and Windows Server 2003 Users ................................................................................11 2.2.2Tray Status Icons ..............................................................................................................................12 2.3Security ...........................................................................................................................................................13 3Marvell Wireless Configuration Utility User Interface .............................................................. 15 3.1Network Status Tab..............................................................................................…

Text truncated - open the document above for the full version.

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. December 19, 2008 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia , Maryland 21046 Subject: Short-term confidentiality request regarding application for Certification of FCC ID: MCL74487604 To whom it may concern: Pursuant to DA 04-1705 of the Commission’s public notice, we request short- term confidential treatment for the following information until June 15, 2009 after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: • External Photos • Test Setup Photos • User’s Manual • Internal Photos Sincerely,

HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. A G E N C Y A U T H O R I Z A T I O N L E T T E R Date: 02. Dez. 2008 To whom it may concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV CPS Taoyuan within the scope of this authorization shall have the same effects as our own. This authorization shall expire six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, _________________________________________ Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

FCC ID: MCL74487604 Report No.: RF971031L01 Modular Approval Request Letter Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Dec. 16, 2008 Dear Application Examiner, HON HAI Precision IND., CO., LTD., It’s 802.11 a/b/g/n MiniPCI module, FCC ID: MCL74487604 would like to have your authorization as a modular approval specific to the mobile device such as PC peripheral requirements, etc. The requirements of Public Notice DA00-1407 have been met and shown on the following statements. 1. “The modular transmitter must have its own RF shielding.”: The radio portion of this module has been shielded, please see exhibition External Photo. 2. “The modular transmitter must have buffered modulation/data inputs.” The EUT has buffered data inputs, it is integrated in chip 88W8060. 3. “The modular transmitter must have its own power supply regulation.” The part number of this regulator is 88PG817B. 4. “The modular transmitter must comply with the antenna requirements of section 15.203 and 15.204(C).” The EUT meets the FCC antenna requirements. The spurious emission, unique antenna connector and photo of antennas are shown in the test report. 5. “The modular transmitter must be tested in a stand-alone configuration” The EUT was tested in a stand-alone configuration via a Mini-PCI extender. Please see section Photographs of Test Configuration in the test report, the EUT was plugged in this extender. 6. “The modular transmitter must be labeled with its own FCC ID number.” Please see exhibition Label Sample for the FCC ID of this module. And also in the exhibition Users Manual, there are instructions give to the OEM on how to label the end product. FCC ID: MCL74487604 Report No.: RF971031L01 7. “The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements.” The EUT is compliant with all applicable FCC rules. Detail instructions for maintaining compliance are given in the Users Manual. 8. “The modular transmitter must comply with any applicable RF exposure requirements.” The EUT is compliant with all applicable RF exposure requirements. RF Exposure is addressed in the RF exposure exhibition. Please contact me if you have any further questions. Thanks for your attention. Best Regards, Gary Chang Assistant Manager Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch

Gentleman, Due to our client request, we would like to change the application to SDR module. Attached please find the request letter from my client and the further info regarding to SDR security access control. Please let us know if further info is required. Thank you for your attention and help! Best regards, Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch 01/21/2009 HON HAI PRECISION IND. CO., LTD. 5F-1,5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. LETTER FOR FORM 731 MODIFICATION Date: 2009/01/20 To whom it may concern: We, the under signed HON HAI PRECISION IND. CO., LTD., hereby would change the application as a software defined radio authorization. Thus a modified Form 731 would need to be update. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, Signature: Rio Chen Compliance Manager HON HAI PRECISION IND. CO., LTD. TEL: +886-3-5784975 FAX: +886-3-5775100 E-mail: [email protected]

HON HAI PRECISION IND. CO., LTD. HSINCHU SCIENCE PARK BRANCH OFFICE MIN SHENG PLANT 5F-1, 5 Hsin-An Road 4-1 Ming-Sheng St., Hsinchu, Science-Based Industrial Park Tu-Cheng Industrila Area, Taiwan, R.O.C. Taiwan, R.O.C TEL:+886-3-5784975 TEL:+886-2-2267 6511 FAX:+886-3-5775100 FAX:+886-2-2267 6512 28 April 2009 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia, MD 21046 Re: FCC ID MCL74487604 with regard to NII filing EA125440 To Whom It May Concern, It is the intent of the Hon Hai Precision Ind.Co.,Ltd. to amend the application for NII grant FCC id MCL74487604 to remove the 5250-5350 and 5475-5725 bands which require DFS functionality and request that only the 5150-5250 band be listed along with the entire DTS set of bands. This alteration of the system will require only that we update the software and firmware to block the DFS bands. The test report and RF exposure report will be resubmitted and reflect only the channels applicable to this amended filing. Please contact me if you have any questions Regards Thank you. Sincerely, Name: Rio Chen Title: Compliance Deputy Manager HON HAI Precision IND.CO.,LTD.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

標籤製作黏貼方式/U58H085T00/02/1 of 2 2 in 1 label for SN and 74-P/N 標籤製作黏貼方式/U58H085T00/02/2 of 2 0000000000 00 MAC ID label 74-4875-XX XX* U58H086T00 VVSS 74-4876-XX XX* U58H085T00 VVSS 74-4875-XX XX* U58H086T00 VVSS 74-4876-XX XX* U58H085T00 VVSS Foxconn label Compliance label

2006.11.29 1/1 1 OF 1 500. V Amy Amy Air Force II Label CCAD08LPXXXXXX 25mm 1:1 2:1 4-R0.5 " " " " NXXXX " " ZXXX " " X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X M o d e l N a m e : H O N H A I P r e c i s i o n I n d . C o . , L t d 25mm 2008.09.18 1 Modify Amy IC : 2878D-74487604 NXXXX ZXXX FCC ID: MCL74487604 CCAD08LPXXXXXX X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X M o d e l N a m e : H O N H A I P r e c i s i o n I n d . C o . , L t d IC : 2878D-74487604 NXXXX ZXXX FCC ID: MCL74487604

Page 3 Page 4 Page 5 Page 6

FCC ID: MCL74487604 Report No.: SA971031L01 1 RF EXPOSURE REPORT REPORT NO.: SA971031L01 MODEL NO.: 74-4876-04 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: HON HAI Precision IND., CO., LTD. ADDRESS: 5F-1, 5 Hsin-An Road Hsinchu, Science-Based Industrial Park Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: MCL74487604 Report No.: SA971031L01 2 RF EXPOSURE MEASUREMENT (MOBILE DEVICE) 1. INTRODUCTION In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF EXPOSURE LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) (A)LIMITS FOR OCCUPATIONAL / CONTROL EXPOSURES 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz FCC ID: MCL74487604 Report No.: SA971031L01 3 3. FRIIS FORMULA Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT OPERATING CONDITION The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: MCL74487604 Report No.: SA971031L01 4 6. TEST RESULTS 6.1 ANTENNA GAIN The maximum Gain measured in Fully Anechoic Chamber are 2dBi or 1.58489 (2.4GHz) & 5dBi or 3.16228(numeric) (5.0GHz). 6.2 OUTPUT POWER INTO ANTENNA & RF EXPOSURE VALUE AT DISTANCE 20cm: 802.11b DSSS MODULATION: 1TX CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1 2412 101.625 20.07 0.032 1.0 6 2437 102.802 20.12 0.032 1.0 11 2462 101.158 20.05 0.032 1.0 802.11g OFDM MODULATION: 1TX CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1 2412 226.986 23.56 0.072 1.0 6 2437 228.560 23.59 0.072 1.0 11 2462 225.424 23.53 0.071 1.0 DRAFT 802.11n (20MHz) OFDM MODULATION: 1TX CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1 2412 160.694 22.06 0.051 1.0 6 2437 161.436 22.08 0.051 1.0 11 2462 159.956 22.04 0.050 1.0 DRAFT 802.11n (20MHz) OFDM MODULATION: 2TX PEAK POWER OUTPUT (dBm) CHAN. CHAN. FREQ. (MHz) CHAIN 0 CHAIN 1 TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1 2412 22.05 22.07 321.389 25.07 0.101 1.0 6 2437 22.08 22.11 323.991 25.11 0.102 1.0 11 2462 22.02 22.05 319.545 25.05 0.101 1.0 FCC ID: MCL74487604 Report No.: SA971031L01 5 DRAFT 802.11n (40MHz) OFDM MODULATION: 1TX CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1 2422 159.956 22.04 0.050 1.0 4 2437 161.808 22.09 0.051 1.0 7 2452 159.588 22.03 0.050 1.0 DRAFT 802.11n (40MHz) OFDM MODULATION: 2TX PEAK POWER OUTPUT (dBm) CHAN. CHAN. FREQ. (MHz) CHAIN 0 CHAIN 1 TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 1 2422 22.03 22.06 320.282 25.06 0.101 1.0 4 2437 22.07 22.09 322.873 25.09 0.102 1.0 7 2452 22.04 22.05 320.280 25.06 0.101 1.0 802.11a OFDM MODULATION: 1TX CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 36 5180 31.769 15.02 0.020 1.0 40 5200 32.063 15.06 0.020 1.0 48 5240 31.915 15.04 0.020 1.0 149 5745 255.270 24.07 0.161 1.0 157 5785 257.632 24.11 0.162 1.0 165 5825 254.097 24.05 0.160 1.0 FCC ID: MCL74487604 Report No.: SA971031L01 6 DRAFT 802.11n (20MHz) OFDM MODULATION: 1TX CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 36 5180 12.677 11.03 0.008 1.0 40 5200 20.184 13.05 0.013 1.0 48 5240 20.230 13.06 0.013 1.0 149 5745 159.956 22.04 0.101 1.0 157 5785 162.555 22.11 0.102 1.0 165 5825 161.436 22.08 0.102 1.0 DRAFT 802.11n (20MHz) OFDM MODULATION: 2TX PEAK POWE…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 3 RADIATED EMISSION TEST 4
